Hakko Electronics Monitouch V7 User manual

V7

Record of Revisions
Reference numbers are shown at the bottom left corner on the back cover of each manual.
Printing Date Reference No. Revised Contents
September, 2002 2010NE0 First edition

Preface
Thank you for selecting the MONITOUCH V7 series.
For correct set-up of MONITOUCH, you are requested to read through this manual to understand
more about the product.
For more information about the V7 series, refer to the following related manuals.
For further details about PLCs (programmable logic controllers), see the manual attached to each
PLC.
Manual Name Contents Reference No.
Reference Manual (Operation) The V-SFT operating procedure is described. 1043NE
Reference Manual (Function) The functions and instructions of the V7/V6 series are
explained. 1044NE
Universal Serial Connection Manual Universal serial specifications and commands are
described. 1021NE
Temperature Control Network The temperature control network function is explained. 1033NE
Specifications for Communication
Unit CC-LINK Instructions for CC-LINK are contained. 1028NE
Specifications for Communication
Unit PROFIBUS-DP Instructions for PROFIBUS-DP are contained. 1036NE
M-CARD SFTE Operation Manual The operating procedure of the memory card editor is
described. 1023NE
Notes:
1. This manual may not, in whole or in part, be printed or reproduced without the prior written
consent of Hakko Electronics Co., Ltd.
2. Information in this manual is subject to change without prior notice.
3. Windows and Excel are registered trademarks of Microsoft Corporation in the United
States and other countries.
4. All other company names or product names are trademarks or registered trademarks of
their respective holders.
5. This manual is intended to give accurate information about MONITOUCH hardware. If
you have any questions, please contact your local distributor.

Notes on Safe Use of
MONITOUCH
In this manual, you will find various notes categorized under the following levels with the signal words
“DANGER,” and “CAUTION.”
Note that there is a possibility that the item listed with may have serious
ramifications.
DANGER Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury and could cause property damage.
•Never use the input function of MONITOUCH for operations that may threaten human life or to
damage the system, such as switches to be used in case of emergency. Please design the
system so that it can cope with malfunction of a touch switch.
•Turn off the power supply when you set up the unit, connect cables or perform maintenance and
inspection. Failure to do so could cause an electric shock or damage to the unit.
•Never touch any terminals while the power is on. An electric shock may occur.
•You must put a cover on the terminals on the unit when you turn the power on and operate the
unit. Without the terminal cover in place, an electric shock may occur.
•The liquid crystal in the LCD panel is a hazardous substance. If the LCD panel is damaged,
never swallow the leaked liquid crystal. If the liquid crystal spills on your skin or clothing, use
soap and wash off thoroughly.
CAUTION
DANGER

[Notes on System Design]
•Never bundle control cables andinput/output cables with high-voltage and large-current carrying
cables such as power supply cables. Keep these cables at least 200 mm away from the power
supply or high-voltage cables. Otherwise, malfunction may occur due to noise.
•For use in a nuclear energy facility, or other facility of such official importance, please consult
your local distributor.
[Notes on Installation]
•Operate (or store) MONITOUCH under the conditions indicated in this manual and related
manuals. Failure to do so could cause fire, malfunction, physical damage or deterioration.
•Understand the following environmental limits for use and storage of MONITOUCH. Otherwise,
fire or damage to the unit may result.
- Avoid locations where there is a possibility that water, corrosive gas, flammable gas,
solvents, grinding fluids or cutting oil can come into contact with the unit.
- Avoid high temperature, high humidity, and outside weather conditions, such as wind, rain or
direct sunlight.
- Avoid locations where excessive dust, salt, and metallic particles are present.
- Avoid installing the unit in a location where vibration or physical shock may be transmitted.
•Equipment must be correctly mounted so that the main terminal of MONITOUCH will not be
touched inadvertently.
•Tighten the MONITOUCH mounting screws to the specified torque. Excessive tightening may
distort the panel surface. Loose tightening may cause MONITOUCH to come off, malfunction or
be short-circuited.
•Tighten terminal screws on the power input terminal block equally to a torque of 0.5 N•m.
•Check the appearance of MONITOUCH when it is unpacked. Do not use the unit if any damage
or deformation is found.
•MONITOUCH has a glass screen. Do not drop or give physical shock to the unit.
[Notes on Cable Connection]
•Connect the cables correctly to the terminals of MONITOUCH in accordance with the specified
voltage and wattage. Over-voltage, over-wattage or incorrect cable connection could cause fire,
malfunction or damage to the unit.
•Be sure to establish a ground of MONITOUCH. The FG terminal must be used exclusively for
the unit with the level of grounding resistance less than 100 Ω.
•Prevent any conductive particles from entering into MONITOUCH. Failure to do so may lead to
fire, damage or malfunction.
(To be continued)
CAUTION

