Gullberg & Jansson Nova Comfort User manual

Rev. 2016.1
Assembly manual
POOL ENCLOSURES
NOVA COMFORT
& STELLA COMFORT

2
Model Outside dimensions Weight
Name Type Glazing Width Height Depth kg
Nova Comfort 3x6 A3
TH*
4750 1350 410 245
Nova Comfort 3x7,5 A3/4 4750 1350 410 320
Nova Comfort 3,5x7 A4S 5250 1350 410 310
Nova Comfort 3,5x8,5 A4L 5250 1350 410 340
Nova Comfort 4x8 A4 5950 1350 410 400
Nova Comfort 4x10 A4/5 5950 1350 410 475
Nova Comfort 5x10 A5 6550 1350 500 590
Nova Comfort 3x6 A3
CL**
4750 1350 410 310
Nova Comfort 3x7,5 A3/4 4750 1350 410 400
Nova Comfort 3,5x7 A4S 5250 1350 410 410
Nova Comfort 3,5x8,5 A4L 5250 1350 410 430
Nova Comfort 4x8 A4 5950 1350 410 450
Nova Comfort 4x10 A4/5 5950 1350 410 550
Nova Comfort 5x10 A5 6550 1350 500 760
*TH: PC Thermo = double walled polycarbonate sheet
**CL: PC Clear = solid, transparent polycarbonate sheet
Model Outside dimensions Weight
Name Type Glazing Width Height Depth kg
Stella Comfort 3x6 M3
TH*
5250 1350 410 310
Stella Comfort 4x8 M4 6700 1840 410 510
Stella Comfort 4x10 M4/5 6700 1840 410 630
Stella Comfort 5x10 M5 6500 2000 540 750
Stella Comfort 3x6 M3
CL**
5250 1350 410 350
Stella Comfort 4x8 M4 6700 1840 410 540
Stella Comfort 4x10 M4/5 6700 1840 410 660
Stella Comfort 5x10 M5 6500 2000 540 860
BOX DISASSEMBLY

3
5
2
4
6
1
BOX DISASSEMBLY

Part list
No. Name Type
1 4,8x50 pen head TRX screw 71300
2a Wedge + 4,2x10 pen head TRX screw 71349
2b TRX screw 71385
3 Pop rivet 12 mm 71302
4a Square lock 71372
4b  71372
4c plug 71373
5 6x60 pen head TRX screw 71364
6 Anchor 71365
7a Interior handle 71320
7b 4,8x25 pen head TRX screw 71327
7c Washer 71363
7d Screw cap 71321
8a Handle 71318
8b Washer 71363
8c 4,8x50 pen head TRX screw 71300
8d Screw cap 71319
9 
10a  
10b M6 nut 71382
10c Washer 71363
10d M6x8 pen head screw 71379
10e M6x35 pen head screw 71378
10f Lock pin 71370
11  
12a Rocker Lever 71375
12b M6x35 pen head screw 71378
12c M6 nut 71382
12d Sleeve 71374
13 Latch Sleeve 71312
14a Rail join comfort 71371
14b  
14 c  71381
14d 6x60 pen head TRX screw 71364
14e Anchor 6x60 71365
15 Sliding door lock 71331
15b Sliding door key 71310
16  71325
16b  71324
17  71317
17b Screw 71326
17c Plug anodized 71315
18  
18b Screw 71380
19  
20  
21 Sliding door bottom rubber 71329
22  71323
PART LIST

5
1
567
8 9 10
11 12 13 14
15
19
T1 T2 T3
4.1 mm 3.5 mm 7 mm TRX 25 TRX 20
T4 T5 T6 T7 T8 T9
16
20 21 22
17 18
2 4
3
a
a
a
a
a
a
a
b
a
A5
a
f
b
b
A5 M5
 
b
c
d
b
c
b
cd
b
c
c
d
a
b
d
e
c

a
b
c
b
4,8x25 pen
head TRX screw
4,8x50 pen head TRX screw
Washer
Washer
Washer
M6x8 pen
head screw
6x60 pen head
TRX screw
4,8x22
 M6x20 pen head
Anchor
M6x35 pen head screw Lock pin
M6 nut
Screw cap
Screw cap
c
M6x35 pen head screw
M6 nut
Sleeve
4,8x50 pen head
TRX screw
Handle 
L-R Hidden arrest L-R

 Rocker lever Latch sleeve 
Sliding door lock + key
Sliding door frame
rubber seal

