Haier MRV Series User manual

31-5000500 Rev.0 04-20 GEA
InstallationInstructions
InstallationManuel
Instruccionesdeinstalación
MVAD007MV2AA
MVAD009MV2AA
MVAD012MV2AA
MVAD018MV2AA
MVAD024MV2AA
Designmayvarybymodelnumber. L’aspectpeutvarierselonlenumérodemodèle. Eldiseñopuedevariarsegúnelnúmerodemodelo.
MRVSeriesMultiZoneAirConditioner
ClimatiseurmultizonedelasérieMRV
AcondicionadordeAireMultiZonadelaSerieMRV

231-5000500 Rev.0
ENGLISH

31-5000500 Rev.0 3
ENGLISH
ThankyouforpurchasingthisHaierproduct.Thisinstallationmanualwill
helpyougetthebestperformancefromyournewheatpump.
Forfuturereference,recordthemodelandserialnumberlocatedon
thelabelonthesideofyourairconditioner/heatpump,andthedateof
purchase.
Stapleyourproofofpurchasetothismanualtoaidinobtainingwarranty
serviceifneeded.
_______________________________________
Modelnumber
_______________________________________
Serialnumber
_______________________________________
Dateofpurchase
ToregisteryournewHaierDuctFreesystemgoto
haierappliances.com/support/register-ductless
andinputthemodel/serialnumberinformationonthispage.Toreceive
a10-yearcompressorandpartswarranty,registrationisrequiredwithin
60daysofinstallation.
RECORDKEEPING
IMPORTANTSAFETYINFORMATION.....................................................................................4
USERMANUAL ...........................................................................................................6
PARTSAND FUNCTIONS .................................................................................................7
MAINTENANCE ..........................................................................................................8
FAULTCHECKUP.........................................................................................................9
INSTALLATIONPROCEDURES .........................................................................................11
ELECTRICALWIRING...................................................................................................15
TESTRUN&FAULTCODE .............................................................................................20
LIMITEDWARRANTY...................................................................................................21
TABLEOFCONTENTS

431-5000500 Rev.0
ENGLISH
Thismanual should begivento the buildingownerand kept forfuturereference.
•There are twotypesif indications. Botharerelated to safetyandshould be strictlyfollowed. WARNING highlights
issuesthat pose ariskof major injuryordeath. CAUTION highlights issues thatposea risk ofequipmentor bodily injury.
•After installation andstart-upcommissioning, please givethemanual to theuser.The manual shouldbekept in safe
placeand close totheunit.
WARNING
•Installation and maintenanceshouldbe performed by
anauthorized agency. Thewrongoperation of thisair
conditioningequipment may causewaterdamage, electric
shockor fire.
•Please install theuniton a solidfoundationor structure
strongenough to supporttheunit.
•The installation ofthisair conditioning equipmentshould
followlocal building codes.
•Use the propersizeelectrical wiring andsecureall
terminals,and organize allwiringand make sureall
wiringis not understress.Inspect all wiringforinsulation
blemishesand damage. Improperwiresize may lead
tofire.
•This unit isonlycompatible with R-410Arefrigerant.
Useof any otherrefrigerantmay lead toabnormallyhigh
pressuresand may causedamageor injury.
•Only use branchfittingssupplied by Haier.Useof any
otherbranches will voidwarranty.
•Make sure allcondensatedrain piping isproperlytrapped
whenconnected to buildingdrainsto avoid drawingfoul
gassesinto the buildingenvelope.
•Care should betakento ensure thatthereare no
refrigerantleaks. R-410A isaheavy gas andwilldisplace
oxygen.Ventilate the areaifa leak iffound.
•Keep equipment awayfromflammable environments.
•The drain pipeshouldbe installed perthismanual to
ensureproper drainage. Thepipeshould be wellinsulated
toavoid condensation. Inadequateinstallationmay lead to
waterdamage.
•Both liquid pipeandthe vapor pipeshouldbe well
insulated.Inadequate insulation mayleadto system
performancedeterioration or condensateformation.
•This equipment shouldnotbe used orservicedby
personnelwho have notbeenproperly trained inits
operationand maintenance.
•Children should besupervisedto ensure thattheydo not
playon or neartheequipment.
•Keep the equipmentandits power supplywiringout of
reachof children.
•This equipment isnotintended to beoperatedby means
ofan external timerorseparate remote-control system.
IMPORTANTSAFETYINFORMATION
CAUTION
•Earth ground conductorshouldbe connected viathe
equipmentdisconnect to thegroundbuss in thebreaker
panel.The earth groundconductorshould not be
connectedto any gaslines,water lines, lighteningrods,or
telephonegrounds.
•A circuit breakermustbe installed. Failuretoinstall a
circuitbreaker may causeelectricshocks or accidents.
•The equipment shouldbechecked for currentleakage
afterinstallation and power-up.
•Water or moisturemaydischarge from theequipment
whenrelative humidity risesabove80%, when condensate
drainlines become blockedorwhen air filtersbecome
blockedor heavily soiled.

