Hamilton Beach The Scoop User manual

READ BEFORE USE
使用前阅读
Questions?
Please call us – our friendly
associates are ready to help.
China: 400-852-2655
使用本设备前，我们建议您仔细阅读
这些说明。
Visit www.hamiltonbeach.cn for our
complete line of products and Use and
Care Guides – as well as
delicious recipes, tips, and
to register your product online!
有关我们所有系列产品的使用与维护指
南 – 以及美味食谱、生活小贴士和
产品在线注册的更多信息，请访问
www.hamiltonbeach.cn 。
如有疑问？
请致电我们，我们的团队
随时准备为您提供帮助。
中国大陆客服热线：
400-852-2655
官方网站：www.hamiltonbeach.cn
型号：49980-CN
此说明书中图片仅供参考，
产品以实物为准。
The ScoopTM 2-Way
Brewer
ScoopTM 智能双模
咖啡机
English ..................... 2
简体中文 ..................16

2
IMPORTANT SAFEGUARDS
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs. Care must be
taken, as burns can occur from touching hot parts or from spilled,
hot liquid.
3. To protect against electric shock, do not place cord, plug, or
coffeemaker in water or other liquid.
4. Close supervision is necessary when any appliance is used by
or near children.
5. Allow to cool before putting on or taking off parts and before clean-
ing the appliance.
6. Coffeemaker must be operated on a flat surface away from the edge
of counter to prevent accidental tipping.
7. Do not operate any appliance with a damaged cord or plug, or after
the appliance malfunctions or has been damaged in any manner. Call
our toll-free customer service number for information on examination,
repair, or adjustment.
8. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter or touch hot
surfaces, including stove.
11. Do not place on or near a hot gas or electric burner, or in a heated
oven.
12. The carafe is designed for use with this coffeemaker. It must never
be used on a range top or in a microwave oven
.
13. Do not set a hot carafe on a wet or cold surface.
14. Do not use a cracked carafe or one with a loose or weakened handle.
15. Do not clean carafe with cleansers, steel wool pads, or other abrasive
materials.
16. Do not use appliance for other than intended use.
17. WARNING: To reduce the risk of fire or electric shock, do not remove
the bottom cover of the coffeemaker. There are no user-serviceable
parts inside. Repair should be done by authorized service personnel
only.
18. To disconnect, turn any control to the OFF position and then remove
plug from wall outlet.
19. Be certain carafe lid is securely in place during brew cycle and when
pouring coffee. Do not use force when placing lid on carafe.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons,
including the following:
SAVE THESE INSTRUCTIONS!
OTHER CONSUMER SAFETY INFORMATION
This appliance is intended for household use only.
The length of the cord used on this appliance was selected to reduce
the hazards of becoming tangled in or tripping over a longer cord. If a
longer cord is necessary, an approved extension cord may be used. The
electrical rating of the extension cord must be equal to or greater than the
rating of the appliance. Care must be taken to arrange the extension cord
so that it will not drape over the countertop or tabletop where it can be
pulled on by children or accidentally tripped over.
To avoid an electrical circuit overload, do not use another high-wattage
appliance on the same circuit with this appliance.

3
Single-Serve Side
Parts and Features
Scoop™ Brew Basket
Multilevel
Cup Rest
Drip Tray
Travel
Mug
Brew Basket
Permanent Coffee Filter
Control Panel
and Display
Keep-Hot Plate
Carafe
Single-Serve
Side Reservoir
Carafe Side
Reservoir
Filter Basket
Travel
Lid
Carafe Side
Parts and Features
Cord-Stuff Storage

How to Use
Single-Serve Side
3
Burn Hazard.
To avoid contact with hot coffee or water:
• Do not use more than 14 ounces
(410 ml) of water.
• Fill single-serve reservoir with mug or
cup into which the coffee will be brewed.
• Fully insert mug or cup under filter
basket.
1
4
WARNING
AUTOMATIC SHUTOFF: The
coffeemaker will automatically
shut off after brew cycle is
complete.
NOTES:
• The unit will only brew on one
side at a time.
• To avoid overflow, use slightly
less grounds when brewing
decaf or flavored coffees.
• For Hotter Coffee: Rinse the
travel mug with warm water
before brewing; then replace
travel mug lid. Brew directly
into the travel mug with travel
mug lid in place.
5
2
Push lever left to select Single-
Serve.
4
REGULAR MUGTRAVEL MUG
OR
OR
OR OR