Rubber seal between
segments Sliding door bottom rubber 

plastic plug + screw 
Wedge + 4,2x10 pen head
TRX screw
Square lock

Pop rivet
12 mm
 plates
6x60 pen head
TRX screw Anchor Interior handle
PART LIST
or or

1
6
1.1
1.3
1.5
1.2
1.4
1.6
BOX DISASSEMBLY

1
7
1.7
1.9
1.11
1.8
1.10
1.12
BOX DISASSEMBLY


8
4
5
6
2a
3
1a
2b
2c 1b
4
5
6
2a
3
1a
2b
2c
1b
7
4
5
6
2a
3
1a
2b
2c 1b
78
1a+1c
1a+1c
1b+1d
1b+1d

Nr. Item name Item
number Pcs 
1a Rail S3/3 4 2
1b Rail S4/3 2 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 1 4
6 3. segment 1 4

Nr. Item name Item nr. Pcs 
1a Rail S1/2 4 2
1b Rail S3/2 4 2
1c Rail S1/2s 2 2
1d Rail S3/2s 2 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 14
6 3. segment 14
7 4. segment 14

Nr. Item name Item
number Pcs 
1a Rail S1/3 6 2
1b Rail S7/3 6 2
1c Rail S1/2s 4 2
1d Rail S7/2s 4 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 14
6 3. segment 14
7 4. segment 14
8 5. segment 14


9
4
5
6
2
3
1a + 1c
1b + 1d
7
4
5
6
2
3
1a + 1c
1b + 1d
7
8
4
5
6
2
3
1a + 1c
1b + 1d
78
9
1a
1b

Nr. Item name Item
number Pcs 
1a Rail S3/3 4 2
1b Rail S4/3 2 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 1 4
6 3. segment 1 4

Nr. Item name Item
number Pcs 
1a Rail S3/3 4 2
1b Rail S4/3 2 2
2 Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 1 4
6 3. segment 1 4
7 Side mounted
sliding door 1 6

Nr. Item name Item nr. Pcs 
1a Rail S1/2 4 2
1b Rail S3/2 4 2
1c Rail S1/2s 2 2
1d Rail S3/2s 2 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 14
6 3. segment 14
7 4. segment 14

Nr. Item name
Item
number

Item
number
A4S
Item
number
A4L
Item
number
A4
Pcs 
1a Rail S1/2 S1/2 S1/2 S1/2 4 2
1b Rail S5/2 S6/2 S2/2 S3/2 4 2
1c Rail S1/2s S1/2s S1/2s S1/2s 2 2
1d Rail S5/2s S6/2s S2/2s S3/2s 2 2
2 Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 1 4
6 3. segment 1 4
7 4. segment 1 4
8 Sliding door 1 6

Nr. Item name Item
number Pcs 
1a Rail S1/3 6 2
1b Rail S7/3 6 2
1c Rail S1/2s 4 2
1d Rail S7/2s 4 2
2a Front wall 1 8
2b Front wall 1 8
2c Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 14
6 3. segment 14
7 4. segment 14
8 5. segment 14

Nr. Item name Item
number Pcs 
1a Rail S1/3 6 2
1b Rail S7/3 6 2
1c Rail S1/2s 4 2
1d Rail S7/2s 4 2
2 Front wall 1 8
3 End wall 1 8
4 1. segment 1 3
5 2. segment 1 4
6 3. segment 1 4
7 4. segment 1 4
8 5. segment 1 4
9 Side mounted
sliding door 1 6


10
2
S4/3
S3/3
6700
4160
3784
2300
2100
2300
M3
A3
3 784
188
4 160
6 700
100 812 812 812 812 812 812 812 812 100
12
1883784188
7695
7695
218001
S/3 S/3
Item Nr. Item name Pcs Notes
S3/3 Rail 4 2300 mm
S4/3 Rail 2 2100 mm
5 Pen head screw 36 6x60
6 Anchor 36
14a Rail joiner 12
Suggested spots for holes on the rail
(depending on the ground surface)
Rail placement
RAIL ASSEMBLY

2
11
S1/2
S1/2s
S5/2
S5/2s
3784
4296
8200
3200
3200
1800
3 784
4296
8 200
100 889 889 889 889 889 889 889 889 889 100
9031
9031
2563784256
12
100 889
256
S/2s S/2S/2sS/2
A3/4
RAIL ASSEMBLY
Item Nr. Item name Pcs Notes
S1/2 Rail 4 3200 mm
S1/2s Rail 4 3200 mm
S5/2 Rail 2 1800 mm
S5/2s Rail 2 1800 mm
5 Pen head Screw 60 6x60
6 Anchor 60
14a Rail joiner 16
Suggested spots for holes on the rail
(depending on the ground surface)
11

