Grundfos Sololift2 WC-1 User manual

Sololift2 WC-1, WC-3
Installation and operating instructions
GRUNDFOS INSTRUCTIONS

2

English (GB)
3
English (GB) Installation and operating instructions
Original installation and operating instructions
CONTENTS
Page
1. Symbols used in this document
2. General description
The WC-1 and WC-3 are small, compact automatic
lifting stations suitable for pumping domestic
wastewater and sewage off places in private
dwellings where wastewater cannot be led directly to
the sewer by means of a natural downward slope.
3. Applications
The product is only suitable for pumping wastewater
from a cabinet shower, bidet and/or washbasin as
well as sewage from a toilet.
1. Symbols used in this document 3
2. General description 3
3. Applications 3
4. Pumped liquids 4
5. Installation 4
6. Electrical connection 4
7. Service 4
7.1 Service documentation 5
7.2 Maintenance 5
7.3 Adjustment of run time 5
7.4 Service instructions 5
8. Technical data 6
9. Fault finding 7
10. Disposal 8
Warning
Prior to installation, read these installation
and operating instructions. Installation and
operation must comply with local
regulations, EN 12056-4 and accepted
codes of good practice.
Warning
The use of this product requires
experience with and knowledge of the
product.
Persons with reduced physical, sensory or
mental capabilities must not use this
product, unless they are under supervision
or have been instructed in the use of the
product by a person responsible for their
safety.
Children must not use or play with this
product.
Warning
If these safety instructions are not
observed, it may result in personal injury.
Caution
If these safety instructions are not
observed, it may result in malfunction or
damage to the equipment.
Note
Notes or instructions that make the job
easier and ensure safe operation.
Caution
If away for a long period (e.g. holidays) we
recommend that you turn off the water
supply to the toilet served by the unit.
Note
This is a domestic unit.
Toilets connected to this unit can be used
like any normal toilet, and require
minimum maintenance. The unit will
operate automatically as soon as the
required level of water enters the tank.
Caution
Only the disposal of toilet paper, faecal
matter and waste water will be covered by
warranty. Any damage due to foreign
bodies such as cotton, condoms, sanitary
towels, wet wipes, food, hair, metal, wood
or plastic objects, will not be covered by
warranty. Solvents, acids and other
chemicals can also cause damage to the
unit, and will invalidate the warranty.
Note
Applications according to EN 12050-3.
Not for public and heavy commercial or
industrial use, only limited number of
users.
Installation with direct connection to toilet
and in the same room as sanitary
appliances.
A second toilet must be available above
the backflow level.
The product must be fastened to the floor
to prevent uplift and turning.

English (GB)
4
4. Pumped liquids
Domestic wastewater and sewage containing toilet
paper and faeces.
Ordinary liquids for cleaning of the appliances
connected. pH value: 4-10.
5. Installation
An alarm device for acoustic alarm in case of
malfunction or high level in the tank is available as
an accessory (noise level 75 dB(A)).
Product number: 97772315.
Fig. 1 Alarm device
Extension pipes between the toilet and lifting station
must not be longer than 150 mm due to the
increased risk of clogging.
6. Electrical connection
Make sure that the product is suitable for the supply
voltage and frequency available at the installation
site.
The electrical connection must be carried out in
accordance with local regulations.
The electrical connection should be made according
the table below.
7. Service
For service kits, see www.product-
selection.grundfos.com.
Caution
The product must not pump harsh
chemicals or solvents. See the quick
guide.
The product is designed for flush volumes
of 4, 6 and 9 litres. A 4-litre flush is
permissible only if the amount of solids in
the pumped liquid is small.
Caution
Do not pull or lift the product by the supply
cable.
Note
The product must be accessible for
maintenance and repair.
The product must be placed in a frost-free
room to prevent the pumped liquid from
freezing.
Make sure that all external pipework is
adequately insulated.
The discharge pipe must be made of rigid
material, such as copper, or of rigid PVC
with solvent-welded joints.
To prevent the transmission of vibrations
to buildings, make sure that the pipework
is thoroughly fixed and that fittings cannot
move and are not in contact with building
parts.
TM04 9469 4310
Warning
The product must be earthed.
The installation must include an earth
leakage circuit breaker for protection
against earth fault currents. This will
ensure protection when using a Schuko
plug or another plug with earth pin.
The product must be connected to a mains
switch with a minimum contact gap of 3
mm in all poles.
In case of overtemperature, a thermal
switch cuts out the motor and cuts it in
automatically when it has cooled
sufficiently.
Market Europe GB AU
Plug
Warning
The product must only be serviced by
trained service personnel.
If the supply cable is damaged, it must
replaced by the manufacturer, the
manufacturer’s service partner or a
similarly qualified person.
To ensure safe and reliable operation,
always use original spare parts from
Grundfos.
Note
The product must be thoroughly cleaned
before it is returned for service. Otherwise
the warranty will be void.