[Notes on Maintenance and Operation]
•Hakko Electronics Co., Ltd. is not responsible for any damages resulting from repair, overhaul or
modification of MONITOUCH that was performed by an unauthorized person.
•Do not use thinners for cleaning because they may discolor the MONITOUCH surface. Use
alcohol or benzine commercially available.
•Do not use a sharp-pointed tool when pressing a touch switch.
•Only experts are authorized to set up the unit, connect the cables or perform maintenance and
inspection.
•MONITOUCH is equipped with a lithium battery. Lithium batteries contain combustible material
such as lithium or organic solvent. Mishandling may cause heat, explosion or ignition resulting
in fire or injury. Read this manual and related manuals carefully and handle the lithium battery
correctly as instructed.
•If a data receive error occurs when MONITOUCH and the counterpart (PLC, temperature
controller, etc.) are started at the same time, read the manual for the counterpart unit and handle
the error correctly.
•Switch resolution of the MONITOUCH V7 series is determined by
the analog-type resistance film. Do not press two or more
positions on the screen at the same time.
If two or more positions are pressed at the same time, the switch
located between the pressed positions activates. Please take
note of this.
[Notes on Disposal]
•At the time of disposal, MONITOUCH must be treated as industrial waste.
CAUTION
F1
F2
F3
F4
F5
F6
F7
SYSTEM
POWER
SWITCH
Pressing two positions at the same time
activates the switch in the center.

Contents
Chapter 1 Hardware Specifications
1. Features.......................................................................................................................... 1-1
2. Models and Peripheral Equipment..................................................................................1-2
MONITOUCH Models.................................................................................................................. 1-2
Peripheral Equipment .................................................................................................................. 1-3
3. System Composition ....................................................................................................... 1-7
System Composition of V7 (Standard)......................................................................................... 1-7
System Composition of V7i (High-performance).......................................................................... 1-8
4. Specifications.................................................................................................................. 1-9
General Specifications................................................................................................................. 1-9
Display Specifications................................................................................................................ 1-10
Touch Panel Specifications........................................................................................................ 1-10
Function Switch Specifications ..................................................................................................1-11
Interface Specifications.............................................................................................................. 1-11
Clock and Backup Memory Specifications................................................................................. 1-11
Drawing Environment................................................................................................................. 1-12
Display Function Specifications.................................................................................................1-12
Function Performance Specifications ........................................................................................ 1-13
5. Dimensions and Panel Cut-out...................................................................................... 1-14
V708/V708i External View and Dimensions............................................................................... 1-14
V710/V710i External View and Dimensions............................................................................... 1-15
V712/V712i External View and Dimensions............................................................................... 1-16
6. Names and Functions of Components.......................................................................... 1-17
7. Mounting Procedure...................................................................................................... 1-20
Mounting Procedure................................................................................................................... 1-20
Mounting Angle.......................................................................................................................... 1-20
8. Power Supply Cable Connection................................................................................... 1-21
Power Supply Cable Connection ............................................................................................... 1-21
Notes on Usage of 100-240 VAC Specifications ....................................................................... 1-22
Grounding.................................................................................................................................. 1-22
9. Coin-type Lithium Battery.............................................................................................. 1-23
Battery Mounting Procedure......................................................................................................1-23
Battery Replacement ................................................................................................................. 1-24
10. DIP Switch Setting......................................................................................................... 1-26
DIP Switch (DIPSW) Setting......................................................................................................1-26
11. Serial Connector (CN1)................................................................................................. 1-28
Serial Connector for PLC Connection........................................................................................ 1-28

