GSS HDC 480 CI AV User manual

English
STC 160 Head-End Station
QPSK AV module
Notes on the Assembly Instructions.
As well as this supplementary Assembly
Instructions, the Assembly Instructions for the
STC 160 apply.
GSS
Grundig SAT Systems GmbH
Beuthener Strasse 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
Email: [email protected]
Internet: www.gss.de
HDC 480 CI AV

- 2 - HDC 480 CI AV
Contents
1 Safety regulations .......................................................................................3
2 General information ....................................................................................3
2.1 Scope of delivery ..........................................................................3
2.2 Meaning of the symbols used..........................................................4
2.3 Technical data...............................................................................4
2.4 Description ...................................................................................5
3 Installation..................................................................................................6
3.1 Retrofitting a CA module ................................................................6
3.2 Installing the digital module ............................................................7
3.3 Connecting the digital module.........................................................8
4 The control panel at a glance.......................................................................9
4.1 Menu items...................................................................................9
4.2 Functions of the control panel buttons...............................................9
5 Programming............................................................................................10
5.1 Preparation.................................................................................10
5.2 Programming procedure...............................................................10
5.3 Programming the digital module....................................................12
Selecting the module / channel strip ..............................................12
LNB oscillator frequency; CA module.............................................13
Configuring the CA module, displaying card information ............13
Input symbol rate.........................................................................14
Input frequency ...........................................................................15
Station filter ................................................................................16
Audio stream for a TV channel ......................................................17
Volume level .............................................................................17
Identification of the stereo / dual tone............................................18
Picture format signal, teletext mode................................................18
Test lines.....................................................................................19
Subtitle functions..........................................................................19
Teletext subtitle page and standard...........................................19
DVB subtitle page...................................................................20
Black bar...............................................................................21
Storing data................................................................................21
6 Final procedures........................................................................................22

- 3 - HDC 480 CI AV
1 safety regulations
 • ThestandardsIEC/EN/DINEN50083resp.IEC/EN/DINEN60728must
be observed.
 • Donotperforminstallationandserviceworkduringthunderstorms.
• Assembly, installation and servicing should be carried out by authorised
electricians.
 • Switchofftheoperatingvoltageofthesystembeforebeginningwithassem-
bly or service work.
 • Avoidshortcircuits!
 • Observetherelevantstandards,regulationsandguidelinesontheinstalla-
tion and operation of antenna systems.
 • Toensureelectromagneticcompatibility,makesureallconnectionsaretight
and the covers are screwed on securely.
 • Noliabilityisacceptedfordamagecausedbyfaultyconnectionsorinap-
propriate handling of the device.
Check the head-end station according to the safety instructions listed in their
assembly instruction.
Takeprecautionstopreventstaticdischargewhenworkingonthedevice!
Electronic devices should never be disposed of in the household rubbish. In
accordance with directive 2002/96/EC of the European Parliament and the
European Council from January 27, 2003 which addresses old electronic and
electrical devices, such devices must be disposed of at a designated collection
facility. At the end of its service life, please take your device to one of these
public collection facilities for proper disposal.
2 general information
2.1 sCope of delivery
1 HDC 480 CI AV module
1 AV cable
1 Brief Assembly Instructions

- 4 - HDC 480 CI AV
2.2 meaning of the symbols used
Important note
—> General note
– /
– /  Optionaluseofthebuttons
 •   Performingworks
2.3 teChniCal data
The requirements of the following are met:
2006/95/EC, 2004/108/EC
The product fulfils the guidelines and standards for CE labelling (page 23).
Unless otherwise noted all values are specified as "typical".
HF input:
Frequency range: ....................................................... 950 … 2150 MHz
Level: ..................................................................... 60 dBμV … 80 dBμV
Input impedance:............................................................................75 Ω
Return loss: .....................................................................................8 dB
Input data rate: ...............................................................1 … 45 MSymb
Output specifications:
Audio
Noise voltage ratio rated (DIN 45633): ...........................................60 dB
Non-linear distortion factor: ............................................................0.6 %
Frequency range: ..........................................................20 Hz … 15 kHz
Level at -12 dB: .......................................................................500 mVrms
Impedance:.....................................................................................1 kΩ
Video
Signal-to-noise ratio:.............................................................54 dB (rated)
Level (75 Ω):..................................................................................1 Vpp
Impedance:.................................................................................... 75 Ω
Connections:
SAT inputs: ............................................................................ 4 F-sockets
Connection strip (20-pin):................... For supply voltages and control circuits
AV output:........................................................................... 26-pin socket

