Grundfos SE1 50 User manual

SE1 50, 80, 100
SEV 65, 80, 100
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

2

Table of contents
3
SE1 50, 80, 100
SEV 65, 80, 100
English (GB)
Installation and operating instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Български (BG)
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Čeština (CZ)
Montážní a provozní návod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Deutsch (DE)
Montage- und Betriebsanleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Dansk (DK)
Monterings- og driftsinstruktion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Eesti (EE)
Paigaldus- ja kasutusjuhend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Español (ES)
Instrucciones de instalación y funcionamiento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Suomi (FI)
Asennus- ja käyttöohjeet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Français (FR)
Notice d'installation et de fonctionnement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Ελληνικά (GR)
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Hrvatski (HR)
Montažne i pogonske upute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Magyar (HU)
Telepítési és üzemeltetési utasítás . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
Italiano (IT)
Istruzioni di installazione e funzionamento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345
Lietuviškai (LT)
rengimo ir naudojimo instrukcija . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374
Latviešu (LV)
Uzstdšanas un ekspluatcijas instrukcija . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 402
Nederlands (NL)
Installatie- en bedieningsinstructies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 431
Polski (PL)
Instrukcja montau i eksploatacji . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 460
Português (PT)
Instruções de instalação e funcionamento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 488
Română(RO)
Instruciuni de instalare i utilizare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 517
Srpski (RS)
Uputstvo za instalaciju i rad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 546
Русский (RU)
,     . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 574
Svenska (SE)
Monterings- och driftsinstruktion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 605
Slovensko (SI)
Navodila za montažo in obratovanje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 633
Slovenčina (SK)
Návod na montáž a prevádzku . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 661

Table of contents
4
SE1 50, 80, 100
SEV 65, 80, 100
Türkçe (TR)
Montaj ve kullanım kılavuzu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 690
Українська (UA)
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 719
中文 (CN)
安装和使用说明书 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 750
Қазақша (KZ)
    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 777
Tiếng Việt (VI)
Hng dn lp t và vn hành . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 806
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 834
Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 848
Declaration of conformity EAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 850
Declaration of performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 851

English (GB)
5
English (GB) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. Symbols used in this document
2. General description
This booklet includes instructions for installation, operation and
maintenance of Grundfos SE1 and SEV submersible sewage and
wastewater pumps with motors of 1.1 to 11 kW. Grundfos SE1
and SEV sewage and wastewater pumps are designed for
pumping domestic, municipal and industrial sewage and
wastewater.
Two types of pumps are available:
• SE1 pumps with S-tube impeller
• SEV pumps with SuperVortex impeller.
The pumps can be installed on an auto-coupling system or stand
freely on the bottom of a pit. They can even be dry-installed in
either vertical or horizontal position.
Grundfos SE1 and SEV pumps are designed with an S-tube and
SuperVortex impeller, respectively, to ensure reliable and
optimum operation.
The booklet also includes specific instructions for the explosion-
proof pumps.
1. Symbols used in this document 5
2. General description 5
2.1 Product drawing 6
2.2 Control and monitoring 6
2.3 Applications 6
2.4 Pump selection 6
2.5 Operating conditions 7
3. Delivery and handling 7
3.1 Transportation 7
3.2 Storage 7
4. Identification 8
4.1 Nameplate 8
4.2 Type key 9
5. Approvals 10
5.1 Approval standards 10
5.2 Explanation to Ex approval 10
6. Safety 11
6.1 Potentially explosive environments 11
7. Installation 11
7.1 Submerged installation on auto coupling 12
7.2 Free-standing submerged installation on ring stand 13
7.3 Dry installation 13
7.4 Tightening torques for suction and discharge flanges 14
8. Electrical connection 15
8.1 Wiring diagrams, 7-core cable 16
8.2 Wiring diagrams, 10-core cable 16
8.3 Pump controllers 18
8.4 Thermal switch, PT 1000 and thermistor (PTC) 19
8.5 WIO sensor 19
8.6 Moisture switch 19
8.7 IO 111 20
8.8 IO 113 20
8.9 Frequency converter operation 21
9. Start-up 22
9.1 SE1 22
9.2 SEV 22
9.3 Direction of rotation 23
10. Maintenance and service 23
10.1 Inspection 24
10.2 Dismantling the pump 24
10.3 Assembling the pump 25
10.4 Oil quantities 26
10.5 Service kits 27
10.6 Contaminated pumps 28
11. Fault finding chart 29
12. Sensor check measurements 30
12.1 Check measurement using a standard instrument 30
13. Technical data 31
14. Disposal 32
Warning
Prior to installation, read these installation and
operating instructions. Installation and operation
must comply with local regulations and accepted
codes of good practice.
Warning
The use of this product requires experience with and
knowledge of the product.
Persons with reduced physical, sensory or mental
capabilities must not use this product, unless they
are under supervision or have been instructed in the
use of the product by a person responsible for their
safety.
Children must not use or play with this product.
Warning
If these safety instructions are not observed, it may
result in personal injury.
Warning
If these instructions are not observed, it may lead to
electric shock with consequent risk of serious
personal injury or death.
Warning
These instructions must be observed for explosion-
proof pumps. We recommend that you also follow
these instructions for standard pumps.
Caution
If these safety instructions are not observed, it may
result in malfunction or damage to the equipment.
Note
Notes or instructions that make the job easier and
ensure safe operation.

