Haier HPP08XCR User manual

Installation and User Manual
Instructions d’installation et
Guide de l’utilisateur
Instrucciones de instalación y
Manual del usuario
HPP08XCR, HPP10XCT, HPP10XCT-E,
QPCD05AXMW
Portable Air Conditioner
Climatiseur portatif
Acondicionador de aire portatil
49-7780
11-17 GEA

TABLE OF CONTENTS
ENGLISH
1
RECORD KEEPING
Thank you for purchasing this Haier product. This user manual will
help you get the best performance from your new air conditioner.
For future reference, record the model and serial number located on
the label on the side of your air conditioner, and the date of purchase.
Staple your proof of purchase to this manual to aid in obtaining war-
ranty service if needed.
_______________________________________
Model number
_______________________________________
Serial number
_______________________________________
Date of purchase
AIR CONDITIONER SAFETY ................................................................................. 2
PARTS AND FEATURES...................................................................................... 3
INSTALLATION REQUIREMENTS ............................................................................ 3
Tools and Parts ..............................................................................................3
Location Requirements ..................................................................................... 4
Electrical Requirements......................................................................................4
INSTALLATION INSTRUCTIONS ............................................................................. 5
Step 1 - Unpack Air Conditioner ..............................................................................5
Step 2 - Install Exhaust Nozzle to Main Window Panel .........................................................5
Step 3 - Install Main Window Panel and Extension Panels.......................................................5
Step 4 - Attach Exhaust Hose to the Exhaust Nozzle ..........................................................6
Step 5 - Connect Exhaust Hose to the Air Conditioner ........................................................7
Step 6 - Complete Installation............................................................................... 7
CONTROL PANEL........................................................................................... 8
Buttons .................................................................................................... 8
Remote Control ............................................................................................ 8
Indicator Lights .............................................................................................8
AIR CONDITIONER USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AIR CONDITIONER CARE ................................................................................... 9
Cleaning ....................................................................................................9
Air Filters....................................................................................................9
Internal Water Tank ..........................................................................................9
Storage .....................................................................................................9
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
LIMITED WARRANTY ......................................................................................11
RECORD KEEPING ......................................................................................... 1

AIR CONDITIONER SAFETY
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Ýòõèçøæè÷ëèõìöîòéĤõèèïèæ÷õìæäïöëòæîìñíøõü÷òóèõöòñöòõçäðäêèúëèñøöìñê÷ëèäìõæòñçì÷ìòñèõ
follow basic precautions, including the following:
• Read all of the instructions before using this appliance.
• Plug into a grounded 3 prong outlet.
• Do not remove ground prong.
• Do not use an adapter.
• Do not use an extension cord.
• Do not operate the air conditioner if it has a damaged
cord or plug, if it is not working properly, or if it has been
damaged or dropped.
• Ýëèäìõæòñçì÷ìòñèõöëòøïçåèöèõùìæèçòñïüåüôøäïìĤèç
service personnel. Call an authorized service company
éòõèûäðìñä÷ìòñõèóäìõòõäçíøö÷ðèñ÷
• Disconnect power before servicing.
• Disconnect power before cleaning.
NOTE: Ýøõñìñêòģóòúèõåüóõèööìñê÷ëèÙòúèõåø÷÷òñ
does NOT disconnect the appliance from the power supply.
• Do not install or use the air conditioner in any area where
the atmosphere contains combustible gases or where the
atmosphere is contaminated. Avoid any chemicals coming
in contact with your air conditioner.
• Do not store anything directly on top of the air conditioner.
• Use two or more people to move and install air conditioner.
• ×èùèõòóèõä÷è÷ëèäìõæòñçì÷ìòñèõúì÷ëòø÷÷ëèĤï÷èõöìñ
place.
• Do not use the air conditioner near a bathtub, shower or
wash basin or other wet area.
READ AND SAVE THESE INSTRUCTIONS
ENGLISH
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will
follow the safety alert symbol and either the word “DANGER,” “WARNING” or “CAUTION.”
These words mean:
DANGER
WARNING
CAUTION
Êñìððìñèñ÷ïüëäýäõçòøööì÷øä÷ìòñâòøæòøïçåèîìïïèçòõöèõìòøöïüìñíøõèçìéüòøçòñđ÷
immediately follow instructions.
A potentially hazardous situation which, if not avoided, could result in death or serious
åòçìïüìñíøõü
A potentially hazardous situation which, if not avoided, may result in moderate or minor
ìñíøõü
Êïïöäéè÷üðèööäêèöúìïï÷èïïüòøúëä÷÷ëèóò÷èñ÷ìäïëäýäõçìö÷èïïüòøëòú÷òõèçøæè÷ëèæëäñæèòéìñíøõüäñç÷èïïüòøúëä÷
can happen if the instructions are not followed.
2

