HAKO Cleanserv PB51/2000 User manual

Instruction Manual
Cleanserv PB51/2000 (7675)

2
Preface
Dear Customer,
We are certain that the excellent quali-
ties of the vehicle will justify the faith
you have shown in us through your pur-
chase.
Please read the Chapter "Safety Infor-
mation" prior to starting the vehicle to
ensure it is operated and used safely.
Your safety, and that of others, basical-
ly lies in your ability to control and oper-
ate the vehicle. Before using the
equipment for the first time, read this
original manual thoroughly, act accord-
ing to the information contained and
keep it in a safe place for future refer-
ence or subsequent owners. The oper-
ating manual contains all the most
important information regarding opera-
tion, maintenance and service.
Throughout this manual, texts which
concern safety are indicated by the cor-
responding danger pictogram. Should
you have any questions in respect of
the vehicle or operating instruction
manual, your authorized Hako dealer is
available to provide help at any time.
We explicitly point out that no legal
claims may be asserted based on the
information contained in this manual.
Ensure only original spare parts are
used should any repairs be necessary.
Only such original spare parts warrant
that the equipment is reliably ready to
use at all times. We reserve the right to
make technical modifications in the in-
terest of further development.
Valid as of: April 2014
Hako GmbH
D-23843 Bad Oldesloe
Hamburger Str. 209-239
Telephone: [phone]
Preface

3
Proper use
The Cleanserv PB51/2000 has been
exclusively designed for cleaning hard
floors of indoor areas. This machine is
suitable for industrial use in e.g. hotels,
schools, clinics, factories, shops, offic-
es and rental stores. Using these ma-
chines beyond this scope of application
will be deemed improper use; The man-
ufacturer cannot be held liable for con-
sequential damages. The term of
proper use also includes operation,
maintenance and repair work to be per-
formed in compliance with the manufac-
turer's specifications.
The Cleanserv PB51/2000 may be op-
erated, serviced and repaired by per-
sonnel only that are familiar with the
machineandawareofpossiblehazards
involved.
The applicable accident prevention
laws must be observed and any gener-
ally accepted health and safety direc-
tives must be maintained.
Based on the conception, design and
construction of the vehicle introduced
onto the market by us, the vehicle com-
plies with the applicable basic safety
and health requirements stipulated in
the EC Directive (refer to the Declara-
tion of Conformity). This declaration is
no longer considered valid in the event
of modifications to the vehicle not au-
thorized by us. The manufacturer is not
deemed liable for any damage resulting
from unauthorized modifications to the
vehicle.
The machine has not
been designed for col-
lecting dusts which are
detrimental to health or
explosive dusts.
Notes on warranty
The terms defined in the purchase
agreement apply. Claims for compen-
sation related to damage are excluded
from the terms of warranty when the
damage is the result of failure to ob-
serve regulations concerning service
and maintenance. Maintenance work
must be performed by authorized Hako
service centers and confirmed in the
“Maintenance Report” which serves as
a warranty logbook. 
The following are excluded from the
terms of warranty: wear and tear
through overuse, defective fuses, im-
proper handling and use or unauthor-
ized modifications. Claims under the
terms of warranty are annulled when
damage occurs to the vehicle resulting
from the use of parts or accessories not
explicitly approved by us or from failure
to observe maintenance regulations.
Acceptance of the vehicle
The vehicle must be inspected directly
after delivery for signs of transport
damage. Replacements for transport
damage will be made when confirma-
tion is provided immediately by the
transporting company with regard to
the damage and you send the damage
report to our authorized contractual
partner together with the consignment
note.
Proper use

