Häfele HC-IF60D User manual

1
USER
MANUAL
PRODUCTS NAME: HOB HC-IF60D
Products Applied: 536.01.911
EnglishVietnamese

2
DEAR CUSTOMER,
Important!
Your hob combines exceptional ease of use with excellent effectiveness. Once you have
read the instructions, operating your hob will not be a problem.
Before being packed and leaving the factory, the safety and functions of this hob were
carefully tested.
We ask you to read the User Manual carefully before switching on the appliance. Following
the directions in this manual will protect you from any misuse.
Keep this User Manual and store it near at hand.
The instructions should be followed carefully to avoid any unfortunate accidents.
The appliance may only be operated when you have read and understood this manu-
al thoroughly. The appliance is designed solely for cooking. Any other use (eg heating
a room) is incompatible with the appliance’s intended purpose and can pose a risk
to the user. The manufacturer reserves the right to introduce changes which do not
affect the operation of the appliance.
Certificate of compliance CE
The Manufacturer hereby declares that this product complies with the general require-
ments pursuant to the following European Directives:
 •TheLowVoltageDirective2014/35/EC,
• ElectromagneticCompatibilityDirective2014/30/EC,
• ErPDirective2009/125/EC,andthereforetheproducthasbeenmarkedwith
thesymbolandtheDeclarationofConformityhasbeenissuedtothemanufacturer
and is available to the competent authorities regulating the market.

3
CONTENTS
Basic Information
Safety instructions
Description of the appliance
Installation
Operation
Cleaningandmaintenance
Troubleshooting
............................................................................................2
...........................................................................................4
.............................................................................8
.....................................................................................................9
......................................................................................................12
...........................................................................22
............................................................................................24

4
SAFETY INSTRUCTIONS
Warning: Theapplianceanditsaccessiblepartsbecomehotduringuse.Careshouldbe
takentoavoidtouchingheatingelements.Childrenlessthan8yearsofageshallbekept
away unless continuously supervised. This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning
useoftheapplianceinasafewayandunderstandthehazardsinvolved.Childrenshall
notplaywiththeappliance.Cleaningandusermaintenanceshallnotbemadebychildren
without supervision.
Warning: Unattended cooking on a hob with fat or oil can be dangerous and may result in
fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover
flame e.g. with a lid or a fire blanket.
Warning: Danger of fire: do not store items on the cooking surfaces.
Warning: If the surface is cracked, switch off the appliance to avoid the possibillity of elec-
tric shock. Metallic objects, such as knives, forks, spoons and lids should not be placed on
the hob surface since they can get hot. After use, switch off the hob element by its control
and do not rely on the pan detector. The appliance is not intended to be operated by means
of an external timer or separate remote-control system. You should not use steam cleaning
devices to clean the appliance.

5
SAFETY INSTRUCTIONS FOR USE
••Beforeusingtheinductionhobforthefirsttime,carefullyreaditsusermanual.Thiswill
ensure user safety and prevent damage to the appliance.
••Iftheinductionhobisoperatedinimmediatevicinitytotheradio,televisionsetorother
radio-frequency-emitting device, make sure that the hob’s touch sensor controls op-
erate correctly.
••Thehobmustbeconnectedbyaqualifiedinstaller.
••Donotinstalltheapplianceneararefrigerator.
••Furniture,wherethehobisinstalledmustberesistanttotemperaturesupto100O•C.
This applies to veneers, edges, surfaces made of plastics, adhesives and paints.
••Theappliancemayonlybeusedoncefittedinkitchenfurniture.Thiswillprotectthe
user against accidental touching the live part.
••Repairstoelectricalappliancesmayonlybeconductedbyspecialists.Improperre-
pairs can be dangerous to the user.
••Theapplianceis not connected to mains when it is unplugged or the main circuit
breaker is switched off.
••Plugofthepowercordshouldbeaccessibleafterappliancehasbeeninstalled.
••Ensurethatchildrendonotplaywiththeappliance.
••Thisapplianceisnotintendedforusebypersons(includingchildren)withphysical,
mental or sensory handicaps, or by those who are inexperienced or unfamiliar with the
appliance, unless under supervision or in accordance with the instructions as commu-
nicated to them by persons responsible for their safety.
••Personswithimplanteddevices,whichsupportvitalfunctions(eg,pacemaker,insulin
pump, or hearing aids) must ensure that these devices are not affected by the induc-
tionhob(thefrequencyoftheinductionhobis20-50kHz).
••Oncepower isdisconnected all settingsand indications areerased. Whenelectric
powerisrestoredcautionisadvisable.Ifthecookingzonesarehot,•H”residualheat
indicator will be displayed. Also child lock key will be displayed, as when the appliance
is connected for the first time.
••Built-inresidualheatindicatorcanbeusedtodetermineiftheapplianceisonandifit
is still hot.
••Ifthemainssocketisnearthecookingzone,makesurethecorddoesnottouchany
hot areas.
••Whencookingusingoilandfatdonotleavetheapplianceunattended,asthereisa
fire hazard.
••Donotuseplasticcontainersandaluminiumfoil.Theymeltathightemperaturesand
may damage the cooking surface.

