It comprises a section of WATER-STOP waterproofing membrane, factory-sealed to
a special adapter to connect to a low profile floor gully and a stainless steel shower
drain and grill.
• TECHNICAL, AESTHETIC AND PRACTICAL EVOLUTION
Separate installation of the drain body and the waterproof membrane, which is easier and
more practical.
Push fit, flexible connections with elastic uncoupling: no gluing needed
The floor gully is easy to adjust and align with the flooring because of the flexibility of the
connections
Minimum installation height of 90 mm including the flooring of 9 mm total thickness with
adhesive.
Dripping holes for secondary drainage with backflow preventer system
The water seal can be eliminated.
Accepts large-format floor coverings with 1 or 2 slopes to the linear drainage.
Different grill installation positions possible.
• Sideways, away from the wall.
• Traditional central installation with 4-way slope.
• Completely flush to the wall with 1 or 3 slopes (with the PERFIL LATERAL
optional accessory).
DESCRIPTION

5
• WATERPROOFING
In the EVOLUX system LINEAR KIT;
2 x 2 m (4 m²) WATER-STOP membrane with the connector in lateral position centred
widthways and 25 cm from the edge.
In the EVOLUX BASE set (depending on model);
BASE 3: 1.5 x 2 m (3 m²) WATER-STOP membrane with the connector centred at
widthways and at 2/3 lengthways (66 cm from the nearest end).
BASE 4: 2 x 2 m (4 m²) WATER-STOP membrane with the connector in lateral position
centred widthways and 25 cm from the edge.
• DRAIN
The EVOLUX BASE set doesn’t include drain extension and cover. It must be
completed with the EVOLUX shower drain and grill, which can be chosen among
the different models available.
Drain bodies and grills of AISI 304 stainless steel 1.5 mm thick. Measures and designs
depending on model.
» Linear drains 69 mm width with internal slopes and 53 mm wide grid defining a
slot of 6 mm oneach side for water drainage. Available in 6 sizes: 60 / 70 / 80 / 90
/ 100 and 120 cm long.
» A traditional square shape for central draining with 4-way slope. The exterior
dimensions of thedrain tray are 11.6 x 11.6 cm, with internal slopes and a 10 x 10
cm grill defining a 6 mm-wideperimeter drainage slot. The INTEGRA model accepts
a standard 10 x 10 tile insert.
» A smart, modern rectangular shape for central draining with 4-way slope or for
an unconventional3-way slope when installed flush to the wall using the PERFIL
LATERAL accessory. The exteriordimensions of the drain tray are 15 x 30 cm, with
internal slopes and a 13.4 x 28.4 cm grill defining a 6 mm-wide perimeter drainage
slot.
5 models of shower grating designs available:
DESCRIPTION
• LISA - With satin finish and plain design.
• PLUS - With satin finish and laser-cut
patterned.
• LISA DARK - with black finish plain
design.
• PLUS DARK - with satin finish and laser-
cut patterned.
• MICRO-CEMENT with microcement
finish design.
• TEMPERED GLASS - with tempered
glass finish design.
• INTEGRA - With a section designed
to accept a piece of the same material
as the surroundingflooring and comes
with special accessories that with a few
simple steps in the installation, makeit a
hidden drain.
• PRINTED - with costumized design
include it in the grid.

6
• DRAINAGE
Low profile trapped floor gully which complies to EN 1253, parts 1 and 2
Side outlet with DN/OD 50 connector. It can be angled through 360º
50 mm-high water seal (can be eliminated).
Reducer: DN 50/40
Push fit connections with O-rings and sliding joints; not gluing.
Drain body and connector: ABS ; Reducer: PP; Joints: EPDM
Flow rate from 0.4 l/s to 0.65 l/s depending on model.
• ACCESSORIES FOR INSTALLATION AND MAINTENANCE
Installation cap to protect the drain and mark the suitable screed level.
Template to use when installing with a very low flooring pavement or the INTEGRA
system.
2 sealing reinforcement for interior corners W-S DIN.
2 sealing reinforcement for shower inlet pipes W-S TUBO.
Hair trap.
DESCRIPTION

