GT Grade 80 User manual

Operating Instructions
Grade 80 Weld on Hook with latch
Note: The Operator must read and fully understand the operating instructions before using this product.


GENERAL INFORMATION
1. Weld-On hooks are to only be welded to a structure, equipment or machinery in an area (load
point) approved by the original equipment manufacturer. (Some manufacturers may not approve
the modification of their product.)
2. For hydraulic excavator lift capacity rating, refer to SAE standard J1097.
3. A visual periodic inspection for cracks, nicks, wear, gouges and deformation as part of a
comprehensive documented inspection program, should be conducted by trained personnel.
4. A visual periodic inspection of the weld should be performed. Check the weld visually, or use a
suitable NDE method if required.
5. As excavator buckets are not specifically designed for constant use with excavator hooks, we
recommend regular and very thorough inspection of the excavator bucket welding area to ensure
no distortion has been made to the work area.
6. Never use a hook whose throat opening has been increased, or whose tip has been bent more
than 10 degrees out of plane from the hook body, or is in any other way distorted or bent.
Note: A latch will not work properly on a hook with a bent or worn tip.
● Never use a hook that is worn beyond the limits shown in Figure 1.
● Remove from service any hook with a crack, nick, or gouge. Hooks with a nick or gouge shall be
repaired by grinding lengthwise, following the contour of the hook, provided that the reduced
dimension is within the limits shown in Figure 1. Contact George Taylor to evaluate any crack.
● Never repair, alter, rework, or reshape a hook by welding, heating, burning, or bending.
● Always make sure the hook supports the load. The load is to be applied within the range shown
in Figure 2. The latch must never support the load (See Figure 3).
● Never side load (See Figure 4), or tip load (See Figure 5) a hook.
● The use of a latch may be mandatory by regulations or safety codes; e.g., OSHA, MSHA,
ANSI/ASME B30, Insurance, etc.
● Ensure latch functions properly. Use only genuine GT replacement parts.
● Never attach more than one sling directly in hook. For collecting two or more slings to the hook,
use proper hardware.
● See ANSI/ASME B30.10 “Hooks” for additional information.



WARNING!
● Loads may disengage from hook if proper procedures are not followed.
● A falling load may cause serious injury or death.
● Hook must always support the load. The load must never be supported by the latch.
● Never apply more force than the hook’s assigned Working Load Limit (WLL) rating.
● Do not use weld on hook for personnel hoisting. See OSHA Rule 1926.1431(g)(1)(i)(A) and
1926.1501(g)(4)(iv)(B).
● Read and understand these instructions before welding on, or using hook.












CAUTION
●The strength of the weld-on hook depends upon the method of attachment. Extreme care must be
used in choice of support as well as during the attachment process.

●The support structure that the hook is attached to must be of suitable size, composition and
quality to support the anticipated loads of all operating positions. The required support structure
material thickness for a given application is dependent on variables such as unsupported length
and material strength, and should be determined by a qualified individual. Minimum plate
thickness required to support the welds are shown in Table 1.

TABLE 1
Working Load Limit (t)
Minimum Plate Thickness (in.)
Minimum Fillet Size All Around (in.)
1
3/16
3/16
2
1/4
1/4
3
5/16
5/16
4
5/16
5/16
5
3/8
3/8
8
1/2
1/2
10
1/2
1/2


● Position the hook to ensure that the load is applied in the plane of the hook, and the load is
supported by the hook in all operating positions. Ensure that the hook does not interfere with the
operation of other mechanisms or cause pinch points.
● Ensure that the maximum gap between hook base and support does not exceed 1/8”. Modify the
support structure if required to reduce gap.
● When welding hook to carbon or low alloy steels (less than .40% carbon), the following welding
recommendations are to be followed. For welding hook to other grades of steel, a qualified weld
procedure must be developed. GT hook material is AISI 8622 modified.
● Welding is to be performed by a qualified welder using qualified procedure in accordance with
American Welding Society (AWS), and/or American Society of Mechanical Engineers (ASME)
requirements.
● Welding electrode to be in accordance with AWS A5.4 E-312-16. Observe the electrode
manufacturer’s recommendations.
● Before welding, the surface to be welded on, including the hook and support structure, must be
clean and free from rust, grease and paint.
● Fillet weld leg size should be of minimum shown in Table 1. Weld profiles to be in accordance
with AWS. Weld size is measured by length of leg.

● Welding should be carried out completely around base in a minimum of two passes to ensure
adequate root penetration at the base of the hook.
● Do not rapidly cool the weld.
● After welding, a visual inspection of the weld should be performed prior to painting.
● No Cracks, pitting, inclusions, notches or undercuts are allowed. If doubt exists, use a suitable
NDE method, such as Magnetic Particle or Liquid Penetrate to verify.
● If repair is required on weld, grind out defect and re-weld using original qualified procedure.
● After welding, the assembly should be proof tested before putting into service.
● Welding preheat range outlined below.
– Minimum preheat temperature: 212F (100C).
– Maximum temperature: 716F (380C).


Important – Instructions for Assembling S-4313 Latch on BH-313 Weld-On Hook
Step 1
1. Place hook flat on work surface as shown.
Step 2 - Hook Sizes 1 to 3 tonnes
2. Position coils of spring over hook cam, with legs of
spring pointing towards hook tip and coil of spring
positioned down as shown below.

Step 2A - Hook Sizes 4 to 10 tonnes
2A. Spread legs of spring and place into drilled
hole. Position coils of spring over hook cam, with
end of spring pointing toward hook tip as shown.
Step 3
3. Position latch over spring, aligning latch ears and
spring coil. On pin hole side of latch, insert non grooved
end of latch pin through hole hole in latch and through
spring until contact is made with hook body (a small
punch may be required for proper alignment).
Step 4
4. Align holes in latch with holes in cam of hook.
Continue pushing the pin through hook, spring
and latch.
Step 5
5. Insert roll-pin into latch, driving it in with a hammer,
while ensuring that latch pin groove is in alignment.

SPECIFICATIONS & DIMENSIONS


Product Code
Model No.
B
C
E
L
W.L.L.
B.L.
Weight


mm
mm
mm
mm
t
t
kgs /
each
G80WH1
SLR0191.0T
78
90
23.5
98
1
5
0.485
G80WH2
SLR0192.0T
92
81
28
114
2
10
0.83
G80WH3
SLR0193.0T
106
116
30
129
3
15
1.2
G80WH5
SLR0195.0T
133
159
39
171
5
25
2.46
G80WH8
SLR0198.0T
136.5
159
36
177
8
40
3.26
G80WH10
SLR01910.0T
169.5
194
48
223
10
50
5.17
