Haier GDZ3.5-1-HK User manual

GDZ3.5-1
Exhaust Type Tumble Dryer
User's Manual
Please read this manual
carefully before using.
Retain it for future reference.

Contents
Specification
Rated Voltage Frequency
Rated Input Power
Rated Fuse Current
Rated Max.Capacity
Overall Dimension
Net Weight
Timer Selector Knob
Strong 1020W Light 670W
Hot air:220min hotair (20min coolingincluded)
Cold air: 60mincold air
SPECIFICATION
Names of the parts
Safety Information
Operation Cautions
Installation Instructions
Using Method
Care and Cleaning
Troubleshooting
Packing And Electrical Safety Tips The back cover

Part Description
Drum
Exhaust Shroud
Air Intake Shroud Timer Selector Knob
Heat Selector Knob
Door Power Cord Exhaust Vent
Back Cover
Casing
For your and the product s safety, the information
related to this symbol must be followed to prevent
dryer damage and personal injury
The information related to this symbol must be
definitely forbidden to prevent dryer damage and
personal injury
Warning
Forbidden
Meaning and descriptionof the symbols
Directions: Allthe figures inthe directions areschematic drawings. Weshould understand thatthe products
you bought orthe related elementsmay not matchthe figures inthe directions becausewe have
new products everyday.
Please check thepower point andthe ground connectioncarefully to securethe safety ofyou.
Transparent
window inside

Safety Information
Do not closeto combustible
materials
Keep your dryeraway from combustible
materials (such asgasoline) during
operation to preventthe risk offire.
Clothes not allowedto load
Clothes containing dry-cleaning solvents, gasoline,
alcohol, machinery oil and cooking oil, be sure that
oil have been throughly cleaned up before put them
into your dryer (the residual oil sometimes will cause
spontaneous combustion during drying operation.
Be careful!)
Location of theDryer
Do not use or place stove, gas device, water
heater, tinder or similars close to your dryer.
Do not locate your dryer in a place with heavy
moisture (like bathroom, water tap and a place
can be easily sprayed or without flashing) to
avoid failure or creepage.
Do not put it directly in sunlight to prevent fading.
Do not allowchildren to climb
Do not allow children to climb on or look
into the drum to prevent injures due to kids
climbing into the dryer.
Do not put kids or any thing alive into your dryer.
Do not excessively bend, stretch, twist, bind power cord or put heavy stuff on it.
Keep the terminator of power cord clean. Carefully clean it with dry cloth if dusts accumulated.
If damaged, power cord or plug must be replaced by our service agent or qualified after-sale
service person to avoid the risk of danger.
Ground
When normally using, the power cord of dryer shall
be easily plugged or unplugged by hand. It must be
unplugged during power blackout, moving, not in
use or cleaning. Do not plug or unplug the power
cord with wet hands.
This dryer shall be connected to a three-wire,
single phase, 220V AC power receptacle more
than 10A, which must be reliably grounded.
A leakage protector shall be used, if possible.
Do not share a receptacle with other appliances. Do not use it when a plug loosely inserted into a receptacle.

Operation Cautions
Do not block exhaust vent
Do not blockthe exhaust ventwhen dryer
operating to preventit from overheating
or other dangers.
Exhaust Vent
Do not operate on packing foam.
Do not let your dryer operate on packing foam,
a kind of non-flame retardant material. Otherwise
it maybe cause fire since heat accumulation or
other external factors.
Safety Information
Do not dry wools in your dryer
Wool will bedamaged.
Woolen clothes shrinkin drying,
which should beavoided.
Woollen
Dry Capacity
Do not exceed
3.5kg (weight
after dried)
Do not let wet clothes in your
dryer too long.
Do not place washed
wet clothes in your
dryer for a long time
not drying them
(which may result
in water leakage).
Sufficiently dehydrated
Only place sufficiently
dehydrated clothes
into your dryer for
drying ,wringing
out wet clothes by
hands should be
avoided to prevent
leakage and longer
drying time.
Do not place any hot or heavy
articles (such as hot kettle)
on your dryer
Clen the scrapsof thread intime
Each time you shouldclean the scraps of
thread promptly especially the scraps onthe
filter of the airexit.
Please do not takethe cover or thefilter net
out of the airexit in case theventilation will
be blocked up.

