Haier HDW100SST User manual

61505
Parts Manual
Dishwasher
Model:
HDW100SST HA
Product Code:
61505

61505
2

61505 - NOVEMBER 2009
Fisher & Paykel Appliances Ltd
78 Springs Road,
East Tamaki,
PO Box 58-732, Botany,
Manukau 2163,
New Zealand
Telephone: [phone]
Facsimile: 09 273 0656
COPYRIGHTFISHER & PAYKEL LTD 2009 - ALL RIGHTS RESERVED
3
PRODUCT
Brand Haier
Voltage 220-240V, 50Hz
Model HDW100SST HA
Product Code 61505

61505
4

61505
5
CONTENTS
CABINET & BASKET AREA .............................................................................................................6
RETICULATION AREA.....................................................................................................................8
DOOR AREA...................................................................................................................................12

61505
6
CABINET & BASKET AREA

61505
7
CABINET & BASKET AREA
REF PART DESCRIPTION
1 H0120103797 COMPLETE TOP
2 H012G2150035 SHELF FASTENING SMALL BLOCK
3 H0120200964 WHEEL FOR LOWER BASKET
4 H012G2150037 DOOR HOOK
5 H012G1310020 UPPER REAR CROSSPIECE
6 H0120104772 PAINTED RIGHT SIDE PANEL
7 H0120104771 PAINTED LEFT SIDE PANEL
8 H0120807361 INSULATED TUB ASSEMBLY
9 H0120300248 TUB GASKET
10 H0120200967 BASKET RAIL STOP
11 H012G1020069 MOBILE RAIL FOR BASKET
12 H0120200966 RAIL SUPPORT ASSEMBLY
13 H0120200124 UPRIGHT SMALL BLOCK
14 H0120200656 RIGHT BASEBOARD SIDE PLATE
15 H0120200655 LEFT BASEBOARD SIDE PLATE
16 H0120200654 BASEBOARD
17 H0120200065 COVER FOR FRONT CROSSPIECE
18 H012G1310027 LOWER FRONT CROSSPIECE
19 H012G1451091 FRONT FOOT SUPPORT
20 H012G1610002 ADJUSTABLE FOOT
21 H012G1310023 REAR INTERMEDIATE CROSSPIECE
22 H012G2160204 DRAIN HOSE STOP
23 H0120101601 LOWER REAR CROSSPIECE
24 H0120105715 TRAY
25 H012G1610002 ADJUSTABLE FOOT
26 H0120106652 UPPER BASKET
27 H0120200963 WHEEL FOR UPPER BASKET
28 H0120200965 WHEEL SUPPORT PIN
29 H0120201235 RACK FOR UPPER BASKET
30 H0120801727 CUTLERY BASKET
31 H0120106687 FIX LOWER BASKET
32 H0120106568 STRENGTHEN IRON (LEFT)
33 H0120106569 STRENGTHEN IRON (RIGHT)