31-5000500 Rev.0 5
ENGLISH
READ AND SAVE THESE INSTRUCTIONS
FORMOREHELP,VISITHAIERAPPLIANCES.COMORCALLTHECONSUMERHELPLINEAT877-337-3639.
•Do not putanyheating apparatus undertheindoor units.
Theheat may causedistortionof the units.
•Pay attention totheventilation to avoidanoxicinjury.
•Do not placeanopen flame inthepath of blowingair.
•Do not installina corrosive environment.Ifthe base
collapses,the unit mayfalland cause damage,product
failure,personal injury ordeath.
•Do not usetheunit for specialpurposessuch as
preservingfoods, works ofartetc. It isanair conditioner
forcomfort cooling /heating,not a precisionrefrigeration
system.
•Size circuit breakerperlocal or nationalcodes,improper
breakeror fuse mayleadto fire, electricshock,explosion,
personalinjury or death.
•Turn off thepowerto save energyifthe unit willbenot
usedfor a longperiod.The unit continuestouse power
eventhough the equipmentisturned off atthecontroller.
•Do not permitwaterto enter theunitand the wired
controller.There is riskofunit failure, fire,electricshock,
personalinjury or death.
•3-minutes protection
Toprotect the unit,thereis a 3-minutetimedelay after
theunit stops orafterpower is applied.
•Closethewindow toavoidoutdoorairgettingin.Curtains
orwindowshutterscanbeput downtoavoidthesunshine.
•Do not touchthepower switch withwethands to avoid
powershock.
•Turn off thesystemand remove powerwhenservicing
theunit.
•Turn equipment offatthe control beforeisolatingpower.
•Do not cleantheunit with waterspray.There is riskof
damagingthe unit, fire,electricshock, personal injury
ordeath.
•Keep flammable gasorcombustibles away fromtheunit.
Thereis risk ofproductfailure, fire, personalinjuryor
death.
•Please keep childrenawayfrom this airconditioning
equipment.
BEFOREYOUBEGIN
Readtheseinstructionscompletelyandcarefully.
•IMPORTANT–Savethese instructionsfor
localinspector’suse.
•IMPORTANT–Observeall governing
codesandordinances.
• Notetoinstaller–Be sure toleave these instructions
withtheConsumer.
• Note toconsumer – Keeptheseinstructions for future
reference.
• Skill level –A licensed certified technician(tohandle
refrigerant R-410A,recovery,etc)andaqualified
electrician are requiredfor installationandservice of
this splitheatpump system.
• Properinstallationistheresponsibilityoftheinstaller.
• Product failure duetoimproperinstallation is not
coveredunderthe limitedwarranty.
• Forpersonal safety,this systemmust be properly
grounded.
• Protectivedevices(fusesor circuitbreakers)acceptable
forinstallationarespecifiedonthe nameplateofeach
unit.
• Makesuretoavoidwiringorplumbinginsidethewall
wheninstalling.
CAUTION
• Aluminum electricalwiring maypresentspecial
problems-consultaqualifiedelectrician.
• Whenthe unitis in theSTOPposition,there is still
voltage totheelectrical controls.
CAUTION
IMPORTANTSAFETYINFORMATION

631-5000500 Rev.0
ENGLISH
Important Informaton:
•MRV series multizoneair conditioning systemscanoperate multiple indoorunitsin heating orcooling.When in cooling,
onlyunits set tocoolwill run. Samelogicapplies for heating..
•Turn power onfor12 hours priortostart-up to allowthecrankcase heater adequatetimeto protect thecompressor.
•All indoor unitsonthe same refrigerationsystemshould use theunifiedpower switch toensurethat all indoorunitsare
allpowered on duringsystemoperation.
Product Features:
1.Low static pressureindoorunits.
2.Space saving design.
3.System automatically displaysanydiagnostic error codes.
4.Brushless DC motorsforimproved energy efficiency.
5.Five fan speedswitha quiet operationmode.
6.Wider range ofESP:0-0.12in.W.G.(0-30Pa).
7.Centralized controller function(optionalfrom Haier).
8.The system willresumethe last modeandsettings it wassetto run inifthere is apoweroutage.
9.This indoor unitonlyhas a wiredcontrolleroption.
Operating Conditions:
Pleaseoperate in theconditionslisted below fornormaloperation.
USERMANUAL
OperatingRangeof Air Conditioner
CoolingDry Indoor Max. DB:90°F(32°C) WB:74°F(23°C)
Min. DB:64°F(18°C) WB:57°F(14°C)
Outdoor Max. DB:115°F(46°C) WB:79°F(26°C)
Min. DB:23°F(-5°C)
Heating Indoor Max. DB: 80°F(27°C)
Min. DB:59°F(15°C)
Outdoor Max. DB:75°F(24°C) WB:59°F(15°C)
Min. DB:-4°F(-20°C)
WARNING
•The power supplywiringmust be replacedbythe manufacturer oraqualified contractor ifitbecomes damaged in
orderto avoid hazardorinjury.
•This equipment shouldnotbe used orservicedby personnel whohavenot been properlytrainedin its operationand
maintenance.
•Children should besupervisedand kept awayfromthis equipment.
•This equipment isnotintended to beoperatedby means ofanexternal timer orseparateremote-control system.
•Keep the equipmentandits cord outofreach of children.