4
Table of Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . 2
Proper use. . . . . . . . . . . . . . . . . . . . . 3
Notes on warranty . . . . . . . . . . . . . . . 3
Acceptance of the machine. . . . . . . . 3
1 Safety Information . . . . . . . . 5
1.1 General Safety Information . . 5
1.2 Safety and Warning Symbols. 6
1.2.1 Generally Applicable Symbols 6
1.3 Labels at the Machine . . . . . . 7
1.4 Operation/Safety Information . 9
1.5 Information on Cleaning. . . . 10
1.6 Maintenance Instructions . . . 11
1.7 Disposal . . . . . . . . . . . . . . . 13
1.8 Accident Prevention Regula-
tion . . . . . . . . . . . . . . . . . . . . 13
2 First Operation . . . . . . . . . . 14
2.1 Battery System. . . . . . . . . . . 14
2.1.1 Mount Battery. . . . . . . . . . . . 15
2.1.2 Charge Batteries . . . . . . . . . 16
2.2 Before Work. . . . . . . . . . . . . 17
2.3 Switch the machine on. . . . . 17
2.4 End of work . . . . . . . . . . . . . 17
3 Operation . . . . . . . . . . . . . . 18
3.1 Control Elements and Indica-
tors. . . . . . . . . . . . . . . . . . . . 18
3.1.1 Key Switch . . . . . . . . . . . . . . 18
3.1.2 Emergency OFF Switch. . . . 18
3.1.3 Battery Charge Indication. . . 18
3.1.4 Direction and Speed Adjust-
ment. . . . . . . . . . . . . . . . . . . 19
3.1.5 Start-up Lever . . . . . . . . . . . 19
3.1.6 Pad Ground Pressure Indica-
tor. . . . . . . . . . . . . . . . . . . . . 19
3.2 Adjust Pad Ground Pressure 20
3.3 Adjust Working or Transport 
Position . . . . . . . . . . . . . . . . 21
4 Technical Data . . . . . . . . . . 22
5 Maintenance/Service . . . . . 24
5.1 Maintenance Instructions. . . 24
5.2 Remedy . . . . . . . . . . . . . . . . 25
5.3 Maintenance Schedule. . . . . 27
5.4 General Provisions. . . . . . . . 28
5.5 Electric System . . . . . . . . . . 28
5.5.1 Fuses . . . . . . . . . . . . . . . . . . 28
5.5.2 Check battery. . . . . . . . . . . . 28
5.6 Install Pads. . . . . . . . . . . . . . 29
5.7 Replace Sealing Strip. . . . . . 30
5.8 Clean Dust Collector . . . . . . 31
5.9 Clean Housing . . . . . . . . . . . 31
5.10 Check Carbon Brushes . . . . 32
Declaration of Conformity..............33
Table of Contents

5
Safety Information
1Safety Information
1.1 General Safety Information
Apart from the instructions contained in
this manual, the general safety instruc-
tions and accident prevention regula-
tions, as imposed by law will have to be
complied with. Do not put the Manual
aside without reading it even if you used
similar cleaning machines before. Take
time to read now and save time later.
Machines with known defects must not
be used. It will be of essence to make
yourself familiar with all accessories
and controls, as well as their functions,
before you start working. Avoid the
mess of having to read this book while
trying to run the machine.
Using the machine in areas with explo-
sion hazard is prohibited. The machine
may be used only for cleaning of hard
floorings and for operation on level
ground with a maximum inclination of
up to 2%.
Use the following 16“-Pads and Dust
Bags:
- Polishing Pad peach, PN.: 7856.05
- Polishing Pad jackeroo, PN.: 7853.05
- Polishing Pad champ., PN.: 7854.05
- Polishing Pad blue ice, PN.: 7855.05
- Papier Dust Bag, PN.: 7676.05
- Hepa Dust Bag, PN.: 7677.05
Notethefollowingsafety
information:
- Before use of the machine, check
the Cleanserv PB51/2000 for per-
fect condition and operational
safety.
- The operator has to use the ma-
chine within its design limits.
- This machine has been designed
for dry use. Do not use or store the
machine outdoor or under wet
conditions.
- Do not exceed the maximum incli-
nation of 10% for transport rides
(e.g. on ramps). Do not take the
machine up a ramp in forward
mode. Uphill ride must not exceed
a duration of 2 minutes and has to
be executed with outmost care (Do
not drive on wet, oily or soiled
ramps).
- The operator of the machine has to
wear firm, closed-toed shoes with
protection against slipping.
- Never leave the machine unattend-
ed before the motors are off and
key pulled and the machine is pro-
tected against unintended move-
ments.
- Keep clear of hazard zone.

6
Safety Information
1.2 Safety and Warning Symbols
1.2.1 Generally Applicable Symbols
One of the following
warning symbols has been attributed to
all paragraphs in this manual referring
to your personal safety, the safety of
your machine and the protection of en-
vironment:
Tab. 1 Versions of safety and
warning symbols used
Symbol
Symbol Hazardous for... Description
DANGER persons and goods dangerous situation
caused by misuse inaccurate adherence of instructions or pre-
scribed work routine
CAUTION the machine important information on handling the Cleanserv PB51/2000 in
order to maintain operability
Ecological hazard the environment due to use of substances representing an inherent danger to
health of environment

