GW Instek PSP-603 User manual

PSP-603/ 405/ 2010
PSP
603/ 405/ 2010
Verification/ Adjustment Manual

Table of Contents
3
Table of Contents
How to Use this Manual................................................ 4
Specification............................................................... 5
Front Panel................................................................. 6
Performance Verification .............................................. 7
Overall Procedure ............................................................. 7
Verification Equipment ...................................................... 7
Output Voltage Verification ................................................ 8
Output Current Verification ................................................ 9
Current Load Regulation Verification ................................. 10
Voltage Load Regulation Verification.................................. 12
Ripple Voltage Verification ............................................... 14
Recording Table.............................................................. 16
Adjustment ...............................................................17
Overall Procedure ........................................................... 17
Adjustment Equipment.................................................... 17
Opening the Case ........................................................... 18
Adjustment Point............................................................ 18
Output Voltage Adjustment.............................................. 19
Output Current Adjustment ............................................. 20
PSP Verification/ Adjustment Manual
4
How to Use this Manual
This manual describes how to verify and adjust the performance of PSP-603/
405/ 2010 Programmable Switching D.C. Power Supplies.
Specification, page5, shows PSP electronic and mechanical specifications.
It also shows the locations of relevant verification and adjustment
procedures in this manual.
Front Panel, page6, describes the front panel switches, terminals, and
indicators. The Default Settings column shows the basic panel settings
applicable to all verification and adjustment items.
Performance Verification, page7, shows how to verify PSP performance,
step by step. Check the necessary equipment and the overall procedure
before start working on each item.
Adjustment, page17, shows how to adjust PSP specification. Same as
Performance Verification, check the equipment and the overall procedure
before start working on each item.

Specification
5
Specification
Output Verification Adjustment
PSP-603 PSP-405 PSP-2010
Voltage 0 ~ 60V 0 ~ 40V 0 ~ 20V Page8 Page19
Current 0 ~ 3.5A 0 ~ 5A 0 ~ 10A Page9 Page20
Voltage Regulation Verification Adjustment
Load ≤10mV Page12 —
Line ≤0.05% — —
Current Regulation Verification Adjustment
Load ≤5mA Page10 —
Line ≤0.05% — —
Ripple Verification Adjustment
Voltage ≤20mVrms Page14 —
Current ≤10mArms — —
Resolution Verification Adjustment
Voltage 20mV (PSP-603)
10mV (PSP-405/ PSP-2010) — —
Current 2mA (PSP-603/ PSP-405)
5mA (PSP-2010) — —
Program Accuracy Verification Adjustment
Voltage ≤0.05% rdg + 20mV — Page19
Current ≤0.1% rdg + 5 digits (PSP-603/ PSP-405)
≤0.3% rdg + 10 digits (PSP-2010) — Page20
Readback (METER) Resolution Verification Adjustment
Voltage 20mV (PSP-603)
10mV (PSP-405/ PSP-2010) — —
Current 2mA (PSP-603/ PSP-405)
5mA (PSP-2010) — —
Readback (METER) Accuracy Verification Adjustment
Voltage ≤0.05% rdg + 20mV — —
Current ≤0.1% rdg + 5 digits (PSP-603/ PSP-405)
≤0.3% rdg + 10 digits (PSP-2010) — —
Protection Verification Adjustment
OVP/ OCP/ OPP/ OTP — —
Power Source Verification Adjustment
AC 115V ±10%/ 230V ±15%, 50/ 60Hz — —
Dimensions & Weight Verification Adjustment
225(W) x 100(H) x 305(D) mm, 4kg — —
Others Verification Adjustment
Output ON/OFF Control, RS-232C Interface, LCD Display — —
PSP Verification/ Adjustment Manual
6
Front Panel
V SET REM LOCK
%%
POWER
OUTPUT
CE N F
I LIMITP LIMIT
ENTER
V LIMIT
OUTPUT
0 60V 0 3.5A
PSP-603 Programmable
Power Supply
V LIMIT key
Sets the Output
Voltage limit
Power Switch
ENTER key
Completes
entering the value
- Output Terminal
P LIMIT key
Sets the Output
Power limit
Ground
Terminal
OUTPUT key
Turns the Output
ON/OFF
+ Output Terminal
I LIMIT key
Sets the Output
Current limit
LCD Display
CE key
Erases previously
entered value V SET key
Sets the Output
Voltage value
+ % key
Increases the
Output by a
predefined value
REM key
Allows remote
controlling PSP
NORMAL key
Turns OFF the
effect of + % and
- %key
N key
Changes the
parameter in
coarse mode Scroll Wheel
Adjusts the
parameters
F key
Changes the
parameter in fine
mode
- %key
Decreases the
Output by a
predefined value
LOCK key
Locks the front
panel operation

