Haier HSU-09LA10 - annexe 1 User manual

Cool only type has no HEAT mode.
Remove the batteries if the remote controller is not to be used for long periods of time.
1
NOTICE:
REMOTE CONTROLLER
Don't tear the batteries apart or throw them into fire, which will lead to irreparable damage.
TIMER&SET OPERATION
ON/OFF timer operation set
ON/OFF timer operation cancellation
¡± ¡±
when the air conditioner is on or off to initiate the
OFF or ON TIMER function.
Every press of button Timer/ increases the ON/OFF time by one hour(24
hours at most).
Press button Timer/CL
CL
¡±
If you want timer operation cancelled, press button Timer/ until the icon
of timer“ ”,the time and “hours on” or “hours off” disappear on the remote
controller display.
CL
To operate,the distance shouldbe within 6 meters from the indoor unit witha clear
line of sight.
Press it to fix the timer setting or
to
set the clock to the present time.
It sends signals to the indoor unit.
Signal ejecting window
OPERATION DISPLAY
OPERATION
MODE button
COOL HEAT FAN DRY AUTO
It displays the current
settings.
Press it to select operation mode:
TEMPERATURE
ADJUSTMENT buttons RUN/STOP button
Press it once, the setting tempera-
-ture decreases by 1 .The range of
setting temperature is 16-31 .
Turns unit ON/OFF.
FAN SPEED button
SLEEP button
Press it to change the fan speed
in the order of low-medium-high
-auto ( ).
TIMER SET/CLOCK button
AUTO
UP&DOWN SWING button
TEMPERATURE
ADJUSTMENT buttons
LEFT&RIGHT SWING button
TURBO button
DISPLAY button
Press it to start turbo function
and press again to stop it.
Press it once to stop the indoor
unit displaying and press again
to make it display.
Press it once, the setting tem-
-perature increases by 1.
Timer operation
Note: When the air conditioner is on timer operation,if you want to reset the
timer you must cancel the former timer, or the setting will not in accord with
actual condition.
¡± ¡±
As long as the remote controller is on power, the clock will run all the time
and it can be adjusted in any condition even when the air conditioner is off.
While the air conditioner is electrified for the first time, the time of the clock
is “ 0:00 ”, the flash of “: ” means the clock counts the time automatically.
Press the button “Timer/ ” for 3 seconds, the time of the clock can be
adjusted. At that time the time of hour flashes, during this period you can
add the time of hours by pressing the button “ ” and reduce the time by
pressing the button“ ”. After setting the time of hour, press the button
Timer/ again to adjust the time of minute(do not need to press it for 3
seconds).When the time of minute flashes, press the button“ ” to add the
time of minute, and press the button “ ” to reduce it. Finish setting the time
of minute, press the button “Timer/ ” for the third time to confirm the time of
the clock.
CL
CL
CL
¡±
Clock set
Note: The time of the clock will only display when the air conditioner isn't set
timer, otherwise it will not display.
2
¡æ
123
TURBO
SLEEP
DISPLAY
TIMER/CL.
MODE
FAN SPEED
I/O
SWING FAN AUTO SWING
Please see“sleep mode”.
As this is a all-purpose remote controller which contains many functional buttons, please refer
to the function of the air conditioner to know about the actual function.
34
5. HEAT mode (only applied to heat pump type)
COOL mode
Press UP & DOWN SWING button to change up/down air flow direction
and LEFT & RIGHT SWING button to change left/right air flow direction.
Press FAN SPEED button to change the fan speed of indoor unit.
Press TEMPERATURE ADJUSTMENT button to change the set temperature.
Press MANUAL SWING button or SWING button to change up/down air
flow direction.
Press FAN SPEED button to change the fan speed of indoor unit.
Press TEMPERATURE ADJUSTMENT button to change the set temperature.
¡± ¡±
OPERATION MODE ADJUSTMENT
4.
FAN mode
DRY mode
2.
3.
Mode Mode
24
26
RT-2 RT-2
Cool Cool
Dry RT-2 RT-2
Dry
Heat
24
21
Room
Temperature (RT)
RT26
25 RT 23
Rt 23
26 RT 25
Heat pump type
Cool only type
Initial Setting Temperature Initial Setting Temperature
1.
AUTO mode
In this mode, the air conditioner can automatically adjust the room
temperature to decide the most suitable temperature. At the start of
operation, the air conditioner will automatically select the operation mode
according to the room temperature. The following table shows the
conditions which are set at start up.
In this mode, the air conditioner automatically sets the room temperature
and this temperature will not appear on display.
TEMPERATURE ADJUSTMENT button and FAN SPEED button are not
functional.
Press UP & DOWN SWING button or LEFT & RIGHT SWING button to
change air flow direction.
In this mode, the outdoor unit does not operate. The indoor fan alone
operates.
Press UP & DOWN SWING button or LEFT & RIGHT SWING button to
change air flow direction.
Press FAN SPEED button to change the fan speed of indoor unit.
6. TURBO function (only applied to turbo series)
This function will make the air conditioner heat or cool quickly and during
this period, the noise of the air conditioner will increase. Turbo function
can be only started up in heat or cool mode(turbo heating or turbo cooling)
otherwise, it can not be started up. When the air conditioner is in cool or
heat mode, press turbo button to initiate turbo function, the remote con-
-troller displays “TURBO”and the icon of fan speed is “ ”,meanwhile
the air conditioner cannot be controlled by the remote controller. Press
turbo button again or start up sleep mode or transit modes to exit turbo
function. After exiting turbo function the fan runs at low speed.
hours OnOff
AUTO
AUTO
Please see“adjustment of air flow
direction”.