7
WITH BASE 3 m2WITH BASE 4 m2
1,2 m
0,9 m
1,4 m
1,2 m
1,2 m
0,9 m
1,6 m
1,2 m
1 m
1,75 m
1,8 m
0,9 m
2 m
2 m
2 m
1,5 m
NEW FORMATS
• MORE SHOWER CONFIGURATION OPTIONS

8
Prepare the shower area
•Decide on the height or depth required to ensure at least 1.5 % gradient towards the
drain. At the drain point, a minimum base thickness of 110 mm is required (including
3 to 25 mm tile thickness with adhesive). Install the siphon body
Warning: Before starting the installation it is very important to check if you need
a trapped drain.
The system main body is designed as a trapped drain but the water seal can
be left out to avoid the risk of clogging for double-trapping when installed
with an external drum trap: just remove the tubular piece (1) and then open
the bottom part of the outlet pipe (2). This is a section made with breaking line
that can be easily broken using a screwdriver or similar (3).
1 2 3
You cannot remove the water seal after the installation nor replace it. It is advisable to keep
the drain trapped and connect directly to the waste pipe without going through an external
trap.
•Install the floor gully body and position the outlet to allow connection to the waste
pipe.
•Check that the outlet has the necessary gradient (minimum 1.5 %) towards the waste
pipe.
•Connect the floor gully outlet to the drain pipe. If needed use the reducer 50/40
supplied. Lubricate the joint with soapy water, introduce the drain pipe and slide up
to the limit.
INSTALLATION
• GENERAL INSTALLATION PROCEDURE FOR THE EVOLUX SYSTEM

9
4. Cut to size (remember to leave 10 cm on
each side to seal wall and floor joints).
5. Connect the membrane by introducing
the adapter into the floor gully and press
down until it pushes home.
6. Fix the membrane with C2 tile adhesive
to the cement base which must be clean
and dry and shower drain.
2. Pour cement screed up to the level
indicated on the protective cap.*
3. Once the cement base has set remove
the protective cap, unroll and position the
WATER-STOP membrane
1
2
3
4
5
6
*To make up for the height when installing a very thin flooring as mosaic glass tiles,
microcement or other (less than 7 mm total flooring depth) and for installing EVOLUX
INTEGRA System, you must use the TEMPLATE provided. To do this, follow the instructions
in the relevant sections later.
INSTALLATION
Make up the cement screed base
1. Cover the floor gully mouth with the cap
supplied.

10
Position the shower drain
• If necessary, prepare the drain by assembling the PERFIL LATERAL accessory.
• Lay a piece of the flooring to set a reference height for the installation.
• Lubricate the shower drain outlet with soapy water and slide into the connector.
•Apply a small amount of C2 class tile adhesive to each side to help seat the shower
channel andpress together.
•Level, align and adjust the height according to floor thickness so that the upper edge
is flush tothe flooring.
Position the flooring
• Cement directly to the WATER-STOP membrane using C2 tile adhesive.
•Seal the joint between the flooring and the shower channel edge with W-S MASTIC or
similar and position the grill.
INSTALLATION
Reducer 50/40
1.5% mín.
1.5% mín.
C2 class tile adhesive
Flooring
W-S MASTIC
Adapter
Trapped body with water seal
WATER -STOP membrane
Slab
50 mm
Waste pipe
78 mm
90 mm
Sloped cement screed
Shower channel
and grill
EVOLUX System installation example with 9 mm flooring thickness
• EVOLUX INSTALLATION DIAGRAM

11
Make up the cement screed base
1. Pour the cement up to the level marked
on the protective cover, embedding the
floor gully.
3. Once the base has set, remove the
drain protection cover and the installation
template.
4. Connect the membrane to the floor
gully as indicated in the general procedure
and apply class C2 tile adhesive under
the membrane in the hollow left by the
template, then bond the membrane by
pressing to fit the shape.
5. Bond the waterproof membrane over
the rest of the surface as indicated in the
general procedure and then set the the
shower channel.
2. Position the installation template in the
cap. To install the template in linear drains,
the wings must be assembled on the
central section and adjusted to the size of
the channel by cutting each wing along the
corresponding dotted line.
1
3
2
The template is the right size for 120 cm
channel. To adjust to the size of the channel
being installed, the wings must be cut
symmetrically. Follow the cutting lines to
adjust for 100, 90, 80, 70 and 60 channels.
Align the template according to where
the drain will be and pour cement screed
up to the top ofthe template, forming the
necessary slope or slopes.
4
5
INSTALLATION
• INSTALLATION WITH TEMPLATE

