Grundfos CMBE Series User manual

CMBE
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

English (GB)
2
English (GB) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. General information 3
1.1 Hazard statements 3
1.2 Notes 3
2. Safety instructions 3
3. Intended use 8
3.1 Pumped liquids 8
4. System sizing 8
5. Mechanical installation 8
5.1 Installation altitude 8
6. Electrical connection 9
6.1 Cable requirements 9
6.2 Standard functional module, FM 200 10
7. Starting up the product 12
7.1 Supplement to quick guide 12
7.2 Priming and venting the product 12
7.3 Adjusting the diaphragm tank pressure 12
7.4 Shaft seal run-in 12
8. Control functions 12
8.1 Dry-running protection 12
8.2 Pressure switch 13
9. Setting the product 13
9.1 Operating panel 13
9.2 Setpoint setting 14
9.3 Start/stop of pump 14
9.4 Resetting of fault indications 14
10. Servicing the product 14
10.1 Cable requirements 14
10.2 Megging 14
11. Taking the product out of operation 14
12. Fault finding 15
13. Technical data 16
13.1 Operating conditions 16
13.2 Supply voltage 16
13.3 Overload protection 16
13.4 Cable requirements 16
14. Further product information 17
15. Disposing of the product 17
Read this document
before installing the
product. Installation and
operation must comply
with local regulations
and accepted codes of
good practice.
This appliance can be
used by children aged
from 8 years and above
and persons with
reduced physical,
sensory or mental
capabilities or lack of
experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and
understand the hazards
involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.

English (GB)
3
1. General information
1.1 Hazard statements
The symbols and hazard statements below may
appear in Grundfos installation and operating
instructions, safety instructions and service
instructions.
The hazard statements are structured in the
following way:
1.2 Notes
The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
2. Safety instructions
Mechanical installation
Electrical connection
DANGER
Indicates a hazardous situation which, if
not avoided, will result in death or serious
personal injury.
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or
serious personal injury.
CAUTION
Indicates a hazardous situation which, if
not avoided, could result in minor or
moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
Observe these instructions for
explosion-proof products.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
WARNING
Electric shock
Death or serious
personal injury
- Switch off the power
supply before you start
any work on the
product.
- Make sure that the
power supply cannot
be switched on
accidentally.
WARNING
Hot liquid
Death or serious
personal injury
- To avoid leakage do
not overtighten the
pipe connections.
CAUTION
Sharp element
Minor or moderate
personal injury
- Wear personal
protective equipment.

English (GB)
4
CAUTION
Crushing of feet
Minor or moderate
personal injury
- Wear safety shoes
when moving the
product.
- Use lifting equipment.
CAUTION
Back injury
Minor or moderate
personal injury
- Use lifting equipment.
DANGER
Electric shock
Death or serious
personal injury
- If national legislation
requires a Residual
Current Device (RCD)
or equivalent in the
electrical installation,
this must be type B or
better, due to the
nature of the constant
DC leakage current.
The RCD must be
marked with the
following symbols:
WARNING
Electric shock
Death or serious
personal injury
- Carry out the electrical
connection in
accordance with local
regulations.
WARNING
Electric shock
Death or serious
personal injury
- Check that the power
plug delivered with the
product is in
compliance with local
regulations.
- The protective earth of
the power outlet must
be connected to the
protective earth of the
product. The plug must
therefore have the
same PE connection
system as the power
outlet. If not, use a
suitable adapter if
allowed by local
regulations.