Please see“adjustment of air flow
direction”.
UP & DOWN SWING function
Every press ofthe UP & DOWN SWINGbutton, the angleof the
up and downswing louver willchange in theorder of
. When itswings automatically, the
swing icon displaysdynamically, meanwhile the letter
displays above theicon.
SWING
SWING“”
LEFT & RIGHT SWING function(only applied to left
& right swing series)
Every press ofthe LEFT & RIGHT SWING button, theangle of the
swing louver willchange in theorder of
. When itswings automatically, the swingicon displays
dynamically, meanwhile the letter displays above theicon.
SWING
SWING“”
7. ADJUSTMENT OF AIR FLOW DIRECTION
When transferring fromone mode to another, it may needs lessthan 3 minutes’delay
to protect compressor.
INOIZER
INOIZER button
Press it to start inoizer function
and press again to stop it.

When 28 st 31 ,the unit will operate at the set temperature all along.¡æ¡æ
When the air conditioner is in heat mode and18 st 16 , the unit will¡æ¡æ
operate at the set temperature all along.
When 19 st 25 , during the 2 hours after sleep mode 2 start up ,the
set temperature will decrease by 1 every hour .The unit will continue
operating at 2 below the set temperature.7 hours later, the set temperature
will increase 1 , the unit will continue operating at this temperature .
¡æ¡æ
Sleep mode 2
When 24 st 27 , during the 2 hours after sleep mode 2 start up, the
set temperature will increase by 1 every hour .The unit will continue
operating at 2 above the set temperature.7 hours later, the set temperature
will decrease 1 ,the unit will continue operating at this temperature .
¡æ¡æ
Sleep mode 3
When the air conditioner is in cooling and dry mode and 23 st 16 ,
during the 3 hours after sleep mode 3 start up, the set temperature will
increase by 1 every hour .The unit will continue operating at 3 above
the set temperature.
¡æ¡æ
56
2
3
8.
SLEEP mode
Sleep mode 1
When the air conditioner is in cooling and dry mode, the indoor fan runs at
low speed.After one hour of operation the set temperature will increase by
1 .One hour later, the set temperature will increase by 1 once more.The
unit will then continue operating at 2 above the set temperature.
Normal sleep
When the air conditioner is in heating mode , the indoor fan runs at low
speed. After one hour of operation the set temperature will decrease by 2 .
One hour later, the set temperature will decrease by 2 once more. The
unit will then continue operating at 4 below the set temperature.
123
When the air conditioner is in cooling and dry mode and 23 st 16 ,
during the 3 hours after sleep mode 1 start up ,the set temperature will
increase by 1 every hour .The unit will continue operating at 3 above
the set temperature. 8 hours later, the set temperature will decrease 2 .
The unit will then continue operating at this temperature.
¡æ¡æ
When 24 st 27 , during the 2 hours after sleep mode 1 start up,
the set temperature will increase by 1 every hour .The unit will continue
operating at 2 above the set temperature.8 hours later, the set
temperature will decrease 2 ,the unit will continue operating at this
temperature.
¡æ¡æ
1
When the air conditioner is in cooling and dry mode and 23 st 16 ,
during the 3 hours after sleep mode 2 start up ,the set temperature will
increase by 1 every hour .The unit will continue operating at 3 above
the set temperature.7 hours later, the set temperature will decrease 1 . The
unit will then continue operating at this temperature.
¡æ¡æ
7
When 19 st 25 , during the 2 hours after sleep mode 1 start up, the
set temperature will decrease by 1 every hour. The unit will continue
operating at 2 below the set temperature.8 hours later, the set temperature
will increase 2 , the unit will continue operating at this temperature .
¡æ¡æ
When 26 st 31 , during the 3 hours after sleep mode 1 start up, the set
temperature will decrease by 1 every hour. The unit will continue
operating at 3 below the set temperature.8 hours later, the set temperature
will increase 2 .The unit will then continue operating at this temperature.
¡æ¡æ
When 28 st 31 ,the unit will operate at the set temperature all along.¡æ¡æ
When the air conditioner is in heat mode and18 st 16 , the unit will¡æ¡æ
operate at the set temperature all along.
When 26 st 31 , during the 3 hours after sleep mode 2 start up, the set
temperature will decrease by 1 every hour. The unit will continue
operating at 3 below the set temperature. 7 hours later, the set temperature
will increase 1 .The unit will then continue operating at this temperature.
¡æ¡æ
When 24 st 27 , during the 2 hours after sleep mode 3 start up, the
set temperature will increase by 1 every hour .The unit will continue
operating at 2 above the set temperature.
¡æ¡æ
When 28 st 31 ,the unit will operate at the set temperature all along.¡æ¡æ
When the air conditioner is in heat mode and18 st 16 , the unit will¡æ¡æ
operate at the set temperature all along.
When 19 st 25 , during the 2 hours after sleep mode 3 start up ,the
set temperature will decrease by 1 every hour. The unit will continue
operating at 2 below the set temperature.
¡æ¡æ
When 26 st 31 ,during the 3 hours after sleep mode 3start up, the set
temperature will decrease by 1 every hour. The unit will continue
operating at 3 below the set temperature.
¡æ¡æ
KY-46B
8
INOIZER function(only applied to inoizer series)
Press inoizer buttonto start orstop inoizer functionwhen the air
conditioner is onor set timer.
The DISPLAY of the remotecontroller
displays “ ”while it isinitiated and extinguisheswhile it stops.
This function canonly be stoppedby pressing inoizerbutton or
turning off the air conditioner.
