Halsey Taylor HAC8FSBLR-Q ADA User manual

This water cooler is certified to
NSF/ANSI 61.
GENERAL
Self-contained, electric refrigerated, bi-level
wall-mounted water cooler designed to be
easily accessible to physically challenged
individuals. When properly installed, unit meets
state and federal requirements for both
children or adults as defined by the
Americans with Disabilities Act. Barrier walls
required or apron installed to meet cane touch
prerequisite. Unit is certified to NSF/ANSI 61,
and meets requirements of the Safe Drinking
Water Act. Unit provides 50° F water at 80° F
inlet water and 90° F ambient.
CABINET
Stainless steel panels resist wear and corrosion.
Durable satin finish helps hide water spots and
fingerprints.
COOLER TOP
Non-corrosive stainless steel cooler top, no.
300 series with satin finish resists stains and
corrosion and is easy to maintain. Anti-splash
ridge reduces splatter. Contoured to insure
proper drainage.
BUBBLER
Exclusive one-piece, chrome-plated two-stream
mound-building bubbler with non-removable
anti-squirt feature and integral hood insures a
satisfying drink of water.
PUSH BAR ACTUATION MECHANISM
Self-closing, light-touch push bars on front and
sides with raised letters for the visually
impaired.
AUTOMATIC STREAM HEIGHT REGULATOR
Self-closing assembly is located inside unit to
prevent tampering. Unit resists corrosion and
liming. A constant stream height is automatically
maintained under line pressures that vary from
20 to 105 psi.
INLET STRAINER
Easily cleaned in-line strainer screen traps
particles of 140 microns or larger before they
enter the waterway.
TEMPERATURE CONTROL
Positive sensing thermostat for controlling
temperature of storage tank water. Factory set
at 50° F Adjustable ± 5° F.
STORAGE TANK
Stainless steel evaporator/storage tank for long
life. Waterways are certified to NSF/ANSI 61,
far exceeding the requirements of the Safe
Drinking Water Act.
REFRIGERATION SYSTEM
Hermetically sealed, positive start compressor
with lifetime lubrication and built-in overload
protection, efficient capillary sizing, large
capacity dryer-strainer, and self-lubricated fan
cools copper/aluminum condenser. System
uses R134A refrigerant. Protected by Halsey
Taylor’s Limited 5 Year Warranty.
VENTILATION
Insure proper ventilation by maintaining
6" (152mm) minimum clearance from
cabinet louvers to wall.
SUGGESTED SPECIFICATIONS
Shall deliver 8.0 GPH of 50° F water at 90° F
ambient and 80° F inlet water. Shall have
stainless steel basin with removable drain
strainer. Bubbler shall be two-stream, mound
building type. Separate valve and automatic
stream regulator shall be mounted within
cabinet. Refrigeration system shall employ high
efficiency, positive start compressor using
R134A, stainless steel tank with totally
encapsulated insulation and be controlled by
positive sensing thermostat. Shall have front
and side push-bar water controls with raised
lettering for the visually impaired. Cooler shall
comply with ANSI 117:1 and ADA for visual
and motion disabilities. The manufacturer shall
certify the unit to meet the requirements of
NSF/ANSI 61, and the Safe Drinking Water Act.
Unit complies with ARI Standard 1010.
NOTE: Continued product improvement
makes specifications subject to change
without notice. See Halsey Taylor website
for most current spec sheet.
Standard Finish Is Stainless Steel
Optional Finish
■■
Platinum Vinyl
Optional Accessories (extra cost)
■■
Glass Filler Kit
■■
Water Filter
■■
Easy-Flex™Bubbler
■■
Cane Touch Apron
HALSEY TAYLOR, 2222 CAMDEN COURT, OAK BROOK, ILLINOIS 60523
A16 / 8-2007
MODEL: ■■HAC8FSBLR-Q ADA
■■HACFSDBLR-L/R ADA
Barrier-Free Cooler
Bi-Level
halseytaylor.com
HAC-Q BARRIER-FREE SERIES
Model GPH Capacity Base F.L. Shipping Rated
No. Cooled to 50° F* Rate Amps Weight Watt
Ambient Air Temp Cap. lb. Usage
70°F 80°F 90°F†100°F
HAC8FSBLR-Q ADA 9.7 8.8 8.0 7.2 8.0 4.0 92 370
*With projector service and tap water at 80° F
†UL listed and complies with ARI Standard 1010
Trap and service stop not included
JOB NAME:
ENGINEER/CONTRACTOR NAME:
APPROVAL:
DATE:
Printed in the U.S.A.
