Hamlet HRDSL524 User manual

ADSL2+ Ethernet Modem
Internet Router with 10/100 LAN Port Interface
User Manual
HRDSL524
www.hamletcom.com

INDEX
1. Introduction..................................................................................................4
1.1 System Requirements .............................................................................................. 4
1.2 Package Contents .................................................................................................... 4
2. Specifications ..............................................................................................5
2.1 LED Meaning............................................................................................................ 6
2.2 Back Panel Connectors............................................................................................ 7
2.3 Factory Default Settings ........................................................................................... 7
3. Hardware Requirements .............................................................................8
3.1 Setting up the Hardware Environment...................................................................... 8
3.2 Powering on ADSL2+ Ethernet Modem.................................................................... 8
4. Installation & Setup.....................................................................................9
4.1 Connection of ADSL2+ Ethernet Modem ................................................................. 9
5. Configuration Procedures ........................................................................11
6. ADSL2+ Ethernet Modem Configuration ................................................19
7. Introduction of the Web Configuration ...................................................22
7.1 Web Configuration Overview.................................................................................. 22
7.2 Accessing ADSL2+ Ethernet Modem Web Configuration....................................... 22
8. Universal Plug-and-Play (UPnP) ..............................................................47
8.1 Universal Plug and Play Overview ......................................................................... 47
8.2 How do I know if I'm using UPnP?.......................................................................... 47
8.3 NAT Traversal ........................................................................................................ 47
8.4 Cautions with UPnP ............................................................................................... 47
8.5 Configuring UPnP................................................................................................... 48
8.6 Installing UPnP in Windows Example..................................................................... 49
8.7 Using UPnP in Windows XP Example.................................................................... 52
8.8 Web Configuration Easy Access ............................................................................ 54
9. Troubleshooting ........................................................................................56
9.1 Using LEDs to Diagnose Problems ........................................................................ 56
9.2 Telnet ..................................................................................................................... 57
9.3 Web Configuration.................................................................................................. 57
9.4 Login Username and Password ............................................................................. 58
9.5 LAN Interface ......................................................................................................... 58
9.6 WAN Interface ........................................................................................................ 58
9.7 Internet Access....................................................................................................... 59
9.8 Remote Node Connection ...................................................................................... 59
10. Technology Glossary..............................................................................60

ADSL2+ Ethernet Modem HRDSL524
3
Dear Customer,
thanks for choosing an Hamlet product. Please carefully follow the instructions for its use
and maintenance and, once this item has run its life span, we kindly ask You to dispose of it
in an environmentally friendly way, by putting it in the separate bins for electrical/electronic
waste, or to bring it back to your retailer who will collect it for free.
We inform You this product is manufactured with materials and components in compliance
with RoHS Directive 2002/95/CE, 2002/96/CE, 2003/108/CE; with WEEE Directive
2003/96/CE, Italian Legislative Decree 2005/151 and the following standards:
EMC Directive 2004/108/EC
EN 300 386: V. 1.3.3
EN 61000-3-2: 2006
EN 61000-3-3: 1995 + A1: 2001 + A2: 2005
LVD Directive 2006/95/EC
EN 60950-1: 2001 + A11: 2004
The complete CE declaration of conformity of the product can be obtained by contacting
Hamlet at inf[email protected]om specifying the product code and the documentation.
The information on the importer for your country are available in the “About Us” section of
the Hamlet website at www.hamletcom.com.
Trademarks and changes
All trademarks and company names mentioned in this manual are used for description
purpose only and remain property of their respective owners.
The material in this document is for information only and subject to change without notice.

ADSL2+ Ethernet Modem HRDSL524
4
1. Introduction
ADSL2+ Ethernet Modem is a low cost, high performance and high-speed device that
provides a full rate ADSL2+ Ethernet Modem with the superb reliability and a complete
solution for home and office router. ADSL2+ Ethernet Modem can have a maximum
downstream data rate of up to 24Mbps and an upstream of up to 1Mbps. When configured
as a DHCP server, it will assign IP address to every connected PC and acts as the only
externally recognized Internet device on your local area network. With build-in NAT,
ADSL2+ Ethernet Modem serves as an Internet firewall, protecting your network from being
accessed by outside users. You can safely enjoy the new generation broadband Internet
with ADSL2+ Ethernet Modem.
1.1 System Requirements
•Pentium 200 MHz processor or above
•Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Vista and
Windows 7
•64 MB of RAM or above
•25 MB free disk space
1.2 Package Contents
•ADSL2+ Ethernet Modem
•CD-ROM (Software & Manual)
•Quick Installation Guide
•Telephone Cable (RJ-11)
•Ethernet Cable (RJ-45)
•DC Power Adaptor