English (GB)
5
7.1 Service documentation
Service documentation is available at www.product-
selection.grundfos.com.
If you have any questions, please contact the
nearest Grundfos company or service workshop.
7.2 Maintenance
The lifting station does not require any special
maintenance, but we recommend that you check
operation and pipe connections at least once a year.
Change the carbon filter once a year.
See section 7.4 Service instructions.
7.3 Adjustment of run time
The default setting ensures proper operation in most
pipework. If the pipework is particularly long or short,
it may be necessary to adjust the run time.
For a guide to adjusting the run time, see
www.product-selection.grundfos.com.
7.4 Service instructions
Thanks to the product design, service is easy in case
of malfunction or blocked pump.
Digits in the following sections refer to the pictures in
the appendix at the end of this booklet.
Impeller/grinder stuck
1.1 Disconnect the power supply.
1.2 Unscrew the plug in the cover.
1.3 Insert a screwdriver (min. 110 mm) through the
plug hole and into the slot of the shaft end.
Turn the shaft right and left to free the impeller/
grinder from dirt.
1.4 Fit the plug, and switch on the power supply to
check if the impeller/grinder can rotate freely.
Operation by means of a power drill
2.1 If the product cannot be operated by electrical
power, disconnect the power supply and empty
the toilet and tank by means of a power drill.
Pressure switch pipe blocked
3.1 If the water level in the tank is above the motor
flange, disconnect the power supply and drain
the tank by means of the drain hose
(accessory).
3.2 Unscrew the cover.
3.3 Pull out the complete pressure switch.
3.4 Check and clean the pressure switch pipe.
Foreign body in tank
If the water level in the tank is above the motor
flange, disconnect the power supply and drain the
tank by means of the drain hose (accessory).
Unscrew the cover. See 3.2.
4.1 Remove the four screws of the motor flange.
4.2 Lift the motor flange to reduce the compression
of the O-ring. Insert a screwdriver into the notch
underneath the supply cable and press it down.
4.3 Lift out the complete motor-pump unit by the
handles.
4.4 Check and clean the tank and impeller/grinder.
Carbon filter
5. Replace the carbon filter once a year to ensure
sufficient filter function.
Warning
Before carrying out any service work,
remove the fuse, pull out the plug, or
switch off the power supply. Make sure
that the power supply cannot be
accidentally switched on.
All rotating parts must have stopped
moving.
The product must only be serviced by
trained service personnel.
Note
The pressure switch unit can be removed
separately.
Caution
Make sure that the little tube in the top of
the pipe did not become blocked when you
cleaned the pipe!
Note
Lubricate the sealing area of the pressure
switch for easier fitting.
Note
Lift the unit vertically before tilting it!
Warning
Beware of the sharp edges on the grinder.
Wear protective gloves.
Note
Instead of using a carbon filter, Sololift can
also be vented through a venting pipe. In
this case a venting valve is needed.
Product number: 98059587.