6
SAFETY INSTRUCTIONS FOR USE
••Solidorliquidsugar,citricacid,saltorplasticmustnotbeallowedtospillonthehot
cooking zone.
••Ifsugarorplasticaccidentallyfallonthehotcookingzone,donotturnoffthehoband
scrapethesugarorplasticoffwithasharpscraper.Protecthandsfromburnsand
injuries.
••Whencookingoninductionhobonlyusepotsandpanswithaflatbasehavingno
sharp edges or burrs as these can permanently scratch the cooking surface.
••Inductionhobcookingsurfaceisresistanttothermalshock.Itisnotsensitivetocold
nor hot.
••Avoiddroppingobjectsonthecookingsurface.Insomecircumstances,pointimpacts
such as dropping a bottle of spices, may lead to cracks and chipping of the cooking
surface.
••Ifanydamageoccurs,seethingfoodcangetintothelivepartsoftheinductionhob
through damaged areas.
••Ifthecookingsurfaceiscracked,switchoffpowertoavoidtheriskofelectricshock.
••Donotusethecookingsurfaceasacuttingboardorworktable.
••Donotplacemetalobjectssuchasknives,forks,spoons,lidsandaluminiumfoilon
the cooking surface as they could become hot.
••Donot install the hob over a heaterwithouta fan, over a dishwasher,refrigerator,
freezer or washing machine.
••Ifthehobhasbeenbuiltinthekitchenworktop,metalobjectslocatedinacabinetbe-
low can be heated to high temperatures through the air flowing from the hob ventilation
system. As a result, it is recommended to use a partition (see Figure 2).
••Pleasefollowtheinstructionsforcareandcleaningofinductionhob.Intheeventof
misuse or mishandling warranty may be void

7
HOW TO SAVE ELECTRICITY
UNPACKING
DISPOSAL
Using the electricity in a responsible manner not only saves money, but also helps protect
the environment. So let’s save electricity! This is how it’s done:
The appliance was protected from damage at the time of transport. After unpacking, please
dispose of all elements of packaging in a way that will not cause damage to the environ-
ment. All materials used for packaging the appliance are environmentally friendly; they are
100%recyclableandaremarkedwiththeappropriatesymbol.
This marking means that the appliance must not be disposed of together with other house-
hold waste after it has been used. The user is obliged to hand it over to waste collection
centre collecting used electrical and electronic goods.
The collectors, including local collection points, shops and local authority departments
providerecyclingschemes.Properhandlingofusedelectricalandelectronicgoodshelps
avoid environmental and health hazards resulting from the presence of dangerous compo-
nents and the inappropriate storage and processing of such goods
Important! Keep the packaging material (bags, Styrofoam pieces, etc.) out of reach of
children during unpacking.
InaccordancewithEuropeanDirective2012/19/UEandPolishlegislationregardingused
electrical and electronic goods, this appliance is marked with the symbol of the crossed-out
waste container.
•●Use the correct cookware
Cookwarewithflatandathickbasecansaveupto1/3ofelectricity.Pleaserememberto
cover cookware with the lid, otherwise electricity consumption increased four times!
•Always keep the cooking zones and cookware bases clean.
Dirt prevents proper heat transfer. Often burnt stains can be removed only with agents
harmful to the environment.
•●Avoiding unnecessary lifting the lid to peek into the pot.
•Do not install the hob in the immediate vicinity of refrigerator / freezer.
The electricity consumption is then unnecessarily increased.

