H3C External PoE Power System PSE2500-A3 User manual

PSE2500-
A
3
External PoE Power System
User Manual
Hangzhou Huawei-3Com Technology Co., Ltd
http://www.huawei-3com.com
Manual Version: V1.00

Copyright © 2006, Hangzhou Huawei-3Com Technology
Co., Ltd. and its licensors
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form
or by any means without prior written consent of Hangzhou
Huawei-3Com Technology Co., Ltd.
Trademarks
H3C, Aolynk, , IRF, H3Care, , Neocean, , TOP
G, SecEngine, SecPath, COMWARE, VVG, V2G, VnG, PSPT,
NetPilot, and XGbus are trademarks of Hangzhou Huawei-3Com
Technology Co., Ltd.
All other trademarks that may be mentioned in this manual are the
property of their respective owners.
Notice
The information in this document is subject to change without notice.
Every effort has been made in the preparation of this document to
ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of
any kind, express or implied.
To obtain the latest information, please access:
Technical Support
[e-mail]
http://www.huawei-3com.com

About This Manual
Organization
H3C PSE2500-A3 External PoE Power System User Manual is
organized as follows:
Chapter Contents
1 Introduction Introduces the concept and
features of power supply.
2 System Description Introduces the structure and
electrical connection of power
supply.
3 Safety Introduces the safety information of
the overall system.
4 Installation and Debugging Introduces the installing and
debugging of the overall system.
5 Engineering Maintenance
and Troubleshooting
Introduces the routine
maintenance and troubleshooting
of the system.
Conventions
The manual uses the following conventions:

I. Command conventions
Convention Description
Boldface The keywords of a command line are in
Boldface.
italic Command arguments are in italic.
[ ] Items (keywords or arguments) in square
brackets [ ] are optional.
{ x | y | ... }
Alternative items are grouped in braces
and separated by vertical bars. One is
selected.
[ x | y | ... ]
Optional alternative items are grouped in
square brackets and separated by vertical
bars. One or none is selected.
{ x | y | ... } *
Alternative items are grouped in braces
and separated by vertical bars. A minimum
of one or a maximum of all can be selected.
[ x | y | ... ] *
Optional alternative items are grouped in
square brackets and separated by vertical
bars. Many or none can be selected.
# A line starting with the # sign is comments.
II. GUI conventions
Convention Description
< > Button names are inside angle brackets.
For example, For example, click <OK>.

Convention Description
[ ]
Window names, menu items, data table
and field names are inside square
brackets. For example, pop up the [New
User] window.
/ Multi-level menus are separated by forward
slashes. For example, [File/Create/Folder].
Symbols III.
Convention Description
Warning Means reader be extremely careful.
Improper operation may cause bodily
injury.
Caution
Means reader be careful. Improper
operation may cause data loss or damage
to equipment.
Note Means a complementary description.
Environmental Protection
This product has been designed to comply with the requirements
on environmental protection. For the proper storage, use and disposal
of this product, national laws and regulations must be observed.

User Manual
PSE2500-A3 External PoE
Power System Table of Contents
i
Table of Contents
Chapter 1 Introduction..................................................................1-1
1.1 Architecture and Configurations.........................................1-1
1.2 Features.............................................................................1-3
Chapter 2 System Description .....................................................2-1
2.1 Overview............................................................................2-1
2.1.1 Rectifier ...................................................................2-1
2.1.2 Rectifier Bracket......................................................2-2
2.1.3 Rectifier Visual Displays..........................................2-2
2.2 Controller............................................................................2-3
2.3 AC Distribution Unit............................................................2-6
2.4 DC Distribution Unit............................................................2-6
Chapter 3 Safety ............................................................................3-1
3.1 Safety Statements..............................................................3-1
3.2 Warning Statements and Safety Symbols.........................3-2
3.3 Precautions........................................................................3-3
Chapter 4 Installation and Debugging.........................................4-1
4.1 Introduction ........................................................................4-1
4.1.1 Guidelines................................................................4-1
4.1.2 EMI Considerations.................................................4-1
4.1.3 Installation Tools and Hardware..............................4-1
4.1.4 Safety ......................................................................4-2
4.1.5 Installation Sequence..............................................4-2
4.2 Physical Mounting..............................................................4-3

User Manual
PSE2500-A3 External PoE
Power System Table of Contents
ii
4.3 Installing Rectifiers.............................................................4-4
4.4 Frame Grounding...............................................................4-5
4.5 Load Connections..............................................................4-6
4.6 Connecting to AC utility/ AC grounding .............................4-7
4.7 Initial Start-up.....................................................................4-7
4.8 Powering on the Device.....................................................4-7
Chapter 5 Engineering Maintenance and Troubleshooting ......5-1
5.1 Maintenance and Troubleshooting.....................................5-1
5.2 LED Indication....................................................................5-1
5.3 Regulatory compliance standards......................................5-3

