Haier HTF-456WM6 User manual

GB
User Manual
Refrigerator-Freezer
HTF-456WM6
HTF-456WB6

Thank You GB
2
Legend
Warning – Important Safety information
General information and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic ap-
pliances. Do not dispose appliances marked with this
symbol with the household waste. Return the product
to your local recycling facility or contact your municipal
oce.
Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions con-
tain important information which will help you get the best out of the appliance and ensure
safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure
you also pass this manual so that the new owner can become familiar with the appliance
and safety warnings.
WARNING!
Risk of injury or suocation!
Refrigerants and gases must be disposed of professionally. Ensure that the tubing of
the refrigerant circuit is not damaged before being properly disposed of. Disconnect
the appliance from the mains supply. Cut o the mains cable and dispose of it. Remove
the trays and drawers as well as the door catch and seals, to prevent children and pets
to get closed in the appliance.

GB Content
3
1- Safety information..................................................................................................................... .4
2- Intended use ............................................................................................................................... .8
3- Product description .................................................................................................................. .9
4- Control panel..............................................................................................................................10
5- Use................................................................................................................................................11
6- Energy saving tips.....................................................................................................................19
7- Equipment ..................................................................................................................................20
8- Care and cleaning .....................................................................................................................23
9- Troubleshooting........................................................................................................................26
10- Installation................................................................................................................................29
11- Technical data .........................................................................................................................32
12- Customer service...................................................................................................................33

1- Safety information GB
4
Before switching on the appliance for the rst time read the fol-
lowing safety hints!:
WARNING!
Before rst use
▶Make sure there is no transport damage.
▶Remove all packaging and keep out of children´s reach.
▶Wait at least two hours before installing the appliance in order to
ensure the refrigerant circuit is fully ecient.
▶Handle the appliance always with at least two persons because it
is heavy.
▶Installation
▶The appliance should be placed in a well-ventilated place. Ensure a
space of at least 10 cm above and around the appliance.
▶Never place the appliance in a damp area or location where it might
be splashed with water. Clean and dry water splashes and stains
with a soft clean cloth.
▶Do not install the appliance in direct sunlight or in the near of heat
sources(e.g. stoves, heaters).
▶Install and level the appliance in an area suitable for its size and use.
▶Keep ventilation openings in the appliance or in the in-built struc-
ture clear of obstruction.
▶Make sure that the electrical information on the rating plate agrees
with the power supply. If it does not, contact an electrician.
▶The appliance is operated by a 220-240 VAC/50 Hz power sup-
ply. Abnormal voltage uctuation may cause the appliance to fail
to start, or damage to the temperature control or compressor, or
there may be an abnormal noise when operating. In such case, an
automatic regulator shall be mounted.
▶Do not use multi-plug adapters and extension cables.
▶Ensure that the power cable is not trapped by the refrigerator. Do
not step on the power cable.

GB 1- Safety information
5
WARNING!
▶Use a separate earthed socket for the power supply which is easy
accessible. The appliance must be earthed.
Only for UK: The appliance’s power cable is tted with 3-cord
(grounding) plug that ts a standard 3-cord (grounded) socket.
Never cut o or dismount the third pin (grounding). After the ap-
pliance is installed, the plug should be accessible.
▶Do not damage the refrigerant circuit.
Daily use
▶This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
▶Keep away children under 3 years of age from the appliance unless
they are constantly supervised.
▶Children shall not play with the appliance.
▶If cool gas or other inammable gas is leaking in the vicinity of the
appliance, turn o the valve of the leaking gas, open the doors and
windows and do not unplug a plug in the power cable of the refrig-
erator or any other appliance.
▶Notice that the appliance is set for operation at a specic ambient
range between 10 and 43°C. The appliance may not work properly
if it is left for a long period at a temperature above or below the
indicated range.
▶Do not place unstable articles (heavy objects, containers lled with
water) on top of the refrigerator, to ovoid personal injury caused by
falling or electric shock caused by contact with water.
▶Do not pull on the door shelves. The door may be pulled slant, the
bottle rack, may be pulled away, or the appliance may topple.
▶Open and close the doors only with the handles. The gap between
the doors and between the doors and the cabinet is very narrow.
Do not extend your hands in these areas to avoid pinching your
ngers. Open or close the refrigerator doors only when there are
no children standing within the range of door movement.