12. Modular Jack (MJ1/MJ2)................................................................................................1-29
Modular Jack 1 (MJ1)/2 (MJ2)................................................................................................... 1-29
V-SFT Setting ............................................................................................................................ 1-30
Transferring Screen Data........................................................................................................... 1-32
Barcode Reader Connection...................................................................................................... 1-32
13. 10BASE-T (LAN)............................................................................................................1-33
10BASE-T Connector ................................................................................................................ 1-33
Notes on Wiring ......................................................................................................................... 1-34
14. CF Card (CF).................................................................................................................1-35
Recommended CF Card............................................................................................................ 1-35
Mounting and Dismounting the CF Card.................................................................................... 1-35
Notes on Handling the CF Card................................................................................................. 1-36
15. Printer Connection (PRINTER)......................................................................................1-37
Printer Connector (PRINTER).................................................................................................... 1-37
Connection with Printer through Serial Interface ....................................................................... 1-38
Chapter 2 MONITOUCH Operations
1. Operation of V7 Main Menu.............................................................................................2-1
Initial Screen................................................................................................................................ 2-1
1. Main Menu Screen..............................................................................................................2-2
2. I/O Test ............................................................................................................................... 2-4
2-1. Self-loop Test...................................................................................................................... 2-5
2-2. Print Check.......................................................................................................................... 2-8
2-3. SYSTEM & Function Switch Test........................................................................................2-8
2-4. Touch Switch Test............................................................................................................... 2-9
3. Card Menu Screen............................................................................................................ 2-11
3-1. CREC Menu Screen.......................................................................................................... 2-12
3-2. Transferring Screen Data from a CF Card........................................................................ 2-15
3-3. Saving Backup Copies of SRAM....................................................................................... 2-21
3-4. Messages during Data Transfer........................................................................................ 2-23
4. Ethernet............................................................................................................................. 2-24
5. SRAM/Clock...................................................................................................................... 2-27
6. Extension Program Information......................................................................................... 2-28
7. Extended Function Setting................................................................................................ 2-29
2. Function Switches..........................................................................................................2-30
Types......................................................................................................................................... 2-30
[SYSTEM] Switch....................................................................................................................... 2-30
3. Errors Displayed on the V7 Series.................................................................................2-32
1. Communication Error........................................................................................................ 2-32
2. Check................................................................................................................................ 2-36
3. Warning............................................................................................................................. 2-36
4. SYSTEM ERROR ............................................................................................................. 2-37
5. Touch Switch is Active...................................................................................................... 2-37