User Manual
PSE2500-A3 External PoE
Power System Chapter 1 Introduction
1-1
Chapter 1 Introduction
1.1 Architecture and Configurations
PSE2500-A3 power system is the extremely flexible system with
strong functions which are designed for PoE application.It can provide
power of up to 2500 W with 1+1 redundant configuration.
PSE2500-A3 architecture integrates two rectifiers (maximum 3
rectifiers), a system controller, and the distribution module in a 4U high
chassis. Local monitor and control of the device status can be
implemented with the system controller.
The general configuration is shown as follows:
Table 1-1 PSE2500-A3 configuration
Description Standard Configuration
4U high chassis D x W x H- 380 x 486 x 175mm(14.96 x
19.13x6.89 in)
System
controller One
NP series
Rectifier One NP2500UAC-PoE
AC distribution
components
1) Three independent lines AC power input each
of socket – with an individual switch
2) 3-phase AC voltage sensor

User Manual
PSE2500-A3 External PoE
Power System Chapter 1 Introduction
1-2
Description Standard Configuration
DC distribution
components Single load output with the max. Load of 2500W
Other -
Figure 1-1 PSE2500-A3 system
Note:
PSE2500-A3 system is configured with one rectifier modules.

User Manual
PSE2500-A3 External PoE
Power System Chapter 1 Introduction
1-3
1.2 Features
PSE2500-A3 system has the following features:
zCompatible with a wide range of input voltages from 90Vac
to 264Vac (configured with NP2500UAC-PoE rectifiers).
zEach bracket is configured with three rectifiers.
zPower factor is above 0.99 and efficiency is over 88% .
zMaximum device output 2500W.
zSystem Controller can real-time monitor and operate the
system.
zApplying hot-swappable components to accomplish quick
installation.
zAchieving remote control through RS232 or RS485
interface.
zAdvanced EMC design.
zHigh Safety and reliability.
(1)(2)(3): NP2500UAC-PoE Rectifier
Figure 1-2 PSE2500-A3 configuration (I)

User Manual
er 1
PSE2500-A3 External PoE
Power System Chapt Introduction
1-4
(a): AC Input Socket (b): DC Output
(c): RS232 and RS485 (d): Frame Ground
Figure 1-3 PSE2500-A3 configuration (II)

User Manual
PSE2500-A3 External PoE
Power System Chapter 2 System Description
2-1
Chapter 2 System Description
2.1 Overview
Figure 2-1 shows the schematic diagram of the PSE2500-A3
power system, showing the interconnections and signal flow among
the modules and components.
Figure 2-1 Schematic diagram of the PSE2500-A3
2.1.1 Rectifier
The output bus power is supplied by the rectifiers.

User Manual
PSE2500-A3 External PoE
Power System Chapter 2 System Description
2-2
2.1.2 Rectifier Bracket
Up to three rectifiers can be mounted in each system of rectifier
bracket. Each rectifier in the bracket receives AC power from the AC
distribution.
2.1.3 Rectifier Visual Displays
The front panel of the rectifier has three LEDs. Their names,
colors and meanings are as follows.
Table 2-1 LEDs state description
Condition AC OK
(green) DC OK (green) Fault (Red)
All OK 1 1 0
Thermal alarm
(Ambient) 1 0 0
Thermal alarm (fan fail) 1 0 1
Blown AC fuse in unit 1 0 1
Low or no AC > 15mS
(single unit) 0 0 0
AC not present in any
rectifier 0 0 0
Over Voltage Latched
shutdown 1 0 1
Any internal failure 1 0 1
The Front panel of the rectifier is as follows.

User Manual
Chapter 2
PSE2500-A3 External PoE
Power System System Description
2-3
Figure 2-2 Front panel of the rectifier
2.2 Controller
The system controller of PSE2500-A3 is installed within the
chassis. See figure 2-3.
Figure 2-3 Front panel of the controller
There are green LED (RUN) indicating operation status and red
LED (ALM) indicating the alarm on the front panel of the PSE2500-A3
controller. When the system has an alarm, such as input failure, input
over-voltage or under-voltage, output over-voltage or under-voltage,

User Manual
PSE2500-A3 External PoE
Power System Chapter 2 System Description
2-4
rectifier failure, rectifier self-protection, the red LED is on. Once the
alarm is gone, the red LED goes off.
The controller of the PSE2500-A3 has two major functions:
I. Monitoring the system operation status
Inside PSE2500-A3 there is an AC sensor card, which can
sample the AC input voltage. The sampled signal is sent into the
controller for data processing. Once the input voltage is lower than the
pre-set alarm level of the input low voltage, the controller reports an
AC input under-voltage alarm. Likewise, if the input voltage is higher
than the pre-set alarm level of the input high voltage, the controller
reports anAC input over-voltage alarm.
The sampled DC output voltage signal is also sent into the
controller. Once the output voltage is lower than the pre-set alarm
level of the output low voltage, the controller will reports a DC Low
alarm. Likewise, if the output voltage is higher than the pre-set alarm
level of the output high voltage, the controller reports a DC output high
alarm.
The rectifier communicates with the controller through RS485
bus. The working status of the rectifier is passed to the controller in
this way. Once the rectifier has an alarm, the information is passed to
the controller. The rectifier failure alarm includes: AC input failure, DC
output failure, fan failure, output high, over temperature, and module
shut-down.
II. Communicate with deamon systems
The controller supports China national standard protocol YD/T
1104-2001. User can apply this protocol to read system information or