1- Safety information GB
6
WARNING!
▶Do not store or use inammable, explosive or corrosive materials
in the appliance or in the vicinity.
▶Do not store medicines, bacteria or chemical agents in the ap-
pliance. This appliance is a household appliance. It is not recom-
mended to store materials that require strict temperatures.
▶Never store liquids in bottles or cans (besides high percentage
spirits) especially carbonated beverages in the freezer, as these
will burst during freezing.
▶Check the condition of food if a warming in the freezer has taken
place.
▶Do not set unnecessarily low temperature in the refrigerator com-
partment. Minus temperatures may occur at high settings. Atten-
tion: Bottles can burst
▶Do not touch frozen goods with wet hands (wear gloves). Espe-
cially do not eat ice lollies immediately after removal from the
freezer compartment. There is the risk to freeze or the formation
of frost blisters. FIRST aid: keep immediately under running cold
water. Do not pull away!
▶Do not touch the inside surface of the freezer storage compart-
ment when in operation, especially with wet hands, as your hands
may freeze onto the surface.
▶Unplug the appliance in the event of a power interruption or be-
fore cleaning. Allow at least 5 minutes before restarting the appli-
ance, as frequent starting may damage the compressor.
▶Do not use electrical devices inside the food storage compart-
ments of the appliance, unless they are of the type recommended
by the manufacturer.
▶Only use drinking water for the water dispenser.
Maintenance / cleaning
▶Make sure children are supervised if they carry out cleaning and
maintenance.
▶Disconnect the appliance from the electrical supply before under-
taking any routine maintenance. Allow at least 5 minutes before
restarting the appliance, as frequent starting may damage the
compressor.

GB 1- Safety information
7
WARNING!
▶Hold the plug, not the cable, when unplugging the appliance.
▶Do not clean the appliance with hard brushes, wire brushes, de-
tergent powder, petrol, amyl acetate, acetone and similar organic
solutions, acid or alkaline solutions. Please clean with special re-
frigerator detergent to avoid damage.
▶Do not scrape o frost and ice with sharp objects. Do not use
sprays, electric heaters like heater, hair dryer, steam cleaners or
other sources of heat in order to avoid damage to the plastic parts.
▶Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the man-
ufacturer.
▶If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualied persons in order to
avoid a hazard.
▶Do not try to repair, disassemble or modify the appliance by your-
self. In case of repair please contact our customer service.
▶Eliminate the dust on the back of the unit at least once in the year
to avoid hazard by re, as well as increased energy consumption.
▶Do not spray or ush the appliance during cleaning.
▶Do not use water spray or steam to clean the appliance.
▶Do not clean the cold glass shelves with hot water. Sudden tem-
perature change may cause the glass to break.
Refrigerant gas information
WARNING!
The appliance contains the ammable refrigerant ISOBUTANE
(R600a). Make sure the refrigerant circuit is not damaged during
transportation or installation. Leaking refrigerant may cause eye
injuries or ignite. If a damage has occurred, keep away open re
sources, thoroughly ventilate the room, do not plug or unplug the
power cords of the appliance or any other appliance. Inform the
customer service.
In case of eyes get into contact with the refrigerant, rinse immedi-
ately it under running water and call immediately the eye specialist.

2- Intended use GB
8
2.1 Intended use
This appliance is intended for cooling and freezing food. It has been designed exclusively
for use in household and similar applications such as sta kitchen areas in shops, oces
and other working environments; farm houses and by clients in hotels, motels and other
residential type environments as well as in bed-and-breakfast and catering business. It is
not intended for commercial or industrial use.
Changes or modications to the device are not allowed. Unintended use may cause haz-
ards and loss of warranty claims.
CAUTION!
When you close the door, the vertical door strip on
the left door should be bent inside (1).
If you try to close the left door and the vertical door
strip is unbent (2), you should bend it rstly, other-
wise the door strip will hit the xing shaft or right
door. Thus a damage to the door slip or a leak will
occur.
There is a heating thread inside the frame. The tem-
perature of the surface will rise a little, which is nor-
mal and won´t aect the function of appliance.
1.
2.
Energy-
lable
Egg trays
Ice maker with
ice scoop User
manual
Warranty
card
3 spacers
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.:2.2):
2.2

