Hama DIR3100MS User manual

Operating Instructions /Bedienungsanleitung /Mode d‘emploi /Instrucciones de uso /
Руководство по эксплуатации /Istruzioni per l‘uso /Gebruiksaanwijzing /Οδηγίες χρήσης /Instrukcja obsługi /
Használati útmutató /Návod kpoužití /Návod na použitie /Manual de instruções /Kullanma kılavuzu /
Manual de utilizare/Bruksanvisning /Käyttöohje /Работна инструкция /Betjeningsvejledning /Manuelt stasjonssøk
Digital Radio
Digitalradio
00054819 (DIR3100MS)
00054824 (DIR3110MS)
00054853 (DIR3115MS)
00054854 (DIR3115MS)
V4

GOperating instructions
Technical Data /Technische Daten
Radio Receiver/
Radio Empfänger
DAB
+
DAB+
+
FM
+
Internet
+
Spotify
+
Connectivity/
Verbindungsfähigkeit LAN (10/100), WIFI(b/g/n), USB (Play/Charge 5V 1A)
Display/
Bildschirm 2.8“ Colour TFT
Encryption/
Verschlüsselung WEP,WPA,WPA2, WPS
Speaker/
Lautsprecher 10 WRMS (2x 5W)
Impedance/
Impedanz
6Ohm
Speaker
75 Ohm
Antenna
Power input/
Stromeingang 110-240 V~50-60Hz
Frequency range/
Frequenzbereich
DAB/DAB+:
174-240 MHz
FM:
87.5-108 MHz
Sensitivity/
Empndlichkeit
DAB/DAB+:
-97 ~99dBm
FM:
-105 ~109 dBm
Power Consumption/
Stromaufnahme
Operation/
Betrieb 12 W Standby/ Bereitschaft
~ 1W
Input &Output/
Anschlüsse Line Out, Aux in, 3.5 mm Earphone Jack, RJ45
Presets/
Favoriten
DAB/DAB+:
30
FM:
30
Internet:
30
Codec/
Formate
IR:
MP3, WMA, ADTS
UPNP:
MP3, WMA v9/ASF,
M4A, ADTS, WAV,
LPCM, FLAC, ALAC
DAB:
MP2, AAC
USB Stick:
MP3, WMA
UI Languages/
UI Sprachen
English, Danish, Dutch, Finnish, French, German, Italian, Norwegian, Polish, Portuguese,
Spanish, Swedish, Turkish
Package Content/
Verpackungsinhalt
Manual, Spotify sheet, remote control, AAA batteries/
Bedienungsanleitung, Spotify yer,Fernbedienung, AAA Batterien
Dimension (WxHxD)/
Größe (BxHxT) 293 x122 x160 mm
Weight/
Gewicht 1900g

A
16151412 17 18
1320 20
19
2 7
1110
9
12
1 8
4 5
3 6
B

C
OK
+
VOL
MODE
ALARM
SLEEP SNOOZE
123
456
78
10
9
MENU INFO MUTE
-
1
2
13
15
3
14
5
10
6
9
8
11
4
7
12
6
10
16
14
17
20
22
27
3
7
15
11
19
21
25
26
1
2
18
4 5
23
9
13
24
8
12
C
1
2