Operation Cautions
Clothes with ribbon or lace should
be dried in a nylon net
Put chemical fiber
and/or clothes with
ribbon or laceinto
a nylon netbefore
drying.
Clothes with zipper
Dry this kindof
clothes with zipper
zipped or fastener
buckled and inside
out (to reducethe
impact noise between
metal and thedrum)
Do not load your dryer when
it is running.
When bleacher used for wash
Rinse these clothes
throughly if them are
washed with bleacher
containing chlorin
before putting
them into your dryer.
Do not dry clearstarched clothes
in your dryer
Avoid todry starched
clothes in yourdryer to
prevent link filterfrom
clogging, which may
lead to badexhaust
performance.
Starch
Solution
Put rumpled clothes in order
Put all clothes
in order after
dehydrated
before
drying them.
Anti-wrinkle method for clothes
crumpled easily
Decrease capacity toget good anti-wrinkle
result (the capacityshall be 4/5of that of
normal clothes).
Capacity reduced
Capacity reduced
.
Loading the dryer
when it is running
shall be avoided to
prevent the clothes
overdried or
incompletely dried.
Remove the clothes out of your dryer as early as
possible to reduce rumples.
Please hang the easily crumpled clothes
up with a hanger after dried
Please flip clothesover manually from
time to time,if necessary, when drying
large ones.
It is noteasy to flip
over large clothes
(such as overcoat)
in the drum,
uneven drying
therefore
happens sometimes.
If necessary,flip them over
manually from timeto time tomake them
dried completely.
Flip over clothes

For your safety and correct using your dryer, please observe all the instructions in this manual to
install and adjust your dryer.
Installation Instructions
If the dryer is not used with bracket, take fixed legs out
of the accessory bag and screw them into the assembly
hole of the dryer to ensure it be placed stable.
Install and use the fixed legs of your dryer
Location of your dryer
Dryer should be located in a dry and well-vented place, not filled with moisture and vapors and
where rain cannot reach (like bathroom,open balcony and water faucet).Do not locate your dryer
in a place where sunlight directly shines.
Locate your dryer on horizontal solid ground, floor or a special
bracket to prevent vibration and noise. Keep a distance of
10cm-15cm away from the rear wall when installing.
Do not use stove, gas ans etc near your dryer to avoid dangers.
The dryer has air intake and exhaust cycles,which needs
good air-exhaust vent in the rear and well-vented room.
If used in a small space, air exchange fan or exhaust
duct can be installed at the vent to exhaust hot wet air outdoors.
The length of exhaust duct shall not exceed 2m.
Special bracket and exhaust duct are available at Haier after-sal service agent for purchsing.
10-15cm
10-15cm
Soft object
Fixed legs

Installation Instructions
Assembly of dryer and bracket
First assemble the bracket (detailed installation method
please refers to the instruction of bracket assembly).
Adjust to the proper height according to the washer type
you purchased (six height levels are available)
(Note: the bracket shall not be touched when the top cover
of washer is open to avoid inconvenient clothes loading
and unloading )
Carefully place your dryer onto the bracket with the control
panel in the bottom (as shown in the right figure).
Align assemble holes on the bracket with the installation
holes, screw and fasten them by the fixing screws and
washers attached.
After assembled, make sure that the distance between the
exhaust vent of the dryer and wall is more than 10-15cm.