31-5000500 Rev.0 7
ENGLISH
PARTSANDFUNCTIONS
Hanging bracket
Drainage pipe
(pump)
Electric box
Drainage pipe (gravity)
Liquid and gas ports
Evaporator
Supply air

831-5000500 Rev.0
ENGLISH
MAINTENANCE
Filter Maintenance:
Cleaningthe air filter&air inlet/outlet grilles.
•Don't remove theairfilter except forcleaningor faults mayoccur.
•Make sure tousea stable platformwhilecleaning or servicingtheequipment. Do notflushthe equipment withwater
orelectric shock mayoccur.(clean filters onceeverytwo weeks).
Cleaning the air inlet/outlet grilles:
•Wipe grilles withasoft dry cloth.
•Water or neutraldrycleaner is recommendedifthe dust cannotberemoved.
Cleaning the air filter:
(A)Brush off dirtandvacuum.
(B)Wash with softclothand mild detergent.
(C)Shake water offandallow the filtertofully air drybeforereinstalling.
WARNING
•This equipment canbecleaned only whenitis switched offanddisconnected from thepowersupply or electricshock
andinjury may occur.
WARNING
•Do not usegasoline,benzene, diluents, polishingpowderor liquid insecticidetoclean them.
•Do not cleanthemwith hot waterofover 122°F (50°C)toavoid fading ordistorting.
WARNING
•Do not usegasoline,benzene, diluents, polishingpowderor liquid insecticidetoclean them.
•Do not cleanthemwith hot waterofover 122°F (50°C)toavoid fading ordistorting.

31-5000500 Rev.0 9
ENGLISH
Installation Requirements Checklist
Pleasecheck the followingbeforecontacting a repairservice:
Underthe following circumstances,immediatelystop the operation,disconnectthe manual supplyswitchand contact
theafter-service personnel.
•When control buttonsareinoperable
•When circuit breakerstriprepeatedly
•When the outdoorunitis blocked withiceor foreign objects.
•When the systemfailsto restart afterpowerreset.
•When system operatesabnormally.
FAULTCHECK
All these are not problems
Symptoms Reasons
Running water noise sound Running water sound can be heard during starting operation, during operation
or immediately after stopping operation. When it starts for 2-3 minutes, the
sound may become louder, which is the flowing sound of refrigerant or the
draining sound of condensate water.
Tapping sound During operation, the air conditioner may make a tapping sound, which is
caused from the temperature changes of the heat exchanger.
Bad smell in outlet air Clean filters and confirm the condensate drain pan and line are clean and
clear.
Operating indicator flashing When switching it on again after power failure, turning on the manual power
switch will show the operating indicator flashes.
Waiting Indicator Displayed when the control is set it to the cooing or heating mode and the
current mode of operation is opposite to the requested setting.
Idle indoor unit still has sound of refrigerant
flowing and radiating
temperatures.
Some refrigerant flow is allowed to pass through idle indoor units to prevent oil
and refrigerant from blocking the metering valve. This flow may result in some
radiating temperature and noise.
Clicking sound when unit comes on. The sound is made due to the expansion valve resetting when the unit is
powered on.
Start or stop working automatically Check if it is set to Timer-ON and Timer-OFF.
Please make another check.
Failure to work Check if there is a power failure.
Check if the supply fuse and breaker are disconnected.
Check if the unit is displaying any faults.
Check if wait symbol is displayed. This is due to other indoor units connected
to the same outdoor unit are running in the opposite mode.
System cannot heat and cool simultaneously.
Poor cooling & heating effects Be sure outdoor unit fan inlet and outlets are not blocked.
Check to be sure doors and windows are closed.
Check for dirty or blocked air filter.
Make sure the fan speed is not too low.
Check if the mode set to Fan mode.
Be sure the temperature control is set only correctly.

