HDW101**
Dishwasher
Service Manual
Models:
HDW101WH
HDW101SS
l
Features
l Two Stars for energy consumption of Autralian/New Zealand standard
l
Economic Washing
l Overflow Protection Function
l Net for separating forks or knives
l Super-capacity for 12 settings
Haier Group
Manual code: 0120502831/0120503010 Edition:2003.10.30

- 2 -
Contents
1. Product Code illumination and Series introduction .. ....3
2. Features .4
3. Specifications .. ..5
4. Safety Precaution .....8
5. Warning and Cautions ... .10
6. Net Dimension ...12
7. Installation and Accessory Parts 12
8. Parts and Functions .. ... ..15
9. Function Schedule ....18
10. Program Diagram ..19
11. Maintenances Service and Trouble Shooting ..20
12. Circuit Diagram .....23
13. Exploded View ..24
14. List of Parts 26

- 3 -
Product Code illumination and Series Introduction
1.Product Code Illurmination and Series Introduction
Model Identification
HDW 101
ABC
A: Abbreviation of Haier DishWasher
B: Series of factory design
C: Colour of dishwasher’s appearance WH: White SS: Stainless Steel BK: Black
Example:
HDW101WH
It represents automatic spraying electronic freestanding dishwasher,the cavity capacity is 12 standard
sets,with white steel outter side.
HDW101SS
It represents automatic spraying electronic freestanding dishwasher,the cavity capacity is 12 standard
sets,with stainless steel outter side.

- 4 -
Features / Specifications
2.Features
2.1 This product is provided with economic washing mode that users can select
optionally.
2.2 This product can contain 12 sets of eating utensils, applicable to big family.
2.3 Knife and fork can be separated by net and cleaned more easily
2.4 Detergent and rinse aid automatic dispenser is provided and can add them properly
that ensured the brightness and cleanness of eating utensils.
2.5 Water overflow protection is provided.

- 5 -
3.Specifications
DISH WASHER Free
Last update 2003-10-302003-10-30
Revision00.0100.01
Supplier Type N°. HDW101WH/HDW101SS
Suppliers bar code N°. EAN
Sales Brand / Model GXCH
Sales bar code N°. EAN
1.
Key-features
Energy efficiency Class
Washing efficiency Class -
Drying efficiency Class -
Noiselevel power / pressure dB(A) 55/-
Energyconsumption* kWh / y 387
kWh/24h 1.06
Waterconsumption* l 15
Duration of programme (Based on65 normal prog.) mins. 137
Place settings (international standard) 12
Programs n°. 5
Programme selection single dial / electronic l/ -
Washing temperatures °C 50/60
Spray levels n°. 3
Certification's (CE / LGA / ISO 9001 / ISO 9002) CE / ISO9001
2.
Technicalequipment
Work top / -removable
- /l
Decor frame / optional l/l
Water heating element hidden / open
- /l
Refill spy-lamps salt / rinse aid - /l
Program progress indicator LED / visual -/ -
Inner door S = stainless steel / P= plastic S
Interior S= stainless steel / P= plastic S
Dispenser system Detergent / Rinse aid l/l
Water softening system / n°. of water hardness levels l
/4
Electronically controlled water hardness -
Easy clean filter system / self cleaning micro filter
l/-
Upper Basket Full load ajustable/Height adjustable - /l
Lower Basket Folding/Not folding - /l
Pates Rack On Upper Basket -
Cuttlery Basket can be
separated for half wash /inseparated
- /l
Height adjustable top basket l
Cuttlery sliding tray / removable basket l/l
Plates sizes bottom basket / uper basket cm 19-26/14
Water inlet hose cold water / hot water l
/-
Water drain hose / -hose support l/l

- 6 -
Drying system Condenser / Turbo vented
Natural
Height adjustable feet n°. / max. mm 4/20
Delay timer (from -to) h -
3.
Safetysystems
Child resistant door lock CDL -
Anti flood system AFS l
Waterproof anti leak system ALS l
Water return protection WRP l
Acqua Stop kit
l
4.
Programs
Normal C° 60
Intensive C° 60
Economic C° -
Delicate or Light wash C° -
Rinse C° 60
Glasses C° 50
Rapid C°
Pre-wash (soak) C° Cold water
Strong C° -
5.
Additional program settings(optional function keys)
Half load
l
Economic l（50）
Rapid
l
Delicate glasses -
Pots -
6.
Technicaldata
Voltage/frequency V/Hz 240V~/50Hz
Nominal power W 2200
Main fuse (intensity) A 13
7.
Productdimensions
Unit dimensions (H x W x D) cm 85X60X60
Depth with open door cm 116
Net weight kg 43
8.
Built-In
Requested measures of niche (H x W x D) cm
Dimensions of door panel (H x W) cm
9.
Packing .
Dimensions of packing (H x W x D) cm 88X66X67.5
Weight of packing (all materials) kg 48
10.
Informations for importer
14,5 m (84 CBM.) Truck load capacity pcs -
Jumbo (120 CBM.) Truck load capacity pcs -
40' Container load capacity pcs -
40' HC load capacity pcs 162

- 7 -
Max. failure rate (12 Months after sales to end customer) pc/% -
11.
Packing materials/ Recycling symbols RS REzY
Carton (weight) g 4,600
Polistyren(weight) g 1,518
Polyetylenefoil (weight) g 65
Other packing materials (weight) g 55
Wood (weight) kg 0.15
12
Delivery Time of First Batch 10. 2003

- 8 -
SafetyPrecaution/Warning and cautions
4. SafetyPrecaution

- 9 -
SafetyPrecuation

- 10-
5.Warning and cautions
1.Shelf(The containerwhich dishes areput in is called shelf)
2.Put the shelf into the washingbox
3.Put in detergent
4.End of cycle