English (GB)
5
Connection terminals for inputs and outputs
Starting up the product
WARNING
Electric shock
Death or serious
personal injury
- A supply disconnecting
device made according
to EN 60204-1 5.3.2
must be provided with
means permitting it to
be locked in the OFF
(isolated) position. This
device must also be
installed in a position
according to EN
60204-1, 5.3.4.
WARNING
Electric shock
Death or serious
personal injury
- Power cables without a
plug must be
connected to a supply
disconnecting device
incorporated in the
fixed wiring according
to local regulations.
WARNING
Electric shock
Death or serious
personal injury
- Comply with local
regulations as to cable
cross-sections.
DANGER
Electric shock
- Death or serious
personal injury
- Make sure that the
wires to be connected
to the connection
groups below are
separated from each
other by reinforced
insulation in their entire
lengths.
WARNING
Hot liquid
Death or serious
personal injury
- If the temperature is
higher than 50 °C, use
gloves and glasses
when venting the pump
to avoid risk of
scalding.
WARNING
Biological hazard
Death or serious
personal injury
- Flush the pump with
clean water before first
use.

English (GB)
6
Servicing the product
Taking the product out of operation
WARNING
Electric shock
Death or serious
personal injury
- Switch off the power
supply before you start
any work on the
product.
- Make sure that the
power supply cannot
be switched on
accidentally.
WARNING
Pressurised system
Death or serious
personal injury
- Depressurise the
system before you start
any work on the
product. The pumped
liquid may be scalding
hot and under high
pressure.
- Drain the system or
close the isolating
valves on either side of
the pump.
WARNING
Biological hazard
Death or serious
personal injury
- When servicing the
product, only use
Grundfos original
spare parts.
WARNING
Electric shock
Death or serious
personal injury
- Comply with local
regulations as to cable
cross-sections.
WARNING
Electric shock
Death or serious
personal injury
- Switch off the power
supply before you start
any work on the
product.
- Make sure that the
power supply cannot
be switched on
accidentally.

English (GB)
7
Fault finding
WARNING
Pressurised system
Death or serious
personal injury
- Depressurise the
system before you start
any work on the
product. The pumped
liquid may be scalding
hot and under high
pressure.
- Drain the system or
close the isolating
valves on either side of
the pump.
WARNING
Electric shock
Death or serious
personal injury
- Switch off the power
supply before you start
any work on the
product.
- Make sure that the
power supply cannot
be switched on
accidentally.
WARNING
Pressurised system
Death or serious
personal injury
- Depressurise the
system before you start
any work on the
product. The pumped
liquid may be scalding
hot and under high
pressure.
- Drain the system or
close the isolating
valves on either side of
the pump.
WARNING
Biological hazard
Death or serious
personal injury
- When servicing the
product, only use
Grundfos original
spare parts.

English (GB)
8
3. Intended use
3.1 Pumped liquids
The product is suitable for pumping clean, thin,
non-aggressive, non-toxic and non-explosive liquids
without solid particles or fibres.
4. System sizing
The pump is by default set to not stop until it reaches
its maximum pressure.
5. Mechanical installation
5.1 Installation altitude
The installation altitude is the height above sea level
of the installation site.
• Products installed up to 1000 m above sea level
can be loaded 100 %.
• The motors can be installed up to 3500 m above
sea level.
The motor output power (P2) in relation to the
altitude above sea level is shown in the graph below.
Fig. 1 Derating of motor output (P2) in relation
to altitude above sea level
This product has been evaluated for use
with clean water only.
Only use the product according to the
specifications stated in these installation
and operating instructions.
If the water contains sand, gravel or other
debris, there is a risk of pump blockage
and pump damage.
Please install a filter on the inlet side or
apply a floating strainer to protect the
pump.
The system in which the CME Booster is
incorporated must be designed for the
maximum pump pressure.
WARNING
Electric shock
Death or serious personal injury
- Switch off the power supply before you
start any work on the product.
- Make sure that the power supply cannot
be switched on accidentally.
WARNING
Hot liquid
Death or serious personal injury
- To avoid leakage do not overtighten the
pipe connections.
CAUTION
Sharp element
Minor or moderate personal injury
- Wear personal protective equipment.
CAUTION
Crushing of feet
Minor or moderate personal injury
- Wear safety shoes when moving the
product.
- Use lifting equipment.
CAUTION
Back injury
Minor or moderate personal injury
- Use lifting equipment.
Motors installed more than 1000 m above
sea level must not be fully loaded due to
the low density and consequent low
cooling effect of the air.
TM05 6400 4712
0
60
80
90
70
00
500 1000 1500 2000 2500 3000 3500
Altitude [m]
P2 [%]