12
Prepare the shower area.
1. Proceed as indicated in point 1 of the
general procedure, but remember that the
drain point needs a minimum height of
90 mm plus the thickness of the flooring
material and adhesive.
ACCESSORIES
4. Proceed to level, align and adjust the
height so the membrane is flush.
2. Proceed as indicated in point 2 of the
general procedure. Make up the cement
screed base using the TEMPLATE and
install the waterproof barrier. Proceed as
indicated in the previous section for using
the template.
3
2
3. Position shower drain. Prepare the drain
body by assembling the PERFIL LATERAL
accessory as dripping edges.
4
1
Installation TEMPLATE (according to the model)
PERFIL LATERAL
SPACERS
5. Cut the facing piece to size to cover the
grill, making sure there are no sharp edges.
Cut the facing according to model:
•Square drain models must respect the
perimeter slot and the facing piece
must measure100 x 100 mm for the
square form and 134 x 284 mm for the
rectangular form.
•The facing piece for linear drain
models must measure 52 mm wide
and be as long as the grill, depending
on model.
• INTEGRA SYSTEM INSTALLATION
INSTALLATION
5

13
6. Place the cover plate frame in the shower
channel and offer up, without bonding, the
facing piece.
8. Apply a thin line of W-S MASTIC or similar
alongside the dripping flanges and begin
laying the flooring directly on the waterproof
membrane using C2 tile adhesive.
7. Insert the spacers each side in the slots
in the channel to ensure there is adequate
gap fordrainage and to set the starting
point for laying the flooring.
9. Apply adhesive to the rough face of the
grill frame and bond the facing material,
ensuring it iscentred using the spacers. The
grill must lay flush with the flooring, which
is achieved by adjusting the depth of the
adhesive. The same tile adhesive can be
used as that used to lay the shower flooring.
7
8
9
INSTALLATION
6
Reducer 50/40
1.5% mín.
1.5% mín.
C2 class tile adhesive
Flooring
W-S MASTIC
Adapter
Trapped body with water seal
WATER -STOP membrane
Slab
50 mm
Waste pipe
78 mm
90 mm
Sloped cement screed
Shower channel
and cover
EVOLUX INTEGRA System installation example with 9 mm flooring thickness
• EVOLUX INTEGRA INSTALLATION DIAGRAM

14
INSTALLATION
Detail of INTEGRA EVOLUX SYSTEM. Content according model.

15
The outlet pipe must have a gradient of at least 1.5% towards the drain (a 1.5 to 2 cm
drop every metre). The length of this section must not exceed 1 metre.
The flooring must be flush with the grill so when installing the drain body, ensure that its
height allows the flooring to be installed later.
The nominal flow rate at 3 bars of pressure for most domestic shower heads is between
9 and 20 litres/minute (between 0.15 and 0.35 l/s). Shower drains must have a minimum
capacity of 0.40 l/s (24 litres/minute) for a single shower head. These values do not
apply to multi-jet showers or where multiple showers are installed with a single drain.
The stated minimum installation height is the minimum possible for the floor gully
dimensions. Each installation will require a real minimum height that allows the outlet
pipe to have the required gradient towards the main drain, plus the thickness of flooring
and adhesive.
TO ADAPT THE POSITION OF THE DRAIN: if the position of the drain needs to
be moved, leading to an overlap of membrane on one side and a gap on the other,
the membrane can be cut (always bearing in mind the minimum required 10 cm
overlap at the wall) and stuck back to cover the gap, respecting the 5 to 10 cm
overlap required for joints, and ensuring that the proud edge is facing downstream
from the water flow.
TO COMPLETE THE WATERPROOF MEMBRANE: bear in mind that to ensure
complete waterproofing, the walls must be sealed as well as the floor, with the
membrane installed to a height of 2 m.
As a minimum we recommend sealing the walls around the inlet and outlet
plumbing by 10 cm above the height of the plumbing and down to the floor.
TO BOND OVERLAPS: in showers and small indoor surfaces which will not be
at risk of flooding, C2 tile adhesive can be used. If water tightness is required, the
overlaps can be sealed using a mastic sealant as W-S MASTIC or W-S BUTIL
double-sided tape.
TO BOND WATER-STOP TO THE SURFACE: on concrete, brick or render use
C2 tile adhesive. For other surfaces such as plaster, old tiles and others, ensure
the adhesive is appropriate for use with the base and follow the manufacturer’s
instructions.
TO BOND FLOORING MATERIAL TO WATER-STOP: on tiled floors use C2
tile adhesive. For other surfaces such as wood, textile, vinyl and others, uses an
appropriate adhesive for the material and for use in wet conditions and follow the
manufacturer’s instructions.
RECOMENDATIONS