61505
8
RETICULATION AREA

61505
9
RETICULATION AREA
REF PART DESCRIPTION
34 H012G2160241 OUTER DUCT
35 H012G4050157 O-RING GASKET
36 H0120202777 UPPER SPRAYER BASE
37 H0120202779 INNER DUCT COVER
38 H0120202780 INNER DUCT SEALING
39 H0120300947 DIVERSION PIPE SEALING
40 H0120201019 UPPER SPRAYER ASSEMBLY
41 H0120202056 SUPPORT FOR FLOAT
42 H0120505219 FLOAT FOR ACQUASTOP
43 H012G6050040 MICRO SWITCH
44 H012G5060020 1-WAY SOLENOID VALVE
45 422680P HOSE INLET LONG (2M) PKD
46 H0120400440 POWER SUPPLY CABLE
47 H012G2160197 AIR BREAK NOZZLE
48 H0120201008 BREATHER RING NUT
49 H012G6010009 THERMO LIMITER
50 H012G1450902 BUSH FOR FASTENING OF HEATING ELEMENT THERMIC SWITCH
51 H012G8040038 ELASTICITY RETAINER
52 H0124000661 DRAIN PUMP
53 H012G4050158 O-RING GASKET
54 H012G1040020 BAND
55 420667P GUIDE DRAIN HOSE
56 H012G2140061 DRAIN HOSE
57 H012G6050043 WATER-LEVEL PRESSURE SWITCH
58 H012G2140067 PRESSURE SWITCH TUBE
59 H012G8050084 BAND
60 H0120202556A INSULATED TUB INLET
61 H012G1040020 BAND
62 H0124000163 THERMO LIMITER ASSEMBLY
63 H012G4050150 O-RING GASKET
64 H012G8060036 DENTIFORM RETAINER
65 H0120203065 WATER GUTTER
66 H012G4050151 CUP GASKET
67 H0120201292 RING NUT FOR CUP FASTENING
68 H012G1040014 MICROFILTER (POLYESTHERE)
69 H0120200949 INNER FILTER SCREEN
70 H012G1040012 PLANE FILTER SCREEN
71 H0120201009 EXTRACTABLE GLASS-FILTER
72 H0120202778 INNER DUCT
73 H012G4050152 RUBBER COUPLING
74 H012G1040028 BAND
75 H012G2160193 LOWER SPRAYER BASE FIXING PIECE
76 H012G4050153 O-RING GASKET
77 H0120201006 RING NUT FOR LOWER SPRAYER FASTENING
Continued next page

61505
10
RETICULATION AREA

61505
11
RETICULATION AREA
REF PART DESCRIPTION
78 H0120201004 LOWER SPRAYER BASE
79 H0120201005 LOWER SPRAYER COLUMN
80 H012G1020070 LOWER SPRAYER
81 H012G4050162 HEATER JACKET
82 H012G1250028 HEATER SUPPORT BLOCK
83 H012G6040016 HEATING ELEMENT
84 H012G405058 RING
85 H0120202557A INSULATED TUB INLET NUT
86 H012G9370094 MOTOR PUMP ASSEMBLY
87 H0120301100 CONNECTION PIPE
88 H012G4050159 VIBRATION-PROOF RING FOR MOTOR
89 H012G9350006 MOTOR SUPPORT BRACKET ASSEMBLY
90 H012G2140092 PVC VELUM FOR SOLENOID VALVE
91 H0120202777 DUCT FOR UPPER SPRAYER
92 H012G4050242 DUCT COUPLING
93 H0124000821 RFI CAPACITOR

61505
12
DOOR AREA

61505
13
DOOR AREA
REF PART DESCRIPTION
94 H0120203443 DASHBOARD
95 H0120801530 KNOB
96 H0120201452 CLOSING HANDLE
97 H0120200504 POWER BUTTON
98 H012G6040017 RED SPY LAMP
99 H0124000084 POWER SUPPLY SWITCH
100 H0124000657 PROGRAM SELECT SWITCH
101 H0120400361B COMPLETE WIRING GROUP
102 H012G6050032 DOOR SWITCH
103 H0120200639 CLOSING SUPPORT
104 H0120200640 HANDLE SMALL BLOCK
105 H012G2150050 CLOSING LEVER
106 H012G1040016 HANDLE SPRING
107 H012G1040017 SPRING FOR CLOSING LEVER
108 H012G2150051 PIN FOR CLOSING LEVER
109 H0120102983 OUTER DOOR
110 H0120800589 COMPLETE HINGE ASSEMBLY
111 H012G9380558 RIGHT HINGE ARTICULATION
112 H012G9380559 LEFT HINGE ARTICULATION
113 H0120104971 DOOR SPRING
114 H012G4050171 DOOR SPRING COVER
115 H0120600060 ELASTICITY RETAINER
116 H012G8080007 HINGE PIN
119 H012G1020080 INNER DOOR ASSEMBLY
120 H0124000215 DETERGENT DISPENSER
121 H0120202617 PCB BOARD COVER BOTTOM
122 H0124000658A PCB BOARD
123 H0120202618 PCB BOARD COVER
125 H0120202582 PVC VELNM FOR PCB BOARD BOTTOM
126 H0120200981 DOOR SIDE COVER