Chapter 3 Serial Communications
1. 1 : 1 Connection.............................................................................................................. 3-1
1 : 1 Connection........................................................................................................................... 3-1
Wiring........................................................................................................................................... 3-2
V-SFT Setting .............................................................................................................................. 3-4
2. 1 : n Connection (Multi-drop)........................................................................................... 3-9
1 : n Connection........................................................................................................................... 3-9
Wiring (RS-422/485).................................................................................................................... 3-9
V-SFT Setting ............................................................................................................................ 3-10
Notes on Communication Errors................................................................................................ 3-10
3. n : 1 Connection (Multi-link 2)........................................................................................ 3-11
Multi-link 2.................................................................................................................................. 3-11
Wiring......................................................................................................................................... 3-12
V-SFT Setting ............................................................................................................................ 3-14
Communication Error................................................................................................................. 3-15
4. n : 1 Connection (Multi-link)........................................................................................... 3-16
Multi-link..................................................................................................................................... 3-16
Wiring......................................................................................................................................... 3-17
V-SFT Setting ............................................................................................................................ 3-18
5. Universal Serial Communications ................................................................................. 3-20
Universal Serial Communications.............................................................................................. 3-20
6. V-Link............................................................................................................................ 3-21
V-Link......................................................................................................................................... 3-21
Wiring......................................................................................................................................... 3-22
V-SFT Setting ............................................................................................................................ 3-24
Protocol...................................................................................................................................... 3-25
NAK: Error Codes ...................................................................................................................... 3-29
1-byte Character Code List........................................................................................................ 3-30
7. PLC2Way...................................................................................................................... 3-31
PLC2Way................................................................................................................................... 3-31
Limitations on Connection at the MJ Port .................................................................................. 3-32
PLCs Compatible with PLC2Way Connection at MJ Port.......................................................... 3-32
Wiring......................................................................................................................................... 3-33
V-SFT Setting – System Setting................................................................................................ 3-35
V-SFT Setting – When the temperature control network/PLC2Way table is used:.................... 3-38
Indirect Memory Designation.....................................................................................................3-45
User Log Read for YOKOGAWA’s PLC..................................................................................... 3-46
Processing Cycle....................................................................................................................... 3-47
Notes on Screen Data Transfer................................................................................................. 3-48
System Memory......................................................................................................................... 3-49
8. Temperature Control Network....................................................................................... 3-52
Temperature Control Network.................................................................................................... 3-52

Chapter 4 Network Communications
1. Ethernet ...........................................................................................................................4-1
Ethernet ....................................................................................................................................... 4-1
Notes on Ethernet Communications ............................................................................................ 4-3
IP Address for the V7 Series........................................................................................................ 4-3
Communication Interface Unit CU-03..........................................................................................4-3
Wiring........................................................................................................................................... 4-5
Transferring Screen Data............................................................................................................. 4-8
V-SFT Setting (PLC Type/Communication Parameter)............................................................. 4-10
V-SFT Setting (Network Table Editing)...................................................................................... 4-14
V-SFT Setting (Macro)............................................................................................................... 4-19
System Memory......................................................................................................................... 4-22
Ethernet Access Functions (HKEtn10.DLL)............................................................................... 4-26
Server Communication Procedure............................................................................................. 4-44
Error Display.............................................................................................................................. 4-45
2. FL-net (OPCN-2)............................................................................................................4-48
FL-net (OPCN-2)........................................................................................................................ 4-48
3. MELSECNET/10............................................................................................................4-49
MELSECNET/10........................................................................................................................ 4-49
4. CC-Link..........................................................................................................................4-51
CC-Link...................................................................................................................................... 4-51
5. OPCN-1 .........................................................................................................................4-52
OPCN-1 ..................................................................................................................................... 4-52
6. T-LINK............................................................................................................................4-53
T-LINK........................................................................................................................................ 4-53
7. PROFIBUS-DP ..............................................................................................................4-54
PROFIBUS................................................................................................................................. 4-54