67A-1 – GROUNDS
5
How to Use Single-Serve Side (cont.)
REGULAR MUG
For regular coffee, use a
maximum of two level table-
spoons of grounds. To avoid
overflow, use slightly less
grounds when brewing decaf
or flavored coffees.
WARNING! Keep ground coffee
below MAX fill line to prevent
overflow.
7A-2 – GROUNDS
Single-serve brew basket has two
markings: the lower level marking
if making 8 oz. (250 ml) of coffee,
and the higher level mark if
making 14 oz. (410 ml) of coffee.
DO NOT fill scoop to top or this
will cause overflow.
MAX FILL
LINE
MIN FILL
LINE
INCORRECT

6
How to Use Single-Serve Side (cont.)
8 9
Press I/O (ON/OFF) button
to begin the flow of coffee.
Coffeemaker will shut off when
brew cycle is complete. To stop
flow of coffee midcycle, press
I/O (ON/OFF) button.

7
2
Push lever right to select Carafe.
How to Use Carafe Side
13
AUTOMATIC SHUTOFF: The coffeemaker will automatically
shut off 2 hours after brew cycle is complete.
NOTE: The unit will only brew on one side at a time.
6 7 8
4
Place a permanent filter in brew
basket. A cupcake-style paper
filter may also be used.
For each cup of coffee being
made, place one level tablespoon
(15 ml) of coffee into filter.
Lift lid and pour water from
carafe into reservoir.
NOTE: Do not fill past the 12-cup
mark (60 ounces [1.8 L]).
Place carafe, with carafe lid
attached, on keep-hot plate.
5

How to Use Carafe Side (cont.)
11
Press I/O (ON/OFF) button to
start. Press I/O (ON/OFF) button
again to turn off.
NOTE: If the coffeemaker is not
turned off manually, it will auto-
matically shut off in 2 hours.
109
Place brew basket in brew basket
well. Ensure brew basket is fully
seated.
NOTE: BOLD mode will require additional time to complete a
brewing cycle. If Brew Option is not selected, the coffeemaker
will automatically brew on the regular/default setting.
For enhanced full/strong-flavored
coffee, press BREW OPTIONS
button until BOLD is displayed.
8

Programming (For Either the Single-Serve OR Carafe Side)
2
Press HOUR and then MINUTE to
set clock.
Hold PROGRAM until clock flashes.
34
Continue holding PROGRAM
button, press HOUR and MINUTE
until the desired brewing start
time is reached, and then release
PROGRAM button.
Press PROGRAM to activate
automatic brewing. A green
LED will illuminate to indicate the
unit is programmed.
1
NOTE: The unit will only brew on one side at a time.
Tips for Best-Tasting Coffee
• All coffees are made from either arabica beans or robusta beans, or
some combination of both. Arabica beans are slightly more expensive,
but tend to produce better-tasting coffee.
• Ground coffee will become stale much faster than whole beans.
If buying preground coffee, choose a package with the latest
expiration date or a smaller quantity.
• If grinding whole beans, set your coffee grinder on a fine/medium
grind. This will yield the best-tasting grounds. Try to use freshly
ground coffee within about a week of grinding.
• Using a water filter, filtered water, or bottled water will yield
better-tasting coffee than tap water.
• Use approximately 1 tablespoon of grounds for each cup of coffee
being made. To avoid overflow, use slightly less grounds (3/4 table-
spoon [11 ml]) when brewing decaf or flavored coffees. Also, be aware
that using coffee that is ground too finely may also cause the filter
basket
to overflow.
• Make sure your coffeemaker is clean. See “Care and Cleaning”
sections. 9

Care and Cleaning – Single-Serve Side
1
Pour 1/2 cup (125 ml) of plain white vinegar and 1/2 cup (125 ml) of
cold water into single-serve side reservoir.
4
Press I (ON) button. Press
O (OFF) button after 30 seconds
and wait 30 minutes. Press I (ON)
button. Press O (OFF) button
when finished.
Run 2–3 more brew cycles with
CLEAN WATER only. Allow to
cool between cycles.
3
DISHWASHER-SAFE
All coffeemakers should be cleaned at least once a month (once a week for areas with hard water).
56
2
10