1
Controls and Displays
A: Front
1[volume -/+] /
[ ]
Rotate: Volume control
Press: On/off switch
2[info] Display additional information
3[menu] Direct access to the menu
4[mode]
Changing operating mode
(Internet radio, Spotify
Connect, Music player,DAB,
FM, Aux in)
5[back] Back one menu level
6[alarm] Direct access to alarm clock
settings
7[memory] List/save favourites
8[enter/
navigate]
Rotate: Select
Press: Conrm
9Infrared receiver
10 [SNOOZE] Snooze settings/
activating Snooze
11 2.8“ colour display
12 Brightness sensor
B: Rear
12 Mains power supply
13 Antenna*
14 Headphone socket
15 AUX IN socket
16 LINE OUT socket
17 LAN connection
18 USB connection
19 Auto dimmer switch
20 Thread for attaching to the
wall bracket
Note
*This radio has achangeable antenna. Youcan use
an active or passive antenna equipped with acoaxial
connetion.
1C: Remote Control
1[]On/off switch
≙Press [volume -/+]/ [ ]
2[OK] Conrm
≙Press [enter/navigate]
3Navigation
keys
∧Up /∨Down /
Back one menu level
≙[back] /
Forward/ Conrm
≙Press [enter/navigate]/[OK]
4Volume keys
[+]/[-]
Volume control
≙Rotate [volume -/+]/ [ ]
5[MENU] Direct access to the menu
≙[menu]
6[MODE]
Changing operating mode
(Internet radio, Spotify Connect,
Music player,DAB, FM, Aux in)
≙[mode]
7[INFO] Display additional information
≙[info]
8[MUTE] Mute
9[ALARM] Direct access to alarm clock
settings ≙[alarm]
10 [ ]previous track (operating mode:
Spotify Connect, Music player)
11 [ ]next track (operating mode:
Spotify Connect, Music player)
12 [  ]
Start/ Stop playback (operating
mode: Spotify Connect, Music
player,Aux in)
13 Number
keys
Direct access to favourites/Save
favourites
14 [SLEEP] Snooze settings
≙[SNOOZE]
15 [SNOOZE] Activating Snooze
≙[SNOOZE]

2
2C: Remote Control
1[ ] On/off switch
≙Press [volume -/+]/ [ ]
2[ ] Mute
3[IR] Direct access to operating
mode Internet radio ≙[mode]
4[DAB] Direct access to operating
mode DAB ≙[mode]
5[FM] Direct access to operating
mode FM ≙[mode]
6[AUX]
Direct access to operating
mode Aux in
≙[mode]
7[ ] Backlight settings
8[MEDIA] Direct access to operating
mode Music player ≙[mode]
9[MODE]
Changing operating mode
(Internet radio, Spotify
Connect, Music player,DAB,
FM, Aux in) ≙[mode]
10 [ ] Equaliser settings
11 [ALARM] Direct access to alarm clock
settings ≙[alarm]
12 [SLEEP] Snooze settings
≙[SNOOZE]
13 [SNOOZE] Activating Snooze
≙[SNOOZE]
14 [MENU] Direct access to the menu
≙[menu]
15 [ ]
previous track (operating
mode: Spotify Connect,
Music player)
16 [ ]
next track (operating mode:
Spotify Connect,
Music player)
17 Navigation
keys
Up /Down /
Back one menu level
≙[back] /
Forward/ Conrm
≙Press [enter/navigate]/[OK]
18 [OK] Conrm
≙Press [enter/navigate]
19 [ ]
Rewind (operating mode:
Spotify Connect,
Music player)
20 []
Fast forward(operating
mode: Spotify Connect,
Music player)
21 Volume keys
[+]/[-]
Volume control
≙Rotate [volume -/+]/ [ ]
22 Favourite keys
[+]/[-] Selection from favourites list
23 []
Start/ Stop playback
(operating mode: Spotify
Connect, Music player,
Aux in)
24 [ ] Back one menu level ≙[back]
25 Number keys Direct access to favourites/
Save favourites
26 [FAVORITES] List/save favourites
27 [INFO]
Display additional
information
≙[info]