8
DESCRIPTION OF THE APPLIANCE
1. ON/OFF
2. Individual Zone
3. SlidingControl
4. SlidingControlIndicator
5. TotalZone
6. Lock
7. PowerLevelDisplay
8. Timer Display
9. DoubleZoneIndicator
10. TimedZoneIndicator
11. Total Zone Indicator
12. Active Lock Indicator
13. TemperatureFunctions
14. TemperatureFunctionsIndicator
15. Less(Timer)
16. More (Timer)
17. Stand-alone Timer Indicator
Control Panel

9
INSTALLATION
Positioning
•the oven is equipped with an appropriate cooling system
•there is no warm
•air leakage from the oven towards the hob
•suitable air-inlets are provided as shown in the figure.
These instructions are to be used by the fitter as a guide to installation, setting and mainte-
nance in line with current regulations and standards. The appliance must be disconnected
from the mains before any work is carried out.
The fixture is especially designed for fitting into a work-top as shown in the corresponding
figure.Placethesuppliedsealingagentalongthehobperimeter.Donotinstallthehobover
an oven; in case you do, make sure of the following:
Do not install the hob above the oven without ventilation.

10
INSTALLATION
Installing hob
••Usinganelectricalcord,connectthehobaccordingtoelectricaldiagramprovided.
••Removedustfromtheworktop,inserthobintotheopeningandpressinfirmly
1 - Worktop
2-Hobflangegasket
3-Ceramichob
1 2 3

11
INSTALLATION
Electrical connection
Warning!
All electrical work should be carried out by a suitably qualified and authorised electrician.
No alterations or wilful changes in the electricity supply should be carried out.
Thehobismanufacturedtoworkwithaone-phasealternatingcurrent(230V1N~50Hz)
andisequippedwitha3x4mm2connectionlead.
The electricity supply for the hob must have a safety switch which enables the power to
be cut off in case of emergency. The distance between the working contacts of the safety
switchmustbeatleast3mm.
Before connecting the hob to the power supply it is important to read the information on
thedataplateandtheconnectiondiagram.Caution!Theinstallerisobligedtoprovidethe
userwith“applianceelectricalconnectioncertificate”(enclosedwiththewarrantycard).
Important! If the fixed power supply cable is damaged, it should be replaced at the manu-
facturer or at an authorized servicing outlet, or by a qualified person to avoid danger.
Connection diagram
Caution!Voltageofheatingelements230V.Caution!Intheeventofanyconnectionthe
safetywiremustbeconnectedtothePEterminal.

12
OPERATION
Before using the appliance for the first time
Induction cooking zone operation principle
Electric oscillator powers a coil placed inside the appliance. This coil produces a magnetic
field, which induces eddy currents in the cookware. These eddy currents induced by the
magnetic field cause the cookware to heat up.
This requires the use of pots and pans whose base is ferromagnetic, in other words sus-
ceptible to magnetic fields.
Overall, induction technology is characterized by two advantages:
Certainsoundscanbeheardduringnormaluseoftheinductionhob,whichdonotaffect
its correct operation.
The noises that can be heard during the normal appliance operation are the result of the
cooling fan operation, cooking method, cookware dimensions, cookware material and the
heat setting. These noises are normal and do not indicate a fault.
••thoroughlycleanyourinductionhobfirst.Theinductionhobshouldbetreatedwiththe
same care as a glass surface.
••switchontheventilationintheroomoropenawindow,astheappliancecouldemitan
unpleasant smell during first use.
••operatetheappliancewhileobservingallsafetyguidelines.
•the heat is only emitted by the cookware and its use is maximised,
•there is no thermal inertia, since the cooking starts immediately when the pot is placed
on the hob and ends once it is removed
••Low-frequencyhumming.Thisnoiseariseswhenthecookwareisemptyandstops
when water is poured or food is placed in the cookware.
••High-frequencywhizz.Thisnoisearisesincookwaremadeofmultiplelayersofdiffer-
ent materials at maximum heat setting. The noise intensifies when using two or more
cooking zones at maximum heat setting. The noise will stop or reduce when heat
setting is reduced.
••Creakingnoise.Thisnoisearisesincookwaremadeofmultiplelayersofdifferentma-
terials. The noise intensity depends on how the food is cooked.
••Buzzing.Buzzingcanbeheardwhenelectronicscoolingfanoperates.

