EN
User Manual
Wine Cellar
HWS84GA
HWS84GNF
HWS49GA
HWS49GAE

Thank You EN
Legend
Warning – Important Safety information
General infor mation and tips
Environmental information
Disposal
Help protect the environment and human health. Put
the packaging in applicable containers to recycle it.
Help to recycle waste of electrical and electronic ap-
pliances. Do not dispose appliances marked with this
symbol with the household waste. Return the product
to your local recycling facility or contact your municipal
o ce.
Thank you for purchasing a Haier Product.
Please read these instructions carefully before using this appliance. The instructions con-
tain important information which will help you get the best out of the appliance and ensure
safe and proper installation, use and maintenance.
Keep this manual in a convenient place so you can always refer to it for the safe and proper
use of the appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure
you also pass this manual so that the new owner can become familiar with the appliance
and safety warnings.
WARNING!
Risk of injury or suff ocation!
Refrigerants and gases must be disposed of professionally. Ensure that the tubing of
the refrigerant circuit is not damaged before being properly disposed of. Disconnect
the appliance from the mains supply. Cut o the mains cable and dispose of it. Remove
the trays and drawers as well as the door catch and seals, to prevent children and pets
to get closed in the appliance.
Old appliances still have some residual value. An environmentally friendly method of dis-
posal will ensure that valuable raw materials can be recovered and used again.
Cyclopentane, a  ammable substance not harmful to ozone, is used as an expander for
the insulationg foam.
By ensuring this product is disposed of corectly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused.
For more detailed information about recycling of this product, please contact your local
council, your household waste disposal service or the shop where you purchased the pro-
duct, handled by the professionals.
2

EN Content
1- Safety information ..................................................................................................................... .4
2- Safety tips...................................................................................................................................... 7
3- Maintenance ..............................................................................................................................11
4-Accessories..................................................................................................................................13
5- Product description .................................................................................................................14
6- Installation ..................................................................................................................................15
7- Use ................................................................................................................................................18
8- Energy saving tips .....................................................................................................................21
9 - Equipment .................................................................................................................................22
10- Care and cleaning ...................................................................................................................23
11- Troubleshooting .....................................................................................................................24
12- Technical data .........................................................................................................................27
13- Customer Service ..................................................................................................................28
14- Wine bottle stacking...............................................................................................................29
3

Safety information EN
This appliance is intended to be used exclusively for the storage
of wine.Before switching on the appliance for the fi rst time read
the following safety hints:
WARNING!
Before fi rst use
▶Make sure there is no transport damage.
▶Remove all packaging and keep out of children´s reach and dis-
pose them in an environmentally friendly manner.
▶Wait at least two hours before installing the appliance in order to
ensure the refrigerant circuit is fully ecient.
▶Handle the appliance always with at least two persons because
it is heavy.
Installation
▶The appliance should be placed in a well-ventilated place.Ensure
a space of at least 10 cm above and around the appliance.
▶WARNING: Keep ventilation openings, in the appliance enclo-
sure or in the built-in structure, clear of obstruction.
▶Never place the appliance in a damp area or location where it
might be splashed with water.Clean and dry water splashes and
stains with a soft clean cloth.
▶Do not install your wine cellar in any location not properly insulat-
ed or heated e.g. garage etc. Your wine cellar was not designed
to operate in ambient temperature below 10 °C.
▶Do not install the appliance in direct sunlight or in the near of
heat sources(e.g.stoves,heaters).
▶Install and level the appliance in an area suitable for its size and
use.
▶Make sure that the electrical information on the rating plate
agrees with the power supply.If it does not,contact an electri-
cian.
▶The appliance is operated by a 220-240 VAC/50 Hz power sup-
ply.Abnormal voltage uctuation may cause the appliance to fail
to start,or damage to the temperature control or compressor,or
there may be an abnormal noise when operating.In such case,an
automatic regulator shall be mounted.
▶Do not use multi-plug adapters and extension cables.
4