3
1. Explanation of Warning Symbols and Notes ...........8
2. Package Contents ................................8
3. Safety Notes ....................................8
4. Informations and notes beforegetting started .........9
4.1 LAN connection (wired network) .......................9
4.2 WLAN connection (wireless network) ...................9
5. Getting started ..................................9
5.1 Remote control ....................................9
5.2 Radio –Connecting and starting up....................10
5.3. General notes on use ..............................10
5.4 Initial setup .....................................12
5.4.1 Setup wizard..................................12
6. Main menu /modes .............................13
7. Internet radio ..................................13
7.1 Station search ....................................13
7.1.1 Search by country or region .......................14
7.1.2 Search by genre ...............................14
7.1.3 Search by name................................14
7.1.4 Popular stations ...............................14
7.1.5 New stations .................................15
7.1.6 Local stations .................................15
7.2 Podcasts ........................................15
7.2.1 Search by country or region .......................15
7.2.2 Search by format (subjects or categories) ............15
7.2.3 Search by name................................16
7.3 Last listened .....................................16
7.4 Favourites (local) ..................................16
7.4.1 Save favourites ................................16
7.4.2 Access favourites...............................16
7.4.3 Management of favourites with the remote control .....17
7.5 Favourites .......................................17
7.5.1 First use –Registering your radio...................17
7.5.2 Managing favourites online ......................18
7.5.3 Opening the favourites list........................18
7.5.4 My Added Stations .............................18
8. Spotify ........................................18
9. Music player (UPNP,USB) .........................20
9.1 Playback from external storage media (USB)..............20
9.2 Playback from acomputer (streaming) ..................20
9.3 Playback from the network –Accessing les using the radio .21
9.4 Playback of playlist ................................21
9.5 General playback options ...........................22
10. DAB .........................................22
10.1 Search/ Automatic search...........................22
10.2 Manual station search .............................23
10.3 Station list ......................................23
10.4 Sort station list ..................................23
10.5 Slideshow/Station information .......................24
10.6 Edit station list...................................24
10.7 Favourites ......................................24
10.7.1 Save favourites ...............................24
10.7.2 Access favourites..............................24
10.7.3 Management of favourites with the remote control ....25
10.8 DRC (Dynamic Range Control) .......................25
11. FM ..........................................26
11.1 Scan setting ....................................26
11.2 Automatic station search ...........................26
11.3 Manual station search .............................26
11.4 Favourites ......................................26
11.4.1 Save favourites ...............................26
11.4.2 Access favourites..............................27
11.4.3 Management of favourites with the remote control ....27
11.5 Audio setting ...................................27
12. Auxiliary Input.................................28
13. Sleep ........................................28
14. Alarms .......................................29
14.1 Alarm settings ...................................29
14.2 Activating/ deactivating the alarm ....................29
14.3 Stopping the alarm/ Snooze function ..................29
15. System settings ...............................30
15.1 Equaliser .......................................30
15.2 Network .......................................30
15.2.1 Network wizard...............................30
15.2.2 Wireless network connection (WLAN) ..............31
15.2.3 Wired network connection (LAN) ..................32
15.2.4 Manual conguration of network connection.........32
15.2.5 View settings.................................33
15.2.6 NetRemote PIN Setup /Smart Radio-App ...........33
15.2.7 Network prole ...............................33
15.2.8 Keep network connected ........................34
15.3 Time/ Date .....................................34
15.4 Language ......................................34
15.5 Factory Reset ...................................34
15.6 Softwareupdate .................................35
15.7 Setup wizard ....................................35
15.8 Info ...........................................35
Content

4
15.9 Backlight ......................................36
15.10 Color theme ...................................36
15.11 AUX: Auto-Standby ..............................36
15.12 Wall mounting...............................36
16. UNDOK –everything in the palm of your hand ......37
16.1 Interface/layout of the UNDOK home screen.............37
16.2 First-time setup of the device with UNDOK..............37
16.2.1 Procedurefor iOS users .........................37
16.2.2 Procedurefor Android users .....................38
16.3 General control of adevice or group ..................38
16.4 Creating/managing multi-room groups.................39
16.5 Multi-room setup on the radio .......................40
16.5.1 General information ...........................40
16.5.2 Creating agroup..............................40
16.5.3 View details .................................40
16.5.4 Add clients to agroup..........................40
16.5.5 List current clients .............................40
16.5.6 Leave group .................................40
16.5.7 Delete group.................................40
16.6 Settings and standby .............................41
17. Careand Maintenance ..........................41
18. Warranty Disclaimer ............................41
19. Service and Support ............................41
20. Recycling Information ..........................41
21. Declaration of Conformity........................42

5
Icon Meaning
Operating mode: Aux in
Operating mode:
Internet radio
Operating mode:
Spotify Connect
Operating mode: Music player
Operating mode: DAB
Operating mode: FM
Menu
Successful LAN connection
Failed LAN connection
Signal strength (WLAN):
bad –very good
No WLAN reception
Signal strength (DAB)
bad –very good
UPnP playback (network)
USB connection
Attention!
See display for further
information
Application not possible
See display for further
information
Icon Meaning
Application failed
See display for further
information
Muted
Shared Media Playback
Playback: Pause
Playback: Stop
RDS (Radio Data System)
Additional station
information available for FM
radio
Playpack: Repeat
Playback: Shue 
Random playback
Further input specication
required
See display for further
information
Application successful
Sleep activated
Alarm 1/2 activated
Stereo
Favourite
Icon overwiew