7
Safety Information
1.3 Labels at the Machine
The following safety and information
signs are legibly attached to the ma-
chine. Missing or illegible stickers have
to be replaced.
Hako nameplate (Fig. 1/1)
Nameplate (Fig. 1/2)
Fig. 1 Safety and
information signs
attached to the
machine
2
1

8
Safety Information
Label Information on the operating in-
structions (read and observe) (Fig.2/1)
Label Pad ground pressure (Fig. 2/2)
36 Volt system (Fig. 2/3)
Fig. 2 Safety and
informationsigns
attached to the
machine
3
1
2

9
Safety Information
1.4 Operation/Safety Information
The Cleanserv PB51/2000 may be run
by qualified personnel only; such per-
sonnelwillhavetohaveevidencedtheir
qualification for running the machine to
the owner or his authorised representa-
tive; operators explicitly will have to be
instructed by the owner or his author-
ized representative to use the machine.
Never leave the machine unattended
before the motors are off and the ma-
chine is protected against unintended
movements. To preclude unauthorised
use of the machine, switch the machine
off and pull the key.
Shut down the motors before transport
of the Cleanserv PB51/2000.
During operation the machine, the oper-
ator has to take account of local condi-
tionsandwhen workinghehas to watch
out for other persons, especially chil-
dren.
Note the following oper-
ating information:
The machine may be used for cleaning
such surfaces approved by the owner
or this authorised representative.
- Do not use the machine on floors
which are not suitable for the ultra-
high speed process (speed of
- 2000rpm max.) such as uneven or
softflooring. The high speed ofthe
machine generates a low pressure
at the pad by which the flooring
may loosen and be thrown off.
- Do not use damaged pads. The
Cleanserv PB51/2000 has not been
designed for collection of dusts
which are hazardous to health or
explosive.
- Never collect explosive fluids, un-
diluted acids and solvents. This in-
cludes gasoline, paint thinners or
fuel oil, which - when penetrating
the air being taken in - may form
explosive vapours or mixtures;
moreoveracetone,undiluted acids
and solvents if they should be ag-
gressive to material used with the
machine.
- Do not get in the near of rotating
parts during operation of the ma-
chine.
- Objects lying on the floor may be
thrown up into the air in the area of
the high-speed pads. Make sure to
remove such objects before opera-
tion.

10
Safety Information
1.5 Information on Cleaning
Specific safety instruction apply for han-
dling of drive batteries. Before proceed-
ing to cleaning of the machine, pull the
key.
Switchoffthe keyswitch
before cleaning the ma-
chine. Disconnect the
battery plug.
Do not allow water to en-
ter any electric part.
Do not park the machi-
nein the near of stoves,
burners, open flames or
other sources of heat.
Protect the machine
against frost.
Do not clean the ma-
chine by means of va-
pourjetorhighpressure
cleaning equipment.
Do not water the ma-
chine by means of a wa-
terhosesincewatermay
accumulate on the bat-
tery.
Remove accumulated
water.

11
Safety Information
1.6 Maintenance Instructions
All daily or weekly maintenance and
service works may be performed by an
operator trained for such works; the re-
maining maintenance work is to be per-
formed by qualified and trained
personnel and working on the electrical
system is limited to approved profes-
sionals.
In case of non-compliance of this in-
struction any claim for refund of conse-
quential damages will be rejected!
For service of your machines, the far-
reaching network of Hako contract deal-
ers and workshops with qualified pro-
fessionals, modern equipment and all
required special tools is at your dispos-
al. You will find professional advice and
effective support there. Refer to the
maintenance schedule for information
on the type and intervals of mainte-
nance work.
Specific safety provisions:
Risk of injury! Switch off
the machine by key
switch and pull key be-
fore maintaining the ma-
chine or replacing parts
of it. Disconnect the bat-
tery plug. Do not switch
machine on during
maintenance.
Before any work at the
electric system, discon-
nectthebatteryplugand
the mains plug of the
charger unit.
Do not use open
flameswhen handling
batteries(explosion haz-
ard).
Proceed to battery
charging with the open
hood only since explo-
sive gas may occur dur-
ing the charging proce-
dure.
Batteries are heavy. For
mounting and dismount-
ing two persons are re-
quired.
Never place metal ob-
jects or tools onto bat-
teries. Short-circuit and
explosion hazard.

