Haas+Sohn HSP 6 Pelletto III 419.08 Technical Document

Geräteblatt Pelletto III
419.08, 434.08
Geräteblatt
Pelletofen DE
Fiche technique
Poêle à pellets FR
Scheda tecnica
Stufe pellet IT
Equipment sheet
Pellet stove GB
Tehnički list
Kotel na pelete HR
Tehnični list
Kotel na pelete SLO
0541908101400d
Technische Dokumentation
Geräteblatt Pelletto III419.08, 434.08

Notes in the text
Of utmost importance there are the notes entitled WARNING. The notes entitled WARNING advise you on
serious danger of damage to the heating device or of an injury.
The note entitled Notice advises you on possible damage to your heating device.
The note entitled Important calls your attention to the information important for the operation of your heating
device.
The note itself calls your attention to the information important for the operation of your heating device in
general.

Contents
Contents
1. Technical data.............................................................................................................................. 1
2. Dimensions................................................................................................................................... 2
2.1. Dimensions Pelletto III 419.08 ................................................................................................. 2
2.2. Dimensions Pelletto III 419.08–C............................................................................................ 2
2.3. Dimensions Pelletto III 434.08 ................................................................................................. 3
2.4. Dimensions Pelletto III 434.08–C............................................................................................ 3
3. Cleaning work .............................................................................................................................. 4
3.1. Cleaning the surface ................................................................................................................. 4
3.2. Cleaning the glass panel .......................................................................................................... 4
3.3. Clean combustion chamber “function instruction” Error F040............................................. 4
3.4. Cleaning the combustion pot - weekly.................................................................................... 4
4. Maintenance work....................................................................................................................... 6
4.1. Cleaning the pellet container - annual maintenance ............................................................ 6
4.2. Cleaning the flue gas passes - long-time ............................................................................... 7
5. Replacement parts list............................................................................................................... 9
5.1. Replacement parts list Pelletto III 419.08, 434.08 (without trim parts) .............................. 9
5.2. Detail A1.................................................................................................................................... 11
5.3. Replacement parts list Pelletto III 419.08............................................................................. 12
5.4. Replacement parts list Pelletto III 419.08–C........................................................................13
5.5. Replacement parts list Pelletto III 434.08............................................................................. 14
5.6. Replacement parts list Pelletto III 434.08–C........................................................................15
6. Circuit diagram ..........................................................................................................................16

Technical data
1
1. Technical data
Pelletto III 419.08 Pelletto III 434.08
Heat output range: 2,4 – 8,3 kW 2,4 – 8,3 kW
Nominal heat output: 8,0 kW 8,0 kW
Height: 988 mm 1180 mm
Width: 529/531 mm 531/533 mm
Depth: 508 mm 498 mm
Weight: 96/143/115 kg 106/137 kg
Diameter of flue elbow: 80 mm 80 mm
Flue gas temperature: 206 °C 206 °C
Testing transport pressure at nominal output: 11 Pa 11 Pa
Testing transport pressure at partial output: 5 Pa 5 Pa
Flue gas flow rate in g/s 5,6 g/s 5,6 g/s
CO level in flue gas (%) (min./max.) 0,001/0,023 % 0,001/0,023 %
Efficiency: 90/95 % 90/95 %
CO level in flue gas: 15 mg/Nm³ 15 mg/Nm³
NOx level in flue gas: 143/- mg/Nm³ 143/- mg/Nm³
OGC level in flue gas: <5 mg/Nm³ <5 mg/Nm³
Proportion of dust in flue gas: 9/- mg/Nm³ 9/- mg/Nm³
Contents of storage container (pellet tank): about 17 kg about 32 kg
Duration of burn with one charge (min./max.): about 10 h/30 h about 20 h/60 h
Permitted fuel: Low-dust wood pellets diameter: 6 mm diameter: 6 mm
to Ö-Norm M 7135, DIN plus, EN plus-A1 length: max. 30 mm length: max. 30 mm
Room heating capacity to Ö-Norm M 7521: max. 230 m³ max. 230 m³
Room heating capacity to DIN 18893, constant heating: 250m³/145m³/98m³ 250m³/145m³/98m³
Room heating capacity to DIN 18893, timed heating: 165m³/95m³/65m³ 165m³/95m³/65m³
Electricity supply: 230 V (50 Hz) 230 V (50 Hz)
Electricity supply input:
in normal operation: max. 50 W max. 50 W
Electric ignition (for max. 15 minutes on ignition): max. 380 W max. 380 W
Electronics fuses: (F3) T 0,315 A, 250 V T 0,315 A, 250 V
Fuses for the ignition, screw conveyor motor, induced
draught, (F1) T 3,12 A, 250 V T 3,12 A, 250 V
Safety distances
Minimal distances from flammable materials:
side: 15 cm
rear: 10 cm
front (radiation area): 80 cm

Dimensions
2
2. Dimensions
2.1. Dimensions Pelletto III 419.08
2.2. Dimensions Pelletto III 419.08–C