GB 3- Product description
9
will be
modied
A
B
14
12
13
4
1
5
15
2
6
7
28
9
10
11
3
1
16
17
3.1
9
3.2 A: Refrigerator compartment
1 Rating plate
2 Bottle holder/Door rack
3 Glass shelves
4 Humidity zone drawer
5 Door strip
6 Ceiling lamp
7 Air duct and sensor (behind panel)
8 Water tank
9 Water dispenser
10 O.K.-temperature indicator (optional)
11 Air duct (behind drawers)
12 Dry zone drawer
B: Freezer compartment
13 Ice maker with ice scoop
14 Freezing tray
15 Freezer storage drawer
16 Air duct
17 Adjustable feet
Notice
Due to technical changes and dierent models, some of the illustrations in this manual
may dier from your model.
Pictures of appliances (Fig. 3.1 and 3.2)

4- Control panel GB
10
Buttons:
A Fridge selector
B Freezer selector
C SMART mode and holiday function on/o
D Power Cool function on/o
E Power-Freeze function on/o
F Panel lock /unlock
Indicators:
a Temperature fridge compartment
b Temperature freezer compartment
c1 holiday mode
c2 SMART mode
d Power Cool function
e Power Freeze function
f Panel lock
Control panel (Fig. 4)
NO FROST
Refrigerator
Freezer
SMART
Power Cool
Power Freeze
Hold on
3 sec.
unlock
Hold on 3 sec.
holiday function
NO FROST
Fridge
Freezer
SMART
Power Cool
Power Freeze
Lock
Hold 3 sec.
3 sec holiday
a
b
c1
c2
d
e
f
B
A
C
D
F
E
4

GB 5- Use
5.1 Before rst use
▶Remove all packaging materials, keep them out of children`s reach and dispose
them in an environmentally friendly manner.
▶Clean the inside and outside of the appliance as well as the interior and accessories
with water and a mild detergent and dry it well with soft cloth.
▶After the appliance has been levelled and cleaned, wait for at least 2 hours before
connecting it to the power supply. See Section INSTALLATION.
▶Precool the compartments at high settings before loading with food. The function
Power-Freeze helps to cool down the freezer compartment quickly.
▶The refrigerator temperature and freezer temperature are automatically set to 5° C
and -18° C respectively. These are the recommended settings. If desired, you can
change these temperatures manually. Please see ADJUST THE TEMPERATURE.
11
5.2 Sensor keys
The buttons on the control panel are sensor keys, which already respond when lightly
touched with the nger.
5.3 Switch on /o the appliance
The appliance is in operation as soon as it is connected to the power supply.
When the appliance is powered on for the rst time, the actual refrigerator and freezer
temperatures are displayed. The display will ash. If the doors are closed it will switch o
after 30 seconds.
Maybe the panel lock is active.
Notice: Panel lock
The control panel is automatically blocked against
activation if 30 seconds no key is touched. For any
settings the control panel must be unlocked.
▶Touch key “F” for 3 seconds to block all panel ele-
ments against activation (Fig. 5.5-1).
▶The buzzer alarms and the related indicator “f” is
5.5 Lock/unlock panel
Lock
Hold 3 Sec.
5.5-15.5-2
5.4 Standby-mode
The display screen turns o automatically 30 seconds after pressing a key. The display will
be automatically locked. It lights up automatically by touching any key or opening the door .
Notice: Presettings
▶The appliance is preset to the recommended temperature of 5°C (refrigerator) and
- 18°C (freezer). Under normal ambient condition you need not to set a temperature.
▶When the appliance is switched on after disconnection from the main power supply, it
may take up to 12 hours for the correct temperatures to be reached.
Empty the appliance before switching o. To switch o the appliance,pull the power cord
out o the power socket.

5- Use GB
12
SMART
sec. holiday
SMART
3 sec. holiday
now displayed (Fig. 5.5-2); the lightening of the panel is switched o. The icon ashes
if a button will be pressed, when the panel lock is activated. The change is not running.
▶For unlocking touch again the key.
5.6 Door opening alarm
When the refrigerator door is opened for more than 3
minutes, the door opening alarm will sound (Fig. 5.6).
The alarm can be silenced by closing the door. If the
door is left open for more than 7 minutes, the light in-
side the refrigerator and control panel illumination will
automatically switch o.
5.6
5.7.1 SMART mode
If you do not have any special requirements, we recom-
mend that you use fuzzy mode :
In the Fuzzy mode, the appliance can automatically ad-
just the temperature setting according to the ambient
temperature and temperature change in the appliance.
This function is totally hand free.
1. Unlock the panel by touching key “F” if it is locked
(Fig. 5.5-1).
2. Touch key “C” (SMART) (Fig. 5.7.1-1). An alarm
sounds.
3. Indicator “c2” illuminates and the function is acti-
vated (Fig. 5.7.1-2).
By repeating the above steps or selecting an other
function this function can be switched o again.
5.7.1-1 5.7.1-2
5.7 Select the working mode
One of the following options can be selected:
5.7.2 Manual adjusting mode
If you want to manually adjust the temperature of the
appliance in order to store a particular food, you can
set the temperature via a temperature adjusting key:
Notice: Conict with other functions
The temperature cannot be adjusted, if any other function (Super-Cool, Super-Freeze,
Holiday or SMART) is activated or the display is locked. The corresponding indicator will
ash accompanying with a buzzer.

