MP 204
Safety instructions and other important information
GRUNDFOS INSTRUCTIONS
Installation and operating instructions
http://net.grundfos.com/qr/i/96650480
English (GB)
2
English (GB) Safety instructions and other important information
Original safety instructions
These safety instructions give a quick overview of
the safety precautions to be taken in connection with
any work on this product.
Observe these safety instructions during handling,
installation, operation, maintenance, service and
repair of this product.
These safety instructions is a supplementary
document, and all safety instructions will appear
again in the relevant sections of the installation and
operating instructions.
Keep these safety instructions at the installation site
for future reference.
General information
Hazard statements
The symbols and hazard statements below may
appear in Grundfos installation and operating
instructions, safety instructions and service
instructions.
Read this document and
the online version of the
installation and
operating instructions
before installing the
product. Installation and
operation must comply
with local regulations
and accepted codes of
good practice.
This appliance can be
used by children aged
from 8 years and above
and persons with
reduced physical,
sensory or mental
capabilities or lack of
experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and
understand the hazards
involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.
DANGER
Indicates a hazardous
situation which, if not
avoided, will result in
death or serious
personal injury.
English (GB)
3
The hazard statements are structured in the
following way:
Notes
The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
Intended use
MP 204 is an electronic motor protector, designed for
the protection of an asynchronous motor or a pump.
It must always be installed in a cabinet.
MP 204 is designed for single- and three-phase
motors. In single-phase motors, the start and run
capacitors are also measured. Cos is measured in
both single- and three-phase systems.
MP 204 must only be installed according to the
technical specifications. See the installation and
operating instructions for the product.
Transporting the product
WARNING
Indicates a hazardous
situation which, if not
avoided, could result in
death or serious
personal injury.
CAUTION
Indicates a hazardous
situation which, if not
avoided, could result in
minor or moderate
personal injury.
SIGNAL WORD
Description of hazard
Consequence of
ignoring the warning.
- Action to avoid the
hazard.
Observe these
instructions for
explosion-proof
products.
A blue or grey circle with
a white graphical symbol
indicates that an action
must be taken.
A red or grey circle with
a diagonal bar, possibly
with a black graphical
symbol, indicates that an
action must not be taken
or must be stopped.
If these instructions are
not observed, it may
result in malfunction or
damage to the
equipment.
Tips and advice that
make the work easier.
CAUTION
Falling objects
Minor or moderate
personal injury
- Wear safety shoes and
helmet.
CAUTION
Sharp element
Minor or moderate
personal injury
- Wear protective gloves
to avoid being cut by
the sharp edges of the
packaging.
English (GB)
4
Mechanical installation Electrical connections
DANGER
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
power supply has been
switched off and that it
cannot be accidentally
switched on.
- Ensure that the power
and sensor cables are
separated when
installing sensors and
switches.
- Always install the
product inside a
suitable cabinet.
DANGER
Electric shock
Death or serious
personal injury
- All cables taken
through the product
and the current
transformers must be
insulated.
- Insulation between the
cabinet and the
product must have a
suitable insulation
resistance or the
cabinet must be
connected to earth.
- Ensure that the trip/
signal relay output is
maximum 400 V AC.
English (GB)
5
Backup fuses
Maximum backup fuse sizes which may be used for
MP 204 appear from the table below:
At motor currents up to and including 120 A, the
cables to the motor can be taken directly through the
L1-L2-L3 of MP 204.
At motor currents above 120 A, current transformers
must be used.
If backup fuses above 50 A are used, the L1-L2-L3
and "5" to MP 204 must be protected separately with
maximum 10 A fuses.
If current transformers are used, the L1-L2-L3 and
"5" to MP 204 must be protected with maximum 10 A
fuses.
WARNING
Electric shock
Death or serious
personal injury
- Before starting any
work on the product,
make sure that the
power supply has been
switched off and that it
cannot be accidentally
switched on.
- Ensure that the power
and sensor cables are
separated when
mounting the relay
output connections.
- Make sure that the
wiring polarity matches
the installation
instructions.
WARNING
Cause of fire
Death or serious
personal injury
- The product must not
be supplied with pump
voltage if it exceeds
the rating mentioned
on the nameplate.
- Ensure that the branch
circuit fuse is maximum
8 A.
MP 204 Maximum size
[A] Type
Without external
current transformer 120 RK5
With 200/5 external
current transformer 200 RK5
With 300/5 external
current transformer 300 RK5
With 500/5 external
current transformer 500 RK5
With 750/5 external
current transformer 750 RK5
With 1000/5
external current
transformer
1000 RK5
English (GB)
6
Three-phase system
The wiring diagram shows an example of a three-
phase pump with insulation measurement.
The connections to L1, L2, L3 and "5" can be made
with a cable of up to 10 mm2. A special fuse unit up
to approximately 50 A is therefore not required.