ADSL2+ Ethernet Modem HRDSL524
5
2. Specifications
ADSL Standards supported
•Compliant to ITU-T G.992.1 (G.dmt), G.992.2 (G.lite), G.992.3 (ADSL2), G.992.4
(splitterless ADSL2), G.992.5 (ADSL2+) for Annex A, B
•G.lite (G.992.2) with line rate support of up to 1.5Mbps downstream and 512Kbps
upstream.
•Supports Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (G.992.1); G.994.1 and
G.996.1(for ISDN only); G.991.1;G.lite (G992.2)).
•Supports OAM F4/F5 loop-back, AIS and RDI OAM cells.
•ATM Forum UNI 3.1/4.0 PVC.
•Supports up to 8 PVCs (UBR, CBR, VBR).
•Multiple Protocols over AAL5 (RFC 1483).
•PPP over AAL5 (RFC 2364).
•PPP over Ethernet (RFC 2516).
Network Address Translation (NAT)
Network Address Translation (NAT) allows the translation of an Internet protocol address
used within one network (for example a private IP address used in a local network) to a
different IP address known within another network (for example a public IP address used
on the Internet).
Universal Plug and Play (UPnP)
Using the standard TCP/IP protocol, the ADSL2+ Ethernet Modem and other UPnP
enabled devices can dynamically join a network, obtain an IP address and convey its
capabilities to other devices on the network.
10/100M Auto-negotiation Ethernet/Fast Ethernet Interface
This auto-negotiation feature allows the ADSL2+ Ethernet Modem to detect the speed of
incoming transmissions and adjust appropriately without manual intervention. It allows data
transfer of either 10 Mbps or 100 Mbps in either half-duplex or full-duplex mode depending
on your Ethernet network.
Dynamic DNS Support
With Dynamic DNS support, you can have a static hostname alias for a dynamic IP
address.
Multiple PVC (Permanent Virtual Circuits) Support
Your ADSL2+ Ethernet Modem supports up to 8 PVC’s.
DHCP Support
DHCP (Dynamic Host Configuration Protocol) allows individual clients (computers) to
obtain TCP/IP configuration at start-up from a centralized DHCP server. The ADSL2+
Ethernet Modem has built-in DHCP server capability enabled by default. It can assign IP
addresses, an IP default gateway and DNS servers to DHCP clients. The ADSL2+ Ethernet
Modem can now also act as a surrogate DHCP server (DHCP Relay) where it relays IP
address assignment from the actual real DHCP server to the clients.

ADSL2+ Ethernet Modem HRDSL524
6
2.1 LED Meaning
Your ADSL2+ Ethernet Modem has indicator lights. Please see below for an explanation of
the function of each indicator light.
Power indicator Ethernet Active indicator
ADSL Link indicator Internet Active indicator
LED function
Label Color On Flash Off
Green Ready Not Ready Power Off
Green Ethernet
Connected
Transmit / Receive
Data
Ethernet
Disconnected
Green Connect to
DSLAM
Disconnect to
DSLAM N/A
Green Connect to
Internet/IDLE
Transmit / Receive
Data
Disconnect to
Internet
The icons appear on the products are for application indication only.
The trademark or intellectual property is belonging to their respective owners.

ADSL2+ Ethernet Modem HRDSL524
7
2.2 Back Panel Connectors
The below table shows the function of each connector and switch of the ADSL2+ Ethernet
Modem’s rear panel.
Connector Description
SWITCH Power Switch, which used to ON / OFF ADSL2+ Ethernet Modem
POWER Connects to your ADSL router 12V DC power adaptor
RESET Reset bottom, RESET the ADSL2+ Ethernet Modem to its default settings
LAN RJ-45 Jack (Ethernet Cable) connects to your PC, or HUB
LINE Connects to your ADSL2+ line – for ADSL2+ Line input
Rear View of the ADSL2+ Ethernet Modem
2.3 Factory Default Settings
Before configuration, please refer to following default settings,
Web interface
Username: admin
Password: hamlet
LAN IP Settings
IP Address: 192.168.1.254
Subnet Mask: 255.255.255.0
DHCP
DHCP Server: Enable

