Operational & Service Manual: Electric Solenoid Control Valve
West Coast USA
6605 Ammunition Road
P.O. Box 505
Tillamook, OR 97141
Ph. 800-542-5526
Ph. 503-842-8886
Fax: [phone]
Central USA
8276 Hwy. 16 North
Poteet, TX 78065
Ph. 877-425-5261
Ph. 830-742-8441
Fax: [phone]
East Coast USA
480 Millrun Rd.
Salisbury, NC 28144
Ph. 800-230-0190
Ph. 704-636-4122
Fax: [phone]
Web: www.hallcoind.com Email: [email protected]
Doc # 99-5641
Solenoid Valve, Normally Closed
# 56-4891
Solenoid Valve, Normally Closed
# 56-4891
Solenoid Valve, Normally Open
# 56-4892
Coil:
12V - # 56-4893
24V - # 56-5586
115V - #56-4894
Valve Body
Valve Assembly:
12V Coils - # 56-4896
24V Coils - #56-5587
115V Coils - # 56-5347

Doc # 99-5641
2
Typical Electric Solenoid Control Valve Plumbing
Fitting, 3/4" Adj. Male O-Ring x 3/4" Female Pipe Swivel
Fitting, 3/4" Adj. Male O-Ring x 3/4" Female Pipe Swivel
Fitting, 3/4" Adj. Male O-Ring x 3/4" Male JIC 90_
Fitting, 3/4" Adj. Male O-Ring x 3/4" Female Pipe Swivel
Electric Solenoid Control Valve
Hose, 3/4" x 72" Length, 3/4" Male Pipe Ends
Hose, 3/4" Size, 3/4" Male Pipe Ends
Hose, 3/4" Size, 3/4" Male Pipe Ends
Hose, 3/4" Size, 3/4" Wide Swept
Female JIC x 3/4" Male Pipe Ends
Hose, 3/4" x 72" Length, 3/4" Male Pipe Ends
Hose, 3/4" Size, 3/4" Male Pipe Ends
These two hose ends
may be swapped.
2
1
3
4
Copyright 2010

Doc # 99-5641
3
Valve Operational Modes
Valve Unload Neutral Load
SV-1 Energized Not Energized Not Energized
SV-2 Energized Not Energized Energized
SV-3 Not Energized Not Energized Energized
SV-1 Pull/Twist No Override No Override
SV-2 Push No Override Push
SV-3 No Override No Override Pull/Twist
Electric
Control
Manual
Control
SV-1
SV-2 SV-3
SV-2, Normally Open
Energize Coil to Close
Manual Override: Push & Hold
SV-3, Normally Closed
Energize Coil to Open
Manual Override: Twist Outward to Open
(Locks at 90_)
SV-1, Normally Closed
Energize Coil to Open
Manual Override: Twist Outward to Open
(Locks at 90_)
Copyright 2010

Doc # 99-5641
4
Valve Configurations & Floor Behavior
○ Valve Open
● Valve Closed
SV-1 SV-2 SV-3 Floor Behavior
●○● Neutral
●●○ Load
○●● Unload
●●● Sequences 1-2-3 Both Ways
○○● No Movement - Neutral
○●○ All Slats Move Together Both Ways
Troubleshooting:
Operation of the Hallco LIVE FLOOR
TM
depends on a functional and adequate hydraulic
supply system, a working hydraulic module, intact and correct external plumbing, and a
correctly operating control valve. This document covers the potential failure modes of the
electric solenoid control valve only. Refer to the floor owner’s manual for additional
troubleshooting information. Contact Hallco if the troubleshooting techniques do not resolve
the floor malfunction.
The table below shows all the possible control valve combinations, and the expected floor
movement associated. Three of the combinations produce standard operational floor
movement and three produce incorrect movement. Compare the configuration of the desired
floor movement with the configuration of the actual floor movement to identify a suspect
solenoid valve.
Each cartridge valve has a manual override option. For normal mode make sure that the
manual overrides of SV-1 and SV-3 are not locked in the override position (out). Operate the
floor with the manual controls to check whether the problem is electrical or hydraulic.
If the floor operates correctly when the valve is controlled manually, then the problem is not in
the solenoid valves. A valve coil may be malfunctioning or not energized correctly. Coils may
be swapped between valves to verify which one is malfunctioning.
If the floor does not operate correctly when it is manually controlled, the problem is likely not
electrical. SV-1 and SV-3 valves may be swapped to verify which one is malfunctioning.
