GW Instek DAQ-9600 User manual

Data Acquisition System
DAQ-9600
USER MANUAL
ISO-9001 CERTIFIED MANUFACTURER
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

This manual contains proprietary information, which is protected by
copyrights. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
right to change specifications, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan (R.O.C.).
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

Table of Contents
3
Table of Contents
SAFETY INSTRUCTIONS ....................................................5
Safety Symbols............................................................................5
Safety Guidelines ........................................................................6
GETTING STARTED ..........................................................10
Characteristics ............................................................................11
Front Panel Overview..................................................................13
Rear Panel Overview ...................................................................17
Status Bar ...................................................................................19
Set Up .........................................................................................22
MODULE OVERVIEW .......................................................24
Modules List ...............................................................................25
Module Installation ....................................................................26
Module Uninstallation ................................................................27
Modules Introduction .................................................................27
OPERATION MENUS.........................................................33
Home Mode................................................................................34
Monitor Mode.............................................................................38
Scan Mode ..................................................................................48
CONFIGURATION MENUS...................................................51
Channel Menu ............................................................................52
Switch Mode for Channels..........................................................86
Computer Channels ....................................................................88
Interval Menu .............................................................................92
Edit Menu ....................................................................................95
Alarm Menu ................................................................................98
View Menu ..................................................................................101
Module Menu .............................................................................112
Math Menu .................................................................................114
Average Menu .............................................................................129
Log Menu....................................................................................131
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

DAQ-9600 Series User Manual
4
DIGITAL I/O ...................................................................134
Digital I/O Overview .................................................................. 135
Application: Alarm Output......................................................... 137
Application: External Trigger ...................................................... 139
SYSTEM & FIRMWARE ...................................................140
View System Info ....................................................................... 141
Firmware Update ....................................................................... 142
MENU SETTING .............................................................144
Configure System ....................................................................... 145
Configure Display ...................................................................... 165
REMOTE CONTROL .......................................................178
Configure Interface .................................................................... 179
Web Control Interface ................................................................ 206
Command Syntax ....................................................................... 210
Command Set ............................................................................ 213
Status system ............................................................................ 330
APPENDIX ......................................................................335
Fuse Replacement ...................................................................... 336
Battery Replacement .................................................................. 337
Factory Default Parameters........................................................ 339
Specifications ............................................................................ 341
DAQ-9600 Section ..................................................................... 342
Declaration of Conformity.......................................................... 356
INDEX ............................................................................357
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

SAFETY INSTRUCTIONS
5
SAFETY INSTRUCTIONS
This chapter contains important safety instructions that
you must follow when operating the DAQ-9600 and
when keeping it in storage. Read the following before any
operation to insure your safety and to keep the
DAQ-9600 in the best possible condition.
Safety Symbols
These safety symbols may appear in this manual or on the DAQ-9600.
WARNING
Warning: Identifies conditions or practices that could
result in injury or loss of life.
CAUTION
Caution: Identifies conditions or practices that could
result in damage to the DAQ-9600 or to other property.
DANGER High Voltage
Attention Refer to the Manual
Protective Conductor Terminal
Earth (ground) Terminal
Do not dispose electronic equipment as unsorted
municipal waste. Please use a separate collection facility
or contact the supplier from which this instrument was
purchased.
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

DAQ-9600 Series User Manual
6
Safety Guidelines
General Guideline
CAUTION
Make sure that the measurement voltage input level
does not exceed DC600V/AC400V.
Do not place any heavy object on the instrument.
Avoid severe impact or rough handling that can lead to
damaging the instrument.
Do not discharge static electricity to the instrument.
Use only mating connectors, not bare wires, for the
terminals.
Do not block or obstruct the cooling fan vent opening.
Do not perform measurement at the source of a
low-voltage installation or at building installations
(Note below).
Do not disassemble the instrument unless you are
qualified as service personnel.
(Note) EN 61010-2-030 specifies the measurement categories and
their requirements as follows.
Measurement category IV is for measurement performed at the source
of low-voltage installation.
Measurement category III is for measurement performed in the
building installation.
Measurement category II is for measurement performed on the circuits
directly connected to the low voltage installation.
Do NOT to use the equipment for measurements on
MAINS.
Do NOT to use the equipment for measurements on
circuits which with a TRANSIENT OVERVOLTAGE
over 1500 V.
Measuring circuits without a MEASUREMENT
CATEGORY: Measuring circuits are not intended to
be directly connected to the MAINS.
Measurement category of the instrument is rated as
without a MEASUREMENT CATEGORY.
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

SAFETY INSTRUCTIONS
7
The transient overvoltage may be present on the
measuring circuits. Refer to the table below for the
transient overvotlage on general mains circuits.
Voltage line to neutral
derived from nominal
voltages AC or DC up to
and including
Rated impulse withstand voltage
Overvoltage Category
I
II
III
IV
V
V
V
V
V
50
330
500
800
1500
100
500
800
1500
2500
150
800
1500
2500
4000
300
1500
2500
4000
6000
600
2500
4000
6000
8000
1000
4000
6000
8000
12000
1250
4000
6000
8000
12000
1500
6000
8000
10000
15000
Power Supply
WARNING
AC Input voltage: 100/120/220/240 V AC ±10%,
50Hz / 60Hz
The power supply voltage should not fluctuate more
than 10%.
Connect the protective grounding conductor of the AC
power cord to an earth ground, to avoid electrical shock.
Power Cord
Requirement
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment
may be impaired. Do NOT replace the detachable
MAINS supply cords by inadequately RATED cords.
Suitable supply cord set for use with the equipment:
Mains plug: Shall be national approval
Mains connector: C13 type
Cable:
1. Length of power supply cord: less than 3 m
2. Cross-section of conductors: at least 0.75 mm2
3. Cord type shall meet the requirements of IEC
60227 or IEC 60245 (e.g.: H05VV-F, H05RN-F)
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