Dimensions
3
2.3. Dimensions Pelletto III 434.08
2.4. Dimensions Pelletto III 434.08–C

Cleaning work
4
3. Cleaning work
WARNING
Before starting any cleaning work, the stove must be cool down! The mains plug must be pulled out of
the power supply socket (always in advance)!
Once the cleaning work is completed, the correct operating status of the device must be re-
established: Put the combustion pot in correctly, close the combustion chamber door.
3.1. Cleaning the surface
Dirt on the upper surface of the stove may be cleaned off with a damp cloth or if necessary with mild soapy
water. You are advised against using corrosive cleaning agents and solvents since these might damage the
surfaces.
3.2. Cleaning the glass panel
To clean the viewing panel, you must first open the stove door. Dirt on the glass panel can be removed with a
glass cleaner or with a damp sponge on which you have sprinkled some of the wood ash present.
(Environmentally friendly). Cleaning the glass panel may only be done with a cooled down stove in the OFF
operating mode.
3.3. Clean combustion chamber “function instruction” Error
F040
• The whole combustion space must be cleaned after 30-hours operation at the latest, or once a week.
• The requirement to clean the fire-box (flickering of the display) appears during heating, in case that the
cleaning interval has elapsed.
• After the fire-box has been cleaned, the error message "Clean the fire-box" will be confirmed automatically.
The condition for automatic confirmation of this error message is that the fire-box door is opened for more
than 60 seconds. This time is necessary for careful cleaning of the fore-box, including the burner.
• This reset of the operating hours counter occurs even if the cleaning of the combustion chamber is
performed before the 30 operating hours have run provided that the stove is in “Off” operating status and the
door is open for longer than 60 seconds during cleaning.
3.4. Cleaning the combustion pot - weekly
During operation, deposits may form in the combustion pot. How quickly the combustion pot becomes dirty
depends solely on fuel quality. The deposits or encrustations must be removed from time to time.

Cleaning work
5
WARNING
If this is not done, the clinker will continue to accumulate. Then the device will no longer be able to ignite
properly. Pellets can pile up in the combustion pot. In extreme cases, this can reach all the way back to the
pellet chute. Backfire in the pellet container and smouldering in the pellet tank might possibly result.
This will destroy your device and is not covered in your guarantee.
WARNING
Cleaning the combustion pot may only be done with a cooled down stove in “OFF” operating mode.
Otherwise there is a risk of burns!
• Take out the burner bowl from the stove.
• Remove the remains of ashes and slag.
• After the cleaning, mount the burner bowl back to its proper position on the burner rest.
• Re-check the proper seating of the burner bowl, in order to avoid any lack of tightness.

Maintenance work
6
4. Maintenance work
WARNING
Before starting any cleaning work, the stove must be cool down! The mains plug must be pulled out of
the power supply socket (always in advance)!
The frequency of maintenance in turn depends to a large extent on the pellet quality (ash content). Quality
pellets have a low ash content of about 0.2-0.3%. However, if the ash content is higher (0.5% and over), the
interval from maintenance to maintenance is reduced and the accumulation of ash increases by 2 or 3 times.
WARNING
Devices that are not maintained in accordance with our specifications must not be operated. Failure to
observe this point will invalidate all guarantee claims.
4.1. Cleaning the pellet container - annual maintenance
• Heat the pellet stove until the storage tank is completely empty.
• Then the protective grille (1) in the pellet tank may be removed.
• Then clean the tank and the intake of the screw conveyor housing with a vacuum cleaner.
• After cleaning, it is essential to put back the protective grille. When doing this, make sure that no screws fall
into the pellet tank so as to avoid consequential damage to the screw conveyor.
Figure 1: Pellet tank
1Protective grille
2 Tank cover

Maintenance work
7
4.2. Cleaning the flue gas passes - long-time
CAUTION
After the consumption of 1000 kg of pellets at the latest, it is recommendable to check & clean the conduits of
combustion products, the (induced) draught fan and the smoke flues. For cleaning, employ a brush or an ash
exhauster.
Please perform the long-time cleaning in two steps:
• Carry out the cleaning as pr the Fig. 2.
Figure 2: Removing the flue baffle

Maintenance work
8
• Carry out the cleaning as pr the Fig. 3.
Figure 3: Removing the side wall
CAUTION
After completion of the cleaning make sure that when putting back the covers, the seals are seated in the right
positions. It is essential to replace defective seals.