6
MAIN MENU
INTERNET RADIO
Last listened
Station list
My Favourites
Local
Stations
Location
Genre
Search stations
Popular stations
New stations
Podcasts
Location
Genre
search podcasts
My Added Stations
Help
Get access code
FAQ
System settings
Main menu
SPOTIFY
System settings
Main menu
MUSIC PLAYER
Shared media
USB playback
My playlist
Repeat play
Shue play
Clear My playlist
Prune servers
System settings
Main menu
DAB
Station list
Scan
Manual tune
Prune invalid
DRC
DRC high
DRC low
DRC off
Station order
Alphanumeric
Ensemble
valid
Slide Show
Picturewith text
full screen
System settings
Main menu
FM
Scan setting
Audio setting
Menu structure

7
System settings
Main menu
AUXILIARY INPUT
System settings
Main menu
SLEEP
ALARMS
SYSTEM SETTINGS
Equaliser
Normal
Flat
Jazz
Rock
Movie
Classic
Pop
News
My EQ
My EQ prole setup
Bass
Treble
Loudness
Network
Network wizard
PBC Wlan setup
View settings
Manual settings
NetRemote PIN Setup
Network prole
Keep network connection
Time/Date
Set Time/Date
Auto update
Update from DAB
Update from FM
Update from
Network
No update
Set format
Set timezone
Daylight savings
Language
Factory Reset
Softwareupdate
Auto-check setting
Check now
Setup wizard
Info
Backlight
Slumber Mode
Operation Mode
Standby Mode
Timeout
Backlight
Multi-room
View details
State
Group
Create new group
Add to group
List current clients
Remove from group
Dissolve group
Color theme
AUX: Auto-Standby

8
Thank you for choosing aHama product.
Take your time and read the following instructions and
information completely.Please keep these instructions in a
safe place for futurereference. If you sellthe device, please
pass these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Risk of electric shock
This symbol indicates product parts energized with a
dangerous voltage of sucient magnitude to constitute
arisk of electric shock.
Warning
This symbol is used to indicate safety instructions or to
draw your attention to specic hazards and risks.
Note
This symbol is used to indicate additional information or
important notes.
2. Package Contents
•Digital radio DIR3100/ DIR3110
•Telescopic antenna with coaxial connection
•Remote Control
•2x AAA batteries
•Quick guide/ operation instructions
•Spotify Connect brochure
3. Safety Notes
•The product is intended for private, non-commercial use
only.
•Protect the product from dirt, moistureand overheating
and us it in dry rooms only.
•As with all electrical devices, this device should be kept
out of the reach of children.
•Do not drop the product and do not expose it to any
major shocks.
•Do not operate the product outside the power limits
given in the specications.
•Keep the packaging material out of the reach of children
due to the risk of suffocation.
•Dispose of packaging material immediately according to
locally applicable regulations.
•Do not modify the device in any way.Doing so voids the
warranty.
Risk of electric shock
•Do not open the device or continue to operate it if it
becomes damaged.
•Do not use the product if the AC adapter,adapter
cable or power cable is damaged.
•Do not attempt to service or repair the product
yourself.Leave any and all service work to qualied
experts.
Warning Batteries
•When inserting batteries, note the correct polarity (+
and -markings) and insert the batteries accordingly.
Failuretodosocould result in the batteries leaking
or exploding.
•Do not allow children to change batteries without
supervision.
•Remove the batteries from products that arenot being
used for an extended period.
•Do not short-circuit batteries.
•Do not charge batteries.
•Do not throw batteries in are.
•Keep batteries out of the reach of children.
•Do not mix old and new batteries or batteries of a
different type or make.