English (GB)
6
2.1 Product drawing
Fig. 1 SE pump
2.2 Control and monitoring
The pumps can be controlled via the Grundfos controllers LC,
LCD 107, LC, LCD 108, LC, LCD 110 and DC, DCD.
Pumps with a sensor are supplied together with an IO 111 or
IO 113 which can receive signals from the following transmitters:
• water-in-oil-sensor (WIO sensor) in the pump
• moisture sensor in the motor
• temperature sensor in the stator windings
• winding resistance sensor in the motor.
For further information, see installation and operating instructions
for the specific sensor.
2.3 Applications
SE1 and SEV pumps are designed for pumping these liquids:
• large quantities of drainage and surface water
• domestic wastewater with discharge from toilets
• wastewater with a high content of fibres
(SuperVortex impeller)
• industrial wastewater
• wastewater with gaseous sludge
• municipal and commercial sewage and wastewater.
SE1 and SEV pumps are ideal for installation in locations such
as:
• public buildings
• blocks of flats
• industry
• garages
• multi-storey car parks
• vehicle washing tunnels
• restaurants.
Stainless steel versions
Stainless steel versions are further more suitable for the following
applications:
• industrial process water containing chemicals
• aggressive or corrosive drain water and effluent
• abrasive particles in wastewater
• wastewater contaminated with seawater.
The compact design makes the pumps suitable for both
temporary and permanent installation.
2.4 Pump selection
The table below shows which pump version to select for a
number of liquids:
Impeller type: 1 = S-tube impeller, V = SuperVortex impeller.
TM02 8112 0616
Pos. Description
1 Lifting bracket
2Nameplate
3 Sleeve
4 Oil screw
5 Discharge flange
6 Discharge
7 Cable plug
8 Top cover
9Clamp
10 Pump housing
5
6
1
2
3
4
7
9
10
8
Pumped liquid Pump passage [mm]
50 65 80 100
Drainage water 1 V 1 / V 1 / V
Domestic wastewater without
discharge from toilets 1 V 1 / V 1 / V
Domestic wastewater with
discharge from toilets 1 / V 1 / V
Wastewater with a high content
of fibres V 1 / V 1 / V
Industrial wastewater 1 / V 1 / V
Wastewater with gaseous sludge 1 / V 1 / V
Municipal wastewater 1 / V 1 / V

