HAKO Minuteman ROS17 Parts list manual

ROS17 Orbital Floor Machine
Parts and Instruction Manual
Minuteman International, Inc.
A Member of the Hako Group
988791 Rev A 08/22

Page 2 ROS 17 Floor Machine #988791 Rev. A 08/22
PREFACE
Thank you for your purchase of the new industry standard for fl oor machines. Minuteman
International takes great pride in off ering the most dependable, reliable and best value in industrial
fl oor machines, power sweepers and scrubbers. We set the standard.
Our Customer Service Department would like to hear from you. If you see any errors, omissions
or something that needs clarifi cation in this Parts Catalog please let us know. We are working hard
towards continually improving our processes to bring you the best you deserve. Please copy the form
below, fi ll out and comment on how you found our catalog.
Thank you!
The Minuteman International Team
Name: ______________________________________________________________________
Title: ______________________________________________________________________
Company Name: _____________________________________________________________
Address: ____________________________________________________________________
Country: ____________________________________________________________________
Type of equipment or model number: ______________________________________________
Comments: __________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
____________________________________________________________________________
Please return to:
Customer Service Manager
Minuteman International, Inc.
14N845 U.S. Route 20
Pingree Grove, Illinois 60140 USA
Phone: [phone]
Email: [email protected]

Page 3
• Stop on level surface.
• Disconnect the power to the machine by pulling the red Battery Connector located under the recovery tank near the batteries.
• Avoid moving parts. Do not wear loose jackets, shirts, or sleeves when working on machine.
• Avoid contact with battery acid. Battery acid can cause burns. When working on or around batteries, wear protective clothing and
safety glasses. Remove metal jewelry. Do not lay tools or metal objects on top of batteries.
• Do not clean machine with a pressure washer.
• Authorized personnel must perform repairs and maintenance. Use Minuteman supplied replacement parts.
For Safety When Servicing or Maintaining Machine
ROS 17 Floor Machine #988791 Rev. A 08/22
Model ROS17
Technical Specifi cations
7(&+1,&$/'$7$ 80 526
:RUNLQJZLGWK PPLQFK 
1XPEHURIRUELW RUEPLQ 
%UXVKKHDGPRWRUUDWHGSRZHU : 
%UXVKKHDGPRWRUQRPLQDOYROWDJH 9 
%UXVKKHDGPRWRUIUHTXHQF\ +] 
0D[LPXPJUDGLHQWZLWKIXOOORDG  
6ROXWLRQWDQNFDSDFLW\RSWLRQDO OJDO 
5HDUZKHHOVGLDPHWHUZLGWK PPLQFK 

$SSOLDQFHOHQJWK PPLQFK 
KHLJKWRIWKHDSSOLDQFHWRWKHEUXVKKHDGFDUWHU PPLQFK 
+HLJKWRIWKHDSSOLDQFHWRWKHVKDIW PPLQFK 
$SSOLDQFHZLGWK PPLQFK 
$SSOLDQFHVHUYLFHZHLJKWZLWKRXWVROXWLRQWDQN NJ/E 
+DQGYLEUDWLRQOHYHO PV

Page 4 ROS 17 Floor Machine #988791 Rev. A 08/22
Table of Contents
Technical Specifi cations .................................................................. 3
Parts Breakdown ............................................................................... 6
Overview ........................................................................................ 6
Handle Assembly ............................................................................ 8
Base Group .................................................................................. 12
Motor Group ................................................................................ 14
Engine Cover ................................................................................ 16
Electric Components Assembly .................................................... 18
Tank Group .................................................................................. 20
Weight Group ............................................................................... 22
Spray Group ................................................................................. 24
Symbols Used in Manual ................................................................26
Identifi cation and Technical Data .................................................. 27
General Safety ................................................................................. 28
Symbols Used on the Appliance ................................................... 33
Getting to Know the Appliance ...................................................... 33
Handling the Packed Appliance .................................................... 33
How to Unpack the Appliance ...................................................... 33
How to Transport the Appliance ................................................... 34
Main Components of the Appliance .............................................. 34
Main Components of the Handlebar ............................................. 34
Main Components of the Column ................................................. 34
Preparation of the Appliance ......................................................... 35
Inserting the Brush ....................................................................... 35
Inserting the Solution Tank ........................................................... 35
Inserting the Detergent Solution ................................................... 36
Work ................................................................................................. 37
At the End of the Work ................................................................... 38
Maintenance .................................................................................... 39