10 31-5000500 Rev.0
ENGLISH
Thismanual cannot completelyillustrateall the propertiesofthe products thatwerepurchased. Please contactthelocal
Haierdistribution center ifyouhave any questionorrequest.
Indoor Units:
1.The distance betweenairoutlet and thegroundshould
notbe more than9ft(2.7m).
2.Select appropriate placesforinstallation where the
airflowcan be spreadevenlythroughout the space.
Arrangeproper locations forconnectingpipes and lines
aswell as thedrainpipeto the outdoor.
3.Ceiling construction mustbesturdy enough toholdthe
weightof the unit.
4.Make sure thattheconnecting pipe, thedrainpipeand
connectingwiring line canbeput into wallstoconnect
theoutdoor units.
5.It is recommendedtomake the connectingpipe
betweenthe outdoor andindoorunits and thedrainpipe
asshort as possible.
6.Please read theattachedinstallation instructions ofthe
outdoorunit for refrigerantchargingif necessary.
7.The connecting flangeshouldbe checked byusers.
8. Electrical appliancessuchastelevision,instruments,
devices,artwork,piano,wirelessequipmentandother
valuablesshouldnotbeplacedundertheindoorunitastoavoiddamagecausedbycondensateleakingfromtheindoorunit.
The following steps can be taken after selecting the installation location:
1.Cut a holeinthe wall andinsertconnection pipe andconnectingwires through afield
suppliedPVC pipe. Theholeshould be inclinedslightlydownward with aninclinationof
atleast 1/100 (seeFigure1).
2.Before cutting thehole,ensure no pipeorrebar is placedbehindthe cutting position
Avoidcutting a holenearwires or connectionpipes.
3.Hang the unitfromrafters, joists ortrussescapable of supportingtheweight of theunit
Noise,vibration or leakagemayresult from unstableunitmounting.
4.Support the unitfirmlyand shape theconnectionpipe, connecting wiresanddrain pipe toallowthem to easily
getthrough the opening.
WARNING
Protectthe indoor unitfromwinds or earthquake,installaccording to localornational building codes.Improper
installationcan cause personalinjuryand property damage.
CAUTION
•Choose a suitableinstallationlocation.
•Avoid places withhighsalinity (salt water)andhigh sulfur gas.Unitwill corrode anddamagewill not becovered
bywarranty.
•Avoid excess oil(includingmechanical oil) andsteam.This can reduceefficienciesand product performance.
•Avoid areas wheremachinesgenerate high frequencyelectromagneticwaves; this cancausecontrol issues.
Required ToolsforInstallation:
•Brazingtorch
•15%silverphosphorouscopperbrazingalloy
•Wirestripper
•Soap-and-watersolutionorgasleakagedetector
•Torquewrench
•T17mm,22mm,26mm
•Tubingcutter
•Reamingtool
•Flaringtool
•Razorknife
•Measuringtape
•Level
•Vacuumpump
•Microngauge
•Nitrogen
•Mini-SplitAD-87Adapter(1/4”to5/16”)
•Non-adhesiveTape
•AdhesiveTape
•Electricalwiring
INSTALLATIONINSTRUCTIONS
Figure 1

31-5000500 Rev.0 11
ENGLISH
Dimensions and Service Clearances
Installation modes of Indoor unit
Thisseries of airconditionerscan be arrangedintwo air returnmodes:
1.Air return fromtheback (factory default).
2.Air return fromthebottom (can beadjustedon site). Seethefollowing figures.
Note: Thedownward air returnmodewill increase noise3-5dB(A).It is recommendedtoinstall the airconditionerin
downwardreturn air mode(figure2) if enoughspaceis available.
Installation space and method
Bodyinstallation
1.Use 3/8” (M10)all-threadrod.
2.Ceiling removal: Pleaseconsultwith an engineeraboutchanges to thebuildingstructure.
a.Ceiling reinforcement: Ensuretheceiling is stableandwill not shake.Theceiling base framemustbe reinforced.
b.Cut off andremovethe ceiling baseframe.
c. Reinforcethe facesleftwhentheceilingisremovedand furtherreinforcethebaseframethatfixboth endsoftheceiling.
d.Install piping andwiringafter the indoorunitinstallation is complete.Beforeinstallation, choose asuitableinstallation
positionand determine theoutgoingdirection of pipes.Especiallyin case thataceiling exists, pleasepullrefrigerant
tubing,drain hoses, andwiringto their positionspriorto actually hangingtheindoor unit.
INSTALLATIONINSTRUCTIONS
Model A B C D E F G H I
MVAD007~12MV2AA 16.5 35.1 14.6 33.5 7.3 25.2 3.6 29.9 6.0
MVAD018~24MV2AA 16.5 47.7 14.6 46.1 7.3 37.8 3.6 42.5 6.0
a
b
c
Hanger dimensions
Dimensions of return air inlet
h
i
Dimensions of pump drainage
hole, OD 1"
Dimensions of natural
drainage hole, OD 1"
Dimensions of drain hose
Air out
30
Air in
g
d
f
e
Dimension of air outlet
Airreturnfromtheback
Figure1
AIR
Airreturnfromthebottom1
Figure2
UP
Airout Airin
Airreturnfromthebottom2
Figure3

