H2O LIFE SOURCE iDUO S5 User manual

iDUO S5 Alkaline Water Ionizer
Users Manual
A Water Science
Company
Please read these instructions
completely before operating this unit.

Control Volume ---------------- 13
Replacing Filter ---------------- 16
Installation
---------------- 17
Troubleshooting
---------------- 18
Specifications
---------------- 19
Resetting the Filter
---------------- 20
Installation Precautions
---------------- 03 ~ 04
Precautions While Using
---------------- 05 ~ 06
Name of Each Part
---------------- 07 ~ 08
Instructions for Use
---------------- 09
Obtaining Alkaline Water
---------------- 10
Obtaining Acidic Water
---------------- 11
Obtaining Purified Water
---------------- 12
Measuring pH /
Replacing Fuse
---------------- 14
Filter Configuration
---------------- 15
Electricity Safety Information ---------------- 01 ~ 02
( Contents )

01
Danger
▶ Please follow the following instructions below as they are there to prevent any
unexpected risk or damage.
▶ Safety-related information is divided according to the magnitude of the urgency of the
risk and the expected loss.
This symbol represents the operations that may be dangerous and the need for attention
!
When this symbol is present, instructions must be followed carefully in order to avoid any risk
!
Electricity Safety Information
Danger If the instructions are not followed, death or serious disability is expected
Warning If the instructions are not followed, significant physical or material harm is expected
Caution If the instructions are not followed, minor physical or material harm is expected
Cause of electric shock and fire
Always clean the power plug before using it by wiping
off any remains or dust on it. If either the power cable
or the power plug is damaged or if the outlet is loose
and can be shaken easily, stop using it and call the
maintenance service. Electric shock or short circuit
could cause fire
Danger
Do not damage, modify, bend, pull, or twist
the electric cord.
it may cause an electric shock, short circuit,
and or cause fire
Do not bend electric cord

02
Danger
Please only use an outlet that is rated higher
than 10A. Octopus wiring may cause fire
due to overheating
Use of correct outlet
Danger
Do not pull or insert power plug with wet hands.
It may cause electrocution
Cause of electrocution
Danger
Unplug power plug when repairing or
inspecting product or when exchanging parts.
It may cause electrocution
When repairing product
Danger
Do not connect device directly with warm water
(greater than 30℃).
It may cause malfunction or accident.
Do not use water with high hardness.
Do not use water that is not suitable for drinking
Do not use warm water! WARM
WATER

03
Installation Precautions
Tap
water
Warning
It is recommended to use tap water as
source water.
Do not use underground water,
polluted water, and water with high
hardness as source water
Do not use warm water as source water
Do not use water unsuitable for drinking
(Unsuitable source water based on Waterworks Law)
Tap water as source water
Danger
Install the product at least 20cm
away from the wall. It could become the cause
of any malfunction.
Install the product away from the wall
Danger
t arbitrarily disassemble or renovate the product,
t use the power cord after arbitrarily
Don’
disassembling or renovating it.
Don’
it could become the cause of electric shock or fire
Prohibition of arbitrary
disassembly or renovation

04
Danger
Do not install product in sloped area.
Do not apply excess strength or force on the product.
Please install main unit on a level surface.
Do not install product in sloped or shaky area.
It may cause damage when dropped or due to collision
Avoid installing on sloped and shaky areas
Danger
Do not use in moist place such as bathroom.
Do not spray water on product or clean
product with water.
It may cause electrocution and short circuit
Cause of electrocution and short circuit
Danger t fold the hose
Make sure the water hose doesn’t get tangled
or folded, it could become the cause of
leakage or short circuit.
Don’
Danger Avoid heated area
Do not install near heating equipment or
place candle or lighted cigarette on top
of product. Do not install on place in direct
contact with fire, place exposed to direct
sunlight, and near heating equipment such
as stove or electric heater.
It may cause malfunction or fire

05
Caution
Precautions While Using
Elderly, or people with physical disabilities, psychological problems, or those
who lack experience and knowledge should not be using this product.
Children needs to be supervised to prevent them from using the product as a toy.
Tap
water
X
Caution
Please unplug the power cord in case
of water shortage.
It could become the cause of
product malfunction.
In case of water shortage
Danger
Don’t assert any excessive shock to the product.
It could become the cause of electric shock
or product malfunction
Prohibition of any impact to the product
Caution
Please don’t move the product while it is
still operating. Don’t tilt the product over
45 degrees while moving the product.
It could become the cause of product malfunction.
No movement of the product
while operating

06
t insert any sharp objects
Danger
Caution
Caution
Alkali Water, Acid Water
When cleaning, do not use benzene,
thinner, cleanser, or pesticide.
Do not place bowl with water, drug, food,
or small metal on top of the product.
If it enters inside the product, it may cause
risk of electrocution, fire, or malfunction.
When cleaning (electrocution, fire)
Do not use alkali water or acid water
as supply water for fish tank with goldfish,
tropical fish, etc
Supply water for goldfish,
tropical fish, etc.
Danger
Don’t insert any sharp wires or drivers into
the product. It could become the cause of
electric shock or product malfunction.
Don’
▶ When disposing any appliances or water filters, please follow the specified procedure.
- It becomes the cause of environment pollution
▶ Don’t install the product in locations where there is a risk of freezing in winter.
▶ The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
▶ Children being supervised not to play with the appliance
▶ When replacing the water filter, please only use the filter from our own company
- It could become the cause of abnormality of water quality or taste.
▶ When installing parts, please use the parts provided from our own company.
(Water valves, water hoses, water filters etc.)
- Otherwise, it could become the cause of leakage or product malfunction.

