GW Instek GPM-8310 User manual

Digital Power Meter
GPM-8310
USER MANUAL
Rev. A
ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

TABLE OF CONTENTS
3
Table of Contents
SAFETY INSTRUCTIONS .................................................. 5
GETTING STARTED........................................................ 10
Characteristics ..........................................11
Appearance ...............................................16
Set Up.......................................................25
BASIC SETTING ............................................................. 28
Setting up measurement range .................29
Setting up measurement status ................33
Setting up System status ..........................72
MEASUREMENT AND OTHER FUNCTIONS .................... 81
Measurement function ..............................82
Other functions ........................................88
Integration measurement function............91
Graph measurement function .................103
DIGITAL I/O / DA4 .......................................................121
Digital I/O / DA4 Overview .....................122
External Remote Control .........................124
DA4 Output Function ..............................125
User / 4094 Mode ...................................130
REMOTE CONTROL ......................................................136
Configure Remote Control Interface ........137
Configure EOL Character ........................144
Return to Local Control ...........................144
COMMAND OVERVIEW ................................................145
Command Syntax ....................................145

GPM-8310 User Manual
4
Command List ........................................149
APPENDIX ....................................................................228
Specifications .........................................229
Status system .........................................239
Dimensions ............................................243
Declaration of Conformity .......................244
Power measurement ...............................245
Introduction to IEC-62301.......................247
EUP Directive Lot6 specifications ...........248
Connection Guide ...................................249

SAFETY INSTRUCTIONS
5
SAFETY INSTRUCTIONS
This chapter contains important safety
instructions that you must follow during
operation and storage. Read the following before
any operation to ensure your safety and to keep
the instrument in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the
instrument.
WARNING
Warning: Identifies conditions or practices that
could result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that
could result in damage to the GPM-8310
or to other properties.
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal

GPM-8310 User Manual
6
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased.

SAFETY INSTRUCTIONS
7
Safety Guidelines
General Guideline
CAUTION
Make sure that the voltage input level does not
exceed AC600V.
Make sure the current input level does not
exceed 20A.
Do not place any heavy object on the
instrument.
Avoid severe impact or rough handling that can
lead to damaging the instrument.
Do not discharge static electricity to the
instrument.
Use only mating connectors, not bare wires, for
the terminals.
Do not block or obstruct the cooling fan vent
opening.
Do not perform measurement at the source of a
low-voltage installation or at building
installations (Note below).
Do not disassemble the instrument unless you
are qualified as service personnel.
Make sure that the COM terminal to earth is
limited to 600Vpk.
Remove all test leads before disconnecting the
mains power cord from the socket.
If the equipment is used in a manner not
specified by the manufacturer, the protection
provided by the equipment may be impaired.
The device should be placed in a place where
the plug connected to it can be removed easily.

GPM-8310 User Manual
8
(Note) EN 61010-1:2010 specifies the measurement categories and
their requirements as follows. The GPM-8310 falls under category II
600V.
Measurement category IV is for measurement performed at the
source of low-voltage installation.
Measurement category III is for measurement performed in the
building installation.
Measurement category II is for measurement performed on the
circuits directly connected to the low voltage installation.
Power Supply
WARNING
AC Input voltage: 100-240 VAC 50/60Hz
The power supply voltage should not fluctuate
more than 10%.
Connect the protective grounding conductor of
the AC power cord to an earth ground, to avoid
electrical shock.
If grounding practice is not well implemented, a
certain amounts of noises will be generated
when connecting to GPM-001, the handy
measurement accessory for GPM-8310.
Cleaning the
Instrument
Disconnect the power cord before cleaning.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid.
Do not use chemicals containing harsh material
such as benzene, toluene, xylene, and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free,
almost non-conductive pollution (Note below)
Temperature: 0°C to 40°C
Humidity: < 30°C: < 80%RH(non-condensing);
30°C~40°C:<70%RH(non-condensing);
>40°C: <50%RH (non-condensing)
Altitude: <2000m
Overvoltage category: OVC II

SAFETY INSTRUCTIONS
9
(Note) EN 61010-1:2010 specifies the pollution degrees and their
requirements as follows. The GPM-8310 falls under degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of
dielectric strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive
pollution occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution
occurs. Occasionally, however, a temporary conductivity caused
by condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-
conductive pollution occurs which becomes conductive due to
condensation which is expected. In such conditions, equipment
is normally protected against exposure to direct sunlight,
precipitation, and full wind pressure, but neither temperature
nor humidity is controlled.
Storage
environment
Location: Indoor
Temperature: -40°C to 70°C
Humidity: <90%RH(non-condensing)
Disposal
Do not dispose this instrument as unsorted
municipal waste. Please use a separate collection
facility or contact the supplier from which this
instrument was purchased. Please make sure
discarded electrical waste is properly recycled to
reduce environmental impact.