English (GB)
7
2.5 Operating conditions
The Grundfos SE1 and SEV pumps are suitable for the following
operating situations:
•Dry installation without separate motor cooling
arrangements.
•Submerged installation
S1 operation (continuous operation)
pH value
SE pumps in permanent installations can cope with the following
pH values:
1) Cast iron impeller, pump housing and motor top.
2) Stainless steel impeller. Cast iron pump housing and motor
top.
3) Stainless steel impeller and pump housing. Cast iron motor
top. Material variant S is available on request.
4) Entire pump in stainless steel.
5) Stainless steel pump according to EN 1.4517/1.4539.
Material variant D is available on request.
6) For fluctuating pH values, the range is pH 4 to 14.
Liquid temperature
0 °C to +40 °C.
For short periods (maximum 1 hour) a temperature of up to 60 °C
is permissible (non-Ex versions only).
Ambient temperature
Density and viscosity of pumped liquid
When pumping liquids with a density and/or a kinematic viscosity
higher than that of water, use motors with correspondingly higher
outputs.
Flow velocity
It is advisable to keep a minimum flow velocity to avoid
sedimentations in the piping system. Recommended flow
velocities:
- in vertical pipes: 1.0 m/s
- in horizontal pipes: 0.7 m/s
Maximum solids size
From 50 to 100 mm, depending on pump size.
Operating mode
Maximum 20 starts per hour.
S1, continuous operation. The pump can operate continuously
without having to be stopped for cooling.
3. Delivery and handling
The pump may be transported and stored in a vertical or
horizontal position. Make sure that it cannot roll or fall over.
3.1 Transportation
All lifting equipment must be rated for the purpose and checked
for damage before any attempts to lift the pump. The lifting
equipment rating must under no circumstances be exceeded.
The pump weight is stated on the pump nameplate.
The polyurethane-embedded plug prevents moisture from
penetrating into the motor via the motor cable.
3.2 Storage
During long periods of storage, the pump must be protected
against moisture, heat and cold.
Storage temperature: -30 °C to +60 °C.
If the pump has been in use, the oil should be changed before
storage. See section 10.2.1 Oil change.
After a long period of storage, the pump should be inspected
before it is put into operation. Make sure that the impeller can
rotate freely. Pay special attention to the condition of the shaft
seal, O-rings, oil and the cable entry.
Pump
type
Material
variant Installation pH value
SE1/SEV Standard1) Dry and
submerged 6.5 to 146)
SEV Q2) Dry and
submerged 6 to 146)
SEV S3) Submerged 5.5 to 146)
Dry 1 to 14
SEV R4) Dry and
submerged 1 to 14
SEV D5) Dry and
submerged 0 to 14
Warning
Explosion-proof pumps must never pump liquids of a
temperature higher than +40 °C.
Warning
For explosion-proof pumps, the ambient temperature
on the installation site must be in the range from -20
°C to +40 °C.
For explosion-proof pumps with WIO sensor, the
ambient temperature at the installation site must be
in the range from 0 °C to +40 °C.
Warning
Always lift the pump by its lifting bracket or by means
of a fork-lift truck if the pump is fixed on a pallet.
Never lift the pump by means of the motor cable or
the hose/pipe.
Warning
If the pumps are stored for more than one year or it
takes a long time before it is put into operation after
the installation, the impeller must be turned at least
once a month.

English (GB)
8
4. Identification
4.1 Nameplate
The nameplate states the operating data and approvals applying
to the pump. The nameplate is fitted to the top cover of the pump.
Fix the extra nameplate supplied with the pump at the installation
site or keep it in the cover of this booklet.
Fig. 2 Nameplate
TM02 8398 0516
Pos. Description
1 Notified body
2
Explosion protection mark, X for special
requirements applicable to explosion-proof
equipment according to IEC 79-15
3 Type designation
4 Product number and serial number
5 Maximum head [m]
6 Enclosure class to IEC 60529
7 Maximum installation depth [m]
8 Number of phases
9 Frequency [Hz]
10 Speed [min-1]
11 Motor input power P1 [kW]
12 Motor output power P2 [kW]
13 Country of production
14 Explosion protection classification and certificate
number
15 EN approval
16 Maximum flow [m3/h]
17 Production code (year/week)
18 Maximum liquid temperature [°C]
19 Insulation class
20 Power factor
21 Rated current 1
22 Rated voltage 1
23 Rated current 2
24 Rated voltage 2
25 Weight without cable [kg]
12 1311 19 6
2
1
3
4
5
7
8
9
10
18
17
16
15
20
21
22
23
24
25
14
CE0344 II2GD KEMA 04ATEX 2201X
Ex cd llB T4, T3 Ex ctD A21 T135 °C, T200°C
Tmax: 40°C
Type: SE1.80.80.40.EX.4.51D P.c. 0030
EN 12050-1
Hmax: Qmax:14.4 m
380-415
V
A
A
25.0 m h
/3
V
Model: 96047601 XXXXXXXX
20 m
8.2
Insul.class: F Cosφ : 0.88
Motor: 50Hz
3
0197
~
n: min2890
-1
kgWeight: 130IP68P1/P2：4.9/4.0 kW
Made in Tatabanya
Hungary
DK-8850 Bjerringbro, Denmark
DOP 96046675 98807641

