Haier 1U125S2SN2FA User manual

SPLIT SYSTEM AIR CONDITIONER
INSTALLATION MANUAL
No. 0150546199
yThis product must only be installed or serviced by qualied personnel.
Please read this manual carefully before installation.This appliance is lled with R32.
Keep this manual for future reference.
Original instructions
6
6
8
9
11
12
15
17
18
19
21
25
Contents
Definitions
Safety consi erations
Before installation
Selecting installation site
Precautions on installation
Refrigerant pipe size an allowable
pipe length
Refrigerant piping
Leak test an vacuum rying
Charging refrigerant
Electrical wiring work
Test operation
Move an scrap the air con itioning
1U105S2SS1FA
1U105S2SS1FB
1U125S2SN1FA
1U125S2SN1FB
1U125S2SN2FA
1U125S2SN2FB
1U140S2SN1FA
1U140S2SN1FB
1U140S2SP1FA
1U140S2SP1FB
1U140S2SP2FA
1U140S2SP2FB
1U160S2SP1FB

3
Português
Haier Industrial Park,Qianwangang Road,Eco-Tech Development Zone,Qingdao 266555,Shandong,P.R.C.
EUROPEAN REGULATIONS
CONFORMITY FOR THE MODELS
IMPORTANT INFORMATION REGA-
RDING THE REFRIGERANT USED
CE
All the products are in conformity with the following
European provision:
- Low voltage Directive
- Electomagnetic Compatibility
ROHS
The products are fullled with the requirements in
the directive 2011/65/EU of the European parliament
and of council on the Restriction of the use of Certain
Hazardous Substances in Electrical and Electronic
Equipment(EU RoHS Directive)
WEEE
In accordance with the directive 2012/19/EU of the
European parliament,herewith we inform the consumer
about the dis- posal requirements of the electrical and
electronic products.
DISPOSAL REQUIREMENTS:
Your air conditioning product is marked
with this symbol.This means that electrical
and electronic products shall not be mixed
with unsorted household waste.Do not
try to dismantle the system yourself:the
dismantling of the air conditioning system,treatment of
the refrigerant,of oil and of other part must be done by
a qualied installer in accordance with relevant local
and national legislation.Air conditioners must be treated
at a specialized treatment facility for reuse, recycling
and recovery.By ensuring this product is disposed of
correctly,you will help to prevent potential negative
cons- equences for the environment and human health.
Please contact the installer or local authority for more
information.Battery must be removed from the remote
controller and dis- posed of separately in accordance
with relevant local and national legislation.
This product contains uorinated greenhouse gases
covered by the Kyoto Protocol.Do not vent into the
atmosphere.
Refrigerant type:R32
GWP:675
GWP=global warming potential
Please ll in with indelible ink,
y1 the factory refrigerant charge of the product
y2 the additional refrigerant amount charged in the
eld and
y1+2 the total refrigerant charge
on the refrigerant charge label supplied with the product.
The lled out label must be adhered in the proximity of
the product charging port(e.g.onto the inside of the2 stop
value cover).
A contains uorinated greenhouse gases covered by the
Kyoto Protocol
B factory refrigerant charge of the product:see unit name
plate
C additional refrigerant amount charged in the eld
D total refrigerant charge
E outdoor unit
F refrigerant cylinder and manifold for charging
Contains uorinated greenhouse gases
covered by the Kyoto Protocol

4
Read the precautions in
this manual carefully before
operating the unit.
This appliance is lled with R32.
Read the operator's manual Service indicator, read technical
manual
After reading this handbook, hand it over to those who will be using the unit.
The user of the unit should keep this mamual at hand and make it available to those who will be performing repairs or
relocating the unit. Also, make it available to the new user when the user changes hands.
WARNING
Ask your dealer or qualied personnel to carry out installation work.Do not attempt to install the air conditioner
yourself. Improper Installation may result in water leakage, electric shocks, re or explosion. All the cables shall
have got the European authentication certicate. During installation, when the connecting cables break off, it must
be assured that the grouding wire is the last one to be broken off.If refrigerant gas leaks during installation, ventilate
the area immediately.oxic gas may be produced.if the refrigerant comes into contact with re,and explosion may be
happen.
Make sure ground connection is correct and reliable.Do not earth the unit to a utility pipe, lightning conductor or
telephone earth lead. Imperfect earthing may result in electric shocks.
The breaker of the air conditioner should be all-pole switch and explosion-proof. The distance between its two
contacts should not be no less than 3mm. Such means for disconnection must be incorporated in the wiring.
The air conditioning sockets should be placed 1m above from the air conditioner, nor under the air conditioner. Be
sure not to use open ame, high static electrical or high temperature equipments etc.nearby the air conditioner.
Do not use means to accelerate the defrosting process or to clean, other than those recommended by the
manufacturer.
The appliance must be stored in a room without continuously operating ignition sources, the radius of the storage area
should be no less than 2.5 m (for example:open ames, an operating gas appliance or an operating electric heater).
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
The appliance must be installed, operated and stored in a room with a oor area larger than the Minimum Room Area
specied in the table on the following pages,The room should be well ventilated.
Comply with national gas regulations.
This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given superivision or instruction concering
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The air conditioner can not be discarded or scrapped Randomly If you need please contact customer service
personnel of Haier to scrap in order to obtain the correct disposal methods.
Reusable mechanical connectors and ared joints are not allowed indoor.
CAUTION
Do not install the air conditioner at any place where there is danger of ammable gas leakage.In the event of a gas
leakage, build-up of gas near the air conditioner may cause a re to break out.
Tighten the are nut according to the specied method such as with a torque wrench.If the are nut is too tight, it may
crack after prolonged use, causing refrigerant leakage.
Take adequate steps to prevent the outdoor unit being used as a shelter by small animals.Small animals.making
contact with electrical parts can cause malfunctions, smoke or re.
Please instruct the customer to keep the area around the unit clean
The temperature of refrigerant circuit will be high, please keep the inter-unit wire away from copper pipes that not
thermally insulated.
Only qualied personnel can handle, ll, purge and dispose of the refrigerant.

5
Português
WARNING
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons
in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
The appliances are not intended to be operated by means of an external timer or separate remote-control system.
Keep the appliance and its cord out of reach of children less than 8 years.
This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for
commercial use by lay persons.
Disconnect the appliance from its power source during maintenance service and when replacing parts.
1) Means for disconnection, such as circuit breaker, which can provide full disconnection in all poles, must be
incorporated in the xed wiring in accordance with the wiring rules.
It is necessary to allow disconnection of the appliance from the supply after installation. The disconnection may be
achieved by incorporating a switch in the xed wiring in accordance with the wiring rules.
The method of connection of the appliance to the electrical supply and interconnection of separate components, and
the wiring diagram with a clear indication of the connections and wiring to external control devices and supply cord are
detailed in below parts.
2) The appliance shall be installed in accordance with national wiring regulations. Wiring must be done by a qualied
electrician. All the wiring must comply with the local electrical codes.
3) The cord of the H05RN-F type or the electrically equivalent type must be used for power connection and
interconnection between outdoor unit and indoor unit. The size of the cord is detailed in below parts.
4) Details of type and rating of fuses, or rating of circuit breakers / ELB is detailed in below parts.
5) The information of dimensions of the space necessary for correct installation of the appliance including the
minimum permissible distances to adjacent structures is detailed in below parts.
