Sangean dpr-39 User manual

DPR-39
GB
Revision 2

1
Important Safety Instructions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not t into your outlet. consult an electrician for
replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
Only use attachments/accessories specified by the
manufacturer.
Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.

2
GB
13.
14.
15.
16.
17.
18.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in anyway, such as power-supply cord or plug
is damaged. liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
To Reduce the Risk of Fire or Electric Shock, Do not
Expose This Appliance To Rain or Moisture.
The Shock Hazard Marking and Associated Graphical
Symbol is provided on the bottom panel of unit.
Apparatus shall not be exposed to dripping or splashing
and no objects lled with liquids, shall not be placed on
the apparatus.
To prevent possible hearing damage, do not listen
at high volume levels for long periods.

3

4
GB
Headphone socket
Preset buttons (1-5)
Power button
LCD display
Volume control
Tuning/Menu jog wheel
Lock switch (Note: If this is activated the radio will not
operate)
USB socket for software upgrade
Battery compartment
Strap holder
Controls
1
2
3
4
5
6
7
8
9
10

5
Battery Installation
Battery cover is located on the back of the unit. Slide the
cover downwards to gain access to the battery compartment.
Insert two AA (UM-3/R6/LR6) batteries into the compartment.
Make sure that the battery is positioned in accordance with
the indicated diagram. Replace cover.
Note:
You can always monitor the battery power from LCD display
battery icon. When battery power becomes very low and
unable to operate the radio, low battery indicator will
appears on the LCD display. The radio will shut off.
Headphones
The 3.5 mm stereo headphone socket located on the top of your
radio is provided for use with stereo headphones or an earpiece.
Important:
Excessive volume levels from earphones and headphones
may cause damage to your hearing.
Setting the clock
The clock will automatically update each time you turn on
the radio and tune to a DAB radio station or to an FM station
which is broadcasting the time via RDS. Time display will
ash 0:00 for a few seconds then display the clock time when
it receives DAB or FM-RDS clock time signal.

6
GB
Initial operation-DAB
This step is only necessary for initial setup-
1. Make sure a headphones/an earpiece is plugged in.
2. Press the Power button on the top of your radio.
3. The display will show “Welcome to Digital Radio” and start
to scan the entire DAB+ channel range and stop at the rst
found station. If the radio has been used before, the last
used station will be selected. Press in the tuning/menu jog
wheel to play the station.
4. Turn the jog wheel either up or down to display station list
and find desired station. Press in the jog wheel to select
the station. The radio will tune to the station and display
the station name.
5. Adjust the volume control for comfortable listening.
Service Information-DAB
The Service Information display-Technical information on the
current status of the station being broadcast.
While listening to DAB+, continually press in the jog wheel to
cycle through information on:
a. Program type (PTY)
b. Multiplex Name
c. Time
d. Date
e. Channel and Frequency
f . Bit Rate and Codec
g. Signal Strength

7
Menu Functions-DAB
Press in and hold the jog wheel for 2 seconds to enter
the menu list. The display will first show DAB and <Find
Services>. Turn the jog wheel up or down and choose from
the following options: ‘Find Services’, ‘Back’, ‘FM mode’,
‘Settings’ and ‘Prune’.
A) Find Services
Press in the tuning/menu jog wheel and turn up or down to select.
● Full scan
press in the jog wheel to scan the whole DAB network in your
area. Radio will tune to rst station found after the scanning is
completed.
● Back
press in the jog wheel to go back to the previous menu display.
● Manual tune
press in and turn the jog wheel to scroll the whole station list.
Press in the jog wheel to select desired station.
B) Back
Press in the jog wheel to go back to current listening status.
C) FM mode
Press in the jog wheel to select FM band.
D) Settings
Press in the jog wheel to select from following settings options:
● Auto select
Press in and turn the jog wheel to select YES or NO. Default
setting is NO. Press YES and the radio will auto select and
tune to the station shown on the display within a few seconds.

8
GB
● Back
Press in the jog wheel to go back to the setting menu.
● Software upgrade
From time to time, new software features for your radio may
be developed. Your radio has therefore been designed to
allow its internal software to be updated using your USB
upgrade port.
You should not attempt to update your radio unless it is
recommended to you by Sangean Customer Services.
Updating the software may remove all network settings and
radio station presets from your radio.
Software updates for your radio may be available in the future.
As software updates become available software and
information on how to update your radio can be found at:
http://sg.sangean.com.tw/rst/rst.asp
http://www.sangean.eu/rst/rst.asp
www.sangean.com.au.
For more information, please contact our Head Office by
sending an email to: [email protected]
● SW version
Press in the jog wheel to view software version installed in the
radio. Press in the jog wheel again to go back to setting menu.
● Factory reset
Press in and turn the jog wheel to select YES or NO. Select
YES to erase all saved settings, station lists and favorites. All
settings will revert to factory default.

9
● Set contrast
Turn and press in the jog wheel to select required LCD display
contrast. Display contrast will change accordingly.
● Set backlight
Press in the jog wheel to select Backlight Auto.
Select YES and display backlight will auto shut off 12 seconds
after last operation.
Select NO and the display backlight will remain on.
● DRC
Dynamic Range Control (DRC) feature can make quieter sounds
easier to hear, especially when your radio is used in a noisy
environment. This function only works within the DAB band.
Press in DRC and turn the jog wheel to cycle through; DRC
off, DRC Low and DRC High. Press in to select your preferred
option:
DRC off-DRC is switched off, broadcast DRC will be ignored.
DRC low-DRC level is set to 1/2 that sent by broadcaster.
DRC high-DRC is set as sent by broadcaster
● Language
Your radio functions can be congured to a different language.
Press in and turn the log wheel to select your desired language.
The current language setting is marked with an asterisk.
● Sleep
Use the Sleep menu to set auto shut off timer. Press in and
turn the jog wheel to cycle through:
Sleep off (auto shut off disabled), 90-60-45-30-15 Auto shut off
timer. Radio will turn off after selected sleep time has elapsed.