Performance Verification
7
Performance Verification
Overall Procedure
1. Prepare the Equipment according to the following table.
2. Verify a specification item and record the result (page8 to
page14). The
Recording Table is at the end of this chapter
(page16).
3. Repeat step 2 for all items.
4. In case of over- or under-specification, continue with the
relevant item in the
Adjustment chapter (page17).
Verification Equipment
Equipment Required Specification Used in Recommended
Model
Digital
Multimeter
•AC & DC Voltage
Accuracy: < ±0.1%
•DC Current Range: > 10A
•DC Current Accuracy:
<±0.1%
All items •GDM-8245
•GDM-8246
Electronic Load
•DC Voltage Range: > 60V
•DC Current Range: > 10A
•CV, CC, CR Mode
•Short Mode
•Current Load
Regulation
•Voltage Load
Regulation
•Ripple Voltage
•Agilent
N3305A
AC Power
Supply
•Capacity: ≥1k VA
•Frequency: 50 – 60Hz
•Line Voltage: ±15%
•Ripple Voltage •APS-9102
•Agilent 6813B
PSP –
Multimeter
cable
•Voltage rating: > 60V
•Current rating: > 6A All items —
PSP –
Electronic Load
cable
•Voltage rating: > 60V
•Current rating: > 6A
•Current Load
Regulation
•Voltage Load
Regulation
•Ripple Voltage
—
Calculator •For calculating the
acceptance ranges All items —
PSP Verification/ Adjustment Manual
8
Output Voltage Verification
Here we verify the accuracy of Minimum and Maximum Output Voltage.
Connection
Digital Multimeter PSP
DC V
A
-+
Verification steps
1. Connect the Multimeter and turn ON the Output.
2. Set the Output Voltage to the minimum level.
3. Set the Output Current to the maximum level.
4. Record the difference between Multimeter and PST readout as
Minimum Output Voltage Accuracy.
5. Set the Output Voltage to the maximum level.
6. Record the difference between Multimeter and PST readout as
Maximum Output Voltage Accuracy.
Acceptance range
PSP-603 PSP-405 PSP-2010
Minimum Output
Voltage Accuracy ±10mV ±10mV ±10mV
Maximum Output
Voltage Accuracy ±10mV ±10mV ±10mV
When out of range…
Refer to
Output Voltage Adjustment , page19.

Performance Verification
9
Output Current Verification
Here we verify the accuracy of Minimum and Maximum Output Current.
Connection
Digital Multimeter PSP
V
DC A
-+
Verification steps
1. Connect the Multimeter and turn ON the Output.
2. Set the Output Current to the minimum level.
3. Set the Output Voltage to the maximum level.
4. Record the difference between Multimeter and PST readout as
Minimum Output Current Accuracy.
5. Set the Output Current to the maximum level.
6. Record the difference between Multimeter and PST readout as
Maximum Output Current Accuracy.
Acceptance range
PSP-603 PSP-405 PSP-2010
Minimum Output
Current Accuracy ±1mA ±1mA ±1mA
Maximum Output
Current Accuracy ±1mA ±1mA ±1mA
When out of range…
Refer to
Output Current Adjustment , page20.
PSP Verification/ Adjustment Manual
10
Current Load Regulation Verification
Here we verify the amount of Output Current change when the load
fluctuates.
Connection
Connect the Digital Multimeter in series with the Electronic Load
and PSP.
Digital Multimeter
Electronic Load
-+
V
DC A
PSP
-+
PSP & Electronic Load Settings
PSP-603 PSP-405 PSP-2010
60V, 3.5A 40V, 5A 20V, 10A

