Habitat Jerry JERR-ET-SS16-A User manual

JERR-ET-SS16-A
Dimensions
Jerry Extending Table
If you need help or have damaged or missing parts, email:
[e-mail] or call: 0344 499 4686
Depth - 85cm
Width - 205cm
Height - 75cm
Dimensions
Assembly Instructions — Please keep for future reference
Important — Please read these instructions before assembly

General care and maintenance
General information
Maximum weight limitCleaning and care of wood and wood veneers
Safety and Care Advice
Important:
max load for table is shown
below.
Assemble on a soft level surface
to avoid damaging the unit or your
floor.
We do not
recommend the
use of power drill/
drivers for inserting
screws, as this could
damage the unit. Only use hand
screwdrivers.
Dispose of all packaging carefully
and responsibly.
Do not stand or put weight on the
product, this could cause damage.
Assemble the item as close to its
final position (in the same room)
as possible.
Do not place furniture directly in
front of radiators, fires or any
other source of heat.
Parts of the
assembly will be
easier with 2
people.
Check you have all the
components and tools listed on
the front cover and pages 2 - 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals away
from the work area, small parts
could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Received, please contact the store
or Habitat Head Office via its web
site: www.habitat.co.uk
or write directly to:
Habitat Retail Ltd.
489-499 Avebury Boulevard,
Milton Keynes MK9 2NW
Please retain your receipt as
proof of purchase.
If you have any comment or
suggestions regarding this
product, assembly instructions
or service.
If for any reason you should have
problems with your Habitat
product, please contact the store
from which you purchased it.
1
Take care to prevent sharp objects
e.g. toys, buckles and heels
from coming into contact with your
furniture, and avoid contact with
chemicals e.g. cosmetics or hair
products which may permanently
mark the surface.
Avoid exposing your furniture to
direct and prolonged periods of
sunlight and heat sources as
fading and cracking may occur.
Take care when moving
furniture - dragging it across
the floor will loosen and damage
the joints. Always lift and move.
From time to time check that
there are no loose fittings.
Tighten as necessary.
The use of furniture polish or
spray is not necessary or
recommended.
Never use abrasive or corrosive
cleaning agents.
Always use place mats and
coasters to protect the surface
from moisture and heat.
Dust regularly with a clean
dry cloth.
Wipe up any spills immediately
with a damp cloth and then dry
the surface with a clean dry
duster.
Repeat this procedure for
periodic cleaning.
Remove stubborn stains with a
weak washing up liquid
solution and a damp cloth and
dry after with a clean cloth.
Max.
30kg
Max.
50kg
Important — Please read these instructions fully before starting assembly

BC
BC
1. Top
3. Leaf2. Leg frame x 2
Components - Panels If you need help or have damaged or missing parts, email:
[e-mail] or call: 0344 499 4686
Note: There are 'Batch Code' lables where shown on the indicated items, these should be retained.
2
Please check you have all the panels listed below

5 55 60 65 70 75 80 85 90 95 100 105 110 115 1205045403530252015100
Fittings contained
in Pack 1
If you need help or have damaged or missing parts, email:
[e-mail] or call: 0344 499 4686Components - Fittings
Note: The quantities below are the correct amount to complete the assembly.
In some cases more fittings may be supplied than are required.
3
Flat washers x 8
B
Lock washers x 8
C
Allen key K4 x 1
A
M8x40 Bolts x 8
D
Please check you have all the fixin
g
s listed below
Ruler — To help correctly identify the fixings

AB
A x 8 D x 1
B x 8 C x 8
C
D
1
2
2
Assembly Instructions
4
Assembly Instructions
Step 1

5
3
Take care when turning over
Step 2