GB 5- Use
13
5.7.2.1 Adjust the temperature for fridge
1. Unlock the panel by touching key “F” if it is locked
(Fig. 5.5-1).
2. Touch key „A“ (Fridge) for select the fridge com-
partment. An alarm sounds. The actual tempera-
ture in the refrigerator compartment is displayed
(Fig. 5.7.2-1).
3. Touch sequentially key “A” (Fridge) until the
desired value of temperature is ashing (Fig.
5.7.2-2). A signal will sound at each key touch.
The temperature increases in sequences of 1°C
from aminimumof 0°C(OFF)toamaximum of8°C.
The optimum temperature in the refrigerator is
5 °C. Colder temperatures mean unnecessary
energy consumption.
If no key is operated in 5 sec., the setting conrms au-
tomatically.
Fridge
Fridge
5.7.2-2 5.7.2-1
5.7.2.2 Adjust the temperature for freezer
1. Unlock the panel by pressing button “F” if it is
locked (Fig. 5.5-1).
2. Touch key “B” (Freezer) for select the freezer com-
partment. An alarm sounds. The actual tempera-
ture in the freezer compartment is displayed (Fig.
5.7.2-3).
3. Touch sequentially key “B” (Freezer) until the
desired value of temperature is ashing (Fig.
5.7.2-4). A signal will sound at each key touch.
The temperature increases in sequences of 1°C
from a minimum of -14°C to a maximum of -24°C,
switching to -14°C again when pressing further.
The optimum temperature in the freezer is -18°C.
Colder temperatures mean unnecessary energy
consumption.
If no key is operated in 5 sec., the setting conrms au-
tomatically.
FreezerFreezer
5.7.2-3
5.7.2-4
Notice: “Fridge-o“ function
By setting the temperature for the refrigerator compartment to 0°C (OFF) you can shut
down the refrigerator. This has no eect on the freezer compartment.
▶Empty the appliance before switching o.
▶Keep the door of the refrigerating compartment open, when „Fridge-o“ function is
activated, in order to avoid odour or mold..

5- Use GB
14
5.9 Power Freeze function
Fresh food should be frozen as quickly as possible to
the core. This preserved the best nutritional value, ap-
pearance and taste. The Power Freeze function ac-
celerates the freezing of fresh food and protects the
goods already stored from undesirable warming. If
you need to freeze a large amount of food once, it is
recommended to set the Power Freeze function on
ahead for 24 h before the usage of frozen room. The
function setting temperature is below -24 °C.
1. Unlock the panel by touching key “F” if it is locked
(Fig. 5.5-1).
2. Touch key “E” (Power Freeze) (Fig. 5.9.-1).
3. Indicator “e” illuminates and the function is acti-
vated (Fig. 5.9.-2).
By repeating the above steps or selecting an other
function this function can be switched o again.
Power Freeze
Power Freeze
5.9-1 5.9-2
5.8 Power Cool function
Switch on the Power Cool function if larger quantity
of food should be stored (for example after the pur-
chase). The Power-Cool function accelerates the
cooling of fresh food and protects the goods already
stored from undesirable warming. The factory setting
temperature is 0 to +1°C.
1. Unlock the panel by touching key “F” if it is locked
(Fig. 5.5-1).
2. Touch key “D” (Power Cool) (Fig. 5.8.-1).
3. Indicator “d” illuminates and the function is acti-
vated (Fig. 5.8.-2).
By repeating the above steps or selecting an other
function this function can be switched o again.
Power Cool
Power Cool
5.8-1 5.8-2
Notice: Automatically switch o
This function will be automatically disabled after 3 hours.
Notice: Inuences on temperatures
The indoor temperatures are inuenced by the following factors:
▶Ambient temperature
▶Frequency of door opening ▶Amount of stored foods
▶Installation of the appliance