If larger backup fuses are used, the voltage to the
L1, L2 and L3 must be protected separately. We
recommend a maximum of 10 A or less.
Fig. 1 Three-phase connection
TM03 0122 2205
1
2
35
46
13
14
S1
K1
S0
22
21
13
14
K1
96
95
E1
K1
A1
A2
L1L2L3
3~
Pt100
E1
L1
L2
L3
+
C
C
I1
I2
I3
T1
T2
FE
5
A
Y
B
Maximum 10 A
MP 204
Pt100/Pt1000
English (GB)
7
Three-phase system with external current transformers
Fig. 2 Three-phase connection with current
transformers
Fig. 3 Five windings per phase through MP
204
TM03 0123 2205
1
2
35
46
K1
13
14
S1
K1
S0
22
21
13
14
R1
96
95
E1
A1
A2
+
C
C
T1
T2
FE
Pt100
E1
L1
L2
L3
I1
I2
I3
5
A
Y
B
L
1
L
2
L
3
3~
Maximum 10 A
MP 204
Pt100/Pt1000
TM03 1398 1905
English (GB)
8
Single-phase system with start and run capacitors
Fig. 4 Single-phase connection
TM03 0124 2205
1
2
3
4
13
14
S1
K1
S0
22
21
13
14
K1
96
95
E1
K1
E1
L1
L2
L3
+
C
C
I1
I2
I3
T1
T2
FE
5
A
Y
B
A1
A2
MA
Pt100
CC
L
1
N
1~
run start
MP 204
Pt100/Pt1000
English (GB)
9
MP 204 with GENIbus
Pump operation with MP 204
Technical data
Ambient temperature:
• During operation: -20 - +60 °C. The product must
not be exposed to direct sunlight.
• In stock: -25 - +85 °C.
• During transport: -25 - +85 °C.
Relative humidity: 5-95 %.
Materials: Enclosure class: IP20.
Weight: 1.25 kg.
Electrical data
Supply voltage: 100-480 VAC, 50/60 Hz.
Current consumption: Maximum 5 W.
Fault finding
Disposing of the product
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
The crossed-out wheelie bin symbol on
a product means that it must be
disposed of separately from household
waste. When a product marked with this
symbol reaches its end of life, take it to a
collection point designated by the local
waste disposal authorities. The separate collection
and recycling of such products will help protect the
environment and human health.
DANGER
Electric shock
Death or serious
personal injury
- Ensure that the power
and sensor cables are
separated when
installing GENIbus.
- Insulation between the
cabinet and the
product must have a
suitable insulation
resistance or the
cabinet must be
connected to earth.
- All cables taken
through the product
and the current
transformers must be
insulated.
DANGER
Cause of fire
Death or serious
personal injury
- The product must not
be supplied with pump
voltage that exceeds
the rating on the
nameplate.
WARNING
Electric shock
Death or serious
personal injury
- Before dismantling,
make sure that the
power supply has been
switched off and that it
cannot be accidentally
switched on.
Appendix
10
Appendix 1
中国 RoHS
ӗӗ૱ѝᴹᇣ⢙䍘Ⲵ〠৺䟿
䜘Ԧ〠
ᴹᇣ⢙䍘
䫵
(Pb)
⊎
(Hg)
䭹
(Cd)
ޝԧ䬜
(Cr6+)
ཊⓤ㚄㤟
(PBB)
ཊⓤ㚄㤟䟊
(PBDE)
ঠࡧ⭥䐟ᶯ
X
O
O
O
O
O
㍗പԦ
X
O
O
O
O
O
ᵜ㺘Ṭ׍ᦞ SJ/T 11364 Ⲵ㿴ᇊ㕆ࡦ
O
˖㺘⽪䈕ᴹᇣ⢙䍘൘䈕䜘Ԧᡰᴹ൷䍘ᶀᯉѝⲴ䟿൷൘ GB/T 26572 㿴ᇊⲴ䲀䟿㾱≲ԕлDŽ
X
˖㺘⽪䈕ᴹᇣ⢙䍘㠣ቁ൘䈕䜘ԦⲴḀа൷䍘ᶀᯉѝⲴ䟿䎵ࠪ GB/T 26572 䈕㿴ᇊⲴ䲀䟿㾱≲DŽ
䈕ӗ૱⧟؍֯⭘ᵏ䲀Ѫ 10 ᒤˈḷ䇶ྲᐖമᡰ⽪DŽ
↔⧟؍ᵏ䲀䘲⭘Ҿӗ૱൘ᆹ㻵о֯⭘䈤᰾Җѝᡰ㿴ᇊⲴᶑԦлᐕ֌
ӗ૱ѝᴹᇣ⢙䍘Ⲵ〠৺䟿