12 31-5000500 Rev.0
ENGLISH
Dimensions and Service Clearances
Installation space:
Installation of air-inlet grille
Theangle of air-inletgrilleshould be
parallelwith that ofairinlet direction,
otherwiseit will causemorenoise.
Exampleshown to theright.
Duct Installation of Indoor Units:
1.Installation of theductwork: With asquaresupply duct, theboreshouldn’t be lessthanthe sizes ofairoutlet duct.
2.Installation of theairreturn duct: Connectoneside of theairreturn duct totheair return oftheindoor units withrivets,
Theduct size shouldn’tbesmaller than theoutlet/inletsize of theindoorunit, as showninFig. 1.
3.Insulating Supply Ducts:Supplyand return airductsshould be insulated.
Selection of fan outlet
Thismachine uses aDCmotor. Multiple ESPadjustmentsare available. Thefactorydefault is standardESP.The ESP &
Silentmode can besetaccording to thestaticpressure and thenoiserequirement. Setting rangesareas follows:
Operation:
YR-E17wired controller: Withthedisplay on, pressFAN + SET keysfor 5s toenterstatic pressure setmode.The static
pressureicon will flashandcurrent static pressurewilldisplay. Press źŸ keytochange static pressuregrade,then press
theSet key toconfirm.
Note: Theseare medium ESPductedunits so allthesettings above mustbedone through awiredcontroller.
INSTALLATIONINSTRUCTIONS
Levelthe unitwithin0.2in(5mm)
IfendAistodrainwater,ensureendBisslightlyhigherthantheendAto
facilitatedrainage.
Otherwise,ensureendAisslightlyhigherthanendB.
4-Ø3/8"(M10)hangingbolt 8-Ø3/8"(M10)hangingnut
8-Ø3/8"(Ø10)washer
Correct
Airin
Wrong
Airout
Airreturnshutter
Airreturnpipe Indoorunit
Revit
Fig.1
Connectionofairreturnpipe
Model Ultra-Silent Silent Standard ESP default High ESP Super High ESP
Grade 1 2 3 4 5
Installationmode
Electric
control
enclosure
>24in.
>40in.
>4in(100mm) Reserve24in×24in
(600mm×600mm)accesshole

31-5000500 Rev.0 13
ENGLISH
Installation of drain hose
Connectionof indoor drainhose.Place with airinletopening
1.Please use theaccessorydrain hose toconnectindoor unit’s drainoutletto a PVCdrainline. Use clampstotighten
themas shown inthefollowing figure:
2.Please use rigidPVCglue for connectiontoPVC pipes andensurethere is noleakage.
3.Drain hose mustbewrapped with insulationsleeveand tightened withastrap to preventairleakage from producing
condensate.
4.To prevent waterflowingback into airconditionerwhen the unitstopsrunning, drain hoseshoulddecline to the
drainageside with aninclinationof above 1/100.Drainhose expansion orwateraccumulation should beprevented,or
elseit will causeabnormalnoise.
5.When connecting thedrainhose, do notpullon it toavoidthe pipe connectionsfromgetting loose ordisconnected.
Drainhose should notbepulled out laterallyformore than 8in(200mm)and should besupportedevery 31-39in
(0.8-1.0m) to avoidbending.
6.The end ofdrainhose should bemorethan 2in (50mm)awayfrom the groundorthe bottom ofdrainagetank. It should
notbe put inwater.To directly draincondensateinto drainage ditch,thedrain hose mustbetrapped to avoidodors
fromentering through thehoseinto room.
Drainage Test:
Ensurethe drain hoseisclear and allconnectionsare tightly sealedbeforetesting.
Performthe drainage testasfollows:
1.Add about 0.132gal(500ml)of water intothedrain pan throughwaterinjection port.
2.Switch on thepowerand operate theunitin cooling mode.Checkthat the wateroutletdrains water normallyandthat
thereare no leakagesatthe connections. Afterthedrainage test iscomplete,replace the waterinjectionport plug. For
theposition of waterinjectionport; see thefigure:
INSTALLATIONINSTRUCTIONS
Indoorunit
Wateroutlet
Snapring Drainhose PVCdrainhose
RigidPVCadhesive
Inclination1/100
Wateroutletheader
"'%ìñ
2~4in
<8in(200mm)
"'%ìñ
2~4in
Multipleunitsusewateroutletheader todrainwaterintobuildingdrain
UP Openorclosethe
waterinjectionportby
rotatingtheportplug
Seta supportingpointatevery31-39in(0.8-1.0m)
<8in(200mm)
"$ìñ
Inclination
1/100
<8in(200mm)