EN Safety information
WARNING!
▶WARNING: Do not locate multiple portable socket outlets or
portable power supplies at the rear of the appliance.
▶WARNING: When positioning the appliance, ensure the supply
cord is not trapped or damaged.
▶Do not step on the power cable.
▶Use a separate earthed socket for the power supply which is
easy accessible. The appliance must be earthed.
▶Only for UK: The appliance´s power cable is tted with 3-cord
(grounding) plug that ts a standard 3-cord (grounded) socket.
Never cut o or dismount the third pin (grounding). After the
appliance is installed, the plug should be accesible.
▶WARNING: Do not damage the refrigerant circuit.
Daily use
▶This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the ap-
pliance in a safe way and understand the hazards involved.
▶Children shall not play with the appliance.
▶Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances, but not allowed to clean and install the
refrigerating appliances.
▶Keep away children under 3 years of age from the appliance un-
less they are constantly supervised.
▶Cleaning and user maintenance shall not be made by children with
out supervision.
▶The appliance must be positioned so that the plug is accessible.
▶If coal gas or other inammable gas is leaking into vicinity of the
appliance,turn o the valve of the leaking gas, open the doors and
windows and do not unplug the power cable of the appliance .
▶Wait at least 7 minutes to reconnect the power after the power
has been disconnected.
▶Do not lift the appliance by its door handles.
▶The keys must be kept out of the reach of children and not in the
vicinity of the appliance to prevent children from being locked in-
side the appliance.
5

Safety information EN
WARNING!
▶Notice that the appliance is set for operation at the secic am-
bient range between 10 and 38°C. The appliance may not work
properly if it is left for a long period at a temperature above or
below the indicated range.
▶Do not place unstable articles(heavy objects,containers lled
with water) on top of the appliance,to avoid personal injury
caused by falling or electric shock caused by contact with water.
▶Open and close the door only with the handles.The gap between
the door and the cabinet is very narrow.Do not put your hands
in these areas to avoid pinching your ngers.Open or close the
appliance doors only when there are no children standing within
the range of door movement.
▶Do not store or use inammable,explosive or corrosive materi-
als in the appliance or in the vicinity.
▶Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
▶Do not store medicines, bacteria or chemical agents in the ap-
pliance.This appliance is a household appliance.It is not recom-
mended to store materials that require strict temperatures.
▶Do not set unnecessarily low temperature in the wine cabinet
compartment. Minus temperatures may occur at high settings.
Attention: Bottles can burst
▶Do not touch the inside surface of the appliance compartment
when in operation,especially with wet hands,as your hands may
freeze onto the surface.
▶For proper wine cooling,do not overload the appliance.
▶Unplug the appliance in the event of a power interruption or be-
fore cleaning.Allow at least 7 minutes before restarting the ap-
pliance, as frequent starting may damage the compressor.
▶WARNING: Do not use electrical devices inside the appliance,unless
they are of the type recommended by the manufacturer. To avoid
risks a damaged power cord must be replaced by the customer
service(see warranty card).
▶To prolong the service life of the appliance, avoid turning it o.
▶Never place the appliance horizontally on the ground.After tilting
the appliance more than 45°,wait for 24hours before plugging it in.
6

EN Safety Tips
WARNING!
Maintenance / cleaning
▶Make sure children are supervised if they carry out cleaning and
maintenance.
▶Disconnect the appliance from the electrical supply before un-
dertaking any routine maintenance. Allow at least 7 minutes be-
fore restarting the appliance, as frequent starting may damage
the compressor.
▶Hold the plug, not the cable, when unplugging the appliance.
▶Do not clean the appliance with hard brushes, wire brushes, de-
tergent powder, petrol, amyl acetate, acetone and similar organic
solutions, acid or alkaline solutions. Please clean with special re-
frigerator/freezer detergent to avoid damage. Eventually use
warm water and baking soda solution - about a tablespoon of
baking soda to a litre/quart of water. Rinse thoroughly with wa-
ter and wipe dry. Do not use cleaning powders or other abrasive
cleaners. Do not wash removable parts in a dishwasher.
▶WARNING: Do not use mechanical devices or other means to ac-
celerate the defrosting process, other than those recommended
by the manufacturer.
▶If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualied persons in order to
avoid a hazard.
▶Do not try to repair, disassemble or modify the appliance by your-
self. In case of repair please contact our customer service.
▶If the illuminating lamps are damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in or-
der to avoid a hazard.
▶Eliminate the dust on the back of the unit at least once in the year
to avoid hazard by re, as well as increased energy consumption.
7