10
GB
E) Prune
If you move to a different part of the country, some of the
stations which were listed may no longer be available. Also,
from time to time, some DAB services may stop broadcasting,
or may change location or frequency.
Stations which cannot be found, or which have not been
received for a very long time are shown in the station list with
a question mark.
The Prune stations function will delete the marked DAB
stations from your station list. Press in the jog wheel to enter
prune station function.
Turn the jog wheel to select YES to cause the stations list to
be pruned, eliminating unavailable stations If you do not wish
to prune stations, select NO and the display will revert to the
previous menu.
Operating your radio-FM
1. Turn on the radio by pressing Power button. Press in jog
wheel for 2 seconds to enter Menu. Turn jog wheel and scroll
to FM Mode and press in to select the FM band.
Search tuning-FM
1. Turn the jog wheel either down or down until display shows
“scanning”.
2. The radio will search in an upwards or downwards direction
until it nds a station of sufcient signal strength.

11
Menu-FM
Press in the jog wheel for 2 seconds to enter FM Menu. Turn
the jog wheel either down or up-down to nd ‘FM Scan Zone’,
‘Back’, ‘DAB mode’ and ‘Settings’.
A) FM Scan Zone
When using the FM mode your radio can be set to either scan
local stations or to scan all stations including distant radio
stations.
Press in and turn the jog wheel to enter FM scan zone setting.
Select ‘Local’: only the stations with the strongest signals are
found during scanning
Select ‘Distant’: all available stations are found during
scanning
B) Back
press in jog wheel to return to FM listening.
C) DAB Mode
press in jog wheel to switch to DAB mode.
D) Settings
press in jog wheel to select from the following settings:
● Audio setting
Turn the jog wheel to select Stereo allowed or Forced mono.
Select ‘Stereo allowed’: the radio will receive FM stereo
broadcasts.
Select ‘Forced mono’: to improve reception of a weak FM
signal.
● Back
Press in the jog wheel to go back to the setting menu.

12
GB
● Software upgrade
From time to time, new software features for your radio may be
developed. Your radio has therefore been designed to allow its
internal software to be updated using your USB upgrade port.
You should not attempt to update your radio unless it is
recommended to you by Sangean Customer Services.
Updating the software may remove all network settings and
radio station presets from your radio.
Software updates for your radio may be available in the future.
As software updates become available software and
information on how to update your radio can be found at:
http://sg.sangean.com.tw/rst/rst.asp
http://www.sangean.eu/rst/rst.asp
www.sangean.com.au.
For more information, please contact our Head Office by
sending an email to: [email protected]
● SW version
Press in the jog wheel to view software version installed in the
radio. Press in the jog wheel again to go back to setting menu.
● Factory reset
Press in and turn the jog wheel to select YES or NO. Select
YES to erase all saved settings, station lists and favorites. All
settings will revert to factory default.
● Set contrast
Turn and press in the jog wheel to select required LCD display
contrast. Display contrast will change accordingly.

13
● Set backlight
Press in the jog wheel to select Backlight Auto.
Select YES and display backlight will auto shut off 12 seconds
after last operation.
Select NO and the display backlight will remain on.
● Language
Your radio functions can be congured to a different language.
Press in and turn the log wheel to select your desired
language. The current language setting is marked with an
asterisk.
● Sleep
Use the Sleep menu to set auto shut off timer. Press in and
turn the jog wheel to cycle through: Sleep off (auto shut off
disabled), 90-60-45-30-15 Auto shut off timer. Radio will turn
off after selected sleep time has elapsed.
Presetting stations-FM & DAB
There are 5 memory presets each for DAB and FM radio.
They are used in the same way for each operating mode.
1. Tune to the required radio station as previously described.
2. To store the station as a preset, press and hold the required
Preset button (1-5) until the display shows 'Preset stored'.
The station will be stored under the chosen preset button.
Repeat this procedure as needed for the remaining presets.

14
GB
3. Stations which are already stored in the presets may be
over written by following the above procedure.
Note:
The radio station presets are retained in memory when the
radio is switched off.
Recalling a preset-FM & DAB
1. Select the required operating mode as previously described.
2. Momentarily press the required Preset button. Your radio
will then tune to the station stored in the selected preset
memory. The chosen preset number is also shown in the
radio display, e.g. 'P2'.
Key lock function
The key lock function is used to prevent unintentional
operation of the radio.
1. Key lock switch is located on the back of the radio. When
the key lock switch is set to LOCK, the power button, volume
control, preset buttons and jog wheel will be disabled. If any
buttons are pressed when the key lock function is set to
lock, display will show “Button Locked” for a few second.
2. To switch off the key lock function switch the key lock button
to opposite position. The key lock function will be disabled.

15
Specication
Power Requirement:
Batteries: 2 x LR6 (AA size) Alkaline
Battery Life:
Approx 12 hours of listening with headphones
for 4 hours a day at normal volume.
Frequency Coverage:
FM 87.50-108 MHz
DAB+ Band III 5A-13 F
Circuit Features
Headphones: 32 ohm, in-ear style
If at any time in the future you should need to dispose of this
product please note that: Waste electrical products should not
be disposed of with household waste. Please recycle where
facilities exist.Check with yourLocalAuthority or retailer for
recycling advice. (Waste Electrical and Electronic Equipment
Directive)
The company reserves the right to amend the specication
without notice