9
4. Informations and notes before getting started
Note
Adetailed description of the UNDOK app and
the fullscope of functions can be found in our
UNDOK guide at:
www.hama.com ->00054819, 00054824,
00054853, 00054854->Downloads
Note –Optimal reception
•This product is equipped with an antenna connection
which allows the use of an active or passive antenna.
The antenna is connected with acoaxial F-connector.
•Atelescopic antenna that enables DAB, DAB+ and
FM reception is included in the delivery.
•Forbest reception, ensurethat the antenna is fully
extended and vertical.
•Tryvarious different positions if necessary to get the
best reception.
Network connection/
Preparing the internet connection
Youcan integrate this radio into alocal network and
even access home servers or other authorised resources.
To receive internet radio or access non-local media
(streaming, such as Spotify Connect), the network must be
connected to the internet.
Note
The LAN connection is less susceptible to faults than a
WLAN connection. That´s why it´s recommended to use
awired connection between access point (AP) and radio
to ensureanundisturbed reception.
4.1 LAN connection (wired network)
•Connect aLAN cable of type RJ45 to afreesocket on
your router,switch or access point.
•Connect the other end of the LAN cable to the RJ45 LAN
socket on the radio.
•Make surethat the router is on and that you have an
Internet or network connection.
•If you have questions about router conguration,
please consult the operating manual of the router for
troubleshooting.
•Adetailed description of how to congurethe LAN
connection is given in the Wired network connection
(LAN) section.
4.2 WLAN connection (wireless network)
•Ensurethat the router is switched on, is functioning
correctly and that thereisaconnection to the internet.
•Activate the WLAN function of your router.
•Follow your router´s operating instructions as regards the
correct functioning of the WLAN connection.
•Adetailed description of how to congurethe
LAN connection is given in the Wireless network
connection (LAN) section.
5. Getting started
5.1 Remote control
•Open the battery compartment cover.Itis located on the
rear of the remote control.
•Pullthe closing tab back (if present) and lift the cover.
With other models of remote control, it suces to simply
push the casing in the direction indicated.
A: Closing tab B: Sliding cover
Insert the batteries provided, paying attention to match the
polarities correctly.The correct polarity is indicated by the
plus and minus symbols in the battery compartment.

10
Note -Remote control
•This radio comes with one of the two remote controls
depicted (C).
•Features that differ between the two remote controls
areindicated in these instructions by the symbols
and
.
5.2 Radio –Connecting and starting up
Connect the network cable to aproperly installed and
easily accessible network socket.
The power supply unit is suitable for mains voltages
between 100 and 240 V, and is thus operable on almost
any AC power grid. Please note that acountry-specic
adapter may be necessary.
Youcan nd an appropriate selection of Hama products at
www.hama.com.
Note
•Only connect the product to asocket that has been
approved for the device. The electrical socket must
always be easily accessible.
•When using amult-socket power strip, make sure
that the sum power draw of all the connected devices
does not exceed its maximum throughput rating.
•If you will not be usingthe product for along period
of time, disconnect it from mains power.
Once the product has been connected to mains power,
initialisation takes place.
The radio starts up.
To assist you in rst-time setup of the radio, a Setup
Wizard is provided.
5.3. General notes on use
Notes on use
•In the following operating instructions, we willfocus
on operating the device via the front panel. We will
deal with functions separately that areonly available
on the app or the remote control.
•The buttons on the remote control –corresponding
to the control buttons on the device (≙)- you will nd
under Controls and Displays.
[OK]and the navigation button on the remote
control correspond to pressing [enter/navigate].
OK]and the navigation buttonon the remote
control correspond to pressing [enter/navigate].
The navigation key on the remote control has the
same function as [back]onthe front of the radio.
The navigation key on the remote control has the
same function as [back]onthe front of the radio.
The navigation keys ∧/∨on the remote control have
the same function as turning [enter/navigate]onthe
front of the radio to the left and right.
The navigation keys /on the remote control
have the same function as turning [enter/navigate]
on the front of the radio to the left and right.
•When aselection among menu items is to be made
(such as YES or NO), the one currently selected has a
light-coloured background ll.
•In menus offering avariety of different options
(such as Equalizer,Update, and so on), the currently
selected option is marked with *.