12
Safety Information
Eating, drinking and
smoking are prohibited
in battery charging sta-
tionstoprecluderisksto
health. Wash your hand
thoroughlyafterworking
at batteries. Provide for
sufficient ventilation.
Do not store batteries in-
discharged condition
but recharge them as
soon as possible!
Keepthebatterydryand
clean and protect it from
soiling e.g. by metal
dust to avoid leakage-
current.
Connect batteries ac-
cording to the battery di-
agram (see Fig. 4) to
avoid short-circuit of the
batteries and the electri-
cal system.
Only use pads as speci-
fied by the manufactur-
er. Using other pads
may affect your safety.
Provide for adequate
disposal of the collected
dust. Wipe away spilled
substances.

13
Safety Information
1.7 Disposal
Render the vehicle inoperable. It must
not represent a source of danger for
children. Dispose of the equipment in
accordance with local regulations. For
further information on handling and re-
cycling, please contact the authorized
Hako dealer where you purchased the
vehicle.
Used batteries with the recycling sym-
bol contain reusable commodities. The
heavy metals contained represent a
majorrisk bothtopeople's healthandto
the environment. Never open or dam-
age batteries. Never touch, inhale or
swallow the content of batteries. Health
hazard! Do not allow batteries to get
into the environment. Risk of contami-
nating the ground and water! In accor-
dance with symbol with the crossed out
garbage bin, these batteries must not
be disposed of in domestic waste. Re-
turn and recycling of old batteries must
be agreed on with Hako's authorized
dealers in accordance with § 6 and § 8
BattG (Battery Law).
1.8 Accident Prevention Regula-
tion
BGV 5 § 29
Power-driven working media
To maintain operability, after modifica-
tionorrepair,the ownerofpower-driven
vehicles has to provide for inspection of
these vehicles at regular intervals (at
least once yearly) by an expert.
Pb

14
First Operation
1 First Operation
Before delivery, the Cleanserv PB51/
2000 hasbeen thoroughlychecked and
subject to a functional test.
Fig. 1 Battery system
1.1 Battery System
Please observe the fol-
lowing safety provision:
Before first operation of the ma-
chine, proceed to a proper initial
charging of the battery which is lo-
cated under the front hood (Fig. 3/1).
For charging, observe the operating
instructions of the charger unit.
Hako cannot be held liable for dam-
ages of the battery resulting from
failing or incorrect initial charging.
1

15
First Operation
1.1.1 Mount Battery
Please observe the fol-
lowing safety provi-
sions:
- Handle batteries with utmost care..
- Do not place metal objects on the
battery cover or terminals.
- Batteries are heavy.
- For mounting and dismounting
two persons are required.
The Cleanserv PB51/2000 uses three
batteries of 12 V / 105 Ah each.
Only used 'dryfit traction block' batter-
ies.
1. Make sure that the machine is
switched off by key switch (Fig. 4/4)
and the key is pulled.
2. Open the front hood (Fig. 4/2).
3. Take the batteries by the handles
and place the three batteries into the
machine as represented in the figure
(Fig. 4/3). Mind the battery cables.
4. Connect the battery terminals ac-
cording to the diagram.
Incorrect connection
may cause damage to
the machine or injury.
Make sure that all termi-
nals fit tightly.
5. Connect battery plug (Fig. 4/4)
again.
6. Close front hood.
Fig. 2 Battery diagram
3
2
1
4

16
First Operation
1.1.2 Charge Batteries
Please observe the fol-
lowing safety provi-
sions:
- Observe the instructions manual
and the safety provisions of the
battery and charger unit manufac-
turer.
- Switch the charger ON only after
battery cable has been connected
to the charger unit.
- Do no close the front hood during
charging procedure
- After charging: First switch charg-
er unit OFF then separate battery
cable and charger unit.
1. Make sure that the machine is
switched off by key switch (Fig. 5/1)
and the key is pulled.
2. Open the font hood (Fig. 4/2)
3. Disconnect battery plug (Fig. 4/3).
4. Connect the battery plug and the
charger unit plug.
5. Connect charger unit to the mains.
6. After charging, first switch off the
charger unit, then separate the bat-
tery cable.
7. Connect battery plug of the Cleans-
erv PB51/2000.
8. Check the charge condition at the
battery indicator, see chapter 3.
Fig. 3 Charge battery
3
21

