GU Electronic ML-2012-180720 User manual

CHEVROLET2012 PAS TD
- MODEL : ML-2012-180720
- DATE : 2020.02.10

GU Electronic
Index
1. Main Spec
2. Block Diagram
3. Dimension
4. External Appearance
5. Connector Pin Assignment
6. Product Composition
7. DIP S/W Setting
8. Mode Change
9. Touch Control
10. OSD(On Screen Display) Control
11. Install Manual
12. Q & A

GU Electronic
1. Main Spec.1. Main Spec.
1. Input Spec. (MULTI VIDEO INTERFACE)
- 1 x Digital RGB Input (Navigation System source)
- 1 x Analog RGB Input (Navigation System output)
- 2 x A/V Input (External video source)
- 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
- 1 x CVBS(FRONT CAMERA) Input. (Front camera source)
- 1 x LVDS Input. (Car Command System)
2. Output Spec.
- 2 x CVBS Output (Video out for Installing Headrest Monitor)
- 1 x Audio L/R Output.
- 1 x Vertual Analog Touch (Navigation System source)
- 1 x Uart Digital Touch (Navigation System source)
- 1 x LVDS Output (LCD Operation)
3. Power Spec.
- Input Power : 8VDC ~ 24VDC
- Consumption Power : 12Watt, Max
4. Switch Input mode
- Possible to select CAR model while switching mode by DIP S/W
- By button on the Commander in the car via CAN

GU Electronic
2. Block Diagram2. Block Diagram
Scaler
(PIP)
MCU
LVDS
TX
INTERFACE
CAR
COMMAND
SYSTEM
LVDS
CAN
EEPROM
CAN
RECEIVER
LVDS
TX
CAR
TFT-LCD
LVDS
RX
RELAY
REAR CAMERA
POWER
REAR CAMERA
LVDS
LVDS
FRONT CAMERA COMPOSITE
NAVIGATION
SYSTEM
COMPOSITE
CVBS1
CVBS2 MUX

GU Electronic
3. Dimension
156mm * 83mm * 22mm
* This can change under manufacturer’s circumstance
156mm
83mm
22mm

GU Electronic
4. External Appearance
LED PROGRAM
A/V
DIP S/W
NAVI
POWER/CAN TOUCH
Digital
RGB
IMAGE LCD-OUT

GU Electronic
4. External Appearance
LED
PROGRAM IMAGE
DIP S/W
A/V
RGB
NAVI
POWER/CAN TOUCH
Digital
NAVI
LCD-OUT

GU Electronic
5. Connector Pin Assignment
*POWER Connect
1. ACC (Red)
2. N.C
3. Rear-DET (Brown)
4. Front-DET (Blue)
5. CAN1-L (Green)
6. CAN1-H (Brown)
7. CAN2-L (Blue)
8. CAN2-H (Orange)
1 15
2 16
9. CAN3-L (Violet)
10. CAN3-H (Yellow)
11. SWC (Pink)
12. Rear-VCC (Red)
13. Front-VCC (Red)
14. Mode (Green)
15. GND (Black)
16. N.C
*NAVI Connect
① R DATA (Red)
②G DATA (Green)
③B DATA (Blue)
④SYNC (White)
⑤GND (Black)
⑥DVB-T-IR
⑦DVD-IR
① ② ③ ④ ⑤ ⑥ ⑦
*Touch Connect
① Y-
②X-
③Y+
④X+
① ② ③ ④

GU Electronic
6. Product Composition
Interface 1 EA
Power Cable 1 EA
OSD Board 1 EA
A/V Cable (24pin) 1 EA
RGB NAVI Cable(7pin) 1 EA
LVDS Cable 1 EA
Touch convertor Cable(KD-900) 1 EA
Mode S/W 1 EA

GU Electronic
6. Product Composition
* CarPlay Set Sales(option) – KPLAY
Interface 1 EA AUX Cable 1 EA
Power Cable 1 EA HDMI Cable 1 EA
Microphone 1 EA
Bluetooth / Wifi Antenna 2EA

GU Electronic
6. Product Composition
CarPlay Main 1 EA AUX Cable 1 EA
Power Cable 1 EA
HDMI Cable 1 EA
* CarPlay(NV17) Set Sales(option)
Microphone 1 EA

GU Electronic
7. DIP S/W Setting
* ON : DOWN , OFF : UP
PIN FUNCTION DIP S/W Selection
1 NAVI ON : Not Used
OFF : Used
2 DVB-T(AV1) ON : Not Used
OFF : Used
3 DVD(AV2) ON : Not Used
OFF : Used
4 N.C
5 N.C
6
CAR type SEL Right Picture7
8
* DIP S/W Example
Malibu 7” 800*480,
Alpheon 7” 800*480,
GL8 7” 800*480,
REGAL 7” 800*480,
LACROSSE 7” 800*480,
HOLDEN Commodore 7”

GU Electronic
8. Mode Change
Mode Change StreeingWheel
Screen switching when pressed for 2 seconds.
Switch screen when pressed twice shortly.
•To use the Streeing button You must
select the “ON" button in the menu.
•Select "OFF" when not in use.
•To use the Streeing button You must
select the “ON" button in the menu.
•Select "OFF" when not in use.

GU Electronic
8. Mode Change
Mode Change Button for MALIBU
Return OEM dispaly
2second OEM dispaly
mode change(1 second)
•To use the Streeing button You must
select the “HOME" or “CONFIG” or “NAV”
button in the menu.
•Select "OFF" when not in use.
•Turn the button to show the oem screen
for 3 seconds

GU Electronic
8. Mode Change
Mode Change Button for ALPHEON/LACROSSE
Return OEM dispaly
2second OEM dispaly
mode change(1 second)
•To use the Streeing button You must
select the “HOME" or “CONFIG” or “NAV”
button in the menu.
•Select "OFF" when not in use.
•Turn the button to show the oem screen
for 3 seconds

GU Electronic
8. Mode Change
Mode Change Button for REGAL
Return OEM dispaly
2second OEM dispaly
mode change(1 second)
•To use the Streeing button You must
select the “HOME" or “CONFIG” or “NAV”
button in the menu.
•Select "OFF" when not in use.
•Turn the button to show the oem screen
for 3 seconds

GU Electronic
8. Mode Change
Mode Change Button for REGAL
Return OEM dispaly
2second OEM dispaly
mode change(1 second)
•To use the Streeing button You must
select the “HOME" or “CONFIG” or “NAV”
button in the menu.
•Select "OFF" when not in use.
•Turn the button to show the oem screen
for 3 seconds

GU Electronic
9. Touch Control
Press and hold for more than 11 seconds on
NAVI, DVB-T, DVD screen.
(Note that it only works the first time after
switching screens)
+ Touch according to the shape coordinates
.
OR
OSD menu -> Utility -> Calibration
Touch control - Calibration

GU Electronic
9. Touch Control
DVB-T/DVD Control
Press Icon
DVB-T DVD

GU Electronic
10. OSD(On Screen Display) Control
OSD control
Mode State
First Menu Second Menu Third Menu
MENU Press to display when there is no OSD
screen.
When OSD screen is on, press it to EXIT or
OFF.
SEL Item Selection, Value Selection
UP Item up
Increase selected value
DOWN Item down
Decrease selected value
MENU SEL UP DOWN