11
Navigation and controls
•Select among menu items by turning [enter/navigate].
•Conrm the selection by pressing [enter/navigate].
This procedureisindicated in these operating instructions
by the following symbols:
selection (navigate) conrmation (enter)
Some features can be
accessed by means
of shortcut buttons.
Pressing shortcut buttons
is indicated herebythis
symbol.
After pressing ashortcut button, navigate amongst the
menu items using [enter/navigate].
Volume adjustment /mute
•Youcan turn the volume up (right) or down (left) by
turning [volume -/+] /[ ]accordingly.
Press [MUTE]onthe remote control to mute the radio.
Press [ ]onthe remote control to mute the radio.
Press [MUTE], on the remote control again to reset the
volume at the level you set beforemute the radio.
Press [ ], on the remote control again to reset the
volume at the level you set beforemute the radio.
Entering passwords, search terms, and so on
•Select each successive letter and digit by turning [enter/
navigate]and conrm each selection by pressing
[enter/navigate].
•To make corrections, select BKSP and conrm. The last
input made is deleted.
•To cancel input, select CANCEL and conrm.
•Once your input is complete, select OK and conrm to
nish.
•Press [info]tojump directly to the BKSP/ OK/ CANCEL
elds.
Additional information
Press [info]todisplay context-dependent additional
information. The information shown depends on the
operating mode as well as the current selection of radio
station, music le, etc.
[info]
•Description
Indicates the radio station, the current program,
contents, subjects, etc.
•Program genre/country
Indicates the genre(music style) and the country or
region of the station.
•Reliability
•Bit-Rate
The currently received digital bit rate of the received
station is displayed.
•Codec
Species the encoding scheme used to digitise the data
or signal (such as MP3 or WMA).
•Sampling rate
Species the sampling rate, or the frequency with which
the audio signal is polled (Sampling-/ Samplerate), in a
certain period of time.
•Signal strength
The signal strength of the received station is displayed
via abar and its length.
•Today’sdate
•Artist
•Album
•Folder
•Path
Species the directory path at which the le currently
being played back is saved.
Switching on/off /Standby
•Press [volume -/+] /[], to switch the radio on or off
(Standby).
•To completely switch off the device, disconnect it from
the power supply.

12
5.4 Initial setup
The Setup Wizardstarts up automatically when the radio
is turned on for the rst time. The default used language
is English. Youcan skip the Setup Wizardand start up
anytime in your language.
Set up your desired language as described in 15.4.
Language.
5.4.1 Setup wizard
Youcan choose between starting the initial setup via Setup
Wizard(YES)and skipping the Setup Wizard(NO).
YES /NO
Note –Starting up with or without
the setup wizard?
•We recommend using the setup wizard(YES)to
quickly and easily congurethe time, date, internet
connection, etc.
•If you wish to skip setup with the setup wizard
anyway,choose NO.All of the settings congured
by the setup wizardcan be congured or changed
individually in the System settings menu. Alternatively,
you may restart the setup wizardatany time.
•Next, choose YES or NO to dene whether the setup
wizardshould start automatically next time the radio
is started up. Youare in the main menu.
Date/ Time
•12/24 hours format
•Auto update
•Update from DAB/ FM
If automatic time and date adjustment is
activated, the device receives time and date
information from the station over the FM/DAB/
DAB+ radio network. This is the best way to
ensurethat the clock will run accurately and the
alarm willtrigger at the correct time, even after
power outages.
•Update from Network
Choose this option to set the time and date
automatically from the internet. Set the timezone
of your current location and, if desired, turn (ON)
automatic adjustment between summer time and
winter time.
•No update
The time and date (DD-MM-YYYY)must be set
manually; no automatic calibration takes place.
Keep network connected
This setting is aradio energy-saving function. If this feature
is disabled (NO*), the network module will be switched
off whenever the radio is not actively using the network
connection (such as in standby mode). This means the
radio will not be accessible via the network from your PC,
smartphone or tablet.
Youshould enable (YES *)this menu item if you want
to use streaming or control functions via the app. This
function is disabled by default.
Network wizard–Conguration of network
connection
Note –Reference to adifferent part of these
operating instructions.
•Because this chapter is extensive, please follow the
directions in section 15.2.1. Network wizard–
Conguration of internet connection
Once the network wizardhas nished, the setup wizard
is nished as well. The display shows amessage to this
effect.
Press [enter/navigate]toenter the main menu.

