Special features
Multi-functional camera
– Photos and video clips
– MP3 player
– Webcam
– Dictaphone
Package contents
Camera
USB connection cable
Adapter cable for operation on TV
CD-ROM with driver and software for PC
2 batteries
Operating manual
Safety
To ensure that this camera provides you with long-term satisfaction and
enjoyment, please observe the following instructions.
This device is designed to record and play back video and audio signals.
Any other use is expressly prohibited.
SPECIAL FEATURES/SAFETY_______________

ENGLISH
5
If the camera is subjected to sudden changes in temperature, for example
when taken from the cold into a warm room, condensation may appear.
Switch off the camera for two hours before using it.
You must make sure that the device is protected from moisture such as rain
or water splashes.
Do not touch the objective of the camera with your bare fingers!
Never open the camera casing. The manufacturer will not accept any
liability for damage resulting from improper handling.
Technical changes and errors reserved!
Cleaning
Clean the device with a clean, moist leather cloth. Do not use any cleaning
agent, as this may damage the casing!
Use a soft brush to remove dust from the objective, the viewfinder and the
display, wiping them afterwards with a soft, dry cloth.
SPECIAL FEATURES/SAFETY ________________________
Picca
ǵ
1,3 Megapixel
L
e
n
s
f
1
0
m
m
F
1
:
2
,
5
Picca
ǵ
1,3 Megapixel
L
e
n
s
f
1
0
m
m
F
1
:
2
,
5
! SERVICE !! SERVICE !! SERVICE !
2h
°C
°C
Picca
ǵ
1,3Megapixel
L
e
n
s
f
1
0
m
m
F
1
:
2
,
5
Picca
ǵ
1,3Megapixel
L
e
n
s
f
1
0
m
m
F
1
:
2
,
5

6
The front of the camera
1Shutter release button
2Flash
3Viewfinder
4Objective
The back and the bottom of the camera
1Card slot
2LED
3Colour function and menu display (LCD)
4Microphone
5Battery compartment cover
6Speaker
7Threaded socket for a tripod (bottom of camera)
OVERVIEW ___________________________________________
Picca
ǵ
1,3 Megapixel
L
e
n
s
f
1
0
m
m
F
1
:
2
,
5
OPEN
ǵOff
PC
SET
OK/REC
VOL
MIC
DSP
1
12 3 5
2 3 4
4
6
7

ENGLISH
7
Function buttons
85a Activates the delayed shutter release
– For selecting photos, movie recordings, voice recordings and
music tracks.
– For settings (e.g. time and date).
DSP Switches the display on and off.
Calls up a menu, depending on the operating mode.
6s6 Switches the flash between on/automatic/off.
For selecting photos, movie recordings, voice recordings and
music tracks.
For settings (e.g. time and date).
OK/REC Starts and stops sound recording.
Confirms various settings.
VOL + Increases the volume.
Moves the cursor up in the menus.
VOL – Decreases the volume.
Moves the cursor down in the menus.
OVERVIEW___________________________________________
ǵOff
PC
SET
OK/REC
VOL
MIC
DSP

8
Rotary switch for the operating modes
There is a selection of nine different operating modes:
0Taking photos
9Movie recording
%MP3 sound playback
$Voice recording
(Operating with a PC
SET Settings
PC Operating as a PC camera or Webcam
RViewing/deleting. Operating with a TV
Off Switching off
Connections on the camera
DC Socket for mains adapter (DC 3,3V/2A)
TV Video output socket
USB socket
ySocket for earphones (3.5 mm jack)
(
Ω
OVERVIEW___________________________________________
OPEN
ǵ
Off
PC
SET
OK/REC
VOL

ENGLISH
9
Display symbols
wTime and date must be set
ŁIndicates playback of a video recording
8Delayed shutter release on
Automatic voice detection on
4All MP3 tracks are repeated
&Photos in series on
7Flash on
!Red-eye reduction on
$Sound recording on
RMemory card inserted
Charge level of the batteries
MIndicates different modes
HQ High image quality on
vWhite balance for clear sky on
+1.0 Displays the exposure value
57 Displays the number of recordings still possible
3
OVERVIEW___________________________________________
wŁ84M7!$RHQ
v+1.0 57
3