13
OPERATION
Pan detector
Pandetectorisinstalledininductionhobs.Pandetectorstartsheatingautomaticallywhen
a pan is detected on a cooking zone and stops heating when it is removed. This helps save
electricity.
The induction hob is equipped with electronic touch control sensor fields, which are op-
erated by touching the marked area with a finger. Each time a sensor field is touched, an
acoustic signal can be heard.
•When a suitable pan is placed on a cooking zone, the display shows the heat setting.
••Inductionrequirestheuseofsuitablecookwarewithferromagneticbase(seeTable).
If a pan is not placed on a cooking zone or the pan is unsuitable, the symbol
isdisplayed.Thecookingzonewillnotoperate.Ifapanisnotdetectedwithin10
minutes, the cooking zone will be switched off. Switch off the cooking zone using the
touch control sensor field rather than by removing the pan.
When switching the appliance on or off or changing the heat setting, attention should
be paid that only one sensor field at a time is touched. When two or more sensor
fields are touched at the same time (except timer and child lock), the appliance ig-
nores the control signals and may trigger a fault indication if sensor fields are touched
for a long time. When you finish cooking switch off the cooking zone using touch
control sensor fields and do not rely solely on the pan detector.
Pan detector does not operate as the on/off sensor.
The protective device:
If the hob has been installed correctly and is used properly, any protective devices are rarely
required.
Fan: protects and cools controls and power components. It can operate at two different
speeds and is activated automatically. Fan runs until the electronic system has sufficiently
cooled down regardless of the appliance or the cooking zones being turned on or off.
Temperature sensor: Temperature of electronic circuits is continuously monitored by a
temperature sensor. If temperature is raised beyond a safe level, this protection system will
reduce cooking zone heat setting or shut down the cooking zones adjacent to the over-
heated electronic circuits.
Pan detection: allows the hob to detect pans placed on a cooking zone. Small objects
placed on the cooking zone (eg, spoon, knife, ring ...) will not be recognised as pans and
the hob will not operate.

14
OPERATION
The high-quality cookware is an essential condition for efficient induction
cooking.
Cookware characteristics
Select cookware for induction cooking
••Alwaysusehighqualitycookware,withperfectlyflatbase.Thispreventstheformation
oflocalhotspots,wherefoodmightstick.Potsandpanswiththicksteelwallsprovide
superior heat distribution.
••Makesurethatcookwarebaseisdry:whenfillingapotorwhenusingapottakenout
of the refrigerator make sure its base is completely dry before placing it on the cooking
zone. This is to avoid soiling the surface of the hob.
••Lidpreventsheatfromescapingandthusreducesheatingtimeandlowersenergy
consumption.
••Todetermineifcookwareissuitable,makesurethatitsbaseattractsamagnet.
•●Cookware base has to be flat for optimal temperature control by the induction
module.
•●The concave base or deep embossed logo of the manufacturer interfere with
the temperature induction control module and can cause overheating of the pot
or pan.
•●Do not use damaged cookware such as cookware with deformed base due to
excessive heat.
•When you use large ferromagnetic base cookware,
whose diameter is less than the total diameter of the
cookware, only the ferromagnetic base heats up.
This results in a situation where it is not possible to
uniformly distribute the heat in the cookware. If the
ferromagnetic area is reduced due to inclusion of al-
uminium parts, then the effective heated area can be
reduced.Problemswiththe detectionof thecook-
ware could arise or cookware may not be detected at
all. To achieve optimum cooking results, the diameter
of the ferromagnetic base should match that of the
cooking zone. If cookware is not detected in a giv-
en cooking zone, it is advisable to try it in a smaller
cooking zone.

15
OPERATION
Cookware size.
Marking of kitchen
cookware
Check for marking indicating that the
cookware is suitable for induction cooking.
Use magnetic cookware (enamelled steel, ferrite stainless
steel, cast iron). The easiest way to determine if your cook-
wareissuitableistoperformthe•magnettest”.Findagener-
ic magnet and check if it sticks to the base of the cookware.
Stainless Steel
Cookwareisnotdetected
With the exception of the ferromagnetic steel cookware
Aluminium Cookwareisnotdetected
Cast iron
Highefficiency
Caution:cookwarecanscratchthehobsurface
Enamelled steel
Highefficiency
Cookwarewithaflat,thickandsmoothbaseis
recommended
Glass Cookwareisnotdetected
Porcelain Cookwareisnotdetected
Cookware with copper
base Cookwareisnotdetected
•In order to achieve best cooking results, use cookware with bottoms (ferromagnetic
part) of the size corresponding to the size of the cooking zone.
••Usingcookwarewiththebottomdiametersmallerthanthecookingzonesizewillre-
duce the effectiveness of the cooking zone and increase cooking time.
••Cookingzoneshavealowerpotdetectionlimitthatdependsonthediameteroffer-
romagnetic part of the pot bottom and the pot material. The use of an unsuitable pot
might lead to pot being undetected by a cooking zone.
•enamelled steel
••castiron
••specialstainlesssteelcookwaredesignedforinductioncooking.
For induction cooking us only ferromagnetic base materials such as:

