Hach AN-ISE sc User manual

DOC023.98.90594
AN-ISE sc, AISE sc, NISE sc probe
Addendum—Operation with the SC1500 Controller
05/2017, Edition 1

3
Table of contents
English..................................................................................................................................................... 5
Deutsch.................................................................................................................................................. 23
Español.................................................................................................................................................. 41
Français ................................................................................................................................................. 59
Italiano ................................................................................................................................................... 79
Nederlands ............................................................................................................................................ 97
Dansk ................................................................................................................................................... 115
Polski ................................................................................................................................................... 133

4
Table of contents

English 5
Section 4 Operation
English
For more information on System Setup (current outputs, relays, and
network interfaces), refer to the sc1500 User Manual.
The following tables show the sensor menu for the AN-ISE sc
probe, AISE sc probe and NISE sc probe. If a menu item does not
apply to all three probes, its applicability is explained in footnotes.
Footnote 1 indicates applicability to the AN-ISE sc probe. The
AN-ISE sc probe is used to determine the ammonium and nitrate
concentration, as well as the potassium and chloride concentration.
Footnote 2 indicates applicability to the AISE sc probe. The AISE sc
probe is used to determine the ammonium and potassium
concentration.
Footnote 3 indicates applicability to the NISE sc probe. The NISE sc
probe is used to determine the nitrate concentration and chloride
concentration.
4.1 Sensor diagnostics menu
SENSOR STATUS
AN-ISE sc or AISE sc or NISE sc
Error list Shows all current error messages.
Warning list Shows all current warnings.
4.2 Sensor setup menu
SELECT AN-ISE sc or AISE sc or NISE sc (if more than one sensor or analyzer is attached)
Calibration
Matrix correction
Matrix correction options.
The most recently used menu is displayed.
The currently active corrections are shown in Information.
None No Matrix corrections activated
1-point matrix correction 1-point matrix correction
NH4+ NO311-point matrix correction for ammonium and nitrate
NH41,2 1-point matrix correction for ammonium
NO31,3 1-point matrix correction for nitrate
NH4+ K 1,2 1-point matrix correction for ammonium and potassium
NO3+ Cl 1,3 1-point matrix correction for nitrate and chloride
NH4+K + NO3+Cl 11-point matrix correction for ammonium, potassium, nitrate and chloride
Take the grab sample
immediately for the lab
analysis.
Information window: When this window appears, the sample must be taken immediately
and then analyzed in the laboratory.
1-point value correction
Perform 1-point value correction.
The most recently used menu is displayed.
The currently active corrections are shown in Information.
NH4–N 1
Select parameter for the 1-point value correction
NO3–N 1
Enter the values for the
first point
Enter the values for the 1-point value correction
Note: The following example shows the input when using a AN-ISE sc probe for
ammonium. When using the AISE sc probe, the input is the same. When using the
NISE sc, it is only possible to input the nitrate and chloride values.

6English
Operation
Calibration (continued)
AN-ISE SC NH4–N Enter the displayed ammonium value
AN-ISE SC K Enter the displayed potassium value
Lab value NH4–N Enter the laboratory ammonium value
Confirm the entry. Confirm the values entered
Correction result Display the correction results
2-point value correction Perform 2-point value correction
NH4–N 1
Select parameter for the 2-point value correction
NO3–N 1
Enter the values for the
first point
Enter the values for the 2-point value correction (first point)
Note: The following example shows the input when using a AN-ISE sc probe for
ammonium. When using the AISE sc probe, the input is the same. When using the
NISE sc, it is only possible to input the nitrate and chloride values.
AN-ISE SC NH4–N Enter the displayed ammonium value
AN-ISE SC K Enter the displayed potassium value
Lab value NH4–N Enter the laboratory ammonium value
Confirm the entry. Confirm the values entered
Enter the values for the
second point.
Enter the values for the 2-point value correction (second point).
Note: The following example shows the input when using a AN-ISE sc probe for
ammonium. When using the AISE sc probe, the input is the same. When using the
NISE sc, it is only possible to input the nitrate and chloride values.
AN-ISE SC NH4–N Enter the displayed ammonium value
AN-ISE SC K Enter the displayed potassium value
Lab value NH4–N Enter the laboratory ammonium value
Confirm the entry. Confirm the values entered
Correction result Display the correction results
More corrections Other matrix correction options
None No More corrections is activated
2-point matrix correction A 2-point matrix correction can be performed here
NH41
Parameter selection for the 2-point matrix correction.
NO31
Concentration
measurement 1 Saves the currently measured measurement for the first point
Date Displays the date of the current correction of the first point
Concentration 1 Entry and display of reference value for the first point
Concentration
measurement 2 Saves the currently measured measurement for the second point
Date Displays the date of the current correction of the second point
Concentration 2 Entry and display of the reference value for the second point
Previous corrections Selection of one of the last corrections performed
Sensor code The sensor code can be activated or entered here
Activate Activates the sensor code for the individual channels
NH4+ K 1Activate the sensor code for ammonium and potassium
NO3+ Cl 1Activate the sensor code for nitrate and chloride
NH4+K + NO3+Cl 1Activate the sensor code for ammonium, potassium, nitrate and chloride
Reset calibration Activates factory calibration
4.2 Sensor setup menu (Continued)