10
Battery operation
1Open the cover of the battery compartment.
2Insert two batteries, observing the polarity on the bottom of the battery
compartment (Mignon type, e.g. 2x1.5V, LR6/AM3/AA).
3Close the cover of the battery compartment.
Note:
The camera display tells you about the state of the batteries:
– » « batteries charged
– » « batteries weak
– » « batteries empty
Remove the batteries when they are flat or when you know that the cam-
era will not be used for a long period of time.
No liability is accepted for damage resulting from leaking batteries.
The batteries are switched off during mains operation.
123
POWER SUPPLY___________________________________
OPEN
ǵ
Off
PC
SET
OK/REC
VOL
MIC
OPEN
OPEN
ǵ
Off
PC
SET
OK/REC
VOL
MIC
OPEN

ENGLISH
11
Operating with NiCd, NiMH or lithium batteries
You can also operate the camera using standard batteries. If you use
rechargeable batteries, do not let them charge up in the camera while using
a mains adapter. Use an external charging device for this purpose.
We recommend that you use batteries, because this improves the
performance of the camera and increases the operating time.
Mains operation
(with mains adapter, 3,3 V DC/2A – accessories)
Note:
Check if the mains voltage on the mains adapter type plate corresponds to
your local mains supply.
The only way to disconnect the camera from the mains supply is to pull the
mains adapter. Only unplug the mains adapter from the socket when you
are not using the camera.
1Plug the mains adapter cable into the »DC « socket on the camera.
2Insert the mains adapter plug in the socket.
Ω
POWER SUPPLY ____________________________________

12
Switching on and off
Switching on
1Switch on the camera by setting the rotary switch to any operating mode
besides »Off«.
– The LED on the back of the camera lights up in green, then in red, and
then in green again.
– The operating mode depends on the setting of the rotary switch.
Note:
If »w« flashes in the display, you need to set the time and date (see
page 19). If the time and date are not set, »Date/Time« »00:00« and
»2002/01/01« appear in the menu.
Switching off
1Switch off the camera by setting the rotary switch to »Off«.
– The LED on the back of the camera goes out.
– Settings made in the menus are lost when you switch off the device.
Note:
The camera switches off automatically if no button has been pressed in the
last 1.5 minutes.
PREPARATION______________________________________
w

ENGLISH
13
Switching the display on and off
1Briefly press »DSP« to switch on the display.
2To switch the display off, hold down »DSP«.
Note:
In the »0« and »9« operating modes you can set the switch-on time
for the display (see page 25).
The storage media of the camera
Your camera is equipped with internal flash storage. It enables you to take
approx. 75 photos in HQ mode or approx. 277 in normal mode. Movie
recordings of up to 1:22 minutes in HIGH mode or 4:19 minutes in NOR-
MAL mode are also possible.
The photographing or recording capacity can be increased with an addit-
ional memory card. Only use memory cards labelled “multimedia card” or
“SD card”.
PREPARATION ______________________________________

14
Selecting the memory medium
You use this function to set the camera to the internal flash memory or to a
memory card that you have inserted (only works if you have inserted a
memory card).
1Select the »SET« operating mode with the rotary switch.
– Display: the »Settings« menu.
2Select the »Current Media« line with »VOL +« or »VOL –« and confirm
with »OK/REC«.
– Display: the »Current Media« menu.
3Select the memory medium you want with »VOL +« or »VOL –«.
– Display: »Int. Memory« for the internal flash memory, »Card« for the
memory card.
4To exit the menu, select the »Back« line with »VOL +« or »VOL –« and
confirm with »OK/REC«.
– The camera records on the internal flash memory or on the memory
card you have inserted.
Note:
If you have inserted a memory card, the camera records on the memory
card automatically without being preset.
PREPARATION ______________________________________

ENGLISH
15
Inserting a multimedia card or SD card
1Switch off the camera by setting the rotary switch to »Off«.
2Open the cover of the card slot.
3Push in the memory card – with the contacts facing downwards – as far
as it will go.
Note:
Do not exert force when inserting the card. Apply only slight pressure.
The memory cards are resistant to dirt and moisture, but must only be in-
serted into the camera in a dry and clean condition.
Never remove memory cards during operation. This can damage the
memory card.
This type of damage will invalidate your warranty.
4Close the cover.
– When the camera is switched on, »R« appears in the display.
PREPARATION ______________________________________
DSP
R