Chapter 5 Connection to PLCs
1. MITSUBISHI PLC............................................................................................................ 5-1
Available PLCs............................................................................................................................. 5-1
Communication Setting................................................................................................................ 5-4
A Series Link, QnA Series Link: Switch Setting........................................................................... 5-6
Available Memory ........................................................................................................................ 5-8
Wiring......................................................................................................................................... 5-11
A Link + Net10........................................................................................................................... 5-15
V-MDD (Dual Port Interface)...................................................................................................... 5-17
Ladder Transfer Function........................................................................................................... 5-18
2. OMRON PLC................................................................................................................. 5-22
Available PLCs........................................................................................................................... 5-22
Communication Setting.............................................................................................................. 5-24
Available Memory ...................................................................................................................... 5-25
Wiring......................................................................................................................................... 5-26
SYSMAC CS1 DNA................................................................................................................... 5-29
3. SHARP PLC.................................................................................................................. 5-30
Available PLCs........................................................................................................................... 5-30
Communication Setting.............................................................................................................. 5-30
JW Series: Link Unit Switch Setting........................................................................................... 5-31
JW100/70H COM Port, JW20 COM Port: System Memory Setting........................................... 5-31
Available Memory ...................................................................................................................... 5-32
Wiring......................................................................................................................................... 5-33
4. HITACHI PLC................................................................................................................ 5-35
Available PLCs........................................................................................................................... 5-35
Communication Setting.............................................................................................................. 5-36
HIDIC-H: Switch Setting............................................................................................................. 5-37
Available Memory ...................................................................................................................... 5-37
Wiring......................................................................................................................................... 5-39
5. MATSUSHITA PLC....................................................................................................... 5-41
Available PLCs........................................................................................................................... 5-41
Communication Setting.............................................................................................................. 5-41
MEWNET: Link Unit Switch Setting........................................................................................... 5-42
Available Memory ...................................................................................................................... 5-42
Wiring......................................................................................................................................... 5-43
6. YOKOGAWA PLC......................................................................................................... 5-45
Available PLCs........................................................................................................................... 5-45
Communication Setting.............................................................................................................. 5-46
Available Memory ...................................................................................................................... 5-47
Wiring......................................................................................................................................... 5-48
7. YASKAWA PLC............................................................................................................. 5-50
Available PLCs........................................................................................................................... 5-50
Communication Setting.............................................................................................................. 5-50
Available Memory ...................................................................................................................... 5-51
Wiring......................................................................................................................................... 5-52

8. Toyopuc PLC.................................................................................................................5-55
Available PLCs........................................................................................................................... 5-55
Communication Setting.............................................................................................................. 5-55
Switch Setting............................................................................................................................ 5-55
Available Memory ...................................................................................................................... 5-56
Screen Editing (Memory Input) .................................................................................................. 5-56
Wiring......................................................................................................................................... 5-57
9. FUJI PLC .......................................................................................................................5-58
Available PLCs........................................................................................................................... 5-58
Communication Setting.............................................................................................................. 5-58
MICREX-F Series, FLEX-PC Series: Switch Setting................................................................. 5-59
Available Memory ...................................................................................................................... 5-60
Wiring......................................................................................................................................... 5-62
10. KOYO PLC.....................................................................................................................5-64
Available PLCs........................................................................................................................... 5-64
Communication Setting.............................................................................................................. 5-65
Available Memory ...................................................................................................................... 5-66
Switch Setting............................................................................................................................ 5-67
Wiring......................................................................................................................................... 5-69
11. Allen-Bradley PLC..........................................................................................................5-72
Available PLCs........................................................................................................................... 5-72
Communication Setting.............................................................................................................. 5-73
Available Memory ...................................................................................................................... 5-74
PLC-5 Series: Switch Setting..................................................................................................... 5-76
SLC500 Series, Micro Logix 100: Transmission Parameter Setting.......................................... 5-78
Wiring......................................................................................................................................... 5-79
12. GE Fanuc PLC...............................................................................................................5-82
Available PLCs........................................................................................................................... 5-82
Communication Setting.............................................................................................................. 5-82
Available Memory ...................................................................................................................... 5-83
Wiring......................................................................................................................................... 5-84
13. TOSHIBA PLC...............................................................................................................5-86
Available PLCs........................................................................................................................... 5-86
Communication Setting.............................................................................................................. 5-86
Available Memory ...................................................................................................................... 5-87
Wiring......................................................................................................................................... 5-87
14. TOSHIBA MACHINE PLC..............................................................................................5-88
Available PLCs........................................................................................................................... 5-88
Communication Setting.............................................................................................................. 5-88
Available Memory ...................................................................................................................... 5-88
Wiring......................................................................................................................................... 5-89
15. SIEMENS PLC...............................................................................................................5-90
Available PLCs........................................................................................................................... 5-90
Communication Setting.............................................................................................................. 5-90
Available Memory ...................................................................................................................... 5-92
Wiring......................................................................................................................................... 5-95