12
2
A4S
S1/2
S1/2s
S6/2
S6/2s
7700
4796
4284
3200
13003200
7 700
4 284 4 796
100 833 833 833 833 833 833 833 833 833 100
2564284256
12
100 833
256
8812
8812
S/2s S/2S/2sS/2
Item Nr. Item name Pcs Notes
S1/2 Rail 4 3200 mm
S1/2s Rail 4 3200 mm
S6/2 Rail 2 1300 mm
S6/2s Rail 2 1300 mm
5 Pen head Screw 60 6x60
6 Anchor 60
14a Rail joiner 16
Suggested spots for holes on the rail
(depending on the ground surface)
rail placement
RAIL ASSEMBLY

2
13
A4L
S1/2
S1/2s
S2/2
S2/2s
9200
4796
4284
3200
28003200
9 200
4 284 4 796
2564284256
12
100 818
256
10148
10148
100 818 818 818 818 818 818 818 818 818 818 818 100
S/2s S/2S/2sS/2
Item Nr. Item name Pcs Notes
S1/2 Rail 4 3200 mm
S1/2s Rail 4 3200 mm
S2/2 Rail 2 2800 mm
S2/2s Rail 2 2800 mm
5 Pen head Screw 72 6x60
6 Anchor 72
14a Rail joiner 16
Suggested spots for holes on the rail
(depending on the ground surface)
rail placement
RAIL ASSEMBLY

14
2
A4
S1/2
S1/2s
S3/2
S3/2s
8700
5302
4790
3200
23003200
M4
8 700
4 790 5 302
9932
9932
100 850 850 850 850 850 850 850 850 850 850 100
2564790256
12
100 850
256
S/2s S/2S/2sS/2
Rail placement
Suggested spots for holes on the rail
(depending on the ground surface)
Item Nr. Item name Pcs Notes
S1/2 Rail 4 3200 mm
S1/2s Rail 4 3200 mm
S3/2 Rail 2 2300 mm
S3/2s Rail 2 2300 mm
5 Pen head screw 66 6x60
6 Anchor 66
14a Rail joiner 16
RAIL ASSEMBLY

2
15
S1/3
S1/2s
S7/3
S7/2s
5440
10700
3200
3200
3200
1100
4790
S1/3
A4/5
10 700
5 440
100 875
100 875 875 875 875 875 875 875 875 875 875 875 875 100
11 723
11 723
4 790
12
3255746325
325
S/2s S/3S/2sS/3
M4/5
Rail placement
Item Nr. Item name Pcs Notes
S1/3 Rail 6 3200 mm
S1/2s Rail 6 3200 mm
S7/3 Rail 2 1100 mm
S7/2s Rail 2 1100 mm
5 Pen head screw 104 6x60
6 Anchor 104
14a Rail joiner 30
Suggested spots for holes on the rail
(depending on the ground surface)
RAIL ASSEMBLY

16
2
A5
S1/3
S1/2s
S7/3
S7/2s
6396
10700
3200
3200
3200
1
100
5746
M5
5 746
10 700
6 396
12 145
12 145
100 875 875 875 875 875 875 875 875 875 875 875 875 100
12
3255746325
100 875
325
S/3S/2sS/2sS/3
Rail placement
Item Nr. Item name Pcs Notes
S1/3 Rail 6 3200 mm
S1/2s Rail 6 3200 mm
S7/3 Rail 2 1100 mm
S7/2s Rail 2 1100 mm
5 Pen head screw 104 6x60
6 Anchor 104
14a Rail joiner 30
RAIL ASSEMBLY
Suggested spots for holes on the rail
(depending on the ground surface)

2
17
2.1
2.3 2.4
2.5 2.6
2.2
14a
17
RAIL ASSEMBLY
Hammer
Hammer drill Measuring tape 
driver 

18
2
2.7 2.8
2.9
2.11 2.12
2.10
6 mm 10 mm
7 mm
7 mm
RAIL ASSEMBLY

2
19
2.13
2.15 2.16
2.17
2.14
6
6 mm
10 mm
10 mm
19
RAIL ASSEMBLY

20
2
2.192.18
2.20 2.21
5
TRX 25
TRXTRX
RAIL ASSEMBLY