14 31-5000500 Rev.0
ENGLISH
INSTALLATIONINSTRUCTIONS
Pipe Length and Height Difference
Pleaserefer to theattachedmanual of outdoorunits.
Tubing Material and Specifications
Specialtools designed forR410Ashould be usedforcutting and flaringpipes.
Refrigerant Recharge Amount
Addrefrigerant according totheinstallation instructions fortheoutdoor unit. Theadditionof R410A refrigerantmustbe
performedwith a digitalscaleto ensure properquantities.Compressor failure canbecaused by overorunder charging
thesystem.
Connection Procedures of Refrigerant
Connectall the refrigeranttubesvia flare connections.
•Dual wrenches mustbeused in theconnectionof indoor unittubing.
•For tightening torquereferto the righttable.
Cutting and Enlarging
•Cut the tubetothe needed length.
•Ream the cuttoremove shoulder. Dothiswith the tubefacingdown to helpfillingsfall out.
•Add supplied flarenutto tube.
•Use R410a flaretoolto create flares.
Wire Connections
1.Connect using circularcrimpterminals:
Themethod of usingcircularterminal is showninthe figure. Takeoffthe screw,
connectit to theterminalafter placing itthroughthe ring attheend of theleadand
tightenit down.
2.Connect using straightterminals:
Themethod of usingstraightterminals is shownasfollows: loosen thescrewbefore putting thewireinto
theterminal block, tightenthescrew and confirmithas been tightenedby
pullingthe line gently.
3.Clamp the wires:
Securethe wires withclipswhich should pressonthe insulation ofthewires.
Model MVAM007!018ME2AA MVAM024~054ME2AA
TubingSizein(mm) GasPipe 1/2"(Ø12.7) 5/8"(Ø15.88)
LiquidPipe 1/4"(Ø6.35) 3/8"(Ø9.52)
TubingMaterial SeamlesscopperpiperatedforR410Arefrigerant
OutDiameterofTubing
in(mm) MountingTorque lb-in(N-m) FlareTorqueSpec ft-lb(N-m)
1/4"(Ø6.35) 104.4(11.8) 13(18)
3/8"(Ø9.52) 216.8(24.5) 30(40)
1/2"(Ø12.7) 443.7(49.0) 43(59)
Wrench
Connecting
circular
terminals
Terminaltier
Pressing
Clip
Correctpressing Wrongpressing

31-5000500 Rev.0 15
ENGLISH
Supply Wiring Drawing
•Indoor units andoutdoorunits should beconnectedto separate circuitbreakers.
•Indoor units mustshareone single electricalbreaker.Circuit breaker specificationsshouldbe calculated. Itis
recommendedto have bothindoor& outdoor unitsconnectedto GFCI andsurgedevices.
ELECTRICALWIRING
WARNING
•Follow local codeswhenselecting wire gaugeandconnecting to housepower.
•Use the cablestrainrelief clips andlockingconduit clamps topreventwires from beingpulledoff terminal posts.
•Unit must beproperlygrounded. Do notusewater or gaspiping,phone ground orlightningrod.
CAUTION
•Only copper wirecanbe used. Aproperlysized breaker shouldbeprovided, or electricshockmay occur.
•Unit requires 208/230VAC–L1, L2 wireanda ground. Noneutralis required.
•All indoor unitsshouldbe wired tothesame breaker topreventsome of theunitsfrom being poweredoffwhile
othersare energized.
•Controller wiring andrefrigeranttubing can bearrangedand ran together.
•Disconnect power frombothoutdoor and indoorunitsprior to servicinganycomponent in thesystem.
L1(L)L2(N)
L1(L) L2(N) L1(L)L2(N) L1(L) L2(N)
......
GroundFaultInterruptor
CircuitBreaker
GroundFaultInterruptor
CircuitBreaker
PowerSource:208/230V~,60Hz
PowerSource:208/230V~,60Hz

16 31-5000500 Rev.0
ENGLISH
Signal Wiring Drawing
Outdoorunits are ofparallelconnection via threelineswith polarity. Themainunit, central controlandall indoor unitsare
ofparallel connection viatwolines without polarity.
Thereare three waysofconnecting the linecontroland indoor units:
A.One wired controltocontrol multiple units,i.e.2-9 indoor units,asshown in theabovefigure, (1-3 indoorunits).The
indoorunit 3 isthewire controlled mainunitand others arethewired controlled subunits.The remote controlandthe
mainunit (directly connectedtothe indoor unitofwired control) areconnectedvia three wireswithpolarity. Other
indoorunits and themainunit are connectedviathree lines withpolarity.SW01 on themainunit of wiredcontrolis set
to0 while SW01onother sub unitsofwired control aresetto 1, 2andso on inturn.(Please refer tothecode setting A
atpage 14)
B.One wired controlcontrolsone indoor unit,asshown in theabovefigure (indoor unit4-8).The indoor unitsandthe
wiredcontrol are connectedviathree lines withpolarity.
C.Two wired controlscontrolone indoor unit,asshown in thefigure(indoor unit 9).Eitherof the wiredcontrolscan be set
tobe the mainwiredcontrol while theotheris set tobethe auxiliary wiredcontrol.The main wiredcontroland indoor
units,and the mainandauxiliary line controlsareconnected via threelineswith polarity.
Note: ForDC motor/low ESPducttype, the PCBcomeswith the terminalblocks.Please be suretopay attention todo
thewiring according tothelabels. The powerlinesand signal linesgothrough the metalwirehole separately withthe
protectivesleeve of theconnectingline.
ELECTRICALWIRING
PQ
PQABC PQABC PQABC
ABC
Outdoor
Indoor1
Indoor4
Indoor7
Indoor2
Indoor5
Indoor8
Indoor3
Indoor6
Indoor9
PQABC PQABC PQABC
PQABC PQABC PQABC
ABC ABC ABC
ABCABC
ABCABC
Wiredcontroller
Wiredcontroller Wired controller Wiredcontroller
Wiredcontroller
Wiredcontroller Wired controller
Wiredcontroller
Communicationwirebetweenindoor
andoutdoorwithoutpolarity Control wireforwiredcontrollerwithpolarity