16
OPERATION
Control Panel
Switching the Touch Control on/off
Automatic off
Switching a cooking zone on/off
After mains voltage is applied, the touch control initialises for approximately one second
before it is ready for use. All displays and LEDs flash for approximately one second after
resetting. Once this period is complete, all displays and LEDs switch off and the touch
control is in standby mode
PresstheON/OFF(1)buttontoswitchthetouchcontrolonfor1second.TheSlidingCon-
trolIndicator(4)flashesforallcookingzoneswhileawaitingtheselectionoftherequired
function.Ifanycookingzone“burns”(hightemperature),indicator(7)appearswithaflash-
ing“H”.
Afterswitchingthetouchcontrolon,itwillremainactivefor20seconds.Ifneitheracooking
zone nor the timer function is selected, the Touch control automatically returns to standby
mode. The touch control is only turned on by pressing the power button. If the power but-
ton is pressed at the same time as other buttons, no action is taken, and the touch control
remains in stand-by mode.
The touch control can be switched off at any time using the power button. This is even
the case when the control has been locked by the child safety feature. The power button
always takes priority in the switching off function.
Onceswitchedon,thetouchcontrolautomaticallyswitchesoffafter20secondsofinac-
tivity.
Placethepanontheappropriatecookingzone.Ifthepanisnotinplace,thesystemwillnot
activate the corresponding zone and the following symbol is shown in the corresponding
display, (7).
WhentheTouchControlisturnedon,anyofthecookingzonescanbeactivatedbypress-
ingonthecorrespondingslidecontrol,(3).Bypressingandslidingthefingeracrossthe
slidecontrol,(3),itispossibletoselectasettinglevelintherangeof0to9.Thesettinglevel
is shown in the corresponding display, (7).
Toswitchoffthecookingzone,justselectsettinglevel0bypressingthecorresponding
sliding control. If the residual heat of the cooking zone is high, the corresponding display,
(7),showsan“H”.

17
OPERATION
Intelligent pan detection
Cooking zones
Thecontrolautomaticallydetectsthepresence/absenceofapanineverycookingzone.
Ifapanisdetected,display(7)ofthecorrespondingzonewillconstantlyread“0”untilthe
required power level is selected. If no pan is detected, display (7) will remain off and not
displayanything.Ifapanisadded/withdrawn,thecontrolwilldetectitandwillturnon/off
the“0”ofthecorrespondingdisplay(7).
There are several possible combinations of cooking zone:
Individual zone (Fig. 7-A)
Thereare4squareindividualcookingzones(A,B,C,D)whichcanbeusedindependently,
by using the appropriate sliding control for each zone. Approximate diameters of the pan
bases:12-20cm
Double zone (Fig. 7-B)
Two individual zones may also be used together to form a single zone controlled by only
oneslidingcontrol.ThepossiblecookingzonecombinationsareA+BorC+D.Thisisdone
bysimultaneouslypressingtheslidingcontrol(3)ofthezonestobecombined.Nextthe
symbolonindicator(9)oftheselectedzoneswillappear.Onlytheslidingcontrol(3)andthe
display (7) located further on the left of the control panel will
remain active. This offers a rectangular cooking zone, particularly suited to rectangular or
oval-shapedpans.Approximatediametersofthepanbases:20-25cm

18
OPERATION
Totalzone(Fig.7-C)
Optionally,the4cookingzoneslocatedfurtherontheleftmayfunctionasasinglezone
(A+B+C+D),controlledbyasingleslidingcontrol.Pressbutton(5)toobtainalargesquare
cooking zone suitable for large square or round pans. Approximate diameters of the pan
bases:30-40cm
TheBoosterfunctioncanbeselectedbypressingthe“P”atthefarrightoftheslidingcon-
trol,(3),fortherequiredcookingzone.Withthisfunction,allthecookingzonesareableto
receive a power supply above the nominal power (the number of zones with booster at the
same time will depend on the power provided to the different zones, which must always
be less than the maximum power of the hob). If the required zone is able to activate the
boosterfunction,thesymbol“P”isdisplayed.
Theboosteractivationtimeislimitedto10minutestoprotectcookingutensils.Afterthe
booster has automatically switched off, the cooking zone continues to operate at setting
level“9”.Theboostercanbereactivatedafterafewminutes.
If the pan is removed from the cooking zone during boosting, the booster function remains
active and the disabling time continues its countdown.
Powermanagementisbasedontheprinciplethatthelastmodificationtothesettinglevelin
the different zones has top priority. This means that the setting levels previously configured
in the other zones may be automatically decreased
- If the induction detects that any of the cooking zones requires a reduction, the display for
thiszoneflashesfor3secondstotimeforcorrectionpriortomodification.
- If the selected zone is re-adjusted within the correction period, power management anal-
yses the power distribution again. If a reduction in power is not required, the flashing stops
and the original setting level remains on the corresponding display.
- Should power distribution be changed again by the user, the setting level will under no cir-
cumstances automatically increase in the zones where it has been automatically reduced.
Booster Function