17
First Operation
1.2 Before Work
1. Firstoperation of thebatterysystem,
(see page 14).
2. Make sure that the flooring is appro-
priate for being polished in UHS pro-
cedure (pad speed up to 2000rpm
max.)
3. Make sure that adequate pads for
this procedure have been fitted and
pad centring tightened.
4. Check the pad condition and its
thickness in regular intervals. Imme-
diately replace damaged pads (see
page 29).
5. Check all connections of the dust
collection system as well as the dust
bag condition (see page 31).
6. Set polishing head into its transport
position and ride to the surface to be
polished (see page 21).
7. This surface has to be clean, level
and free from objects.
1.3 Switch the machine on
1. Switch the machine on by the key
switch. Check emergency switch
and release if required.
2. Check battery condition (see page
18).
3. Set polishing head into working posi-
tion (see page 21).
4. Use direction switch to select the rid-
ing direction.
5. Press the levers to start-up.
6. Check pad ground pressure (see
page 20).
7. Adjust riding speed (see page 19).
Move the machine upon
switching ON! Never let
the machine run on the
spot! The floor may be
damaged by such high
speed of the pads.
1.4 End of work
1. Depress pedal tolift-upthe paddrive
and let the pedal arm catch.
2. Switch off key switch and pull key.
3. Clean machine by mild detergent
and damp cloth.
4. Recharge batteries at the end of
each working cycle or in case of in-
sufficientchargecondition(seepage
16).

18
Operation
1Operation
1.1 Control Elements and Indica-
tors
Fig. 1 Control elements
1 Control panel
2 Pad ground pressure adjustment screw
3 Start lever (on both sides)
4 Dust collector
5 Polishing headf
6 Emergency off
7 Pedal
8 Front hood
9 Carbon brush wearing indicator
1.1.1 Key Switch
Use key switch (Fig. 7/1) to turn ma-
chine on and off.
1.1.2 Emergency OFF Switch
Pressemergency off switch(Fig.7/2) to
set the machine to a safe state in case
of emergency or to prevent such emer-
gency.
1.1.3 Battery Charge Indication
Switch the machine on by key switch
(Fig. 7/1). Charge condition of the bat-
teries is checked and shown by indica-
tor
(Fig. 7/2) after approx. 20 seconds.
Seven yellow lighting LEDs indicate a
fully
charged battery. As battery discharges,
the LEDs are extinguishing from the
right to the left. Shortly before battery
discharge, the left yellow LED flashes.
Then flashes the red LED and signals
end of function. Immediately re-charge
batteries!
The battery indicator integrates a low
discharge signal sender. The machine
switchesoffautomaticallyiftheredLED
zone is attained.
Fig. 2 Control panel
1234 5
678
1
3
2
1

19
Operation
1.1.4 Direction and Speed Adjust-
ment
Use the switch (Fig. 8/2) to adjust travel
drive direction.
• Press direction switch top
- yellow LED lights
- forward direction
• Press direction switch bottom
- red LED lights
- reverse direction
The driving speed can be continuously
modified. Turn the rotary knob (Fig. 8/3)
to the limit stop for maximum speed.
1.1.5 Start-up Lever
The start-up levers are located at the
handles next to the control panel.
These levers (Fig. 6/3) are used to
switch on the travel drive assembly and
the pad drive.
1.1.6 Pad Ground Pressure Indica-
tor
The Cleanserv PB51/2000has been
equipped with a pad ground pressure
indicator (Fig. 8/1).
Pad ground pressure on the machine is
correctly set if the green LEDs light.
Lighting of the red LED zone signals in-
sufficient pad ground pressure.
See "Adjust Pad Ground Pressure".
Unevenfloormayleadto
changing indication.
Fig. 3 Pad ground pressure
indicator
1
3
2
3

20
Operation
1.2 Adjust Pad Ground Pressure
Adapt the pad speed to the type of floor-
ing to be polished. The adjustment
screw (Fig. 9/1) for pad ground pres-
sure is located on the control panel.
Proceed as follows for pad speed ad-
justment
• Turn adjustment screw counter-
clockwise to increase pad ground
pressure.
• Turn adjustment screw clockwise to
decrease pad ground pressure.
Optimum operating condition of the pol-
ishingmachineismaintained as longas
the pad indication (Fig. 9/1) remains in
the green LED zone.
Do not let the machine
run on the spot for a
longer time.
Always move the machine upon switch-
ing on in order to avoid possible
damaging of the floor. Increase or re-
ducepadgroundpressureonlyafterthe
machine has run and moved.
If pad pressure indication attains the
red zone decrease pad ground pres-
sure. Should the machine be operated
in the red zone for a longer period, the
pad drive will be overloaded and the
70A fuse activated.
Check the pad ground pressure:
Constantly check the pad ground pres-
sure indication (Fig. 8/1)
during polishing and do not exceed
ground pressure in order to shorten the
working cycle of one battery charge.
Avoid the red zone!
Fig. 4 Adjust pad ground
pressure
1