English (GB)
9
6. Electrical connection
Check that the supply voltage and frequency
correspond to the values stated on the nameplate.
6.1 Cable requirements
See section 13.4 Cable requirements for more
information on cable cross-sections and conductor
types.
6.1.1 Motor protection
The pump requires no external motor protection. The
motor incorporates thermal protection against slow
overloading and blocking, TP 211 according to IEC
34-11.
6.1.2 Protection against mains voltage transients
The pump is protected against voltage transients by
built-in varistors between the phases and between
phases and earth.
DANGER
Electric shock
Death or serious personal injury
- If national legislation requires a
Residual Current Device (RCD) or
equivalent in the electrical installation,
this must be type B or better, due to the
nature of the constant DC leakage
current. The RCD must be marked with
the following symbols:
WARNING
Electric shock
Death or serious personal injury
- Carry out the electrical connection in
accordance with local regulations.
WARNING
Electric shock
Death or serious personal injury
- Check that the power plug delivered
with the product is in compliance with
local regulations.
- The protective earth of the power outlet
must be connected to the protective
earth of the product. The plug must
therefore have the same PE connection
system as the power outlet. If not, use a
suitable adapter if allowed by local
regulations.
WARNING
Electric shock
Death or serious personal injury
- A supply disconnecting device made
according to EN 60204-1 5.3.2 must be
provided with means permitting it to be
locked in the OFF (isolated) position.
This device must also be installed in a
position according to EN 60204-1,
5.3.4.
WARNING
Electric shock
Death or serious personal injury
- Power cables without a plug must be
connected to a supply disconnecting
device incorporated in the fixed wiring
according to local regulations.
WARNING
Electric shock
Death or serious personal injury
- Comply with local regulations as to
cable cross-sections.

English (GB)
10
6.2 Standard functional module, FM 200
6.2.1 Inputs and outputs
The module has these connections:
• two analog inputs
• two digital inputs or one digital input and one
open-collector output
• Grundfos Digital Sensor input and output
• two signal relay outputs
• GENIbus connection.
All inputs and outputs are internally separated from
the mains-conducting parts by reinforced insulation
and galvanically separated from other circuits. All
control terminals are supplied with protective
extra-low voltage (PELV), ensuring protection
against electric shock.
6.2.2 Signal relay 1
LIVE: You can connect supply voltages up to 250
VAC to the output.
PELV: The output is galvanically separated from
other circuits. Therefore, you can connect the supply
voltage or protective extra-low voltage to the output
as desired.
6.2.3 Signal relay 2
PELV: The output is galvanically separated from
other circuits. Therefore, you can connect the supply
voltage or protective extra-low voltage to the output
as desired.
6.2.4 Connection terminals for the mains supply
6.2.5 Connection terminals for inputs and
outputs
Fig. 2 Connection terminals, FM 200
Phases Terminals
Single-phase N, PE, L
Three-phase L1, L2, L3, PE
DANGER
Electric shock
- Death or serious personal injury
- Make sure that the wires to be
connected to the connection groups
below are separated from each other by
reinforced insulation in their entire
lengths.
TM05 3510 3512
3
15
8
26
23
25
24
7
B
Y
6
5
2
4
10
A
AI2
GDS RX
GDS TX
GND
GENIbus A
GENIbus B
+5 V
+24 V
+24 V
GND
GENIbus Y
GND
+5 V
DI1
AI1
DI3/OC1
+24 V*
+
+
+24 V*/5 V*
+24 V*
+5 V*
NC
C2
NO
NC
C1
NO
+24 V*
++
+24 V*/5 V*
+24 V*
+24 V* OC DI
GND
