GRA-430 Assembly Manual
GRA-430
The GRA-430 rack mount is suited for use with the APS-7300 AC power sources.
Only one power source can be used with the GRA-430 rack adapter. The
GRA-430 will accommodate a 9U-sized rack.
Rack Mount Adapter Component List
Description
Please check to make sure all the components of the
GRA-430 rack mount kit are provided.
Item
Part NO.
Description
QTY
1
594B-W4012NS1
SCREW BMS, 4*12, ISO, N (WASHER
P.S) , RoHS
6
2
62RA-430HP101
GRA-430 9U LEFT
BRACKET ,RoHS
1
3
62RA-430HP201
GRA-430 9U RIGHT
BRACKET ,RoHS
1

GRA-430 Assembly Manual
3
Assembly
Initial setup
1. Remove the four wheel casters from the APS-7300 as
shown in the below diagram.

Specification
4
2. Remove the six screws located on each side panel of the
APS-7300 as shown in the below diagram.
3. Screw the left bracket (62RA-430HP101) to the left side
panels of the APS-7300 and right bracket
(62RA-430HP201) to the right side panel of the APS-7300
using the six (594B-W4012NS1) screws as shown in the
below diagram.
1
3
2

GRA-430 Assembly Manual
5
Specification
Rack Dimensions
APS-7300