31-5000500 Rev.0 17
ENGLISH
ELECTRICALWIRING
Wiregauge size andbreakersize for totalindooramp draw. CurrentNECguidelines and localcodeswill trump thischart.
•The electrical powerlineand signal linesmustbe tightened.
•Every indoor unitmusthave a groundconnection.
•The power wireshouldbe size upifit exceeds thepermissiblelength.
•Shielding of thewireof all theindoorand outdoor unitsshouldbe connected andgroundedat one pointinthe outdoor
unit.The far endofthe shielding wireshouldbe wrapped backandtaped.
•Signal lines shouldnotexceed 3280ft (1000m).
WiredController ABC Chart
•The shielding layerofthe controller wiremustbe grounded attheequipment end, andtapedback at theterminalend.
•The total lengthofthe controller wireshallnot be morethan820ft (250m).
Items Cross Section
AWG (mm²)Length in(mm) Rated Current ofOverflow
Breaker (A)
Rated Current of
Residual Circuit
Breaker (A)
GroundFault
Interrupter (mA)
Response Time (S)
Cross
SectionalArea
ofSignal Line
<7 14(2.5) 65.6(20) 10 10A,30mA,0.1S orbelow 16 AWG(1.25mm²)
7and<11 12(4) 65.6 (20) 15 15 A,30 mA,0.1Sorbelow
11and<16 10(6) 82 (25) 20 20A,30mA, 0.1Sor below
16and<22 8(8) 98.4 (30) 30 30 A,30 mA,0.1Sorbelow
22and<27 6(10) 131 (40) 30 30A,30mA,0.1S orbelow
TotalCurrent
ofIndoor
Units(A)
LengthofControllerWireft(m) WiringDimensionsAWG(mm²)
820(250) 18(0.75)x3 coreshielding line

18 31-5000500 Rev.0
ENGLISH
ELECTRICALWIRING
Dip Switch Setting
•The dip switchisset to the"On"position if “1”isindicated in thetable.The dip switchisset to the"Off"position if "0"is
indicatedin the table.
•Dip switches setinthe factory toonare marked withred.
Definition principles of code switches:
(A)Definition of SW01:
•SW01_1-4 is usedtoset indoor addresswhengrouping multiple indoorunitsconnected to singlewiredcontroller
YRE16Bor YR-E17.
•SW01_5-8 set capacityofthe indoor unit(factoryset). Must onlysetwhen replacing board.
Note :A wired controllercanbe connected tosixteenultrathin air-duct indoorunits.
(B)Definition and descriptionofSW03
•SW03_1-8 is usedtoset indoor unitaddresson system. Setaddressonly if usingcentralcontroller YCZ-A004.
Leavedefault if nocentralcontroller is used.
Note:
•Set the addressbycode when connectingthecentralized controller, gatewayorcontrol system.
•Address of centralizedcontroller= communication address+0 or +64.
SW03_2=OFF, address ofcentralizedcontroller = communicationaddress+ 0 =communicationaddress
SW03_2=ON, address ofcentralizedcontroller = communicationaddress+ 64 (applieswhencentralized controller is
usedand there aremorethan 64 indoorunits)
SW01_1
SW01_2
SW01_3
SW01_4
Addressofwire
controlledindoorunit
(groupaddress)
[1] [2] [3] [4] Addressofwirecontrolledindoor unit(groupaddress)
0 0 0 0 0#(wirecontrolledmainunit) (default)
0 0 0 1 1#(wirecontrolledsubunit)
0 0 1 1 2#(wirecontrolledsubunit)
0 0 1 1 3#(wirecontrolledsubunit)
••• ••• ••• ••• •••• •••
1 1 1 1 15#(wirecontrolledsubunit)
SW01_5
SW01_6
SW01_7
SW01_8
Capabilityofindoorunit [5] [6] [7] [8] Capabilityof indoorunit
0 0 0 1 7000BTU
0 0 1 0 9000BTU
0 0 1 1 12000BTU
0 1 1 0 18000BTU
0 1 1 1 24000BTU
SW03_1 Addressofsetting
mode [0] Automaticaddresssettingorwiredcontrolleraddresssetting(default)
1 Code-setaddress
SW03_2
~
SW03_8
Code-setindoorunit
addressandcentralized
controlleraddress
[2] [3] [4] [5] [6] [7] [8] Addressofindoorunit Addressofcentralizedcontroller
0 0 0 0 0 0 0 0#(Default) 0#(Default)
00000011# 1#
00000102# 2#
••• ••• ••• ••• ••• ••• ••• ••• •••
0 1 1 1 1 1 1 63# 63#
1 0 0 0 0 0 0 0# 64#
1 0 0 0 0 0 1 1# 65#
1 0 0 0 0 1 0 2# 66#
••• ••• ••• ••• ••• ••• ••• ••• •••
1 1 1 1 1 1 1 63# 127#