E Casters
F Center Drain Cap
G Power Cord Storage
H Air Filter
I Real Air Discharge
J Lower Drain Cap
A Control Panel
B Side Handle
C Vertical Air Vent
Louver
D Horizontal Air Vent
Louver
TOOLS AND PARTS
Gather the required tools and parts before starting
installation.
TOOLS NEEDED
•Flat-blade Screwdriver •Phillips Screwdriver
PARTS SUPPLIED
• Main Window
Panel • Extension Panels (2) • Flat Screws (6) 4 for extension
panels
2 for nozzles
•Pointed Screws (7)
2 for top window
brackets
1 for security brack-
et
4 for main
window panel
• Top Window
Bracket (2)
• Exhaust
Nozzle
•Bottom
Window
Bracket (2)
• Exhaust Hose
(1 or 2 depend-
ing on model)
• Security
Bracket
INSTALLATION REQUIREMENTS
PARTS AND FEATURES
ENGLISH
3
A
B
C
D
E
F
G
H
I
H
J

WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power cord
plug.
Do not use an adapter.
Do not use an extension cord.
Ïäìïøõè÷òçòöòæäñõèöøï÷ìñçèä÷ëĤõèòõèïèæ÷õìæäï
shock.
RESET
TEST
ENGLISH
• Top Foam Strip
(10 mm x 10
mm x 102 cm)
• Remote Control
• Bottom Foam
Strip
(3 mm x 10 mm
x 102 cm) • Batteries (2)
4
ELECTRICAL REQUIREMENTS
POWER SUPPLY CORD
Wiring Requirements
• 115 Volt, 60Hz, 15-amp fused grounded 3 prong outlet
• The use of a time-delay fuse or time-delay circuit breaker
is recommended.
• Use a dedicated circuit only.
NOTE: Do not operate any other electrical appliances on
this circuit or you may trip the circuit breaker/fuse.
If this power supply cord is damaged, it cannot be repaired. It
must be replaced with a cord from the product manufactur-
er. If the power supply cord is damaged call Haier Customer
Service: 1-877-337-3639.
To test the power supply cord before operation:
1. Plug the power cord into a grounded 3 prong outlet.
2. Press the Test button, and then press and release the
Reset button to restore power.
20”
(51 CM)
20”
(51 CM)
REQUIRED GROUNDING METHOD
This air conditioner must be grounded. The air conditioner is
equipped with a power supply cord that has a 3 prong grounding
plug. The power supply cord must be plugged into a mating,
grounded 3 prong outlet, and grounded in accordance with all
local codes and ordinances.
115V
15 Amp
LOCATION REQUIREMENTS
• Ùïäæè÷ëèäìõæòñçì÷ìòñèõòñäĥä÷ïèùèïöøõéäæèìñä
location that is at least 20” (51 cm) from any wall.
NOTE: The recommended distance from the window for
optimal performance is 30” (76 cm).
• Maintain a minimum 20” (51 cm) clearance around the air
æòñçì÷ìòñèõ÷òñò÷åïòæîäìõĥòú
• Keep the air conditioner free of any obstructions such as
drapes, curtains, blinds, etc.
• The exhaust hose should be free of any obstructions.
• Do not place the air conditioner on an unstable or raised
öøõéäæèåèæäøöèì÷æòøïçéäïïäñçæäøöèçäðäêèòõìñíøõü
• Do not place the air conditioner in direct sunlight or near
a heat source such as baseboard heaters, stoves, etc.
• The window panel can be installed in a window with a
minimum 20” (51 cm) to a maximum 40” (101.6 cm)
opening.

