Guardsman G1510 Install guide

Cx4
DOG GUARD
FITTING INSTRUCTION
HUNDESCHUTZGITTER
EINBAUANLEITUNG
PROTECTION CONTRE LES CHIENS
INSTRUCTIONS DE MONTAGE
HUNDEGITTER
MONTERINGSVEJLEDNING
CONJUNTO PROTECTOR
PARA PERROS
INSTRUCCIONES DE MONTAJE
subject to alteration without notice - technische anderungen vorbehalten - sous reserves de modifications techniques - reservadas modificaciones tecnicas - med forbehold for tekniske - con riserva di apportare modifiche techniche - tekniske forendringer voorbeholdes - technische wijzigingen voorbehouden - med reservation for tekniska andringar - tekniset muutokser pidatetaan
1 2
3
Mazda Cx-5
2017 Onwards
G1510
BR/H
only
4
Ex1
C
LEAVE
LOOSE
E 1
A
Gx2
Fx2
@376mm
Bx1 L/H Bx1 R/H
G1510 is1 - 7/18 is 2 1/20
www.guardsmandogguards.co.uk
KIT
2
BL/H
Fix the Right Hand Side Arm (B) to the Dog Guard.
Use the allen Key (E) with Bolts (C). Do Not Fully tighten
Manouvre the Dog Guard into the correct position behind
the rear seats
Position the Left Hand Side Arm on the outside of the
Dog Guard.
Insert the Dog Guard Right Side first then manouvre the
left hand side in. The mesh goes to the back of the car
OKaNOKr
SEATS FULLY BACK
SITZT VOLLSTÄNDIG
ZURÜCK

7
6c
RH&LH
E
RH&LH
G
TIGHTEN
a
6
F
6a
6b
5
C
LEAVE
LOOSE
Partially secure with the Handwheels (G) to hold the Dog
Guard in place. If You are fitting a Boot Divider do it now.
Make sure the Dog Guard is centred and tighten the side
arms.
Finally tighten the Handwheels (G) evenly both sides
Position the Left Hand Side Arm (B) on the outside of the
Dog Guard - Fix with the Bolts (C). Do not fully tighten
Take the securing Bar F and put it through the tubular guide in the lower rail of the Dog Guard.
Then hook the securing Bar under the Child Seat Tether
subject to alteration without notice - technische anderungen vorbehalten - sous reserves de modifications techniques - reservadas modificaciones tecnicas - med forbehold for tekniske - con riserva di apportare modifiche techniche - tekniske forendringer voorbeholdes - technische wijzigingen voorbehouden - med reservation for tekniska andringar - tekniset muutokser pidatetaan
G1510 is1 - 7/18 is 2 1/20

1
9
4
7
2
KIT
6
D x2
C x2A B x2
2x
8
2x
3
A
5
C
a
D
B x 2
CAN ONLY BE USED IN
CONJUNCTION WITH
GUARDSMAN
Mazda Cx-5
(2017 onwards)
Dog Guard
part number. G1510
Nur mit Hundegitter Guardsman
Mazda Cx-5
(Teilenummer G1510)
kompatibel.
subject to alteration without notice
G1510D v1 - 12/18
Variable Boot Divider
Kofferraum-Trenngitter
www.guardsmandogguards.co.uk
[email protected]
Mazda CX-5
(2017 onwards)
G1510D
B x 2
! LOOSEN FIXINGS !
! Befestigungen lösen !
! TIGHTEN FIXINGS !
! Befestigung anziehen !