Using Method
Using
1. Plug the power cord
The appliance shallbe supplied with220V,50Hz,
connected to aspecial receptacle morethan
10A (reliablygrounded).
2. Place the dehydrated clothes in your dryer
Check the followingitems before puttingclothes in.
They shall beloaded in sucha way that2-3 pieces
each time andnot in agroup to avoidtangling, which
is not easyto turn itover resulting inuneven drying
since the clotheswere wrapped.
Before drying your clothes
Make sure if clothes have any special requirements and suitable for drying.
Do not dry your clothes in your dryer if the materials of which cannot be dried
in a dryer or they bear the following labels:
Carefully check the clothes to be dried and remove combustible
material such as lighter and match as well as sharp metal items
like coin, hair clip and safety pin maybe mixed with the clothes
and in pockets.
Clothes with zipper or fastener shall be put into your dryer inside
out with zipper zipped and fastener buckled.
Do not tumble dry
Do not tumble dry
Hang to dry
Hang to dry Drip dry
Dry flat
Dry flat
Dry in the shade
Dry in the shade
Please put theclothes into thecylinder of themachine
leaving nothing outsidethe edge ofthe machine incase
the clothes willbe packed andtangled up orthe sealing
washer will bepulled out.All the errorsabove will result
in failure inthe drying.

According to theselected dry timeand heater workingor not,five dry
combinations are available:cooling,ironing,regulardry,extra dryand air fluff
Using Method
OFF
OFF
60
40
20
220
200
180 160 140
120
100
80
60
40
20
Regular Dry (min)
For drying laundryin large quantityin
one time (morethan 1/2 ofthe capacity
of drum) orparticularyly thicker clothes.
Timer set morethan 150 minuteswith
"Heat selector knob"in "Strong dry"
position to drythe clothes throughly.
For down,sweater,
mohair,cotton sweater
and cotton-padded
clothes needing
freshening,tumbles
without heat.Also can
be individually usedfor
clothes long timein
closet with the
same results.
For normal laundry,timer set between60 to
150 minutes andset "heat selectorknob" in "
Strong" or "Light"postion as required.After
the dryer stopsrunning, clothes normally
can be dried,cooled and anti-wrinkle.
Set "Dry Timer"between 30
to 60 minutesbased on
laundry quantity andset
"Heat selector knob"in "
Light" position.After the
timer stops (including
Cooling program),the
laundry will stillcontain
some moisture whichcan
be ironed withan
electrical iron. This
program is mainlyused for
laundry needs tobe ironed.
Motor keeps runningafter dryer time
heating finished whileheater stops
working and coldair into thedrum to
cool laundry.The whole coolingwill be
finished once thetimer knob getsto
"OFF " position.Its mainly usedfor
cooling the driedlaundry to prevent
rumples.
Power off whenthe
timer knob in
"OFF" position.
The dryer starts
when turn theknob
clockwise.
3. Control panel and its functions
Heat Selector Knob
Select "Strong Dry"for clothes particularlythick and inlarge
quantities or inlower room temperature.
Select "Light Dry"for clothes notresistant to heat(like nylon,
chemical fibre andsilk.
Strong
Light
Select drying levelaccording to thematerial, quantity anddrying
requirements of theclothes to bedried as shownin the figure
Heat Selector Knob
Drying Timer Knob
Strong Dry Regular Dry
Anti-wrinkle
Air Fluff
Cooling
OFF
Air Fluff Cooling

Using Method
6. Do not take the laundry out until drying process is done
The last 20minutes of hotair drying is
cooling to reducethe temperature of
laundry inside thedrum.
To takethe laundry outduring drying,
please run coolingoperation first since
the temperature insidethe drum must
be high.
Static electricity,due to friction,will be
generated on clothesmade of chemical
fiber after dried.You can feel itwhen
taking them out,which is normaland
shall not tobe worried about.
7. Unplug the power cord
Please hold plugto unplug powercord
from a receptacle.Do not pullelectrical
wire directly toprevent internal breakage
or bad connection.
8. Clean filters
Refer to theinstructions on page11.
5. Dry time settings
Please refer topage 9 "functionsof control panel".
4. Set "heat selector knob" to select "Strong dry" or
"Light dry" level.
"Strong dry" levelfor large quantityand low roomtemperature.
"Light dry" fornon heat-resistant clothes. Light
Heat selector knob
Select dry programaccording to clothesmaterials and quantity,
turn the timerknob to relativeposition. The dryerstarts running.
Strong