07
Name of Each Part

08
No movement of the product while operating
Controller Button
ORP
pH
FLOW
DARC
FILTER
Acidic water outlet,
Cleaning progress
Blinking
Volume
( 0 ~9 )
After the selection of funcrions, click ON/OFF button and selected water will be dispensed
Selected level

09
Instructions for Use
Before Use
- Choose a safe place for the installation.
- Connect with tap water
- Flush generated water for 2-3 minutes after installation is completed.
- Prepare a plastic cup or glass container for collectiong the drinking water.
Do not use a metallic container.
※ NOTE : Alkaline 2 step set-up when factory delivery.
Storage and management method after usage
1. Make sure the power is off when moving the unit.
2. When cleaning, do not let water enter inside the main unit.
3. Do not block output or bend, twist, or press hose.
4. Use smooth cloth to lightly wipe the surface of main unit.
5. Do not store in hot, moist places.

10
Obtaining Alkaline Water
1. Touch ALKALINE button to select desired level (level 1~4)
2. After choosing the desired level of alkali water,
touch the start/stop button to get water
3. Press start/stop button to stop the water after getting
the desired amount of alkali water

11
Obtaining Acidic Water
1. Touch Acidic button to select desired level (level 1~2)
2. After choosing the desired level of Acidic water,
touch the start/stop button to get water
3. Press start/stop button to stop the water after getting
the desired amount of acidic water

12
Obtaining Purified Water
1. Touch Purified button.
2. start/stop button to get water
3. Press start/stop button to stop the water after getting
the desired amount of Purified water

13
3. When the desired volume indicator is lit,
press on to the volume button for 3 seconds to select that volume.
1. When the Volume Button is pressed, the screen's volume icon will flash
<< Volume setting stage >>
1Level : Button sound 1st 2Level : Button sound 2st
3Level : Button sound 3st 4Level : Button sound 1st + ment 1st
5Level : Button sound 2st + ment 2st (Initial value)
6Level : Button sound 3st + ment 3st
7Level : Button sound 1st + ment 1st + Melody 1st
8Level : Button sound 3st + ment 2st + Melody 2st
9Level : Button sound 3st + ment 3st + Melody 3st
~
Control Volume
2. After choosing the desired Volume, As the button is pressed,
it will switch in the following order, (1 ~ 9 )

14
Do not put pH measured water into eye or drink it.
Seal pH measured water and store in place away from children’
Do not place near fire. It may cause fire
pH concentration color table
Fuse change
Measuring pH / Replacing Fuse
pH measurement method
Drop 3 drops of pH measurement liquid in container and
fill 10cc with water to be measured. Shake 2~3 times and
color changes. Compare color with colorimetric table and
read the color’ value to complete measurement.s
s hands.
The fuse is located at the upper portion
of the back of the unit.
1
3
2
Note: When changing the fuse, please
make sure to unplug the power cord first.
Not doing so, may cause electric shock.
3) Tighten the fuse rotating it clockwise
with a screwdriver.
2) Insert the new fuse(3.15A)
1) The fuse can ve removed if rotated
counter-clockwise with a screwdriver

15
Filter Configuration
Usage Environment and Condition
Compound filter (Lifespan: 6 months)
Insist on using iDUO original filter replacement
from H2O LIFE SOURCE.
1. Do not use source water unsuitable by Waterworks Law standard.
2. Do not use in place with high temperature such as bathroom.
3. Do not use in place with high moisture or temperature.
4. Do not use in chemical drug storage or area generating gas.
5. Do not use in place affected by air including air pressure, wind, sunlight, salt, etc.
6. Please use in stable location without slope.
7. Do not use in place with low water pressure (below 14.2psi)
1. High-density FELT Film
2. Granulated activated carbon
3. Powdered activated carbon
4. 1st Depth sediment filter
5. 2nd Depth sediment filter
6. Anti-microbial ceramic (ZrO2, SiO2)
7. Super ceramic (Quartz)
8. Anion ceramic (Zeolite, Silver)
9. Calcium and chlorine removal
10. Final Depth sediment filter
※ To drink clean water, exchange filter regularly according to filter exchange period.
※ Exchange filter when icon telling filter exchange on display unit flashes.
※ Even if filter exchange icon does not operate, exchange if any of the following cases.
- When there is smell or odd taste
※ Filter exchange period may differ depending on usage amount,
(refer to display matters)
water quality, and water pressure.
※ For more details, please refer to the details on the sticker attached to the filter
and source water quantity (under 1ℓ/min).
8. Usage condition
※ Temperature: ±5℃ ~ +50 ℃ ※ Moisture: ±70% ※ Air pressure: 1013hpa ~ 877hpa

16

17
Installation

18
Troubleshooting