Replacement parts list
9
5. Replacement parts list
5.1. Replacement parts list Pelletto III 419.08, 434.08 (without
trim parts)

Replacement parts list
10
Pos. Description Piece No. PR
Replacement parts list Pelletto III 419.08, 434.08 (without trim parts)
A1 Complete combustion chamber door/grey 1 piece 0541908015300
A1
Complete combustion chamber door/
anthracite 1 piece 0541908005300
1Burner cast 1 piece 0551908005706
2Protection grate 1 piece 0551908006709
3Combustion chamber cladding left 1 piece 0551908005040
4Combustion chamber cladding back 1 piece 0551908005041
5Combustion chamber cladding right 1 piece 0551908005039
6Flame temperature sensor 1 piece 0561008005541
7Bottom temperature sensor 1 piece 0561008005543
8Draught baffle plate 1 piece 0551908005701
9Door contact switch 1 piece 0089500040005
10 Door hinge (complete)/anthracite 1 piece 0551908005410
10 Door hinge (complete)/grey 1 piece 0551908015410
11 Complete control unit 1 piece 0541908005569
12 Backup battery CR 2032 1 piece -
13a Stand — front 2 piece 0089501090005
13b Stand — back 2 piece 0551908505005
14 Ignition 1 piece 0541908005202
15 Room temperature sensor 1 piece 0089500390005
16 Flue gas thermosensor 1 piece 0561008005540
17 OC 1 piece 0089500080005
18 Cover hinge pins DIN 427 M5x18 1 piece 0541908005015
19 Protective grille 1 piece 0551908005931
20 Tank cover/anthracite 1 piece 0541908017190
20 Tank cover/grey 1 piece 0541908117190
21 Operator console 1 piece 0571207005510
22 Seal, tank cover (1000 mm) 1 piece 0561008006197
23 Grip 1 piece 0089500940005
24 Induced draught fan 1 piece 0561008005807
25 Heat exchanger 1 piece 0561008007072
26 Seal - set 1 piece 0561008005042
27 Tank cover + screw DIN 7981 ST 4,8x13 - set 1 piece 0561008016043
28 Screw conveyor motor 1 piece 0089500880005
29 Motor plate - set 1 piece 0571207007080

Replacement parts list
11
30 Conveyor 1 piece 0571207015060
31 Screw conveyor 1 piece 0571207027030
32 Lower screw conveyor bearing 1 piece 0571207005027
33 Collet 1 piece 0089000345000
34 Screw UN5950 M5x10 4 piece —
5.2. Detail A1
Pos. Description Piece No. PR
Detail A1
A1.1. Screwing door 1 piece 0541908305001
A1.2. Door hinge/anthracite - Set 1 piece 0541908005340
A1.2. Door hinge/grey - Set 1 piece 0541908006340
A1.3. Glass holder/anthracite - Set 1 piece 0551908005308
A1.3. Glass holder/grey - Set 1 piece 0551908025308
35 Combustion chamber door/anthracite 1 piece 0541908005220

Replacement parts list
12
35 Combustion chamber door/grey 1 piece 0541908006220
36 Seal glass 10x4 mm (900 mm) 1 piece 0040210040005
37 Door glass (383x224x4) 1 piece 0551908005305
38 Seal door 11 mm (1306 mm) 1 piece 0040300110006
5.3. Replacement parts list Pelletto III 419.08
Pos. Description Piece No. PR
Replacement parts list Pelletto III 419.08
39 Side wall right grey 1 piece 0541908016150
39 Side wall right anthracite 1 piece 0541908006150
39 Side wall right white 1 piece 0541908116150
40 Front plate anthracite 1 piece 0541908006120
40 Front plate grey 1 piece 0541908016120
41 Side wall left grey 1 piece 0541908016165
41 Side wall left anthracite 1 piece 0541908006165

Replacement parts list
13
41 Side wall left white 1 piece 0541908116165
42 Back wall 1 piece 0551908506118
5.4. Replacement parts list Pelletto III 419.08–C
Pos. Description Piece No. PR
Replacement parts list Pelletto III 419.08–C
43 Side wall right anthracite 1 piece 0541908006140
44 Side part C ceramic ahorn right 1 piece 0541908016185
45 Front plate anthracite 1 piece 0541908006120
45 Front plate grey 1 piece 0541908016120
46 Side wall left anthracite 1 piece 0541908006240
47 Side part C ceramic ahorn left 1 piece 0541908016186
48 Back wall 1 piece 0551908506118

Replacement parts list
14
5.5. Replacement parts list Pelletto III 434.08
Pos. Description Piece No. PR
Replacement parts list Pelletto III 434.08
49 Side wall right grey 1 piece 0543408006140
49 Side wall right white 1 piece 0543408116140
50 Front plate anthracite 1 piece 0543408006120
51 Side wall left grey 1 piece 0543408006150
51 Side wall left white 1 piece 0543408116150
52 Back wall 1 piece 0553908006118

Replacement parts list
15
5.6. Replacement parts list Pelletto III 434.08–C
Pos. Description Piece No. PR
Replacement parts list Pelletto III 434.08–C
53 Side wall right anthracite 1 piece 0543408716140
54 Side part C ceramic ahorn right 1 piece 0543408716185
54 Side part C ceramic coffee-bean right 1 piece 0543208716185
55 Front plate anthracite 1 piece 0541908006120
56 Side wall left anthracite 1 piece 0543408716240
57 Side part C ceramic ahorn left 1 piece 0543408716186
57 Side part C ceramic coffee-bean left 1 piece 0543208716186
58 Back wall 1 piece 0553908006118

Circuit diagram
16
6. Circuit diagram
Circuit diagram IO 33.3