INSTALLATION INSTRUCTIONS
WARNING
Excessive Weight Hazard
Use two or more people to move and install air
conditioner.
Ïäìïøõè÷òçòöòæäñõèöøï÷ìñåäæîòõò÷ëèõìñíøõü
A
A
B
ENGLISH
STEP 1 - UNPACK AIR
CONDITIONER
• Remove packaging materials. Save the carton and the foam
packaging for storing the air conditioner when not in use.
NOTE: There are NO packing materials inside the
air conditioner to remove—Do Not open the cabinet.
• Properly dispose of/recycle all packing material.
• Handle the air conditioner gently.
• Keep the air conditioner upright and level. Do not set the air
conditioner on its side, front, back or upside down.
STEP 2 - INSTALL EXHAUST
NOZZLE TO MAIN WINDOW PANEL
1. Hold the main window panel so that the L-shaped edges
of the panel are facing you.
A L-Shaped
Edges
2. Align the exhaust nozzle with the slots in the opening, and
then insert and slide the nozzle to access the hole from the
back of the main window panel.
A Main
Window
Panel
B Exhaust
Nozzle (1 or
2 depending
on model)
3. Turn the main window panel over, so that the nozzle is away
éõòðüòøÒñöèõ÷äĥä÷öæõèú÷ëõòøêë÷ëèëòïè÷òéäö÷èñ÷ëè
window panel to the adapter.
5
NOTE: On a dual hose unit, install the smaller hose
nozzle to the left-hand hole in the panel.
A AFlat
Screw
STEP 3 - INSTALL MAIN WINDOW
PANEL AND EXTENSION PANELS
NOTE: Depending on the size of your window opening, use
the main panel and one or both of the extension panels.
1. Open the window and place the main window panel into
the window.
NOTE: The window assembly is designed to
accommodate either a vertical slide or horizontal slide
window.
Vertical Slide Window
A
A Main Window Panel
Horizontal Slide Window
A Main Window Panel
2.Êçíøö÷÷ëèèû÷èñöìòñóäñèï¤ö¥÷ò÷÷ëèúìç÷ëòõëèìêë÷òé÷ëè
window as shown.
A
NOTE: Some window installations may require the
extension panels to be trimmed.
3. Depending on the number of extension panels used, use
÷úòòõéòøõĥä÷öæõèúö÷òöèæøõè÷ëèðäìñóäñèï÷ò÷ëè
extension panel(s).

A A Exhaust Nozzle (1 or
B
C
2 depending on
model)
B Hose (open end)
C Hose (connector
end)
NOTE: Do not attach additional hoses to extend the
ïèñê÷ëÝëìöúòøïççèæõèäöèæòòïìñêèĦæìèñæüäñçðäü
damage the air conditioner.
2. Using a counterclockwise motion, attach the open end
of the exhaust hose to the exhaust nozzle.
STEP 4 - ATTACH EXHAUST HOSE
TO THE EXHAUST NOZZLE
1. Grasp both ends of the exhaust hose and gently pull to
expand the hose.
B
A
ENGLISH
NOTE: There are many window types on the market
today. Use the foam strips and brackets (provided) to
secure the extension panels that ll the window opening.
4. Place the two top window brackets and two bottom
window brackets where they will best support the
extension panels.
Before Assembly
A
B
A
A Top Window Brackets
B Bottom Window Brackets
After Assembly
B
5. Apply the top foam strip (provided) across the top of the
window panel assembly, and then apply the bottom foam
strip (provided) across the bottom front edge of the window
panel assembly, as shown.
A
B
C
D
A Top Foam Strip
B Top Bracket
C Extension Panel
E
D Bottom Bracket
E Bottom Foam Strip
6. Place the window panel assembly in the window, and using
the screws provided, fasten the assembly to the window
sill and window frame.
7. Using one pointed screw, install the Security bracket to the
window.
6
NOTE: The security bracket prevents the window
from being opened from the outside.
A Security Bracket
B Pointed Screw (1)

