Haas+Sohn HSP 6 537.08-WT RLU/PGI Technical Document

HSP 6 537.08–WT RLU/PGI
Equipment sheet
Pellet stove with heat exchanger GB
0553708001403b
Equipment sheet
HSP 6 537.08–WT RLU/PGI

GB
Notes in the text
Of utmost importance there are the notes entitled WARNING. The notes entitled WARNING advise you on
serious danger of damage to the heating device or of an injury.
The note entitled Notice advises you on possible damage to your heating device.
The note entitled Important calls your attention to the information important for the operation of your heating
device.
The note itself calls your attention to the information important for the operation of your heating device in
general.

Contents
GB
Contents
1. Technical data.............................................................................................................................. 1
2. Dimensions................................................................................................................................... 2
2.1. Dimensions ................................................................................................................................. 2
2.2. Connection of the exchanger ................................................................................................... 3
3. Cleaning work .............................................................................................................................. 4
3.1. Cleaning the surface ................................................................................................................. 4
3.2. Cleaning the glass panel .......................................................................................................... 4
3.3. Clean combustion chamber “function instruction” Error F040............................................. 4
3.4. Cleaning the combustion pot - weekly.................................................................................... 4
4. Maintenance work....................................................................................................................... 6
4.1. Cleaning of the ash pan - once a week................................................................................... 6
4.2. Cleaning of the exchanger - once a week.............................................................................. 8
4.2.1. Vertical cleaning of the exchanger....................................................................................... 8
4.2.2. Horizontal cleaning of the conduits of combustion products............................................ 9
4.3. Cleaning of the exchanger...................................................................................................... 13
4.4. Cleaning the pellet container - annual maintenance .......................................................... 16
5. Replacement parts list............................................................................................................. 17
5.1. Replacement parts list HSP 6 537.08–WT RLU/PGI (without trim parts)........................ 17
5.2. Detail A1.................................................................................................................................... 20
5.3. Replacement parts list HSP 6 537.08–WT RLU/PGI ......................................................... 21
6. Circuit diagram .......................................................................................................................... 22

Technical data
GB
1
1. Technical data
HSP 6 537.08–WT RLU/PGI
Heat output range: 2,7 – 10 kW
Nominal heat output: 10 kW
Output delivered by the stove body only (NO/PO): 2,1/0,2 kW
Output available for heating of water (NO/PO): 7,9/2,5 kW
Height: 1200 mm
Width: 545 mm
Depth: 498 mm
Weight: 174 kg
Diameter of flue elbow: 80 mm
Flue gas temperature: 148 °C
Testing transport pressure at nominal output: 12 Pa
Testing transport pressure at partial output: 5 Pa
Flue gas flow rate in g/s 6,1 g/s
CO level in flue gas (%) (min./max.) 0,01/0,03 %
Efficiency (NO/PO): 94/98 %
CO level in flue gas: 150 mg/Nm³
NOx level in flue gas: 102 mg/Nm³
OGC level in flue gas: <5 mg/Nm³
Proportion of dust in flue gas: 20 mg/Nm³
Contents of storage container (pellet tank): about 32 kg
Duration of burn with one charge (min./max.): about 15 h/60 h
Permitted fuel: Low-dust wood pellets diameter: 6 mm
to Ö-Norm M 7135, DIN plus, EN plus-A1 length: max. 30 mm
Room heating capacity to DIN 18893, constant heating: 340m³/220m³/130m³
Room heating capacity to DIN 18893, timed heating: 225m³/132m³/90m³
Electricity supply: 230 V (50 Hz)
Electricity supply input:
in normal operation: max. 85 W
Electric ignition (for max. 15 minutes on ignition): max. 660 W
Electronics fuses: (F3) T 0,315 A, 250 V
Fuses for the ignition, screw conveyor motor, induced draught, (F1), pump
(F2) T 3,15 A, 250 V
Maximum operating over-pressure of the exchanger: 200 kPa (2 bar)
Water contents of the exchanger: 30 l
Nominal flow rate: 315 l/h
Pressure loss at nominal flow rate: 130 mbar
Safety distances
Minimal distances from flammable materials:
side: 10 cm
rear: 5 cm
front (radiation area): 80 cm

Dimensions
GB
2
2. Dimensions
2.1. Dimensions

Dimensions
GB
3
2.2. Connection of the exchanger
Item Name
AHeating water output (outside thread G3/4")
BReturn water intake (outside thread G3/4")
COutlet of the safety valve (outside thread G1/2")
DFilling of the circulation system
EVenting valve