English 7
Operation
Calibration (continued)
Sensor code Entry of the sensor code
Lab value correction The laboratory values of the last matrix correction can be changed
Enter the lab value. Enter the laboratory values if 1-point matrix correction or 2-point matrix correction has
been selected
Ammonium1,2 Entry of ammonium laboratory value
Nitrate 1,3 Enter the laboratory value for nitrate
Potassium 1,2 Enter the laboratory value for potassium
Chloride1,3 Enter the laboratory value for chloride
Confirm the entry. Confirm the values entered
Correction result Display the correction results
NH4–N 1,2 Displays whether or not the ammonium correction was successful
NO3–N 1,3 Shows whether or not the nitrate correction was successful
K+ 1,2 Displays whether or not the potassium correction was successful
Cl 1,3 Displays whether or not the chloride correction was successful
Information Information on the matrix correction used per parameter
NH4–N 1,2 Matrix correction used for ammonium
NO3–N 1,3 Matrix correction used for nitrate
K+ 1,2 Matrix correction used for potassium
Cl 1,3 Matrix correction used for chloride
Settings
Name Enter or edit the name.
Up to 10 alphanumeric characters
Unit Select either mg/L or ppm as the measurement unit
Parameter Select NH4–N or NH4and/or NO3–N or NO3
Temperature Selection of °C or °F as temperature unit
Offset temperature Enter a temperature offset
Response time Entry of the response time (30 sec to 300 sec)
Datalog interval Select the data log interval (OFF, 30 sec, 1 min, 2 min, 5 min, 10 min, 15 min and
30 min), 5 min is the factory setting
K+ compensation 1,2
Select automatic potassium compensation:
On
Off
0 = compensation OFF
0.1–2000 mg/L Cl = Fixed compensation value
K+ concentration 1,2 Only shown when K+ COMPENSATE is OFF
Cl - compensation 1,3
Select automatic chloride compensation:
On
Off
0 = compensation OFF
0.1–2000 mg/L Cl = Fixed compensation value
Cl - concentration 1,3 Only shown when Cl COMPNSATE is OFF
Reset configuration Resets the configuration to the factory setting
Maintenance
Sensor information Information on the connected sensor
Sensor type Name of the connected sensor
4.2 Sensor setup menu (Continued)

8English
Operation
Maintenance (continued)
Name Serial number or name of the measurement location
Serial number Serial number of the connected sensor
Sensor type Instrument designation of the connected sensor
Software Software version
Calibration history Data of the selected matrix correction and information about slope and offset of the
individual channels, for example
NH4–N 1,2 Matrix correction selected for ammonium
NO3–N 1,3 Matrix correction selected for nitrate
K+ 1,2 Matrix correction selected for potassium
Cl 1,3 Matrix correction selected for chloride
Signals Signals and measurement results of the individual measurement channels
Ammonium 1,2 Display the signals and measurement results for ammonium
Nitrate 1,3 Shows the signals and measurement results for nitrate
Potassium 1,2 Display the signals and measurement results for potassium
Chloride 1,3 Display the signals and measurement results for chloride
Reference electrode Displays the signals and measurement results for the reference system
mV RAW Display the signals and measurement results for MV RAW
Impedance status Display the signals and measurement results for impedance
Temperature Display the signals and measurement results for temperature
Moisture Display the signals and measurement results for humidity
RFID Display the signals and measurement results for RFID
Last calibration Shows the age of the last matrix correction
Ammonium 1,2 Display the age of the last matrix correction for ammonium
Nitrate 1,3 Display the age of the last matrix correction for nitrate
Service
Cartridge test Perform a sensor check with the test cartridge
Cartridge test Display whether the individual sensor channels are OK or not
Maintenance Displays whether or not DIAG/TEST is OK
Ground rod Displays whether or not GNDROD is OK
Reference electrode Displays whether or not REF channel is OK
NO31,3 Displays whether or not NO3 channel is OK
NH41,2 Displays whether or not NH4 channel is OK
ORP Displays whether or not ORP channel is OK
Cl-1,3 Shows whether or not Cl channel is OK
K+ 1,2 Displays whether or not K channel is OK
Temperature Displays whether or not temperature channel is OK
Cartridge replacement Follow the menu process
Cleaning... Follow the menu process
1 Applies to AN-ISE sc
2 Applies to AISE sc
3 Applies to NISE sc
4.2 Sensor setup menu (Continued)

