6.4 Assembly
6.4.1 Stator
1. Insert the stator in motor housing (pos. 1017).
Note Make sure that the fixation holes for alignment are
positioned correctly.
Caution Take care not to damage any wires.
1. Fit screw (pos. 1044), sealing washer (pos. 1056) and nut (pos.
1046). Tighten the screw slightly by hand and the nut according
section Tightening torques and lubricants.
Related information
4. Tightening torques and lubricants
6.4.2 Motor flange and bearing
1. Lubricate bearing (pos. 1047) with oil and insert it in motor
flange (pos. 1020).
2. Fit O-ring (pos. 1071) on intermediate ring (pos. 1057) and
lubricate both parts with oil.
3. Insert intermediate ring (pos. 1057) in motor flange (pos. 1020).
The inner recess must point away from the bearing. Insert
retaining ring (pos. 1058) in motor flange (pos. 1020).
Caution
The water-in-oil sensor must be removed if it is
necessary to heat the motor flange
(max. 70 °C/158 °F).
6.4.3 Rotor bearing
Caution If a bearing heater is used, the temperature must not
exceed 80 °C (176 °F).
Note Use a hydraulic press if a bearing heater is not available.
1. Insert rotor (pos. 1019) in motor flange (pos. 1020) and place
the unit in a hydraulic press.
2. Fit bearing (pos. 1039) on the N-end of rotor shaft (pos. 1019).
3. Press it carefully home by pressing on inner bearing ring (pos.
1039).
6.4.4 Water-in-oil sensor
1. Lubricate the threads of water-in-oil sensor (pos. 1049) with
Loctite 511.
2. Fit and tighten water-in-oil sensor (pos. 1049) in motor flange
(pos. 1020) using a spanner.
6.4.5 Rotor
1. Lubricate the groove for O-ring (pos. 1022) in motor flange (pos.
1020) with Loctite MR 5923.
2. Fit and lubricate the O-ring with Loctite MR 5923.
3. Fit compensation disc (pos. 1038) in the hole for bearing (pos.
1039) in the N-end of the motor housing.
4. Insert rotor (pos. 1019) in the top of the motor housing.
5. Lower or press rotor (pos. 1019) into the motor housing until the
wires for the water-in-oil sensor can be connected.
6. Connect the wires.
Caution Make sure that the wires of the water-in-oil sensor are
not pinched when inserting the rotor.
1. Turn motor flange (pos. 1020) so that the marks are aligned.
2. Lower or press rotor (pos. 1019) home in the motor housing.
3. Fit retaining ring (pos. 1059) in the motor housing.
6.4.6 Shaft seals
1. Fit stationary shaft seal part (pos. 1048) on the shaft and press
it home.
Caution Take care not to damage the seal face. Make sure that
the surface is clean.
2. Lubricate the inside of rotating shaft seal part (pos. 1048) with a
little bit soapy water/cream. Fit it on the shaft with the seal face
towards the stationary part.
3. Fit shim (pos. 1050) on the shaft. Press the shim and the
rotating shaft seal part against the stationary part.
4. Fit retaining ring (pos. 1051) on the shaft.
Caution Make sure that the retaining ring is fitted correctly in
the groove.
5. Lubricate the groove for O-ring (pos. 1142) in motor flange (pos.
1020) with Loctite MR 5923 and fit the O-ring.
6. Lubricate the groove for O-ring (pos. 1043) in sealing flange
(pos. 1141) with Loctite MR 5923.
7. Fit and lubricate the O-ring with Loctite MR 5923.
8. Fit sealing flange (pos. 1141) in motor housing (pos. 1017) with
the higher of the two holes for plugs (pos. 1145) upwards.
9. Fit two screws (pos. 1144) in opposite holes and tighten them
until sealing flange (pos. 1141) is in place.
10. Remove the two screws and lubricate screws (pos. 1144) with
Loctite 511. Cross-tighten the screws. See section Tightening
torques and lubricants.
11. Fit stationary shaft seal part (pos. 1098) on the shaft and press
it home.
Caution
Make sure that it is fitted correctly in the groove.
Take care not to damage the seal face. Clean the
surface with Loctite 7063.
12. Lubricate the inside of rotating shaft seal part (pos. 1098) with a
little bit soapy water/cream. Fit it on the shaft with the seal face
towards the stationary part and press it carefully against the
stationary part.
13. Lubricate the top of sealing flange (pos. 1141) around stationary
shaft seal part (pos. 1098) with Loctite MR 5923.
14. Fit O-ring (pos. 1168) on the stationary shaft seal part and
lubricate it with Loctite MR 5923.
15. Fit lip seal B2 (pos. 1169) in sleeve (pos. 1148).
16. Fit sleeve (pos. 1148) on sealing flange (pos. 1141).
17. Press it carefully against the sealing flange while inserting
screws (pos. 1149). Tighten the screws a little by hand.
18. Add gear oil through the hole for plug (pos. 1145). See section
Oil types and quantity.
19. Fit and tighten plugs (pos. 1145) by hand.
20. Press carefully on the back of rotating shaft seal part (pos.
1098) and fill the seal chamber with gear oil. See section Oil
types and quantity.
Caution Make sure that the seal chamber is full.
21. Fit key (pos. 1105) in the keyway.
22. Fit protection ring (pos. 1146) on motor housing (pos. 1017).
23. Fit and tighten screws (pos. 1147) a little by hand.
Related information
4. Tightening torques and lubricants
5. Oil types and quantity