31-5000500 Rev.0 19
ENGLISH
ELECTRICALWIRING
Dip Switch Setting of YR-E17 Wired Controller
FunctionSwitches
Forother wired remotecontrollersettings, please refertocontroller manual.
Thedifference between mainandsub wired controller.
DIP Switch On/OffStation Function DefaultSetting
Sw1 On Subwiredcontroller Off
Off Mainwiredcontroller
Sw2 On Ambienttemp.displayon Off
Off Ambienttemp.displayoff
Sw3 On Collectambienttemp.fromPCB ofindoor Off
Off CollectambientTemp.fromwired controller
Sw4 On Non-volatilememoryinvalid Off
Off Non-volatilememoryvalid
Sw5 On Oldprotocol Off
Off Selfadaption
Sw6 On Reserved Off
Off Reserved
Sw7 On ModelwithUp/DownandLeft/Right swing Off
Off ModelwithUp/Downswing
Sw8 On Fresh Airunit Off
Off Generalunit
Comparison
Item MainWired Controller SubWiredController
Function AllFunction 1.ON/OFF,Mode,Fanspeed, Temp,Setting, Swing,Energysaving,Clockfunction, ModeSetting,
ScreenSavingandChildlock areavailable.
2.Cancelthefiltercleaning icon.
3.Lookupthedetailed parameterand malfunctioncode.

20 31-5000500 Rev.0
ENGLISH
TESTRUNANDFAULTCODE
Before Test Run
•Apply power tosystemto energize thecrankcaseor sump ofthecompressor. Power onsystemat least 12hoursbefore
operationto protect thecompressor.
Check the connections at the drainpipe and wire connection lines to make sure they are correct.
•The drain outletshouldbe placed lowerthanthe drain outletofthe unit. Insulatethecondensate drain linestoprevent
condensationforming on thepipe.The drain lineshouldslope away fromtheindoor unit.
Checkup of Installation
•Check if themainvoltage is matching
•Check for anyleaksat the pipingjoints
•Check main electricalconnectionsfor indoor andoutdoorunits
•Check if theserialnumbers of theterminalsare matched properly
•Check to makesurethe structure canproperlyaccommodate the indoorunits
•Check for excessivenoise
•Check insulation onrefrigerantand condensate drainlines
•Check condensate drainsforfree flow
•Check final positionofindoor units
Test Run
•The installation technicianshouldcomplete a runtestand evaluation. Comparethetesting procedures accordingtothe
manualand check ifthetemperature control worksproperly.
•The following procedurecanbe used toforcethe system intorunningmode if thesystemfails to start.Thefunction is
notavailable for thetypewith remote control.
•Set the YR-E17wiredcontroller to cooling/heatingmode,press "ON/OFF" buttonfor10 seconds toenterinto the
compulsivecooling/heating mode. Press"ON/OFF"button again toquitthe compulsive runningandstop the operation
ofthe system.
Fault Remedies
Whenany fault appears,referto “Inquiry offaultrecords of indoorunits”at the previouspageand consult thefaultcode
ofline control orthenumber of LEDflasheson the controlpanel.Refer to thebelowtable lookup faultdescriptions.
IndoorUnit Faults
Failure Code at Wired
Controller PCB LED5 (indoor Units) / Receiver Timer Lamp (Remote
Controller)
FaultDescriptions
01 1 Faultofindoorunitambienttemp.sensorTA
02 2 Faultofindoorunitpipetemp.sensorTC1
03 3 Faultofindoorunitpipetemp.sensorTC2
04 4 Faultofindoorunitdualheatsourcetemp.sensor
05 5 FaultofindoorunitEEPROM
06 6 Faultofcommunicationbetweenindoor&outdoorunits
07 7 Faultofcommunicationbetweenindoorunitandwiredcontrol
08 8 Faultofindoorunitfloat switch
09 9 Fault ofduplicateindoor unitaddress
12 12 Faultofindoorunit50Hz Zero-crossing
14 14 Fault ofindoorunit DCmotor
18 18 BSvalveboxor4WV switchfailure
20 20 Correspondingfaultsof outdoorunits