English 9
Operation
4.3 Calibration/matrix correction
The four electrodes with the reference system of the compact
sensor cartridge were calibrated with one another at the factory
using special standard solutions (CARTICALTM). However, the
membranes on the ion-selective electrodes are not 100% selective
due to other substances that may affect the measurement. Perform
a matrix correction (refer to 4.3.4, page 11) to compensate for other
ions present on the ISE electrodes.
Potassium has the largest interference effect on the ammonium
membrane, while chloride has the largest effect on the nitrate
membrane. The AN-ISE sc probe compensates for this problem
with the aid of a built-in potassium/chloride electrode.
When using the AISE sc probe, only the ammonium membrane and
the integrated potassium electrode are active.
When using the NISE sc probe, only the nitrate membrane and the
integrated chloride electrode are active.
Cross sensitivities between ammonium and potassium/nitrate are
automatically eliminated. Solids do not interfere with the
measurement. Due to matrix effects, correction and validation
cannot be performed with standard solutions. A matrix correction
can be carried out quickly and easily at any time.
4.3.1 Sensor code calibration
The sensor code is a calibration code and is delivered with the
sensor cartridge certificate. It contains the factory calibration
described in section 3.12, page 9 for the sensor cartridge.
Instruments with automatic sensor code recognition
(LXG440.99.x000x) read this automatically and assume the
Cartrical calibration.
Instruments without automatic sensor code recognition
(LXG440.99.x001x) require the sensor code to be entered during
the initial setup and whenever a new sensor cartridge is activated. If
the sensor code certificate has been lost, carry out factory
calibration (under the sensor code menu) as a temporary solution.
After activating the code, the sensor is fully calibrated but not yet
adapted to the specific matrix of the relevant application on a waste
water treatment plant. At least 12 hours must elapse before a
matrix correction is performed to allow the cartridge to adapt to the
specific matrix.
NOTICE
A matrix correction may only be performed if the sensor has been
immersed in the corresponding waste water matrix for over 12 hours.
This is the minimum time required to adapt the ISE membranes to the
waste water matrix.

10 English
Operation
Proceed as follows to change the sensor code:
1. Select SENSOR MENU > AN-ISE SC or AISE SC or NISE SC >
CALIBRATION > MORE CORRECTIONS> SENSOR CODE >
ENTER
2. Enter the sensor code.
3. Press ENTER to confirm and activate the sensor code. The day
meter for the cartridge is set to zero.
All old calibration data are now overwritten with the new calibration
data from the sensor code. The sensor code data is checked by the
system. If an error is indicated, check the sensor code and, if
necessary, enter the sensor code again.
4.3.2 Matrix correction via LINK2SC
The LINK2SC procedure offers a secure method of data exchange
between process probes and LINK2SC-compatible photometers
using an SD memory card or via a local area network (LAN). Two
different options are available:
a. The pure laboratory control measurement
b. A matrix correction that involves the measurement data
generated in the laboratory being used to correct the probe
During a pure control measurement, the measurement data is
transferred from the probe to the photometer where it is then
archived together with the photometric reference data that has
been recorded.
During a matrix correction, the reference data generated in the
laboratory is transferred to the probe to be used for the correction.
The matrix correction process requires operating steps to be
completed on the sc controller and on a LINK2SC-compatible
photometer.
Refer to the LINK2SC user manual for a detailed description of the
LINK2SC procedure.
When using the LINK2SC software, sections 4.3.3 and 4.3.4 are
not relevant.
4.3.3 Matrix correction – manual
ISE probes offer different options (refer to Table 1) for correcting
the sensor value with laboratory values (as a reference value).
The laboratory value of the water sample is entered as nitrate
nitrogen (NO3–N) and/or as ammoniacal nitrogen (NH4–N). This
laboratory value replaces the prior value measured by the sensor.
