GSO PWC-L60 User manual

POOL WATER CURTAIN
(PWC)
Operating instructions
Contents
All models 1.
Technical detailes 2.
Equipment diagram 3.
Install steps 4.
Maintenance / Cleaning 5.
Part number 6.
Water smile
GSO

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
PWC- L60 PWC- L40
Pool Water Curtains
PWC - L60
1-2 Identification Codes
Water curtain Length
40/60 cm
1- All models of PWC nozzle
Figure 1-1
www.gsofountain.com
Page 2 OF 7

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
B
C
D
A
Figure 2-1
2- Technical detailes
TECHNICAL DETAILES: ( PW
C Nozzle)
TYPE
PWC
L60 L40
Water curtain length (mm)
600~1000 400~700
Dimensions
(mm)
A 600 400
B 700 460
C 750 500
D 840 590
Water Thickness(mm)
6 4.5
Holder
yes yes
Connection size (inch)
2 1/2" 2"
Flow (m3/hr)
30 17
Pressure Drop (bar)
0.2 0.2
Material
Stainless steel.316 Stainless steel.316
Weight (kg)
22 12
Order code
PWC-L60 PWC-L40
www.gsofountain.com
Page 3 OF 7

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
Figure 5-1
5
5
4
3
2
1
Figure 5-2
3- Equipment diagram
For better performance fountain, we suggest using other equipment such as pump, cartridge filter, UV filter and
other equipment as shown in the figure 5-1 , 5-2.
ITEM
NO
EGUIPMENTS
1 Pool water curtain
2 Holder pool water curtain
3 Pool pump
4 Water suction point
5 Pipe work
www.gsofountain.com
Page 4 OF 7

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
L+10cm
W+10cm
H+10cm
Figure 3-1 Figure 3-2 Figure 3-3 Figure 3-4
Figure 3-5 Figure 3-6
You can install the device on the floor by the holder. Note the following figures 3-1, 3-2, 3-3, 3-4, 3-5, and 3-6.
Figure 3-1: Create a pit with 10 cm more than holder dimensions.
Figure 3-2: Connect the inlet pipe DN75 to the nozzle holder.
Figure 3-3: Install the holder to connect the water pipe to the pothole
Figure 3-4: Adjust Holder Level. Fill the hole with concrete
Figure 3-5: Install the pump and other equipment in the plumbing circuit.
Figure 3-6: Install the nozzle on the holder with screws.
4- Install steps
www.gsofountain.com
Page 5 OF 7

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
2
3
1
4
Figure 6-1
V
1
2
2
1
Figure 5-1
6- Explod / Part number
Product name: PWC-L60
Cleaning the unit
Loosen the screws for nozzle (Poa .1) 1.
Remove the nozzle for holder (pos.2) 2.
Wash the inside of the nozzle and holder with water 3.
flow
Important instruction:
The maintenance and cleaning of the machine should be
carried out by technical personnel
5- Maintenance / Cleaning
ITEM
NO.
PART NUMBER QTY.
1
32 60- Nozzle-Pool water
curtain
1
2
33 60-Holder-Pool water
curtain
1
3
B18.6.7M - M10 x 1.5 x 16
Type I Cross Recessed
FHMS --16N
15
4
SCREW: M10 x 1.5 x 16 --
Type I Hex cap
3
www.gsofountain.com
Page 6 OF 7

F.N: 32-60-Operating Instruction-Pool Water Curtain-2
U
U
SECTION
U-U
SCALE
1 : 50
www.gsofountain.com