16
Formatting the memory card
If you have been using the multimedia card or SD card in another device, it
has to be reformatted for your camera.
Note:
In reformatting the card you delete its contents.
1Select the »SET« operating mode with the rotary switch.
– Display: the »Settings« menu.
2Select the »Format« line with »VOL +« or »VOL –« and confirm with
»OK/REC«.
– Display: the »Format Media« menu.
3Select the »Format« line with »VOL +« or »VOL –« and confirm with
»OK/REC«.
– A progress bar shows the progress of formatting and when it is
complete.
– The display returns to the »Settings« menu.
PREPARATION ______________________________________
Settings
4
3
Date/Time
Compression
Current Media
Format
Save Last
ĵĵ
Settings
4
3
ĵĵ
4-2
Cancel
Format
Memory
Format Memory

ENGLISH
17
Note:
If you select the »Cancel« line in the »Format« menu, the display switches
back to the »Settings« menu without carrying out any formatting.
If »Error« is displayed, the memory card could not be formatted.
Repeat the formatting procedure with the same card or with a new one.
Displaying memory capacity
1Set the rotary switch to the »SET« operating mode.
– Display: the »Settings« menu.
2Select the »Memory« line with »VOL +« or »VOL –« and confirm with
»OK/REC«.
– Display: memory capacity and free memory space.
PREPARATION ______________________________________
Settings
7
3
TV System
Memory
Version
Defaults
ŁŁ
Settings
6
3
Memory Status
Capacity
16,515,072 bytes
Free Space
15,138,816 bytes
7-1
Back

18
Switching the memory function for the last file number
on and off
If this function is switched off, the last file number is reset (e.g. from »0012«
to »0002«) when you change the memory card, or during formatting.
If the function is switched on, the last file to be stored is saved, so that the
next file to be stored on the memory card or in the flash memory is given the
next available number (e.g. last file stored »0014«, next file to be stored
»0015«).
1Set the rotary switch to the »SET« operating mode.
– Display: the »Settings« menu.
2Select the »SAVE LAST« line with »VOL +« or »VOL –« and confirm with
»OK/REC«.
– Display: the »Save last« menu.
3Select the »Off« or »On« line with »VOL +« or »VOL –« and confirm
with »OK/REC«.
– The display returns to the »Settings« menu.
PREPARATION ______________________________________
Settings
5
3
Date/Time
Compression
Current Media
Format
Save Last
ĵĵ
Settings
5
3
Date/Time
ĵĵ
ǵOn
ǵ
●Off
Save Last
5-3
Back

ENGLISH
19
Setting the time and date
1Set the rotary switch to the »SET« operating mode.
– Display: the »Settings« menu, the »Date/Time« line is selected.
2Select the »Date/Time« line with »OK/REC«.
– Display: the »Date/Time« menu.
Note:
Incorrect entries can be deleted by pressing »85a «.
To leave the menu, select the »Back« line with »VOL +« or »VOL – « and
confirm with »OK/REC«. The camera returns to the »Settings« menu and
the settings are not saved.
3Select »Change« with »6s6« and confirm with »OK/REC«.
4Enter the day with »VOL +« or »VOL –« and switch to the month with
»6s6«.
5Enter the month with »VOL +« or »VOL –« and switch to the year with
»6s6«.
6Enter the year with »VOL +« or »VOL –« and switch to the hour with
»6s6«.
PREPARATION ______________________________________
Settings
1
3
Date/Time
07 / 10 / 2002
11 : 00
Date/Time
1-2
Back Change
Settings
1
3
Date/Time
Compression
Current Media
Format
Save Last
ĵĵ

20
7Enter the hours with »VOL +« or »VOL – « and switch to the minutes
with »6s6«.
8Enter the minutes with »VOL +« or »VOL – « and confirm them with
»OK/REC«.
– The display returns to the »Settings« menu.
Resetting the camera to the factory settings
With this function you can delete all stored settings, recordings, etc. and
reset the camera to its original state.
1Set the rotary switch to the »SET« operating mode.
– Display: the »Settings« menu.
2Select the »Defaults« line with »VOL +« or »VOL –« and confirm with
»OK/REC«.
– Display: the »Restore Defaults« menu.
Note:
To leave the menu, select the »EXIT« line with »VOL +« or »VOL – « and
confirm with »OK/REC«. The camera returns to the »Settings« menu and
the settings are not saved.
PREPARATION ______________________________________
Settings
1
3
Date/Time
Compression
Current Media
Format
Save Last
ĵĵ ŁŁ
Settings
9
3
TV System
Memory
Version
Defaults
ŁŁ
Settings
9
3
9-2
Cancel
Restore
Restore Defaults
ŁŁ