User Manual
PSE2500-A3 External PoE
Power System Chapter 2 System Description
2-5
command the operation through equipment which has RS232 or
RS485 interface and can support this protocol.
There is one RS485 port and one RS232 interface on the rear
panel.
Their definitions are as follows:
Table 2-2 RS232
Pin Definition
1 Not used
2 Receive
3 Transmit
4 Not used
5 Ground
6 Not used
7 Not used
8 Not used
9 Not used
Table 2-3 RS485
Pin Definition
1 Transmit, +
2 Transmit, -
3 Receive, +

User Manual
PSE2500-A3 External PoE
Power System Chapter 2 System Description
2-6
Pin Definition
4 Ground
5 Not used
6 Receive, -
7 Ground
8 Not used
2.3 AC Distribution Unit
There are three AC input sockets on the rear panel of the device
rating at 20 A, 250VAC. Each socket supplies one rectifier module.
There are three switches beside each socket which is rated at 20 A
250VAC. They control the on/off of each supply.
2.4 DC Distribution Unit
Copper bus bars and two 10 mm2cables provide 54 VDC output
of the device. You can connect the output of this device to user
equipments by using them.
Figure 2-4 Distribution panel

User Manual
PSE2500-A3 External PoE
Power System Chapter 3 Safet
y
3-1
Chapter 3 Safety
3.1 Safety Statements
Please read and follow all safety instructions and warnings before
servicing the PSE2500-A3 system. Reference the individual module
product manuals for additional safety statements specific to the
modules.
zThe device must be in a restricted access area (dedicated
equipment rooms, equipment closets, or the like) where the
applicable requirements of the device are met.
zThe equipment must be in a controlled environment (an area
where the humidity is maintained at levels that cannot cause
condensation on the equipment, the contaminating dust is
controlled, and the steady-state ambient temperature is
within the range specified).
zDo not install this equipment at a combustible place.
zThis equipment has been evaluated for use in a continuous
ambient temperature of up to 50°C.
zTorque electrical connections conform to the values
specified on labels or in the product documentation.
zRefer to the product documentation for the proper hardware.
Use only the parts specified in the equipment documentation
zImproper fuses/circuit breakers may cause body injury or
equipment damages.
zExternal circuit breakers must be sized as required by the
applicable local codes. Refer to the equipment ratings to

User Manual
PSE2500-A3 External PoE
Power System Chapter 3 Safet
y
3-2
assure rating of equipment no to exceed 80% of the value of
the breaker chosen.
3.2 Warning Statements and Safety Symbols
The symbols may sometimes be accompanied by some types of
statement, for example “Hazardous voltage/energy inside”, “Risk of
injury”. “This device must be accessed only by qualified personnel.”
This symbol identifies the need to refer to
the equipment instructions for important
information.
This symbol is used to identify the
protective safety earth ground for the
equipment.
This symbol is used to identify other
bonding points within the equipment.
This symbol is used to identify the
presence of hazardous ac or dc
voltages.It may also be used to warn of
hazardous energy levels
Note:
These symbols are used to identify the presence of hazardous AC/DC
main voltage and also can be used to alarm the level of danger.

User Manual
PSE2500-A3 External PoE
Power System Chapter 3 Safet
y
3-3
3.3 Precautions
When working on this type of equipment, the following
precautions must be noted:
zThis unit must be installed, serviced, and operated only by
skilled and qualified personnel who have the necessary
knowledge and practical experience with electrical
equipment and who understand the hazards that can arise
when working on this equipment.
zThe PSE2500-A3 system can be powered by multiple AC
inputs. Ensure that the appropriate circuit protection device
for each AC input being serviced is disconnected before
servicing the equipment.
zHigh leakage currents may be possible on this type of
equipment. Make sure the equipment is properly earth
grounded before connecting power.
zHazardous energy and voltages are present in the device
and on the interface cables that can shock or cause serious
injury. Follow all safety warnings and practices when
servicing this equipment.
zExercise care when servicing this area.
In addition to proper job training and safety procedures, the
following are some basic precautions that should always be used:
zUse only properly insulated tools.
zRemove all metallic objects (key chains, glasses, rings,
watches, or jewelry, and so on).
zWear safety glasses.
zTest circuits before touching.