Care and Cleaning – Carafe Side
1
Pour 1 pint (2 cups/500 ml)
vinegar into carafe side reservoir.
4
Press I (ON) button. Press
O (OFF) button after 30 seconds
and wait 30 minutes. Press I (ON)
button. Press O (OFF) button
when finished.
Run 2–3 more brew cycles with
CLEAN WATER only. Allow to
cool between cycles.
3
DISHWASHER-SAFE
All coffeemakers should be cleaned at least once a month (once a week for areas with hard water).
56
2
11

PROBLEM
Weak coffee.
Coffee overflows from
brew basket, travel mug,
or regular mug.
Coffee tastes bad.
PROBABLE CAUSE
• Not enough ground coffee used. See “How to Use Single-Serve Side.”
• Excessive amount of water in single-serve reservoir. Use travel mug or mug into which coffee
will be brewed to fill reservoir. Use slightly less grounds when brewing decaffeinated or flavored
coffees. Set coffee grinder to automatic drip grind.
• Coffeemaker needs cleaning.
• Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled water).
Troubleshooting (Single-Serve Side)
12

PROBLEM
Brew basket overflows
or coffee brews slowly.
Coffee leaks onto base.
Coffee tastes bad.
PROBABLE CAUSE
• Excessive amounts of ground coffee.
• Decaffeinated and/or coffee ground too finely can cause overflow. Set coffee grinder to
automatic drip grind and use slightly less grounds.
• Coffeemaker needs cleaning.
If using a paper filter:
• Coffee grounds between paper filter and brew basket.
• Paper filter not open and in proper position.
• Rinse brew basket before inserting paper filter so the edges will remain pressed against the
sides of the basket.
• Poor-quality paper filter.
• Carafe removed from keep-hot plate for more than 20 seconds during the brewing cycle.
• Coffeemaker needs cleaning.
• Coffee ground too coarsely or too finely. Set coffee grinder to automatic drip grind.
• Coffee-to-water ratio unbalanced. Adjust for personal preference.
• Poor coffee quality and freshness.
• Poor water quality (use filtered or bottled water).
Troubleshooting (Carafe Side)
13

Troubleshooting (Carafe Side) (cont.)
PROBLEM
Coffee sediment in cup.
Coffee not brewing or
unit will not turn on.
Longer than normal
brew time.
PROBABLE CAUSE
• Use a high-quality, basket-style paper filter instead of permanent coffee filter.
• Carafe not positioned on keep-hot plate.
• Water reservoir is empty.
• Unit is unplugged.
• Power outage.
• Power surge. Unplug; then plug the unit back in.
• Clock requires reset after power outage.
• Mineral deposits can build up in the pump of your coffeemaker. Periodic cleaning of the inside
of the unit is recommended. More frequent cleaning may be necessary, depending on the
hardness of your water. See “Care and Cleaning – Carafe Side” section.
NOTE: Do not disassemble the unit.
14