Bi-Level
Barrier-Free Cooler
(CONTINUED)
MOUNTING INSTRUCTIONS
Locate and secure wall hangers to wall.
Note location of waste trap (in left side unit).
To insure proper engaging of waste line into
trap, centerline of trap must be 41/8" from wall
face. Mount refrigerated unit on right wall
bracket and secure cabinet to wall using holes
in lower back of frame. Mount fountain
(non-refrigerated) unit on left wall bracket and
against left side of refrigerated unit. Secure
cabinet to wall using holes in lower back
of frame. Install connecting waste line to
tailpieces on both units. Insulated water line
furnished to connect fountain to refrigerated
unit. Connect building water supply line to
“water inlet” connection on refrigerated unit.
Complete instructions packed with unit.
Trap and service stop not included.
OPERATING PRESSURES:
Supply water - 105 psi maximum
Minimum 40 psi supply line pressure required
in special circumstances when both sides of
bilevel are in use simultaneously to ensure
adequate stream height. Does not apply to
non-refrigerated units.
ELECTRICAL
Furnished with plug-in, 3-wire grounding type
service cord. Standard 120 volt, 60 Hz, single
phase. Install 120-volt receptacle, rated at
15-amp minimum, to receive 3-wire parallel
blade grounding type male plug.
*
HANGER BRACKET
RIM HEIGHT
ORIFICE HEIGHT
ORIFICE HEIGHT
C
5/16" (8mm) DIA. (10 HOLES)
B
E
E
E
D
A
F
F
FINISHED FLOOR
L
C
L
C
13 7/8"
352mm
7 1/4"
185mm
2 9/16"
65mm 6 1/4"
159mm
11/16"
18mm
4 9/16"
116mm
18 3/4"
476mm
37 1/2"
952mm
6 1/2"
165mm
18 1/16"
459mm
5 3/4"
146mm
5 3/4"
146mm
5 3/4"
146mm
5 3/4"
146mm
1 3/8"
35mm
1 3/8"
35mm
1 3/8"
35mm
1 3/8"
35mm
2 7/16"
63mm
5"
127mm
10"
254mm
20 3/8"
518mm
26 11/16"
678mm
31 11/16"
805mm
3 1/2"
89mm
4 1/2"
114mm
12 5/16"
313mm
27"
686mm
4 1/8"
105mm
18 5/8"
473mm
2 9/16"
65mm
31 7/8"
810mm
33"
838mm
39 1/2"
1003mm
6 3/4"
172mm
8"
203mm
A. RECOMMENDED WATER SUPPLY LOCATION. 3/8" O.D. UNPLATED COPPER TUBE CONNECT STUB
1-1/2" (38mm) OUT FROM WALL SHUT OFF BY OTHERS
B. RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/ 2" O.D. DRAIN
C. 1-1/2" TRAP NOT FURNISHED
D. ELECTRICAL SUPPLY (3) WIRE RECESSED BOX
E. INSURE PROPER VENTILATION BY MAINTAINING 6" (152mm) MIN. CLEARANCE FROM CABINET LOUVERS TO WALL
F. 7/16" BOLT HOLES FOR FASTENING UNIT TO WALL
FRONT VIEW SIDE VIEW
*Adult ADA requirement. 24" (609mm) for Child ADA.
Adjust other measurements accordingly.
HAC8FSBLR-Q ADA,
HACFSDBLR-L/R ADA