EN
Safety Tips
▶Do not spray or  ush the appliance during cleaning.
▶Do not use water spray or steam to clean the appliance.
▶Do not clean the cold glass door with hot water. Sudden temper-
ature change may cause the glass to break.
▶If you leave your appliance out of use for an extended period, leave
it open to prevent odour and unpleasant smells building up inside.
Refrigerant gass information
WARNING!
The appliance contains the  ammable refrigerant ISOBUTANE
(R600a). Make sure the refrigerant circuit is not damaged during
transportation or installation. Leaking refrigerant may cause eye
injuries or ignite. If a damage has occurred, keep away open  re
sources, thoroughly ventilate the room, do not plug or unplug the
power cords of the appliance or any other appliance. Inform the
customer service.
In case of eyes get into contact with the refrigerant, rinse it imme-
diately under running water and call immediately the eye specialist.
WARNING: The refrigeration system is under high pressure. Do not
tamper with it. Since the  ammable refrigerants are used, please,
install, handle and service the appliance strictly according to the in-
struction and contact the professional agent or our after-sales ser-
vice to dispose of the appliance.
8

EN Safety Tips
Intended use
This appliance is intended to be used in household and similar ap-
plications such as
- sta kitchen areas in shops, oces and other working environ-
ments;
- farm houses and by clients in hotels, motels and other residen-
tial type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
▶To ensure the safe preservation of wine, please comply with this
instruction for use.
▶The details on the most appropriate part in the compartment of
the appliance where specic types of food shall be stored, con-
sidering the distribution of temperature that can be present in
the dierent compartments of the appliance are in the other
part of the manual.
Changes or modications to the device are not allowed. Unin-
tended use may cause hazards and loss of warranty claims.
9

EN
Safety Tips
▶Disposal
The symbol on the product or on its packaging indicates that
this product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential negative con-
sequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this prod-
uct. For more detailed information about recycling of this product,
please contact your local city o ce, your household waste disposal
service or the shop where you purchased the product.
Since the  ammable insulation blowing gases are used, please con-
tact the professional agent or our after-sale service to dispose of
the appliance.
WARNING!
Risk of injury of suffocation!
Refrigerants and gases must be disposed of professionally. Ensure
that the tubing of the refrigerant circuit is not damaged before be-
ing properly disposed of. Disconnect the appliance from the mains
supply. Cut o the mains cable and dispose of it. Remove the trays
and drawers as well as the door catch and seals to prevent children
and pets to get closed in the appliance.
10

EN Maintenance
▶WARNING: Disconnect the appliance from the power supply be-
fore cleaning.
▶Do not clean the appliance with hard brushes, wire brushes,
detergent powder,petrol,amyl acetate,acetone and similar
organic solutions,acid or alkaline solutions. Please clean with
special refrigerator detergent to avoid damage.
▶Clean the appliance when only little or no wine is stored.It is only
necessary to clean it when it is dirty.
▶Clean the inside and housing of the ap-
pliance with a sponge damped in warm
water and neutral detergent
▶Rinse with clean warm water and dry
with soft cloth.
▶Do not clean any of the parts of the ap-
pliance in a dishwasher.
▶Allow at least 7 minutes before re-
starting the appliance as frequent starting may damage the
compresssor.
Clean the door gasket:
▶The door gaskets should be cleaned every 3 months to assure a
proper seal. As below : Remove: Grasp the door gasket and pull
it out according to the direction of ar-
row to remove the whole door gasket
in order.
Dip the brush with water or food grade
alcohlo,clean up the door gasket
groove rstly by pulling back and forth
the brush. Then wipe door gasket sur-
face with a towel dipped with water or
food grade alcohol. Finally,wash the door gasket clean and wipe it
dry with a clean towel.
11