English (GB)
9
4.2 Type key
The pump can be identified by the type designation stated on the pump nameplate. See section 4.1 Nameplate.
Code Example SE 1 .80 .80 .40 .A .Ex .4 .5 1D B
SE
Pump type
Grundfos sewage/wastewater pumps
Blank
Material version
Standard
1
V
Impeller type
S-tube impeller
SuperVortex (free-flow) impeller
80
Pump passage
Maximum solids size [mm]
80
Pump discharge
Nominal diameter of pump discharge port [mm]
40
Output power, P2
P2 = Code number from type designation/10 [kW]
Blank
A
Sensor
Standard (without sensor)
Sensor version
Blank
Ex
Pump version
Non-explosion-proof pump (standard)
Explosion-proof pump
2
4
Number of poles
2-pole, 3000 min-1, 50 Hz
4-pole, 1500 min-1, 50 Hz
Blank
Number of phases
Three-phase motor
5
Frequency
50 Hz
0B
0D
1D
0E
1E
Voltage and starting method
400-415 V, DOL
380-415 V, DOL
380-415 V, Y/D
220-240 V, DOL
220-240 V, Y/D
Blank
A
B
Generation
First generation
Second generation
Third generation etc.
The generation code distinguishes between structurally different pumps with the same power rating
Blank
Q
R
S
D
Pump materials
Cast iron impeller, pump housing and motor top according to EN-GJL-200/250.
Stainless steel impeller according to EN 1.4408, cast iron pump housing and motor top according to EN-GJL-250.
Entire pump in stainless steel according to EN 1.4408.
Stainless steel pump housing, impeller and intermediate flange (according to EN 1.4408) and cast iron motor top according to
EN-GJL-250 (available on request).
Stainless steel pump according to EN 1.4517/1.4539 (available on request).

English (GB)
10
5. Approvals
The standard versions of SE1, SEV pumps have been tested by VDE, and the explosion-proof versions approved by KEMA according to
the ATEX directive.
5.1 Approval standards
The standard variants are approved by LGA (notified body under the Construction Products Directive) according to EN 12050-1 or
EN 12050-2 as specified on the pump nameplate.
5.2 Explanation to Ex approval
The SE1 and SEV pumps have the following explosion protection classifications:
CE 0344 II2 GD Ex c d IIB T4, T3 Ex c tD A21 IP68 T135 °C,T200 °C X
CE 0344 II 2 GD Ex c d mb IIB T4, T3 Ex c tD A21 IP68 T135 °C,T200 °C X
* For motors supplied via a frequency converter, the type of protection is Ex c d IIB T3 and T 200 °C.
5.2.1 Australia
Explosion proof variants for Australia are approved as Ex nA II T3 according to IEC 79-15 (corresponding to AS 2380.9).
Directive/standard Code Description
ATEX
CE 0344 = CE marking of conformity according to the ATEX directive 94/9/EC, Annex X.
0344 is the number of the notified body which has certified the quality system for ATEX.
= Marking of explosion protection.
II = Equipment group according to the ATEX directive, Annex II, point 2.2, defining the requirements
applicable to the equipment in this group
2=
Equipment category according to the ATEX directive, Annex II, point 2.2, defining the requirements
applicable to the equipment in this category
G = Explosive atmospheres caused by gases, vapours or mists
D = Explosive atmospheres caused by dust EN 61241-0:2006
Harmonized
European standard
EN 50014
Ex = The equipment conforms to harmonized European standard
c Constructional safety according to EN 13463-5:2003 and EN 13463-1:2001
d = Flame-proof enclosure according to EN 60079-1:2007
mb = Encapsulation according to EN 60079-18:2004
II = Suitable for use in explosive atmospheres (not mines)
B = Classification of gases, see EN 60079-0:2006, Annex A. Gas group B includes gas group A.
T4/T3 = Maximum surface temperature is 135 °C/200 °C according to EN 60079-0:2006*
tD = Protection by enclosure EN 61241-0:2006
A21 = The zone in which the pump can be used according to EN 61241-1:2004
IP68 = Enclosure class according to IEC 60529
X
The letter X in the certificate number indicates that the equipment is subject to special conditions for
safe use. The conditions are mentioned in the certificate and the installation and operating
instructions.
Standard Code Description
IEC 79-15:1987
Ex = Area classification according to AS 2430.1
nA = Non-sparking according to AS 2380.9:1991, section 3 (IEC 79-15:1987)
II = Suitable for use in explosive atmospheres (not mines)
T3 = Maximum surface temperature is 200 °C
X
The letter X in the certificate number indicates that the equipment is subject to special conditions for
safe use. The conditions are mentioned in the certificate and the installation and operating
instructions.