English (GB)
6
8. Technical data
Supply voltage
1 x 220-240 V - 10 %/+ 6 %, 50 Hz.
Power consumption
Max. 620 W.
Power factor
Cos φ0.87 / 0.92.
Speed
2800 min-1.
Rated current
3.0 A.
Insulation class
F.
Noise level
< 70 dB(A) to 12050-2.
Flow rate
Max. 149 l/min.
System pressure
Max. pump head: 8.0 m.
Max. system head: 6.0 m.
Supply cable
1.5 m, 0.75 mm2(H05VV-F-3G).
Net weight
7.3 kg.
Start and stop levels
Start: 72 mm above bottom.
Stop: 52 mm above bottom.
Liquid temperature
Max. 50 °C.
Ambient temperature
+5 °C to +35 °C.
Duty
S3 - 50 % - 1 min. (30 sec. on; 30 sec. off).
Marking
Approvals
Note
The system pressure should not exceed 6
m head to guarantee a sufficient drain of
the connected sanitary appliances.

English (GB)
7
9. Fault finding
See also section 7.4 Service instructions.
Warning
Remove the fuse, pull out the plug, or
switch off the power supply.
Make sure that the power supply cannot
be accidentally switched on.
All rotating parts must have stopped
moving.
The product must only be serviced by
trained service personnel.
Fault Cause Remedy
1. Motor does not start
when the level in the
tank reaches the start
level.
a) Supply failure. Reestablish the power supply.
b) Fuse blown.
If new fuse blows at once,
either cable or motor is faulty.
Replace the fuse.
Measure cable and motor. If cable or
motor is defective, replace the defective
parts.
c) Impeller/grinder stuck.
Thermal switch tripped.
Free the impeller/grinder, and wait until
the motor is cooled down and the
thermal switch has reset.
d) Pressure switch pipe blocked. Remove the pressure switch and clean
the pipe.
2. Motor hums but does
not operate.
a) Impeller/grinder stuck. Free the impeller/grinder and check that
it can rotate freely.
b) Motor or capacitor defective. Replace the motor or capacitor.
c) Control board defective. Replace the control board.
3. Motor runs
continuously or at
irregular intervals.
a) Water leaking from inlet into
tank.
Check for leaking appliances.
b) Water leaking back into tank
from discharge pipe.
Check the non-return flap.
c) Pressure switch defective. Replace the pressure switch unit.
4. Motor runs but does
not evacuate water.
a) Pump or tank blocked. Remove blockage.
b) Air lock in pump or vent hole in
pump housing blocked.
Check operation of vent valve in the
tank.
Check that the carbon filter is not wet.
Check that the vent hole in the pump
housing is not blocked.
c) Discharge port or pipe blocked. Remove blockage.
Check the non-return flap.
5. The lifting station
evacuates slowly.
a) Discharge pipe is too long or
has an excessive number of
bends.
Increase discharge pipe size.
Change pipework to reduce number of
bends.
Change bends to soft bends.
b) The pump housing is leaky. Replace the pump housing
(service part).
c) Hydraulics or grinder blocked. Check and clean the hydraulics and
grinder.
6. Rattling noise from the
lifting station, but
water is evacuated.
a) Foreign body hitting the
impeller/grinder.
Remove the foreign body.
7. Odour from the tank. a) Carbon filter contaminated. Replace the carbon filter.

English (GB)
8
10. Disposal
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest
Grundfos company or service workshop.
Subject to alterations.
8. Water from shower or
another appliance
connected to the lower
inlets drains off slowly.
Backflow from the
lifting station.
a) Non-return flap in inlet stuck,
does not open or does not close
sufficiently.
Check the non-return flap.
b) Hydraulics or grinder blocked. Check and clean the hydraulics and
grinder.
c) The start level has changed. Check and clean the pressure switch
pipe.
d) Inlet pipe diameter is too small. Use a pipe with a larger diameter.
Fault Cause Remedy

Appendix
9
Appendix 1

Appendix
10