- 5 - HDC 480 CI AV
2.4 desCription
The module HDC 480 CI AV, in the following called digital module, has a QPSK
AV converter which simultaneously converts four QPSK modulated channels into
AV signals. It is equipped with four common interfaces, which enable the de-
scrambling of four scrambled channels when used in conjunction with four CA
modulesandfourappropriatesmartcards.Onechannelcanbedescrambled
with every common interface.
The digital module has four SAT inputs and one AV interface, through which
the decoded AV signals are fed to the corresponding modulator module. Com-
ponents (e.g. LNB) which are connected upstream can be powered through
the SAT inputs.
The channel strips "A" "B", "C" and "D" can be individually programmed. This
means it is possible to select up to 4 channels from four transponders.
Signal transfer principle:
Channel strip "A"
Channel strip "B"
Channel strip "C"
Channel strip "D"
TUNER
"A"
TUNER
"B"
TUNER
"C"
TUNER
"D"
CA module
CA module
CA module
CA module
The prepared input signals are fed to the modulator module via the AV in-
terface. From there, they are fed to the HF output collector of the head-end
station, through which the level of the output signal can be adjusted via the
software in the head-end station.
The digital module operating software can be updated using a PC or note-
book and the software "BE-Flash" via the 9-pin D-SUB socket on the head-end
station. You can find the current operating software for the digital module,
the software "BE-Flash" and the current assembly instructions on the website
"www.gss.de".
This digital module is designed exclusively for use in the STC 160 head-end
station.

- 6 - HDC 480 CI AV
3 installation
Caution
– Ensure the head-end station is mounted so it will not be able to vibrate.
Avoid, for example, mounting the head-end station onto a lift shaft or any
other wall or floor construction that vibrates in a similar way.
– Before installing or changing a module, switch off the head-end station or
unplug the power cable from the mains power socket.
 TakemeasurestoprotectagainstESD!
3.1 retrofitting aCa module
The digital module is equipped with four common interfaces for CA modules
of various scrambling systems and service providers. Scrambled channels can
only be descrambled with a CA module suitable for the scrambling system and
the corresponding smart card. The smart card contains all the information for
authorisation, descrambling and subscription.
– The hardware and software of the module HDC 480 CI AV have been thor-
oughly prepared and tested.
– Any changes made by program providers to the structures in the program
data might impair or even prevent this function.
– When working with a CA module, please read the corresponding operat-
ing manual from the respective provider.
 • Insertthesmartcard 1into the CA module 2so that the chip 3 on the
smart card faces the thicker side (top) of the CA module (fig. 1).
 • PushtheCAmodule2without canting into the guide rails 4of the com-
mon interface slot 5according to the following picture and contact it to
the common interface.
5
2
3
4
1

- 7 - HDC 480 CI AV
3.2 installing the digital module
– If a CA module is used, check that the plug contacts of the CA module are
tightly seated in the terminal strip on the digital module and make sure there
is a reliable contact.
– Always position modules which belong together next to each other. The
digital module must be installed to the left of the modulator module.
– When installing the digital module, make sure that it is inserted in a long
numbered groove in front of a contact strip on the board at the rear wall of
the housing.
The shorter not numbered grooves without a contact strip on the board at
the rear wall of the housing are for add-on modules only.
 • Openthehousingofthehead-end station in accordance with the assembly
instructions for the STC 160.
 • Openthelockingdevice1in the direction of the arrow.
1
 • InsertthedigitalmoduleingroovesAand Bof an open slot left to the as-
sociated modulator module and gently slide it into the head-end station until
it makes contact with the board on the rear wall.
B
A
C