GPM-8310 User Manual
10
GETTING STARTED
This chapter describes the GPM-8310 in a nutshell,
including accessories, package contents, its main
features and front / rear panel introduction.
Characteristics ................................................................11
Accessories .............................................................................................. 14
Package Contents .................................................................................... 15
Appearance.....................................................................16
Front Panel ..............................................................................................16
Main Display Overview ...........................................................................19
Rear Panel................................................................................................ 22
Set Up ............................................................................25
Tilting the Stand ...................................................................................... 25
Power Up .................................................................................................26
Connect the wires to the GPM-8310....................................................... 27

GETTING STARTED
11
Characteristics
The GPM-8310 is a high-precision, programmable power meter for
using in standby measuring the device with low power such as
switching power supplies, transformers, power supplies, adapter
and other devices. It equips with a color TFT-LCD screen and also
multiple graph displays which are very convenient for reading the
measurement results. The GPM-8310 has become a reliable power
measurement instruments because of its simple operation, excellent
performance, user-friendly graph displays and automatic
measurement interface.
Operation
Press the buttons on the front panel to easily
turn on the GPM-8310 measurement function.
All settings and measurements results are
displayed on the 5-inches TFT-LCD screen panel
for easy use of each function.
Standard display mode: 2 main measurement
results and 8 secondary measurement results are
displayed in this screen.
Simple display mode: 4 major measurement
results are displayed in this screen.

GPM-8310 User Manual
12
Performance
6 selectable voltage ranges available from 15V to
600V with 0.1% of reading + 0.05% of range.
12 selectable current ranges available from 5mA
to 20A with 0.1% of reading + 0.05% of range.
It can even measure the voltage of abnormal
wave of CF 3. The half-range CF is up to 6 or 6A.
It can even measure the current of abnormal
wave of CF 3. The half-range CF is up to 6 or 6A.
Total harmonic distortion measurement.
50-orders harmonic test and analysis function.
Graph display for measurement results
including harmonic orders distribution.
Plug-in USB disk data store function including
log and screenshot.
Auto range function for integration measurement.

GETTING STARTED
13
Features
Full five-digit measurement.
Voltage measurement range: 15V ~ 600V or
automatic switching
Current measurement range: 5mA ~ 20A or
automatic switching
Maximum accuracy of 0.1% of reading + 0.05%
of range
2 main measurement readings and 8 minor
measurement readings are displayed in the
screen of standard display mode.
4 main measurement readings are displayed in
the screen of simple display mode.
Added stand-alone display of total harmonic
distortion measurement function (50 steps)
Test bandwidth of voltage and current: DC ~
100kHz.
Selectable boot settings (Previous / Default)
Waveform display up to 10kHz along with
Harmonic bar and list table
Interface
Standard interface: USB / RS232 / LAN / GPIB
Optional interface: Digital IO / DA4
Application
It can be applied to production test such as
power supplies, transformers, motors, electrical
equipment and other equipment with low standby
power.
It can be applied to power measurement
conforms to IEC 62301
It can be applied to assess the power
consumption of product design.

GPM-8310 User Manual
14
Accessories
Standard Accessories
Part number
Description
82PM-83100E01
User Manual CD
82GW1SAFE0M01
Safety Instruction Sheet
Region dependent
Power Cord
GTL-209
Test leads: 1x red, 1x black
GTL-212
Test leads: 1x yellow, 1x blue
Optional Accessories
Part number
Description
GPM-001
Test Fixture
GTL-234
RS232C cable
GTL-246
USB cable
GTL-248
GPIB cable
GCP-300
Current Probe
GRA-422
Rack Adapter Panel (19”, 2U)
Option
Name
Description
Opt.01
DA4 (Factory installed)

GETTING STARTED
15
Package Contents
Check the contents before using the instrument.
Opening the box
Contents
(single unit)
Main unit
Test leads (red x1,
black x1, yellow x1,
blue x1)
Power cord x1 (region
dependent)
User manual CD
Safety instruction
sheet

GPM-8310 User Manual
16
Appearance
Front Panel
Digital Power Meter
POWER
V-Range
MAX Hold
Mode Setup Hold
I-Range
Start Stop Reset
Local
Trigger ESC
INTEGRATOR
Enter
Key Lock
Hardcopy
GPM -8310
: Long Push
LCD Display Function Keys
Enter
Key
Soft
keys Arrow Keys Trigger Key ESC Key
Power
key USB Host Port
Hardcopy Key
Power Key
Turns On or Off the main
power. For the power up sequence,
see page 26.
USB Host Port
Connects with USB flash drive for
data storage or screenshot.
Hardcopy Key
Captures the current screenshot or
saves the data log for reading. For
details, refer to page 67.