Cleaning work
GB
4
3. Cleaning work
WARNING
Before starting any cleaning work, the stove must be cool down!
Once the cleaning work is completed, the correct operating status of the device must be re-
established: Put the combustion pot in correctly, close the combustion chamber door.
3.1. Cleaning the surface
Dirt on the upper surface of the stove may be cleaned off with a damp cloth or if necessary with mild soapy
water. You are advised against using corrosive cleaning agents and solvents since these might damage the
surfaces.
3.2. Cleaning the glass panel
To clean the viewing panel, you must first open the stove door. Dirt on the glass panel can be removed with a
glass cleaner or with a damp sponge on which you have sprinkled some of the wood ash present.
(Environmentally friendly). Cleaning the glass panel may only be done with a cooled down stove in the OFF
operating mode.
3.3. Clean combustion chamber “function instruction” Error
F040
• The whole combustion space must be cleaned after 30-hours operation at the latest, or once a week.
• The requirement to clean the fire-box (flickering of the display) appears during heating, in case that the
cleaning interval has elapsed.
• After the fire-box has been cleaned, the error message "Clean the fire-box" will be confirmed automatically.
The condition for automatic confirmation of this error message is that the fire-box door is opened for more
than 60 seconds. This time is necessary for careful cleaning of the fore-box, including the burner.
• This reset of the operating hours counter occurs even if the cleaning of the combustion chamber is
performed before the 30 operating hours have run provided that the stove is in “Off” operating status and the
door is open for longer than 60 seconds during cleaning.
3.4. Cleaning the combustion pot - weekly
During operation, deposits may form in the combustion pot. How quickly the combustion pot becomes dirty
depends solely on fuel quality. The deposits or encrustations must be removed from time to time.

Cleaning work
GB
5
WARNING
If this is not done, the clinker will continue to accumulate. Then the device will no longer be able to ignite
properly. Pellets can pile up in the combustion pot. In extreme cases, this can reach all the way back to the
pellet chute. Backfire in the pellet container and smouldering in the pellet tank might possibly result.
This will destroy your device and is not covered in your guarantee.
WARNING
Cleaning the combustion pot may only be done with a cooled down stove in “OFF” operating mode.
Otherwise there is a risk of burns!
• Take out the burner bowl from the stove.
• Remove the remains of ashes and slag.
• After the cleaning, mount the burner bowl back to its proper position on the burner rest.
• Re-check the proper seating of the burner bowl, in order to avoid any lack of tightness.

Maintenance work
GB
6
4. Maintenance work
WARNING
Before starting any cleaning work, the stove must be cool down! The mains plug must be pulled out of
the power supply socket (always in advance)!
WARNING
Devices that are not maintained in accordance with our specifications must not be operated. Failure to
observe this point will invalidate all guarantee claims.
4.1. Cleaning of the ash pan - once a week
WARNING
The frequency of maintenance in turn depends to a large extent on the pellet quality (ash content). Quality
pellets have a low ash content of about 0.2-0.3%. However, if the ash content is higher (0.5% and over), the
interval from maintenance to maintenance is reduced and the accumulation of ash increases by 2 or 3 times.

Maintenance work
GB
7
Figure 1

Maintenance work
GB
8
4.2. Cleaning of the exchanger - once a week
CAUTION
We recommend you to clean the conduits of combustion products and the exchanger once in a week.
Please perform the short-time cleaning in two steps:
4.2.1. Vertical cleaning of the exchanger
• For the purposes of vertical cleaning, move the cleaning lever 5 times at least, in compliance with the Fig. 2.
Figure 2

Maintenance work
GB
9
4.2.2. Horizontal cleaning of the conduits of combustion products
• Get the cleaning bar from the rear cover of the stove. Next, remove the cover plug and dismount the screw
M10x70 by means of an Allen wrench, located behind the ash-pan door. After having finished the cleaning
by means of the blade, mount the screw and fit the cover plug to their places again. (see Fig. 3a-3c).

Maintenance work
GB
10
Figure 3a

Maintenance work
GB
11
Figure 3b

Maintenance work
GB
12
Figure 3c
Pos. Description Piece No. PR
1Cover plug 1 piece 0553808006180
2Allen wrench 6mm 1 piece 9001700060005
3Screw M10x70 1 piece 0030121000705
4Drawbar of cleaning 1 piece 0433317006063

Maintenance work
GB
13
4.3. Cleaning of the exchanger
CAUTION
Check and clean the flue-gas ways, exhaust (flue-gas) fan and flue-gas ducts at the latest after 1000 kg of
pellets have been consumed. Clean with a brush or an ash extractor.
CAUTION
After completion of the cleaning make sure that when putting back the covers, the seals are seated in the right
positions. It is essential to replace defective seals.
Please perform the long-time cleaning in two steps:

Maintenance work
GB
14
Figure 4

Maintenance work
GB
15
Figure 5: Removing the side wall

Maintenance work
GB
16
4.4. Cleaning the pellet container - annual maintenance
• Heat the pellet stove until the storage tank is completely empty.
• Then the protective grille (1) in the pellet tank may be removed.
• Then clean the tank and the intake of the screw conveyor housing with a vacuum cleaner.
• After cleaning, it is essential to put back the protective grille. When doing this, make sure that no screws fall
into the pellet tank so as to avoid consequential damage to the screw conveyor.
Figure 6: Pellet tank
1 Protective grille
2 Tank cover