Performance Verification
11
Verification steps
1. Connect the Multimeter and Electronic Load and turn ON the
Output.
2. Set the Electronic Load level according to the Settings table on
the previous page and turn ON the load.
3. Set the PSP Output Voltage and Current according to the
Settings table on the previous page.
4. Record the Multimeter readout.
5. Short the Electronic Load.
6. Record the Multimeter readout.
7. Calculate the difference between the previous Multimeter
readout and record it as Current Load Regulation.
Acceptance range
PSP-603 PSP-405 PSP-2010
≤5mA ≤5mA ≤5mA
PSP Verification/ Adjustment Manual
12
Voltage Load Regulation Verification
Here we verify the amount of Output Voltage change when the load
fluctuates.
Connection
Electronic Load
-+
Digital Multimeter
DC V
A
PSP
-+
PSP & Electronic Load Settings
PSP-603 PSP-405 PSP-2010
60V, 3.5A 40V, 5A 20V, 10A

Performance Verification
13
Verification steps
1. Connect the Multimeter and Electronic Load and turn ON the
Output.
2. Set the Electronic Load level according to the Settings table on
the previous page and turn ON the load.
3. Set the PSP Output Voltage and Current according to the
Settings table on the previous page.
4. Record the Multimeter readout.
5. Turn OFF the Electronic Load.
6. Record the Multimeter readout.
7. Calculate the difference between the previous Multimeter
readout and record it as Voltage Load Regulation.
Acceptance range
PSP-603 PSP-405 PSP-2010
≤10mV ≤10mV ≤10mV
PSP Verification/ Adjustment Manual
14
Ripple Voltage Verification
Here we verify the amount of AC Ripple Voltage when the power source
fluctuates.
Connection
Electronic Load
-+
AC Power Supply
Digital Multimeter
AC V
A
PSP
-+
PSP & Electronic Load Settings
PSP-603 PSP-405 PSP-2010
60V, 3.5A 40V, 5A 20V, 10A
AC Power Supply Settings
230V rating 115V rating
−15%, 50Hz −10%, 50Hz
+15%, 50Hz +10%, 50Hz
−15%, 60Hz −10%, 60Hz
+15%, 60Hz +10%, 50Hz

Performance Verification
15
Verification steps
1. Connect the Multimeter and Electronic Load and turn ON the
Output.
2. Set the Electronic Load level according to the Settings table on
the previous page and turn ON the load.
3. Set the PSP Output Voltage and Current according to the
Settings table on the previous page.
4. Check the Power Supply Select Switch on the rear panel for
Power Supply Voltage Rating.
5. Set AC Power Supply Output to the top setting in the previous
page’s table.
6. Record the Multimeter readout (AC Voltage).
7. Repeat step 5 and 6 for the rest of the AC Power Supply
Output settings.
8. Pick up the largest value of the four as Ripple Voltage.
Acceptance range
PSP-603 PSP-405 PSP-2010
≤20mV ≤20mV ≤20mV
PSP Verification/ Adjustment Manual
16
Recording Table
PSP-603 PSP-405 PSP-2010
Multimeter PSP Multimeter
−PSP Pass/ Fail Note
Minimum
Output
Voltage VV
mV P F
Multimeter PSP Multimeter
−PSP Pass/ Fail Note
Maximum
Output
Voltage VV
mV P F
Multimeter PSP Multimeter
−PSP Pass/ Fail Note
Minimum
Output
Current VV
mV P F
Multimeter PSP Multimeter
−PSP Pass/ Fail Note
Maximum
Output
Current VV
mV P F
Multimeter
Load ON
Multimeter
Load Short
Load ON −
Short Pass/ Fail Note
Current
Load
Regulation VV
mV P F
Multimeter
Load ON
Multimeter
Load OFF
Load ON −
OFF Pass/ Fail Note
Voltage Load
Regulation VV
mV P F
AC Power Multimeter Largest Pass/ Fail Note
−15/10%,50Hz mV
+15/10%,50Hz mV
−15/10%,60Hz mV
Ripple
Voltage
+15/10%,60Hz mV
P F