15
重要安全说明
1. 阅读所有相关说明。
2. 请勿直接接触任何发热表面。请使用手柄或者旋钮。特别注意：在直接
接触电器高温部件或溅到高温液体的情况下，可能造成皮肤烫伤。
3. 为防止触电，请勿将电源线、插头或咖啡机放入水或其他液体中。
4. 当电器由儿童使用或距离儿童较近时，需有成人看护。
5. 拆装咖啡机部件以及清洁前，必须让咖啡机冷却。
6. 咖啡机必须放在平整桌面进行操作，远离桌子边缘，以防其意外倾翻。
7. 当电源线或电插头受损，电器出现故障或因任何其他方式出现电器损坏
时，请勿使用任何电器。请拨打我们的免费售后服务电话，咨询有关电器
检查、修理或调整的相关信息。
8. 使用非电器制造商推荐的配套附件可能会带来伤害。
9. 请勿在户外使用。
10. 请勿将电源线搭置在桌台边缘上以及与发热表面接触，包括加热器。
11. 请勿靠近或放置在燃气或电炉上，或放进加热烤箱内。
12. 咖啡壶专为本咖啡机设计使用。使用时，切勿放在桌面边缘或置于微波
炉中 。
13. 请勿将热咖啡壶放置在潮湿或冰凉表面。
14. 请勿使用带裂缝、手柄松弛或脆弱的咖啡壶。
15. 请勿使用清洁剂、钢丝垫或其他磨砂型材料清洁咖啡壶。
16. 请勿将电器用作其他非预期用途。
17. 警告：为防发生火灾或触电，请勿取下此咖啡机的底盖。此咖啡机内部
无任何用户可维修的部件。仅允许授权的维修人员执行维修。
18. 断开咖啡机电源时，先将控制按钮调至 OFF 位置，再拔除插头。
19. 冲泡咖啡或倒咖啡时，请确保咖啡壶盖已扣紧。
为避免发生火灾，触电以及人身伤害，在使用家用电器时，需遵守以下基本安全防护措施：
请妥善保管这些说明！
其他用户安全信息
此电器建议于家庭使用。
此电器的电源线长度是经特别设计，以防电源线缠绕或绊倒他人。倘若需要
更长的电源线，可使用批准的电源延长线。电源延长线的额定电功率必须等
于或大于此电器的额定电功率。电源延长线使用时需特别注意，以防将其搭
设在桌台上，造成儿童扯拉或绊倒他人。
为防电路过载，请勿在此电器的同一电路上使用其他高功率电器。

16
单杯式
部件与功能
Scoop™ 过滤器
多层式杯座
承滴盘
旅行
马克杯
咖啡篮
控制面板和
显示面板
保温板
咖啡壶
单杯式水箱
咖啡壶
水箱
咖啡篮
旅行
马克杯杯盖
咖啡壶式
部件与功能
收线式存储
永久过滤器

17
如何使用
单杯式
3
烫伤危险
为避免触到热咖啡或热水：
• 请勿使用超过 14 盎司（410 毫升）的水。
• 使用马克杯或咖啡杯向水箱中加入用来冲
泡咖啡的水。
• 将马克杯或咖啡杯放在咖啡篮下面。
1
4
自动停止：冲泡周期完成后，咖啡
机将自动关闭。
注意：
• 咖啡机一次只可进行一侧冲泡。
• 为避免溢出，冲泡脱因咖啡或调
味咖啡时，请稍减咖啡粉用量。
• 冲泡更热的咖啡：冲泡前，请用
温水冲洗旅行马克杯，然后再冲
洗杯盖。盖紧杯盖后，直接将热
咖啡冲入旅行马克杯中。
5
2
将滑块拨至左边，选择单杯式。
常规马克杯旅行马克杯
或
或
或或
警告

18
67A-1 – 咖啡粉
如何使用单杯式（续）
常规马克杯
要冲泡普通咖啡，请最多使用两
咖啡勺咖啡粉。为避免溢出，冲泡
脱因或调味咖啡时，请稍减咖啡粉
用量。
警告！请将咖啡粉用量保持在最大
加注线以下，防止溢出。
7A-2 – 咖啡粉
单杯式过滤器有两个标记：冲泡 8
盎司（250 毫升）咖啡的较低水位
标记和冲泡 14 盎司（410 毫升）
咖啡的较高水位标记。请勿将过
滤器加至最高水位，否则将会导致
溢出。
最大加注线 最小加注线
错误

19
如何使用单杯式（续）
8 9
按 I/O ( 开/关) 按钮，开始冲泡咖
啡。冲泡周期完成后，咖啡机将会
关闭。要中途停止冲泡，则按 I/O
(开/关) 按钮。

20
2
将滑块拨至右边，选择咖啡壶。
如何使用咖啡壶式
1 3
自动停止：冲泡周期完成 2 小时后，咖啡机将自动关闭。
注意：咖啡机一次只可进行一侧冲泡。
6 7 8
4
将永久过滤器放在咖啡篮中。也可
使用杯型纸质过滤器。
每冲泡一杯咖啡，则请将一咖啡勺
（15 毫升）咖啡粉倒入过滤器。
拉起瓶盖，将水从咖啡壶倒入水箱。
注意：加水请勿超过 12 杯标记
（60 盎司 [1.8 升]）。
盖上瓶盖，将咖啡壶放在保温板上。
5