GETTING STARTED
17
Function Keys
V-Range key, up/down arrow keys
and Enter key can be used together
to select a voltage range or auto
range measurement mode. Also,
press and hold the V-Range key to
toggle between manual and auto
range setting. See page 29.
I-Range key, up/down arrow keys
and Enter key can be used together
to select a current range or auto
range measurement mode. Also,
press and hold the I-Range key to
toggle between manual and auto
range setting. See page 29.
Press this button to display the
maximum measurement reading.
See page 89.
Press this key to select measure
mode (DC/AC/AC+DC/V-MEAN).
See page 90.
Press this key to enter the
measurement settings menu. See
page 33.
Press this key to switch window and
stop refreshing. See page 89.
Use the left and right
arrow keys to select
Integrator mode, and
press Enter button to
enter the time integrator
function. See page 91.

GPM-8310 User Manual
18
Press this key to toggle to key lock. In
Remote control mode, press this button
to switch to local mode. See page 90.
Enter Key
This button is used to enter the menu,
confirm the settings and switch
between the standard display mode
and simple display mode (no function
table and display icon). See page 89.
Trigger key
Activates the Trigger function. See
page 89.
ESC Key
Press this button to cancel the
current setting. The cursor returns to
the default position or return to the
previous menu according to the
situation. See page 90.
Arrow Keys
This four arrow keys are
used to edit the parameters,
browse the menu system and
select the parameter range.
Soft Keys
The 5 soft keys have varied functions
from the OSD (On-Screen Display)
options, individually, per different
settings. In addition, from the main
display, the 5 soft keys act like
shortcuts leading to the 5 secondary
menus, for which refer to the page 21.
The mapping sequence is from top to
bottom of soft keys corresponding to
from left to right of secondary menus.
For instance, the top soft key enables
shortcut to the far left secondary
menu (Enlarge) directly.

GETTING STARTED
19
Main Display Overview
Current Range
Voltage Range Mode Update Rate CF
VT
Remote
CT SF
Max. Hold
Average
Key Lock
Sync
Source External
Display Hold
Peak Voltage
Peak Current
Harmonic
Calculation
Measure
Storage
Frequency
Filter
Remote Error
Secondary Menus
Minor
Measurement
Display
Line Filter
Main
Measurement
Display
Item
Status icon
Description
Voltage Range
V-Range 15V
Voltage measurement range.
Example here range is 15V.
V-Auto means that Voltage Auto
Range is turned on.
Current Range
I-Range 5A
Current measurement range.
Example here range is 5A.
I-Auto means that Current Auto
Range is turned on.
Mode
AC+DC
Measurement mode
(AC, DC, AC+DC, V-MEAN)
Date Update
Rate
Update 0.1s
Data update rate
(0.1/0.25/0.5/1/2/5/10/20/Auto)
Crest Factor
CF3
Crest Factor (3/6/6A)

GPM-8310 User Manual
20
VT Ratio State
VT
External voltage magnification
(On/Off)
CT Ratio State
CT
External current magnification
(On/Off)
Power Ratio
State
SF
External power magnification
(On/Off)
Remote
RMT
Remote control mode (On/Off)
Line Filter
L.F
Voltage and current filters (On/Off)
Frequency Filter
F.F
Frequency filters (On/Off)
Maximum Hold
MAX Hold
Retain and display the maximum
measurement reading.
Average
AVG-8
Average number of sampling
(8/16/32/64)
Sync Source
SYNC.V
Synchronization source (V/I/Off)
Keyboard Lock
Key Lock
Lock Key button
Harmonic
Calculation
HRM.I
Harmonic calculation method
(IEC/CSA/Off)
Measure Storage
STORE
Measured date storage (On/Off)
External Input
EXT1
External signal input function
(Ext1/Ext2/Off)
Display Hold
Hold
Retain and display the current
measurement reading.
Peak Voltage
P.V
The voltage exceeds the
measurement range
Peak Current
P.I
The current exceeds the
measurement range
Remote Error
Error-XXX
An error occurs in remote
command