DAQ-9600 Series User Manual
8
Fuse
WARNING
Fuse type: T0.125A 100/120 VAC
T0.125A 220/240 VAC
Make sure the correct type of fuse is installed before
power up.
To avoid risk of fire, replace the fuse only with the
specified type and rating.
Disconnect the power cord before fuse replacement.
Make sure the cause of a fuse blowout is fixed before
fuse replacement.
Cleaning the
Instrument
Disconnect the power cord before cleaning.
Use a soft cloth dampened in a solution of mild
detergent and water. Do not spray any liquid into the
DAQ-9600.
Do not use chemicals or cleaners containing harsh
material such as benzene, toluene, xylene, and acetone.
Operation
Environment
Location: Indoor, no direct sunlight, dust free, almost
non-conductive pollution (Note below)
Temperature: Full accuracy for 0°C to 55°C.
Humidity:
< 30°C: < 80%RH (non-condensing)
30°C~40°C: <70%RH (non-condensing)
>40°C: <50%RH (non-condensing)
Altitude: <2000m
(Note) EN 61010-1 specifies the pollution degrees and their
requirements as follows. The DAQ-9600 falls under degree 2.
Pollution refers to “addition of foreign matter, solid, liquid, or
gaseous (ionized gases), that may produce a reduction of dielectric
strength or surface resistivity”.
Pollution degree 1: No pollution or only dry, non-conductive pollution
occurs. The pollution has no influence.
Pollution degree 2: Normally only non-conductive pollution occurs.
Occasionally, however, a temporary conductivity caused by
condensation must be expected.
Pollution degree 3: Conductive pollution occurs, or dry, non-conductive
pollution occurs which becomes conductive due to condensation which
is expected. In such conditions, equipment is normally protected
against exposure to direct sunlight, precipitation, and full wind pressure,
but neither temperature nor humidity is controlled.
Storage
Environment
Location: Indoor
Temperature: −40°C to 70°C
Humidity: <90%RH(non-condensing)
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

SAFETY INSTRUCTIONS
9
Disposal
Do not dispose this instrument as unsorted municipal
waste. Please use a separate collection facility or contact
the supplier from which this instrument was purchased.
Please make sure discarded electrical waste is properly
recycled to reduce environmental impact.
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

DAQ-9600 Series User Manual
10
GETTING STARTED
This chapter describes the DAQ-9600 in a nutshell,
including an Overview of its main features and front /
rear panel introduction. After going through the
Overview, follow the Power-up sequence to properly
setup the DAQ-9600.
Please note the information in this manual was correct at
the time of printing. However as GW Instek continues to
improve its products, changes can occur at any time
without notice. Please see the GW Instek website for the
latest information and content.
Home
Monitor Scan
Interval
Menu Lock Local
LogAverage
Math
Channel Edit
ModuleViewAlarm
Enter
Auto
ON / STBY
Data Acquisition System
: Long Push
ESC
0/
123
456
789
Characteristics ........................................................................... 11
Accessories ............................................................................... 12
Front Panel Overview ................................................................. 13
Rear Panel Overview .................................................................. 17
Status Bar .................................................................................. 19
Set Up ........................................................................................ 22
Horizontal/Tilt/Vertical Applications ........................................ 22
Power Up .................................................................................. 23
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

GETTING STARTED
11
Characteristics
The DAQ-9600 is a portable, dual-display digital
multimeter suitable for a wide range of applications, such
as production testing, research, and field verification.
Performance
The highest DCV accuracy: 35ppm
The highest current:2A
The highest voltage: 600VDC,400VAC
The highest ACV frequency response: 300 kHz
The fastest sampling rate: 38.4K Readings /sec
Internal memory:100k read memory
Data Logging to USB
Features
3-Slot mainframe with built-in 6½ digit DMM
Multi functions: ACV, DCV, ACI, DCI, 2W/4W R, Hz,
Temp, Strain, Diode, Period, Capacitance test, REL,
dBm, Hold, MX+B, 1/X, REF%, dB, Compare and
Statistics.
Manual or Auto ranging
AC true RMS
Up to 3 temerature measurements:
RTD, Thermistor and Thermocouples (Built-in
Cold-Junction Compensation)
Graph Display: BarMeter, TrendChart, Histogram
Interface
USB device/LAN for remote control /
GPIB(factory install)
9-pin Digital I/O port
USB device port supports USBCDC and USBTMC
USB Host
Software
DAQ-Data Logger
ES France - Département Tests & Mesures
127 rue de Buzenval BP 26 - 92380 Garches
Tél. [phone]
Fax. [phone]
e-mail : [email protected]
Site Web : www.es-france.com

DAQ-9600 Series User Manual
12
Accessories
Standard
Accessories
Part number
Description
82xx-xxxxxxxx
Safety Instruction Sheet
Optional
Accessories
Part number
Description
GTL-246
USB Cable, USB 2.0, A-B type, 1200mm
GTL-258
Mini GPIB Cable, approx. 1.9m
GRA-422
Rack Mount Kit (19” 2U)
GRA-436
Rack Mount Kit (19”, 2U)
for two sets