STEP 5 - CONNECT EXHAUST HOSE
TO THE AIR CONDITIONER
IMPORTANT: When connecting the hose, the air conditioner
must be close enough to the window that you will not
dislodge the window seal plate. Once the hose is connected,
move the air conditioner 20” (51 cm) from the wall.
1. Align the notches on the connector end of the exhaust
hose with the ridges in the opening on the back of the air
conditioner.
2. Holding the air conditioner with one hand, snap the
connector end of the hose into the air outlet on the back
of the air conditioner.
CONTROL PANEL
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power
cord plug.
Do not use an adapter.
Do not use an extension cord.
Ïäìïøõè÷òçòöòæäñõèöøï÷ìñçèä÷ëĤõèòõ
electrical shock.
ENGLISH
STEP 6 - COMPLETE INSTALLATION
1. Plug the power cord into a grounded 3 prong outlet.
2. Press the Reset button on the power cord to ensure the
safety plug is providing power to the air conditioner.
7
Timer
°C
Hr
°F
High Low Water Full Cool Fan Dehum Sleep POWER
A B C D E F G
BUTTONS
A TIMER BUTTON
Program a time from (1-hour to 24-hours) for the air
æòñçì÷ìòñèõ÷ò÷øõñØģòõØñàëèñäÝìðèÍèïäüìö
programmed, the Timer indicator light will illuminate.
While the air conditioner is operating:
1. Press the Timer button.
2. Press the Up/Down arrow buttons to select the number
of hours you want the air conditioner to continue to
òóèõä÷èåèéòõè÷øõñìñêØģ
NOTE: àäì÷äóóõòûìðä÷èïü%öèæòñçöéòõ÷ëèÝøõñ¡Øģ
time to be saved.
While the air conditioner is o:
1. Press the Timer button.
2. Press the Up/Down arrow buttons to select the number
of hours you want the air conditioner to remain o before
turning On.
NOTE: Wait approximately 5 seconds for the Turn-On
time to be saved.
To cancel the timer:
• Press the Timer button once, the hours remaining will
ĥäöëóõèöö÷ëè÷ìðèõåø÷÷òñäêäìñäñç÷ëè÷ìðèõúìïïåè
canceled.
B FAN SPEED BUTTON
Ýëèéäñöóèèçæäñåèäçíøö÷èçéõòðÕòúöóèèç÷òÑìêë
speed when the air conditioner is in operation.
NOTE: Ýëèéäñöóèèçæäññò÷åèäçíøö÷èçúëèñ÷ëèøñì÷ìö
in Dehum mode.
•Press the Fan Speed button to toggle among the two
speeds. The corresponding fan speed indicator will
illuminate.
C REMOTE CONTROL SIGNAL RECEIVING WINDOW
Aim the Remote Control at this window so the Control will
receive the signal.
D CONTROL PANEL DISPLAY
Displays the Set Temperature in degrees Fahrenheit or
degrees Celsius, or the hours remaining in a Time Delay.
The corresponding indicator light will illuminate.

ENGLISH
8
E UP AND DOWN ARROW BUTTONS
Êçíøö÷ö÷ëèÝèðóèõä÷øõèòõÑòøõöìñÝìðèÍèïäü
To Set the Temperature:
The temperature can be set between 62ºF and 86º F
(17ºC and 30º C) when the air conditioner is in Cool
mode.
1. Press the Mode button until the Cool mode is selected.
2. Press the Up Arrow or Down Arrow buttons to
select the Temperature.
NOTE: The temperature cannot be set when the air
conditioner is in either Fan or Dry mode.
F MODE BUTTON
Press the Mode button to toggle among the three
operating modes. The corresponding indicator will
illuminate.
Cool – Cools the room to the set temperature.
Dehum – Reduces the humidity in the room
Fan – Circulates the air in the room without cooling
G POWER BUTTON
Turns ON/OFF power to the air conditioner.
NOTE: Turning o power by pressing the Power button
does NOT disconnect the appliance from the power
supply.
•Press the Power button. The Power indicator will
illuminate.
A
REMOTE CONTROL
1. Insert the two batteries (provided).
2. Aim the remote control at the signal receiver on the
control panel to operate the air conditioner.
A SLEEP BUTTON
Increases the set temperature by 2ºF (1ºC) after
2-hours, and then increases the temperature by an
additional 2ºF (1ºC) after another 2-hours.
NOTE: The fan will operate at Low speed and cannot
åèäçíøö÷èçúëìïèìñÜïèèóðòçè
Press the Sleep button to enter Sleep mode. The
Sleep indicator will illuminate.
To Cancel Sleep Mode:
•Press the Sleep button or the Mode button (Cool, Fan
or Dry) on the remote control.
B
B ºC/ºF BUTTON
•Press the ºC/ºF button to toggle between displaying
the temperature in degrees Fahrenheit or degrees
Celsius. The corresponding indicator will illuminate.
INDICATOR LIGHTS
A
Illuminate to indicate the selected mode, speed or
condition.
A WATER FULL
The Water Full indicator illuminates, when the internal
úä÷èõ÷äñîëäöĤïïèçúì÷ëæòñçèñöèçúä÷èõÝëèäìõ
conditioner will turn o automatically. To drain the water
tank, see “Air Conditioner Care” for instructions.
Timer High Low Water Full Cool Fan Dehum Sleep POWER