Page 5
ROS 17 Floor Machine #988791 Rev. A 08/22
Recommended Maintenance Operations ..................................... 39
Control and Cleaning of the Brush ............................................... 39
Control and Cleaning of the Brush ............................................... 40
Checking and Cleaning the Solution Tank .................................... 41
Checking and Cleaning the Detergent Solution Draught Filter ..... 42
Checking and Cleaning the Detergent Solution Spray Nozzle ..... 42
Disposal ........................................................................................... 43
Troubleshooting .............................................................................. 43

Page 6 ROS 17 Floor Machine #988791 Rev. A 08/22
Parts Breakdown
Overview
&5
&5
&5
&5

&5

&5
&5

&5

Page 7
ROS 17 Floor Machine #988791 Rev. A 08/22
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-448283 1 LABEL
2 ROS-448284 1 LABEL
3 ROS-445005 1 PAD HOLDER
CR-01 ROS-227170 1 "HANDLEBAR CONTROL
GROUP"
CR-02 ROS-226507 1 BASE GROUP
CR-03 ROS-225410 1 MOTOR GROUP
CR-04 ROS-227983 1 "ENGINE COVER TP43 SPRAY
ROS17"
CR-05 ROS-224831 1 ELECTRIC COMPONENTS
CR-06 ROS-226954 1 TANK
CR-07 ROS-226539 1 GROUP MASS
CR-08 ROS-227697 1 SPRAY ASSEMBLY

Page 8 ROS 17 Floor Machine #988791 Rev. A 08/22
Handle Assembly





 
 




























Page 9
ROS 17 Floor Machine #988791 Rev. A 08/22










 










Page 10 ROS 17 Floor Machine #988791 Rev. A 08/22
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-416493 1 LEVER
2 ROS-416504 1 LEVER
3 ROS-439036 2 LEVER
4 ROS-401122 1 LEVER
5 ROS-416501 1 SUPPORT
6 ROS-416723 1 SPRING
7 ROS-439037 1 REINFORCEMENT
8 ROS-439034 1 HANDLE BAR BODY
9 ROS-416828 1 CLAMP
10 ROS-409082 7 LOCK NUT
11 ROS-408506 9 SCREW
12 ROS-408799 4 SCREW
13 ROS-227841 1 JOINT
14 ROS-409164 2 LOCK WASHER
15 ROS-409382 1 SPLIT PIN
17 ROS-437831 2 TANK SUPPORT
18 ROS-409156 2 WASHER
19 ROS-410230 1 KNOB
20 ROS-416820 1 FAIRLEAD
21 ROS-439035 1 REAR DOOR
22 ROS-416817 1 PROTECTION CAP
23 ROS-416811 1 SWITCH
24 ROS-409765 1 CABLE GRIP
25 ROS-418269 2 SELF-TAPPING SCREW 2,9x19 TC T.C. ZNT
26 ROS-417828 1 FAIRLEAD
27 ROS-416787 2 SCREW
28 ROS-407666 4 SCREW
29 ROS-409160 1 WASHER
30 ROS-416808 1 CONTACT BREAKER
31 ROS-440567 1 CABLE
Handle Assembly BOM