GB 5- Use
A
C
15
5.10 Holiday function
This function sets the refrigerator temperature per-
manently to 17°C.
This allows to keep the door of the empty refrigera-
tor closed without causing an odour or mold - during
a long absence (e.g. during holiday). The freezer com-
partment is free for your setting.
1. Unlock the panel by touching key“F” if it is locked
(Fig. 5.5-1).
2. Touch key “C” (SMART) for 3 seconds (Fig. 5.10.-1).
3. Indicator “c1” illuminates (Fig. 5.10.-2).and the
function is activated.
By repeating the above steps or selecting an other
function this function can be switched o again.
SMART
3 sec. holiday
SMART
3 sec. holiday
5.10-15.10-2
Notice: Automatically switch o
The Super-Freeze function will automatically switch o after 50 hours. The appliance is
then operated at the previously set temperature.
WARNING!
During the Holiday function no goods must be stored in the refrigerator compartment.
The temperature of + 17 ° C is too high for storing food.
5.11 Water dispenser
With the water dispenser cool drinking water can be tapped.
The water tank should be cleaned before rst use (see CARE AND CLEANING).
WARNING!
Use drinking water only.
1. Ensure that the water tank is properly inserted
(see EQUIPMENT)
2. Rotate and lift the round lid (A)and ll the water
tank up with fresh drinking water (Fig. 5.11.1).
3. Fill water only up to the mark (1.8 l); as it could
overow when the door opens and closes.
4. Close the round lid (A) until it clicks into place.
5.11.1 Filling the water tank
5.11.1

5- Use GB
16
Notice: Water dispenser
▶Before relling dispose residual water and clean the water tank.
▶When you don‘t need water for a long time, please empty the water tank and insert
the cleaned tank.
▶The cover (C) on the water tank (Fig. 5.11.1) is additionally used to save energy. If you
do not want to get water from the water dispenser for a long period, please still install
the cover because of better insulating and saving energy.
5.11.2 Getting water from the dispenser
1. Place a glass underneath the water outlet.
2. Push it gently against the water dispenser lever
(Fig. 5.11.2).
Make sure the glass is in line with the dispenser to
prevent the water from splashing out
3. Water in the tray (B) should be removed in time,as
it could overow when the door opens and closes.
WATER DISPENSER
5.11.2
B

GB 5- Use
17
5.12 Tips on storing fresh food
5.12.1 Storing into the refrigerator compartment
▶Keep your fridge temperature below 5°C.
▶Hot food must be cooled to room temperature before storing in the appliance.
▶Foods stored in the refrigerator should be washed and dried before storing
▶Food to be stored should be properly sealed to avoid odour or taste alterations.
▶Do not store excessive quantities of food. Leave spaces between foods to allow cold
air owing around them, for a better and more homogeneous cooling.
▶Foods eaten daily should be stored at the front of the shelf.
▶Leave a gap between foods and the inner walls, allowing air owing. In special way
don’t store foods against the rear wall: foods could freeze against rear wall. Avoid di-
rect contact of food (especially oily or acidic food) with the inner liner, as oil/acid can
erode the inner liner. Clean away oily/acid dirt whenever it is found.
▶Defreeze frozen food in the fridge storage compartment. This way, you can use the
frozen food to decrease the temperature in the compartment and save energy.
▶The ageing process of fruit and vegetables such as courgettes, melons, papaya, ba-
nana, pineapple, etc. can be accelerated in the refrigerator. Therefore, it is not advis-
able to store them in the refrigerator. However, the ripening of strongly green fruits
can be promoted for a certain period. Onions, garlic, ginger and other root vegeta-
bles should also be stored at room temperature.
▶Unpleasant odours inside the fridge are a sign that something has spilled and clean-
ing is required. See CARE AND CLEANING.
▶Dierent foods should be placed in dierent areas according to their properties (Fig.
5.12):
1 Butter, cheese, etc.
2 Eggs, cans, canned food, spices, etc.
3 Drinks and bottled foods.
4 Pickled foods, canned food, etc.
5 Meat products, snack foods, pasta, canned
food, milk, tofu, dairy etc.
6 Cooked meat, sausages, etc.
7 Dry zone drawer : dry fruits, butter oils, choco-
late
8 Humidity zone drawer: Fruit, vegetables, sal-
ad, etc.
3
1
2
3
14
5
6
7
8
5.12
Notice: Keep distance
▶Please keep the distance more than 10 mm between the food placed and air duct or
sensors to ensure the cooling eect.