- 8 - HDC 480 CI AV
—> The figure below shows the slots 1 (digital module) and 2 (modula-
tor module). The slot between them (without a contact strip on the
board at the rear wall of the housing) is for an add-on module only.
 • Installtheappropriatemodulatormodule.
1
D
G
E
F
 • Afterinstallingthemodulesclosethelockingdevice1in direction of the
arrow.
3.3 ConneCting the digital module
 • ConnectSAT-IFinputsCof the digital module to the preinstalled Ftermi-
nals in the rear wall of the head-end station via the cable inlets Eusing
HF cables made on-site or if applicable to one of the outputs of a retrofitted
SAT-IF input distributor.
 • UsingtheribboncableDto connect the AV output of the digital module to
the AV input of the modulator module.

- 9 - HDC 480 CI AV
4 the Control panel at aglanCe
4.1 menu items
Programme the module using the buttons on the head-end station control unit.
The menus appear on the two-line display of the control unit.
The parameters and functions to be set are underlined.
With the button select the channel strip / other modules.
You can use the button to select the following menu items:
– LNB oscillator frequency
– Symbol rate
– Input frequency
– Station filter
– Audio stream selection
– Audio output level
– Stereo decoding / audio type selection
– Picture format signal (WSS)
– Test lines
– Teletext subtitle / DVB subtitle / black shield
– Store
4.2 funCtions of the Control panel but tons
S
M
– To move the cursor
– To adjust values and functions
– To store the programmed data
– To switch to the next menu

- 10 - HDC 480 CI AV
5 programming
5.1 preparation
 • Connectthedigitalmoduletoaprogrammedmodulatormodule.
—> For the programming of the output channels please read the assem-
bly instructions of the corresponding modulator module.
 • ConnectthetestreceivertotheHFoutputonthemodulatormodule.
 • Adjustthetestreceivertotheoutputchannelofthechannelstriptobeset:
Digital module – channel strip "A" —> modulator module – channel strip "A",
Digital module – channel strip "B" —> modulator module – channel strip "B",
Digital module – channel strip "C" —> modulator module – channel strip "C",
Digital module – channel strip "D" —> modulator module – channel strip "D".
5.2 progr a mming proCedure
Bx 1A
10600 MHz
LNB
>
A
Bx 1A
C5-12,S3-24
TWIN-SAT
C07
Böx 4
C5-12,S3-24
TWIN-SAT
C07
Bx 1B
WDR Köln
QUAD
V 12
SETUP
Bx 1A
Das Erste
QUAD
V 12
V 8
Bx 1A MENU
Information *)
1/6
M
M
/
/
/
/
M
Ein/On
Bx 1A
11836 MHz
FREQ
+0.2
/
/
Bx 1A
Das Erste
01/07 + TV
M
M
Bx 1A
Level
AUDIO
0 dB
M
Bx 1A
mpeg
AUDIO
DUAL norm
M
M
Bx 1A
01 / 02 “deu”
AUDIO
-26 … 6 dB
Bx 1A
WSS off
VIDEO
TXT on
M
/
/
/
/
Bx 1A
27500
SYMBOL /
/
M
Das Menü wird nur bei Auswahlmöglichkeit
mehrerer Begleittöne angezeigt.
This menu is only displayed if several audio
streams are selectable.
*) Die angezeigte Information ist abhängig vom verwendeten CA-Modul
The information displayed is dependent on the CA module used
norm / swap
on / off
mpeg / VPS
/
/
/
/
M
Bx 1A
off
TESTLINES
on / off
Programmauswahl / Channel selection
Bx 1A
txt
SUBTITLE
150 west
Bx 1A
off
SUBTITLE
M/
/
//
/
A
CANCEL
Bx 1A
S => STORE
MEMORY
S
M
M M
Bx 1A
dvb
M
west / east 0…63
off / txt / dvb / black
nur wenn Untertitel
verfügbar sind:
Sprache auswählen
only if subtitles are
available:
select language
SUBTITLE
– –
/
/
Bx 1A
black
SUBTITLE
40/10
BE160
Page 11