Do not wash directly with water.
Clean it with neutral detergent.
Do not use thinner,gasolene or alcohol.
Clean the buildup such as lints on filters in time after each use, otherwise it will affect
the performance of your dryer.
Please unplug the power cord first when cleaning it.
1. Remove the filters
Remove by pulling straight up with hands inserted
into the four holes around the exhaust vent shroud
in the sequence of "Exhaust vent shroud - Lint filter -
Exhaust filter", as shown in figure 1.
3. Install the filters
After cleaning, assemble in the sequence of "exhaust filter
-filter-exhaust vent shroud",align the recesses in the center
of filter with the projection in the center of drum and make
sure that it is firmly inserted (as shown in figure 3).
2. Clean the lints
Separate "exhaust vent shroud","lint filter" and "exhaust
filter" and clean the lints on the filter and exhaust filter
with a soft brush or vacuum cleaner.
Do not damage the filters (as shown in figure 2)
The lint filter must be used for drying.
It must be cleaned in time after each use.
Cleaning of filters
Note:The filter fixed in the bottom of the drum shall also
be cleaned with a soft brush.
Lints
Exhaust
vent shroud
Figure 1
Cleaning of theair intake filter
Remove by pullingoutwards with holdingthe upper and
lower ends ofthe air intakeshroud. Remove thefilter
inside the shroudand clean itwith a softbrush or cleaner.
Reassemble and installit back asbefore.
The filter shallbe cleaned approximatelyevery month.
Slightly push upwards
with your thumb until
latch hook disconnected
and take it out.
Air Intake Shroud
Air Intake Filter
Air Intake Filter
Clean the interiordrum or dryerhousing,
with wet softcloth, if stained.
Cleaning of Housing
Lint
filter
Lint Filter
Exhaust
Filter
Exhaust Filter
Figure 3
Care and Cleaning
Dust Cleaner
Figure 2

(If your dryer exhibits problems, please unplug the power cord before checking) The following maybe
unrelated to a malfunction of the dryer itself, please reconfirm before calling a serviceman. If it does
relate to a malfunction, please contact our service agent or after-sales service and do not repair it
by yourself.
Troubleshooting
Problem Possible Cause What to do
Is the doorclosed?
Is the powercord inserted firmly?
Does the receptaclehave power?
Have the dryer have been
added during operation?
Is the timerincorrectly
set up incold air?
Timer knob does not turn
Drum does notturn
No hot airblown out
Close the door.
Insert the powercord firmly
Check the power cord receptacle.
Set to hotair
Clean the filter.
Are the frontand back filters
clogged?
Dryer does not start
Is the timer in OFF position? Set dry time
Is power failure?
Is the power cord inserted firmly?
Try again after power recovered
Insert the power cord firmly
Reduce the laundryquantity.
Have the clothes
been fully dehydrated? Dehydrate the laundrycompletely.
Is the laundrytoo much?
The laundry is not
throughly dried (some
of the clothes still wet
after dryer stops)
Is the powercord inserted? Insert the powercord firmly.
Is the doorclosed? Close the door
Does the laundry twist? Loose the twisted laundry and
dry again.
Have any clothes dry easily and
hardly been dried together? Dry the undried laundry again.
Dry the undried laundry again.
Is the dryer placed in a small
and badly-vented space?
Place the dryer in a well-vented place.

Packing Notes
Use Manual
Designation
Warranty certificate
One
Quantity
Four
One
Legs of the dryer
Drum-type dryer
One
Electrical Safety Tips
Please be careful when using your dryer since this product is class appliance.
1.Reliably grounded power supply must be used with the earth wire buried
underground. Do not connect with public utilities such as water pipe.
Separate earth wire from zero line and do not connect them together.
2. An individual sepcial receptacle must be used, which shall be a product
have been qualified by national compulsive product certification.
For your and your family's safety, please improve as soon as possible
if any discrepancies with the above-mentioned requirements existed.