19
Temperature Functions
Residual heat indicator
There are three temperature functions available that allow a given temperature level to
be chosen for the required cooking zone. This temperature will remained fixed without
changingovertime.Toactivatethisfunction,simplypressthebutton(13)correspondingto
therequiredcookingzone.Theindicator(14)willdisplaythesymbolcorrespondingtothe
selected temperature level and display (7) will show the following symbol:
This informs the user that the glass is at a dangerous temperature should the area around
the cooking zone be touched. After switching off the cooking zone, the corresponding
display(7)willindicate“H”untilthetemperatureinthezonehasdroppedbelowthecritical
level.
Automatic disconnection (operating time limit)
A maximum operating time is defined for each activated cooking zone.
The maximum operating time depends on the selected cooking power.
When the maximum operating time has passed, the cooking zone automatically switches
off.
Each time that the cooking zone mode is activated (change in cooking power, etc.) the tim-
er returns to the initial setting. The timer settings take priority over the operating time limits
when adjusting the cooking power.
OPERATION
There are three temperature functions available:
Level1:42o•C
Recommendedfordefrostingormelting(chocolate,forexample).Pressbutton(13)once.
Level2:70•o•C
Recommendedforheatingfoodorkeepingithot.Pressbutton(13)twice.
Level3:94•o•C
Recommended for simmering.
Pressbutton(13)threetimes.
Tocancelthisfunction,repeatedlypressbutton(13)untilthesymbolontheindicator(14)
disappears,orselectamediumpowerlevelwiththeslidingcontrol(3).

20
OPERATION
Button lock (child safety feature)
-Ifthetouchcontrolisturnedonbutnocookingzonesareoperating(alltheindicators(4)
are flashing), the stand-alone timer can be activated by simultaneously pressing buttons
(15)and(16)untilindicator(17)turnson.If,however,anyofthezonesisatapowerlevel
otherthan“0”,thestand-alonetimercanbeactivatedbysimultaneouslypressingbuttons
(15)and(16)severaltimesuntilindicator(17)turnson.Thetimerdisplay(8)shows“0.00”.
Nowitispossibletoselecttherequiredtimebetween0and119minutes.Ifnovalueis
selected,thetimerisdeactivatedafter5seconds.
- To select the required time, simply press the More button (16) to increase the time or the
Lessbutton(15)toreduceit.
- After the programmed time, an intermittent sound signal is activated and the display (8)
showsanflashing“0.00”.Both“0.00”andthesoundsignalturnoffwhenanyofbuttons
(15),(16)or(1)arepressed,orafter2minuteshaveelapsed.
-Ifitisactive,whentheTouchControlisswitchedoffusingtheON/OFFbutton(1),the
stand-alone timer continues the countdown.
Protection against unintentional activation
IftheTouchControldetectscontinuedpressureonabuttonformorethan10seconds:
-IfitistheON/OFFbutton,(1),allthedisplaysflashwiththesymbolshownbelowuntilthe
pressure is removed and any one of the buttons is pressed again. - If it is the sliding control,
the control produces a continuous acoustic signal and the symbol shown below flashes
onthecorrespondingdisplay(7).Ifthepressureismaintained,TouchControlswitchesoff
afterafurther20seconds.
Water or food spilt on the glass in the control zone may be detected as a continuous pres-
sure on one or more buttons.
Ifnocookingzoneisactivatedwithin20secondsafterswitchingonthetouchcontrol,itwill
return to standby mode.
-Whenthecontrolisswitchedon,theON/OFFbuttontakespriorityovertheotherbuttons,
to allow the control to be switched off at any time, in the event of multiple or continuous
pressure on the buttons.
-•Instandbymode,noeffectwillbecausedbybuttonsbeingkepthelddown.Inanycase,
to switch the electronic control back on, the control must have detected that no buttons
are pressed down.
