Grundfos Liftaway B User manual

Liftaway B
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

English (GB)
2
English (GB) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. General information 3
1.1 Hazard statements 3
1.2 Notes 3
2. Safety instructions 3
3. Product introduction 4
3.1 Applications 4
3.2 Pumped liquids 4
4. Function 5
5. Technical data 5
6. Components 5
7. Dimensions 5
8. Installation of tank 6
9. Mounting the pump in the tank 7
10. Startup and venting 9
11. Servicing the product 9
12. Disposing of the product 9
Read this document
before installing the
product. Installation and
operation must comply
with local regulations
and accepted codes of
good practice.
This appliance can be
used by children aged
from 8 years and above
and persons with
reduced physical,
sensory or mental
capabilities or lack of
experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and
understand the hazards
involved.
Children shall not play
with the appliance.
Cleaning and user
maintenance shall not
be made by children
without supervision.

English (GB)
3
1. General information
1.1 Hazard statements
The symbols and hazard statements below may
appear in Grundfos installation and operating
instructions, safety instructions and service
instructions.
The hazard statements are structured in the
following way:
1.2 Notes
The symbols and notes below may appear in
Grundfos installation and operating instructions,
safety instructions and service instructions.
2. Safety instructions
Mounting the pump in the tank
Startup and venting
DANGER
Indicates a hazardous situation which, if
not avoided, will result in death or serious
personal injury.
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or
serious personal injury.
CAUTION
Indicates a hazardous situation which, if
not avoided, could result in minor or
moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
Observe these instructions for explosion-
proof products.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
DANGER
Electric shock
Death or serious
personal injury
- The protective earth of
the socket outlet must
be connected to the
protective earth of the
pump. Therefore the
applied plug must have
the same PE
connection system as
the socket outlet, or a
suitable adapter must
be applied.
CAUTION
Biological hazard
Minor or moderate
personal injury
- The product are only to
be use with rainwater
or grey wastewater.

English (GB)
4
Servicing the product 3. Product introduction
Grundfos Liftaway B 40-1 for underfloor installation
is a compact mini lifting station consisting of a tank
and a wastewater pump, type Unilift KP 150, Unilift
KP 250 or Unilift AP12, with level switch for
automatic start/stop. The lifting station is designed
for the pumping of wastewater from wash basins,
washing machines, showers and floor drains. The
Liftaway B 40-1 can also be used for the collection
and pumping of rain water.
The variable height of the tank, which is installed
under the floor, makes it easy to adjust the tank to
floor level.
3.1 Applications
The Liftaway B 40-1 in combination with the Unilift
KP 150, Unilift KP 250 or Unilift AP12 is designed for
the pumping of wastewater from wash basins,
washing machines, showers and floor drains where
the wastewater cannot be led directly to the sewer by
means of a natural downward slope.
The lifting station is typically used:
• as draining well for the collection of drainage and
surface water,
• the pumping of wastewater from basements and
laundry rooms below sewer level.
3.2 Pumped liquids
Wastewater, not containing solid particles.
Liquid temperature: Maximum 70 °C.
The tank is resistant to weak acids with pH values of
4 to 10.
See also installation and operating instructions for
the pump.
DANGER
Electric shock
Death or serious
personal injury
- Switch off the power
supply before you start
any work on the
product.
- Make sure that the
power supply cannot
be switched on
accidentally.
CAUTION
Biological hazard
Minor or moderate
personal injury
- The product will be
classified as
contaminated if it has
been used for a liquid
which is injurious to
health or toxic.
- Wear personal
protective equipment.
These instructions apply to the Liftaway B
40-1 tank and installation kit only.
See also the installation and operating
instructions supplied with the pump.
Liftaway B 40-1 must not be used for the
pumping of sewage water from toilets.
Do not discharge wastewater containing
fat into the tank.

English (GB)
5
4. Function
Wastewater from the connected units is discharged
into the lifting station. The pump starts and stops by
means of the level switch, depending on liquid level
in tank.
The wastewater is pumped through the outlet pipe
to the main sewer line.
5. Technical data
6. Components
1. Plastic cover. The cover can be turned to any
position.
2. Plastic tank.
3. Stainless steel drain grating with water seal.
4. 3 inlet connections (DN 100) and 1 connection for
venting and/or cable entry (DN 70).
5. Hole for outlet connection.
6. Telescopic part for height adjustment. An
additional telescopic part is available. This part
gives a maximum height of 795 mm.
7. Kit including non-return valve and various fittings
required for pump connection.
7. Dimensions
Outlet connection: R 1 1/4.
Inlet connections: 3 x DN 100.
Connection for venting
and/or cable entry: DN 70.
Technical data for pump: See pump instructions.
TM01 1016 3597
3
1
5
6
4
2
TM01 1018 3297
ø42
DN70
310
min.: 640
max.: 760
ø500
602
400
3 x DN100
583 400
140
140