Adjustment
17
Adjustment
Overall Procedure
1. Prepare the Equipment according to the following table.
2. Adjust the specifications according to your needs (page19 to
20).
3. When the adjustment is completed, run the
Performance
Verification
again to verify the result (page7).
Adjustment Equipment
Equipment Required Specification Used in Recommended
Model
Digital
Multimeter
•AC & DC Voltage
Accuracy: < ±0.1%
•DC Current Range: ≥6A
•DC Current Accuracy:
<±0.1%
All items •GDM-8245
•GDM-8246
PSP –
Multimeter
cable
•Voltage rating: > 60V
•Current rating: > 6A All items —
Flathead Screw
Driver Small
•1.5mm
•For adjustment All items —
Phillips Screw
Driver Large
•3mm/ 4mm
•For opening the case All items —
PSP Verification/ Adjustment Manual
18
Opening the Case
1. Take off four screws, 3x6mm, on the side panels.
2. Take off two screws, 3x6mm, on the top of the rear panel.
3. Hold the case, slide it behind, and pull it off upward.
Adjustment Point
VR2
Rear
Panel
Front ->
Top View
VR1 VR3
VR4

Adjustment
19
Output Voltage Adjustment
Here we adjust the accuracy of Minimum and Maximum Output Voltage.
Connection
Digital Multimeter PSP
V
A
-+
Adjustment steps
1. Connect the Multimeter. Turn ON the Power key and VSET
key together and keep pressing VSET key.
2. The display will show (SAVE) message with a buzzer
sound.
3. Set the Output Voltage to the minimum level.
4. Set the Output Current to the maximum level.
5. Adjust VR2 to bring the Multimeter readout close to PSP. For
VR location, refer to page18.
6. Set the Output Voltage to the maximum level.
7. Adjust VR4 to bring the Multimeter readout close to PSP.
8. Press ENTER key to finish adjustment.
Acceptance Range
PSP-603 PSP-405 PSP-2010
Minimum Output
Voltage Accuracy ±10mV ±10mV ±10mV
Maximum Output
Voltage Accuracy ±10mV ±10mV ±10mV
PSP Verification/ Adjustment Manual
20
Output Current Adjustment
Here we adjust the accuracy of Minimum and Maximum Output Current.
Connection
Digital Multimeter PSP
V
A
-+
Adjustment steps
1. Connect the Multimeter. Turn ON the Power key and VSET
key together and keep pressing VSET key.
2. The display will show message with a buzzer sound.
3. Set the Output Voltage to the minimum level.
4. Set the Output Current to the maximum level.
5. Adjust VR1 to bring the Multimeter readout close to PSP. For
VR location, refer to page18.
6. Set the Output Voltage to the maximum level.
7. Adjust VR3 to bring the Multimeter readout close to PSP.
8. Press ENTER key to finish adjustment.
Acceptance Range
PSP-603 PSP-405 PSP-2010
Minimum Output
Current Accuracy ±1mA ±1mA ±1mA
Maximum Output
Current Accuracy ±1mA ±1mA ±1mA