5- Use GB
5.12.2 Storage into the freezer compartment
▶Keep the freezer temperature at- 18°C.
▶24 hours before freezing switch on the Power-freeze function; -for small quantities
of food 4-6 hours are sucient.
▶Hot food must be cooled to room temperature before storing in the freezer com-
partment.
▶Food cut into small portions will freeze faster and be easier to defrost and cook. The
recommended weight for each portion is less than 2.5 kg
▶It is better to pack food before putting it into the freezer. The outside of the pack-
aging must be dry to avoid bags sticking together. Packaging materials should be
odour-free, airtight, non-poisonous and nontoxic.
▶In order to avoid expiration of storage periods, please note the freezing date, time
limit and name of the food on the packaging according to the storage periods of dif-
ferent foods.
▶WARNING!: Acid, alkali and salt etc. could erode the internal surface of the freezer.
Do not place the food having these substances (e.g. sea sh) directly on the internal
surface. Salt water in the freezer should be cleaned up immediately.
▶Do not exceed the food storage times recommended by the manufacturers. Only
take the required amount of food out of the freezer.
▶Consume defrosted food quickly. Defrosted food cannot be re-frozen unless it is
rst cooked, otherwise it may bless edible.
▶Do not load excessive quantities of fresh food in the freezer compartment. Refer
to the freezing capacity of the freezer – See TECHNICAL DATA or data at the type
plate.
▶Food can be stored in the freezer at a temperature of at least -18°C for 2 to 12
months, depending on its properties (e.g., meat: 3-12 months, vegetables: 6-12
months)
▶When freezing fresh food, avoid bringing it in contact with already frozen food. Risk
of thawing!
When storing commercially frozen foods, please follow these guidelines:
▶Always follow manufacturers’ guidelines for the length of time you should store food
for. Do not exceed these guidelines!
▶Try to keep the length of time between purchase and storage as short as possible to
preserve food quality.
▶Buy frozen foods, which have been stored at a temperature of –18 °C or below.
▶Avoid buying food which has ice or frost on the packaging – This indicates that the
products might have been partially defrosted and refrozen at some point – temper-
ature rises aect the quality of food.
18
Notice: Keep distance
▶Please keep the distance more than 10 mm between the food placed and air duct to
ensure the cooling eect.

GB 6- Energy saving tips
19
Energy saving tips
▶Make sure the appliance is properly ventilated (see INSTALLATION).
▶Do not install the appliance in direct sunlight or in the near of heat sources(e.g. stoves,
heaters).
▶Avoid unnecessarily low temperature in the appliance. The energy consumption in-
creases the lower the temperature in the appliance is set.
▶Functions like POWER- FREEZE or POWER-COOL consume more energy.
▶Allow warm food to cool down before placing it in the appliance.
▶Open the appliance door as little and as briey as possible.
▶Do not overll the appliance to avoid obstructing the air ow.
▶Avoid air within the food packaging.
▶Keep door seals clean so that the door always closes correctly.
▶Defreeze frozen food in the fridge storage compartment.

7- Equipment GB
20
7.1 Multi-air-ow
The refrigerator is equipped with a multi-air-ow sys-
tem, with which cool air ows are located on every
shelf level (Fig. 7.1). This helps to maintain a uniform
temperature to ensure that your food is kept fresher
for longer.
7.1
7.3 Dry zone drawer
In this compartment the humidity level is around 45% This drawer is suitable to store dry
fruit and other dry food with low water content like like butter, fats and oils or chocolate.
7.2 Adjustable shelves
The height of the shelves can be adjusted to t your
storage needs.
1. To relocate a shelf, remove it rst by uplifting its
hind edge (1) and pulling it out (2) (Fig. 7.2).
2. To reinstall it, put it on the lugs on both sides and
push it to the most rearward position until the rear
of the shelf is xed inside the slots in the sides
7.2
7.4 Humidity zone drawer
In this compartment the humidity level is around 85%. It is controlled automatically by the
system and is suitable to store fruits,vegetables, salads etc.
Notice: Humidity drawer
▶Do not remove the plastic cover inside the two zones.
They maintain the humidity.
▶Cold-sensitive fruits like pineapple, avocado, bananas,
grapefruits and vegetables such as potatoes, auber-
gines, beans, cucumbers, zucchini and tomatoes and
cheese should not be stored in these two drawers.
Notice: Shelves
Ensure that all ends of a shelf are level.