EN
Maintenance
Installation door gasket after cleaning:
Before installation, make sure that there is no water on the door
gasket. Insert the door gasket into the groove , and press the door
gasket tightly from the top to the bottom by hand until the whole
door gasket is inserted into the groove.
Cleaning the shelves:
▶All shelves can be taken out for cleaning.
▶Take out all bottles.
▶Lift each shelf a little and take it out.
▶Clean the shelf with a soft towel.
▶Wait until the shelves are dry before putting them back in.
WARNING:
Wait at least 7 minutes to reconnet the power after the power
has been disconnected.
12

EN Accessories
Check the accessories and literature in accordance with this list:
without isolation.
Name User
Manual
Service
Card
Shelf
Small
shelf
Hinger-
Cover
Energy
Label
Key Left cam
of door
HWS84GA 1 1 6 1 1 1 2 2
HWS84GNF 1 1 6 1 1 1 2 2
HWS49GA 1 1 4 1 1 1 2 2
HWS49GAE 1 1 4 / / 1 / /
13

Product description EN
Notice
1
8
7
6
2
3
4
5
1. Fan(except HWS49GAE)
2. Shelf
4. Adjustable feet
5. Lock (except HWS49GAE)
6. Door
7. LED lamp
8. Display (on front of the door)
Picture of appliance
14

EN Installation
3. Space requirements
Required space to open the door (Fig. 3):
Width
in mm Depth in mm Distance to wall in mm
W1 W2 D1 D2 D3 D4
495 630 535 1033 1047 100
4. Ventilation space
For safety and energy reasons, the required ventilation
distance of 10 cm in all directions must be observed
(Fig. 4).
1. Unpacking
▶Take the appliance out of the packaging.
▶Remove all packaging materials including the foam base and all adhesive tape hold-
ing the accessories.
2. Environmental conditions
the temperature inside the appliance and its energy consumption. Do not install the appli-
ance near other heat-emitting appliances (ovens, refrigerators) without isolation.
15
5. Aligning the appliance
surface.
1. Tilt the appliance slightly backwards (Fig. 5).
2. Set the adjustable front feet to the desired level
by turning them.
3. The stability can be checked by alternately
bumping on the diagonals. The slight swaying
should be the same in both directions. Other-
wise the frame can warp; possible leaking door
seals are the result. A low tendency to the rear
facilitates the closing of the door.
max 45°
1.
2.
3.
5
W2
D1
D3
D2
W1 D4
3
10 cm
10 cm 10 cm
10 cm
4
WARNING!
▶Keep ventilation openings in the appliance or in the in-built structure clear of ob-
struction. This refrigerating appliance is not intended to be used as a built-in appliance

EN
Installation
16
6. Fine tuning of the door
The appliance closes more easily if the levelling feet on
the front are used:
Rotate the adjustable feet (Fig. 6) to turn them up or
down:
▶Turning the feet clockwise raises the appliance.
▶Turning the feet counterclockwise lower the appli-
ance.
WARNING!
To avoid risks a damaged power cord must be replaced by the customer service (see
warranty card).
WARNING!
▶The appliance is heavy. You need two persons to carry out the door reversibility.
▶
▶Do not tilt the appliance more than 45 ° to prevent damage of the cooling system.
8. Electrical connection
Before each connection check if:
▶power supply, socket and fusing are appropriate to the rating plate.
▶the power socket is earthed and no multi-plug or extension.
▶
Connect the plug to a properly installed household socket.
7. Waiting time
The maintenance-free lubrication oil is located in the
capsule of the compressor. This oil can get through
the closed pipe system during transport if the appli-
ance is tilted. Before connecting the appliance to the
power supply, wait 24 hours (Fig. 7) so that the oil runs
back into the capsule.
9. Door Reversibility(except HWS49GAE)
Before connecting the appliance to the power supply you should check, whether the door
swing must changed from right (as delivered) to left, if this is required by the installation
location and the usability
6
24 h
7