16
PRODUCT DATA SHEET
ESTIL GURÚ S.L.U. P.I. El Pla Carrer dels telers, 22 - Apdo. 584
46870 ONTINYENT · Valencia · España
www.estilguru.com [email protected]
Tel. [phone] Fax. [phone]
Flow rate *1 Article 5.9.1 Article 4.8 *1 > 0,5 l/s *1
Depth of water seal Article 5.3.1 Article 4.1.5 50 mm
Resistance of water seal to pressure Article 5.3.2 Article 4.1.6 > 400 Pa
Self-cleansing capacity Article 5.4.2 Article 4.2.2 Pass
Blockage prevention Article 5.4.3 Article 4.2.3 Pass
Thermal behaviour Article 5.5 Article 4.5 Clase A
Watertightness for bodies Article 5.8.2 Article 4.6.2 Pass
Watertightness for extensions Article 5.8.2 Article 4.6.3 Pass
Odour-tightness Article 5.8.1 Article 4.6.1 Pass
Watertightness of floor gully used with membrane
(vacuum test) Article 5.8.3 Article 4.7.3.4 Pass
Mechanical strength of the factory fixed membrane
attachement Article 5.7.3 Article 4.7.3.4 > 100N
Loading strength Article 5.6 Article 4.7.1 Clase K3
Apertures in gratings (dimensions) Article 5.1 Art. 4.1.3 < 8 mm
Appearance - Art. 4.1.2 Pass
Materials - Art. 4.4 Pass
EVOLUX SYSTEM
Description: Trapped oor gully with factory-sealed integrated waterproong comprising a section of WATER-STOP membrane.
Use: the construction of tiled showers for domestic or public use.
Normative References: UNE EN 1253-1:2015
Manufacturer: Estil Gurú S.L.U. Factory Code: 310-G
Drain and channel trays / grates (lenght x width x
height) Stainless Steel
AISI 304
60/70/80/90/100/120/150/180
x 6,9 x 1
11,6 x 11,6 x 1 15 x 30 x 1
cm
Lateral dripping flanges (for INTEGRA) Width: 16 mm
Coupling flange/connector
ABS
DN/DI 50 mm
Main drain body Height 78 mm
Reducer PP DN 50/40 mm
Nominal size - Side outlet connection
DN/ID 50
Waterproof membrane*2 WATER-STOP 2 x 2 = (4 m²) / 1,5 x 2 = (3 m²) m
O rings / Sliding joints SBR / NBR --
1
PRODUCT DATA SHEET
CHARACTERISTICS METHOD REQUIREMENTS VALUE
UNE EN 1253-1 UNE EN 1253-1
SYSTEM COMPONENTS COMPOSITION DIMENSIONS UNIT

17
Estil Gurú S.L.U. as manufacture of waterproofing systems, guarantees the quality
and performance of its products.
The drain used in the EVOLUX system complies with EN 1253 parts 1 and 2 as it
relates to the Declaration of product compliance.
The WATER-STOP barrier used on the EVOLUX system has EC compliance with
EN 13956:2013 and has minimum VOC (Volatile Organic Compound) emission
level.
The WATER-STOP barrier is appropriate for use in waterproofing floors where
water drainage is installed and holds Technical Approval (Avis Téchnique) nº 13/14-
1258 issued by the French Notified Body CSTB.
Waterproofing systems using the WATER-STOP barrier are backed by a 10 year
guarantee.
All accrediting documentation, certificates and declarations are available for
download in the downloads section at www.estilguru.com or may be requested
by e-mail from our customer service department at:
customer.assistance@estilguru. com
WARRANTY

Pol. Industrial El Pla, Carrer dels Telers, 22
Tel.: [phone]
www.estilguru.com