16. SHINKO PLC................................................................................................................. 5-98
Available PLCs........................................................................................................................... 5-98
Communication Setting.............................................................................................................. 5-98
Available Memory ...................................................................................................................... 5-98
Wiring......................................................................................................................................... 5-99
17. SAMSUNG PLC.......................................................................................................... 5-100
Available PLCs......................................................................................................................... 5-100
Communication Setting............................................................................................................ 5-100
Available Memory .................................................................................................................... 5-100
Wiring....................................................................................................................................... 5-101
18. KEYENCE PLC........................................................................................................... 5-102
Available PLCs......................................................................................................................... 5-102
Communication Setting............................................................................................................ 5-103
Available Memory .................................................................................................................... 5-104
Wiring....................................................................................................................................... 5-106
19. LG PLC........................................................................................................................ 5-108
Available PLCs......................................................................................................................... 5-108
Communication Setting............................................................................................................ 5-108
Available Memory .................................................................................................................... 5-109
Wiring....................................................................................................................................... 5-111
20. FANUC PLC................................................................................................................ 5-113
Available PLCs......................................................................................................................... 5-113
Communication Setting............................................................................................................ 5-113
Available Memory .................................................................................................................... 5-113
Wiring....................................................................................................................................... 5-114
21. FATEK AUTOMATION PLC........................................................................................ 5-116
Available PLCs......................................................................................................................... 5-116
Communication Setting............................................................................................................ 5-116
Available Memory .................................................................................................................... 5-116
Wiring....................................................................................................................................... 5-117
22. IDEC PLC....................................................................................................................5-118
Available PLCs......................................................................................................................... 5-118
Communication Setting............................................................................................................ 5-118
Available Memory .................................................................................................................... 5-118
Wiring....................................................................................................................................... 5-119
23. MODICON PLC........................................................................................................... 5-120
Available PLCs......................................................................................................................... 5-120
Communication Setting............................................................................................................ 5-120
Available Memory .................................................................................................................... 5-120
Wiring....................................................................................................................................... 5-121
24. YAMATAKE PLC......................................................................................................... 5-122
Available PLCs......................................................................................................................... 5-122
Communication Setting............................................................................................................ 5-122
Available Memory .................................................................................................................... 5-122
Wiring....................................................................................................................................... 5-123

25. TAIAN PLC ..................................................................................................................5-124
Available PLCs......................................................................................................................... 5-124
Communication Setting............................................................................................................ 5-124
Available Memory .................................................................................................................... 5-124
Wiring....................................................................................................................................... 5-125
26. SAIA PLC.....................................................................................................................5-126
Available PLCs......................................................................................................................... 5-126
Communication Setting............................................................................................................ 5-126
S-BUS Configuration................................................................................................................ 5-126
Available Memory .................................................................................................................... 5-126
Wiring....................................................................................................................................... 5-127
27. MOELLER PLC............................................................................................................5-128
Available PLCs......................................................................................................................... 5-128
Communication Setting............................................................................................................ 5-128
Available Memory .................................................................................................................... 5-128
Wiring....................................................................................................................................... 5-129
28. Telemecanique PLC ....................................................................................................5-130
Available PLCs......................................................................................................................... 5-130
Communication Setting............................................................................................................ 5-130
Available Memory .................................................................................................................... 5-130
Wiring....................................................................................................................................... 5-131
29. Automationdirect PLC..................................................................................................5-132
Available PLCs......................................................................................................................... 5-132
Communication Setting............................................................................................................ 5-132
Available Memory .................................................................................................................... 5-133
Wiring....................................................................................................................................... 5-133

1. Features
2. Models and Peripheral Equipment
3. System Composition
4. Specifications
5. Dimensions and Panel Cut-out
6. Names and Functions of Components
7. Mounting Procedure
8. Power Supply Cable Connection
9. Coin-type Lithium Battery
10. DIP Switch Setting
11. Serial Connector (CN1)
12. Modular Jack (MJ1/MJ2)
13. 10BASE-T (LAN)
14. CF Card (CF)
15. Printer Connection (PRINTER)
Hardware
Specifications

