Haier HW-24CE03 User manual

Air ConditionerEdition:2006/01/19
OPERRATION

Parts Name
Machine body
Operation panel
Mode selection
Auto swing
Thermostat
Ventilation
WAIT 3 MINUTES BEFORE RESTARTING
VENTILATOR
Mode selection
Temp. setting
Auto swing
MODEL: HW-18L03(T3)
Front
Air inlet (indoor)
Air outlet (indoor)
Operation
Air Conditioner

Edition:2006/01/19

Operation Guide
When the mode selection switch is turned to " " or " " ,
the air conditioner will only blow out air without cooling.
If the mode selection switch is turned from cooling mode to fan
mode, do not turn it back until at least 3 minutes have elapsed.
<1>
<2>
<3>
<4>
Auto swing
Mode selection
<5>
When set to " ", fan motor runs at high
speed to blow out strong air.
When set to " ", fan motor runs at low
speed to blow out gentle air.
When set to " ", air conditioner will start
cooling at low speed, blowing out gentle air.
When set to " ", air conditioner will start
speedy cooling, blowing out strong air.
When set to " ", air conditioner stops
running.
Mode selection switch controls the fan motor
speed and cooling speed.
Hint
Auto air deflector switch
When the switch is set to " ", the indicator lights
Mode selection switch
up, and vertical louvers will swing from side to side,
delivering gentle air thus making you feel very
comfortable. When it is set to " ", the indicator
goes out, and the vertical louvers stop at any position.
Air Conditioner

Edition:2006/01/19

Operation Guide
VENTILATOR VENTILATOR
In cooling mode, after you turn thermostat switch counter-clockwise,
do not turn it back until at least 3 minutes have elapsed.
Otherwise, the fuse may blow due to overload.
Do not exceed the selection range.
This switch controls the preset indoor temperature
to makethe air conditioner start or stop automatically,
so as to reduce power consumption and operate the
system both comfortably and economically.
The compressor stops running when the
set temperature is reached but the fan
continues to operate to keep an even
indoor temperature.
Remarks
Temp. setting
Ventilation Lever
When the slide lever is at
"" position, the vent door
opens to allow air, smoke or
odors to be expelled from the
room.
"" position, the vent door is
closed and the air inside the room
is circulated and conditioned.
Vertical airflow direction
Vertical Airflow Direction Vane (Airflow
direction adjustment Up-and-Down)
The Vertical Airflow Direction Vane is
manually controlled by positioning the
vane todischarge the air upward,
downward or straight out.
Thermostat switch
CAUTION
Air Conditioner

Edition:2006/01/19

Maintenance
Air filter cleaning: Please clean the air filter every two weeks
When dirt accumulates in the air filter, air circulation will be blocked, and causes
poor
Removal of air filter
(1) Loosen the air inlet by pushing " PUSH " at
both edges as shown.
(2) Open the air inlet.
(3) Hold the handle at lower part of the air filter
and draw outward to remove the air filter.
1. Gently tap the dirt off the air filter.
2. Carefully wash the air filter in warm water
(below 40 oC). To obtain better cleaning
effect, soapy water or neutral detergent
may be used.
3. Flush the air filter carefully with clean water
after removing the dirt. Let it dry
completely.
(1) Put the air filter on.
(2) Push the part marked " PUSH " until you hear a click.
Air filter cleaning
Installation of filter
Washing
air filter
PUSH
Air inlet PUSH
(1) Loose the air filter by pushing " PUSH "
at both ends of air inlet.
(2) Hold the air filter by frame and lift it
forward for approx. 5 mm.
(3) Pull it out downward .
(1) Hold the filter by its frame and push it upward along
the
groove under air inlet until it comes to a complete stop.
(2) Push the part marked with " PUSH " until you hear a
click.
For HW-18L03(T3):
For HW-24CE03:
For HW-18L03(T3):
For HW-24CE03:
WAIT3MINUTESBEFORERESTARTING
VENTILATOR
Modeselection
Temp.setting
Autoswing
PUSH PUSH
WAIT3MINUTES BEFORE RESTARTING
VENTILATOR
Modeselection
Temp.setting
Autoswing
Air Conditioner

Edition:2006/01/19

Tips For Energy Saving
Avoid opening doors and windows
as much as possible.
Use curtain or blinds.
Direct sunlight may reduce cooling
effect, so always use window
Keep heat sources away from the
air conditioner.
Do not hang clothes in the vicinity
of the air inlet. This will decrease
the cooling effect and cause abnormal
operation.
Before operating the mode selec
-tion switch, check whether the air
inlet or outlet has been blocked.
Go
No
Keep away from
For longer and trouble-free operation of the unit, pay special attention to
the following:
Install the air conditioner at a location strong enough to support the unit.
Leave enough space around the air inlet and outlet for better circulation.
Avoid sites where flammable gas leaks.
Problems may occur if the unit is installed in the following areas:
Place where oil exists in the air including engine oil, seaside with
salt breeze, and hot springs area with air-borne sulfurous gas.
For Trouble-Free Operation
Air Conditioner

Edition:2006/01/19
curtain.