Page 11
ROS 17 Floor Machine #988791 Rev. A 08/22
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
32 ROS-440824 1 SPRING
33 ROS-408634 1 SCREW
34 ROS-416789 1 SCREW
35 ROS-416777 2 SCREW
36 ROS-225126 1 PIPE
37 ROS-442314 1 ROD
38 ROS-439950 1 SOCKET
39 ROS-410545 7 INSERT
40 ROS-411366 1 HOSE
41 ROS-226709 1 COVER
42 ROS-445553 1 SWITCH
43 ROS-445554 1 PROTECTION CAP
44 ROS-445555 1 CABLE
45 ROS-441024 1 CABLE
46 ROS-446102 1 O-RING
47 ROS-204524 4 SPRING PIN

Page 12 ROS 17 Floor Machine #988791 Rev. A 08/22
Base Group































Page 13
ROS 17 Floor Machine #988791 Rev. A 08/22
Base Group BOM
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-408677 6 SCREW
2 ROS-409177 4 WASHER
3 ROS-409088 6 LOCK NUT
4 ROS-445273 1 BRUSH BASE
5 ROS-441490 2 WHEEL
6 ROS-445281 1 MOTOR SUPPORT
7 ROS-418000 2 WASHER
8 ROS-442006 2 WASHER
9 ROS-226544 3 GASKET
10 ROS-417298 2 SPACER
11 ROS-445322 2 BUSHING
13 ROS-442865 2 SCREW
14 ROS-409093 2 NUT
15 ROS-416649 1 DECAL
16 ROS-417979 6 WASHER
17 ROS-409036 1 NUT
18 ROS-409154 2 WASHER
19 ROS-445903 2 SUPPORT
20 ROS-445902 4 ANTI VIBRATION
21 ROS-417831 2 THREAD
22 ROS-445904 4 SCREW
23 ROS-415901 4 NUT
25 ROS-416783 4 LOCK WASHER
26 ROS-446066 2 WASHER
27 ROS-408977 2 SCREW
28 ROS-415927 1 WASHER
29 ROS-407658 4 SCREW

Page 14 ROS 17 Floor Machine #988791 Rev. A 08/22
Motor Group










Page 15
ROS 17 Floor Machine #988791 Rev. A 08/22
Motor Group BOM
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-441776 1 FLANGE
2 ROS-224829 1 MOTOR
3 ROS-441514 5 WING NUT
5 ROS-409082 4 LOCK NUT
6 ROS-409156 4 WASHER
7 ROS-409160 4 WASHER
8 ROS-442899 1 ORBITAL MECHANISM
8.1 ROS-415927 1 WASHER
8.2 ROS-441611 1 DOWEL

Page 16 ROS 17 Floor Machine #988791 Rev. A 08/22
Engine Cover









Page 17
ROS 17 Floor Machine #988791 Rev. A 08/22
Engine Cover BOM
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-418277 6 SELF-TAPPING SCREW
2 ROS-408860 4 SCREW
3 ROS-409156 4 WASHER
4 ROS-416056 1 FAIRLEAD
5 ROS-226542 1 COVER
6 ROS-227982 1 ENGINE COVER TP43 ROS17 FOR SPRAY COMP
6.1 ROS-416786 3 SCREW
6.2 ROS-445243 1 PROTECTION CAP
6.3 ROS-227981 1 ENGINE COVER TP43 P. PMS209 SPRAY

Page 18 ROS 17 Floor Machine #988791 Rev. A 08/22
Electric Components Assembly








Page 19
ROS 17 Floor Machine #988791 Rev. A 08/22
Electric Components Assembly BOM
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 ROS-408877 2 SCREW
2 ROS-410275 2 CLAMP
3 ROS-416788 2 SCREW
4 ROS-442197 1 SUPPORT
5 ROS-436775 1 CONDENSER
6 ROS-445598 1 RELAY
7 ROS-443822 1 START CONDENSER

Page 20 ROS 17 Floor Machine #988791 Rev. A 08/22
Tank Group


