13
Proceed as follows to choose your desired language:
[menu]
System settings

Language

desired language
6. Main menu /modes
Access the main menu as follows:
[menu]
Main menu
The main menu contains the various operating modes as
well as other options that areexplained separately in the
following chapters.
7. Internet radio
8. Spotify
9. Music player
10. DAB
11. FM
12. Auxiliary Input
13. Sleep
14. Alarms
15. System settings
Select amongst the available operating modes by
repeatedly pressing [mode].
[mode]
7. Internet radio
The radio uses the station list on the vTuner* portal.
Youcan use stations without direct registration on the
following portal: http://www.wiradio-froniter.com.
Youwill nd detailed operating instructions under Section
7.5 Favourites
Note
*Ifnecessary,itispossible to switch providers in order
to make all features and functions of the product
available.
From the main menu or after pressing [mode]repeatedly,
activate Internet radio mode.
[menu]
Main menu

Internet radio
Alternatively,press [IR]onthe remote control to switch
directly to this operating mode.
7.1 Station search
This radio offers various ways to search for stations.
•Use [enter/navigate]tonavigate through each search
function and its options.
•Once you have found astation you like, conrm by
pressing [enter/navigate]. The radio starts playing the
selected station.

14
7.1.1 Search by country or region
To search for astation by continent, country and region,
proceed as follows:
[menu]
Station list

stations

Location
Once you have restricted the results to acertain country or
region, select astation from the complete list or from alist
sorted by genre.
7.1.2 Search by genre
To search for astation of acertain genreorsubject focus,
proceed as follows:
[menu]
Station list

stations

Genre
Once you have restricted the results to acertain genre,
select astation from alist of all stations available, or from
apre-selected list, or from alist sorted by country.
7.1.3 Search by name
If you know the name of the desired station, you can
search for it directly.
[menu]
Station list

stations

Search stations
Enter the complete name, or apart thereof,inthe input
screen and select OK to start the search. Youreceive alist
of all available stations whose names contain the search
key.
7.1.4 Popular stations
Youcan nd aselection of the most popular stations as
follows:
[menu]
Station list

stations

Popular stations

15
7.1.5 New stations
Stations that have recently been added to the database
can be found as follows:
[menu]
Station list

stations

New stations
7.1.6 Local stations
To search for stations from your own country (the country
in which the radio is currently located), proceed as follows:
[menu]
Station list

Local <Country>
Note
Replace the <Country> placeholder with the country you
arecurrently located in.
Youcan lter this local list by genre, or select astation
from the complete list, or select from apre-selected list.
7.2 Podcasts
Podcasts areprograms on various topics and include,
for example, talk shows, news and much more. Podcasts
can be downloaded from the Internet. Thereare normally
approximately 10,000 programs available. Similarly to
radio stations, the radio makes it possible to lter alarge
number of Podcasts, or to search the entiredatabase for a
matching result.
7.2.1 Search by country or region
To search for apodcast by continent, country and region,
proceed as follows:
[menu]
Station list

Podcasts

Location
Once you have restricted the results to acertain country or
region, select astation from the complete list or from alist
sorted by genre.
7.2.2 Search by format (subjects or categories)
To search for apodcast by continent, country and region,
proceed as follows:
[menu]
Station list

Podcasts

Genre

16
7.2.3 Search by name
If you know the name of the desired Podcasts, you can
search for it directly.
[menu]
Station list

Podcasts

Search podcasts
Enter the complete name, or apart thereof,inthe input
screen and select OK to start the search. Youreceive alist
of all available Podcasts whose names contain the search
key.
7.3 Last listened
The radio saves the last stations and podcasts listened to in
their own list. To access the list, proceed as follows:
[menu]
Last listened
7.4 Favourites (local)
Youcan save up to 30 of your favourite stations for quick
and direct access.
7.4.1 Save favourites
•Set the station that you would like to save as afavourite
station preset.
•If the station is received, press and hold [memory]on
front of the radio.
[memory]
An overview window with the station presets should open
after approx. 2seconds.
•Youcan switch between the station presets (1 to 30) by
turning [enter/navigate].
•Press [enter/navigate]tosave the station on the
desired station preset.
7.4.2 Access favourites
Press [memory]toopen the overview window with the list
of saved stations.
[memory]
Use [enter/navigate]toselect one of your favourites.
Note
Favourites cannot be deleted.
If all30station memory slots arelled and you wish to
save anew station, choose one of the occupied slots.
The station in this slot will be overwritten with the new
station.
