Hamilton/Buhl DSIP-DOCK Programming manual

MODEL: DSIP-DOCK
DOCKING STATION & LISTENING CENTER
For MP3 PLAYERS
OWNER'S MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
More great products from
Docking Station
Listening Center
DSIP-SC7V
Deluxe
Headphone
SC7V
V
al-U-Pack CD/Cassette
Listening Center
LCP/CD385/HA2
Sound Vision
DVD Boom Box w/ Screen
MV-8920
Personal
Headphone
HA2
Hamilton Buhl
a division of Vcom
www.hamiltonbuhl.com
Sound Vision Video
Listening Center
LCP/MV8920/HA5
Trouble Shooting
• My iPod is not making a connection with docking pin.
- Remove protective sleeve on MP3 Player before docking.
- Make sure you are using the adaptor provided with your iPod from
the manufacturer.
• I am getting a lot of feed back.
- Lower volume on MP3 Player completely to minimize feedback
- Switch off Wi-Fi on MP3 Player to minimize feedback

2
1. DOCKING STATION – Compatible
with Apple devices including iPod
Classic, iPod Nano, iPhone and
iTouch. (Your apple issued cradle
adapter that was included with your
apple device must be used issued in
order to maintain a stable
connection.)
2. POWER/VOLUME – Turn the knob
to the right to turn the unit on. And
continue to the right to increase the
volume level. Turn the knob to the left
to decrease the volume. Turn knob all
the way to the left to turn the unit off.
3. POWER INDICATOR LIGHT –
When illuminated indicates that your
unit is powered on.
4. SPEAKER/EARPHONE SWITCH –
Flipping the switch will activate the
sound either in the speakers or to the
headphone jacks as indicated. You
cannot have sound in both the
headphone jacks and speakers at the
same time. Please note a headphone
must be plugged in to the unit in order
to hear sound when using
headphones.
5. HEADPHONE JACKS – Accepts
1/8” stereo headphones. Can plug in
up to 6 headphones at one time.
6. LINE IN – Use the LINE IN jack to
connect other audio source to be
played on the speakers or
headphones. A 1/8” phono connection
is required.
7. DC Connector – Plug in the
detachable DC cord here.
8. SPEAKERS – 2 Watt speakers
9. DC Cord – The DC line cord UL
approved must be attached in order to
provide power.
(iPod is a registered trademark of Apple Inc.)
3
1
32
4
5
76
8
9
Features:Warnings and Precautions
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE. To reduce the risk of electric shock,
do not remove cover (or back). There are no user-serviceable parts inside.
Please refer any servicing to qualified service personnel. WARNING:
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Operations
Listening and Charging Your iPod (iPod not included)
• Insert DC cord into back of unit in the DC 5V jack. Plug cord into wall
outlet.
• Remove protective cover from pin before docking
• In power off mode, insert the iPod onto the dock on the top of unit.
• To turn the unit on, turn the ON/VOLUME knob to the right. The POWER
INDICATOR light will illuminate.
• The iPod will power on automatically.
To Listen with Headphones
• Switch the SPEAKER/EARPHONE SWITCH to the EARPHONE setting.
• Plug in up to six headphones in to the HEADPHONE JACKS in the front of
the unit. Note – headphones must have a 1/8” plug and must operate in
stereo mode.
To Listen with Speakers
• Switch the SPEAKER/EARPHONE SWITCH to the SPEAKER setting.
Adjusting the Volume
• Adjust the volume by turning the ON/VOLUME knob on the unit.
• When finished listening, power off the unit by turning the ON/VOLUME
knob to the far left until you hear a click. Also the POWER INDICATOR light
will turn off once the unit is powered off.
NOTE: If your iPod doesn’t fit onto the dock, connect it via the LINE IN jack
as noted in the LINE IN JACK section below.
• To recharge the iPod, insert the iPod onto the docking station. The iPod
will recharge automatically.
• You cannot listen to both the headphones and speakers at the same time.
Line in Jack:
• Connect a 1/8” jack stereo connection cable (not included) to the LINE IN
jack on the rear of unit to the Phones/Line out/AUX out jack on the external
device such as MP3 Players, CD Discman, MP4 Players …. etc.
(iPod is a registered trademark of Apple Inc.)
This item is not an Apple product, licensed by Apple, or authorized or approved by Apple