1
1. Features 1-1
Hardware Specifications
1. Features
The V7 series inherits and heightens the features of the V6 series as described below.
1. 32k-color Display
32,768-color display makes colorful expression possible. Bitmap files are clearly
displayed in brilliant colors.
2. CF Card Interface as Standard
The CF card can be used for saving multiple screen data, sampling data, recipe data,
hard copyimages, andother varioususages. Large-sized video capture images, JPEG
or WAV files can be saved.
3. Connector for 10BASE-T (for high-performance type only)
This connector enables Ethernet connection with a host computer. High-speed
communications are possible via Ethernet for uploading/downloading screen data and
reading/writing data from/to the server.
4. Video Display Upgraded (for high-performance type only, optional)
The video display function is upgraded drastically to allow: saving the current video
screen, taking snapshots of multiple exposures, superimposing a semi-transparent
operation screenon a video display, showing four video channels at the same time, and
so on.
5. Web Server Function (for high-performance type only)
The V7i screens are converted into HTML files and displayed on the WWW browser
using the Ethernet.
6. Animation Function
The animation function enables representation of the field close to the real image.
7. Play of WAV File (for high-performance type only, optional)
WAV files can be played with ease simply by connecting the option unit to the speaker.
It is possible to use sound for notifying the field conditions, such as an occurrence of an
error. The monitoring operator can work from a distance.

1-2 2. Models and Peripheral Equipment
2. Models and Peripheral
Equipment
MONITOUCH Models
The model name consists of the following information.
V 7 Power supply specification
D: 24 VDC specification (in compliance with CE/UL/cUL)
None: 100-240 VAC specification
Device specification
S: TFT color LCD (SVGA)
T: TFT color LCD (VGA)
C: STN color LCD (VGA)
Functional specification
i: High-performance type
None: Standard type
Screen size
08: 8-inch
10: 10-inch
12: 12-inch

1
2. Models and Peripheral Equipment 1-3
Hardware Specifications
The following models are available.
Peripheral Equipment
The following options are available for using the V7 series more effectively.
Series and
Size Model Name Specifications Remarks
V708 series
8-inch
V708SD TFT color, 800 × 600 dots, standard, DC power supply Compliant with CE/UL/cUL
V708iSD TFT color, 800 × 600 dots, high-performance, DC power
supply Compliant with CE/UL/cUL
V708CD STN color, 640 × 480 dots, standard, DC power supply Compliant with CE/UL/cUL
V710 series
10-inch
V710T TFT color, 640 × 480 dots, standard, AC power supply
V710TD TFT color, 640 × 480 dots, standard, DC power supply Compliant with CE/UL/cUL
V710iT TFT color, 640 × 480 dots, high-performance, AC power
supply
V710iTD TFT color, 640 × 480 dots, high-performance, DC power
supply Compliant with CE/UL/cUL
V710S TFT color, 800 × 600 dots, standard, AC power supply
V710SD TFT color, 800 × 600 dots, standard, DC power supply Compliant with CE/UL/cUL
V710iS TFT color, 800 × 600 dots, high-performance, AC power
supply
V710iSD TFT color, 800 × 600 dots, high-performance, DC power
supply Compliant with CE/UL/cUL
V712 series
12-inch
V712S TFT color, 800 × 600 dots, standard, AC power supply
V712SD TFT color, 800 × 600 dots, standard, DC power supply Compliant with CE/UL/cUL
V712iS TFT color, 800 × 600 dots, high-performance, AC power
supply
V712iSD TFT color, 800 × 600 dots, high-performance, DC power
supply Compliant with CE/UL/cUL
V-SFT (drawing software: English version)
Application software for editing display data for the V series.
(Windows98/NT4.0/Me/2000/XP compatible) The V7 series is
supported with ver. 2.00 and later.