ADSL2+ Ethernet Modem HRDSL524
8
3. Hardware Requirements
To use ADSL2+ Ethernet Modem, please have following hardware / accessories ready.
•A PC with pre-installed Ethernet Adapter (Required)
•12V power adaptor (Included in the package)
•RJ-45 Ethernet cable (Included in the package)
•RJ-11cable (Included in the package)
3.1 Setting up the Hardware Environment
Note! Be sure that you are well insulated from any power source to avoid electricity shock.
Please kindly refer to chapter 4.0 “Installation & Setup”
3.2 Powering on ADSL2+ Ethernet Modem
1. Connect the power to the ADSL2+ Ethernet Modem by plugging the power supply into
an appropriate electrical outlet.
2. If the Power LED is off, refer to “Troubleshooting” for information.
Note! Use only the manufacturer-approved power supply that shipped with the ADSL2+
Ethernet Modem.
Please kindly refer to chapter 4.0 “Installation & Setup”

ADSL2+ Ethernet Modem HRDSL524
9
4. Installation & Setup
Follow each step carefully and only go to the next step once you have completed the
previous one.
4.1 Connection of ADSL2+ Ethernet Modem
If you have an ISDN telephone line Connect the router as shown below.
1. Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to the ADSL2+
Ethernet Modem's LAN Port.
2. Connect the supplied RJ11 telephone cable from your home's telephone jack to the
LINE port of the supplied ATF057 splitter. Connect the other supplied RJ11 telephone
cable to the MODEM port of the splitter and connect the other end of this cable to the
LINE port of your ADSL2+ Ethernet Modem. (If there is no option Splitter, please
connect the supplied RJ11 telephone cable from your home's telephone jack to the
LINE port of your ADSL2+ Ethernet Modem.)
3. Connect a RJ11 telephone cable to the PHONE port of the splitter and connect the
other end to the telephone.
4. Connect the power adapter to the power inlet POWER of the ADSL2+ Ethernet Modem
and turn the ON/OFF SWITCH switch of your ADSL2+ Ethernet Modem on.

ADSL2+ Ethernet Modem HRDSL524
10
If you have a PSTN telephone line (normal analog line) Connect the router as shown below.
1. Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to ADSL2+
Ethernet Modem's LAN Port.
2. Connect the supplied RJ11 telephone cable from your home's telephone jack to the
LINE port of the supplied ATF085A1R splitter. Connect the other supplied RJ11
telephone cable to the DSL port of the splitter and connect the other end of this cable
to the LINE port of your ADSL2+ Ethernet Modem. (If there is no option Splitter, please
connect the supplied RJ11 telephone cable from your home's telephone jack to the
LINE port of your ADSL2+ Ethernet Modem.)
3. Connect a RJ11 telephone cable to the PHONE port of the splitter and connect the
other end to your telephone.
4. Connect the power adapter to the power inlet POWER of the ADSL2+ Ethernet Modem
and turn the ON/OFF SWITCH switch of your ADSL2+ Ethernet Modem on.

ADSL2+ Ethernet Modem HRDSL524
11
5. Configuration Procedures
Before starting the ADSL2+ Ethernet Modem configuration, please kindly configure the PC
computer as below, to have automatic IP address / DNS Server.
For Windows 98SE / ME / 2000 / XP
1. Click on Start > Control Panel (in Classic View). In the Control Panel, double click on
Network Connections to continue.
2. Single right click on Local Area connection, then click Properties.

ADSL2+ Ethernet Modem HRDSL524
12
3. Double click on Internet Protocol (TCP/ IP).
4. Check Obtain an IP address automatically and Obtain DNS server address
automatically then click on OK to continue.
5. Click Show icon in notification area when connected (see screen image in 3. above)
then Click on OK to complete the setup procedures.

ADSL2+ Ethernet Modem HRDSL524
13
For Windows Vista-32/64
1. Click on Start > Control Panel > View network status and tasks.
2. In the Manage network connections, click on Manage network connections to
continue.

ADSL2+ Ethernet Modem HRDSL524
14
3. Single right click on Local Area connection, then click Properties.
4. The screen will display the information User Account Control and click Continue to
continue.
5. Double click on Internet Protocol Version 4 (TCP/IPv4).

ADSL2+ Ethernet Modem HRDSL524
15
6. Check Obtain an IP address automatically and Obtain DNS server address
automatically then click on OK to continue.

ADSL2+ Ethernet Modem HRDSL524
16
For Windows 7-32/64
1. Click on Start > Control Panel (in Category View) > View network status and tasks.
2. In the Control Panel Home, click on Change adapter settings to continue.

ADSL2+ Ethernet Modem HRDSL524
17
3. Single right click on Local Area connection, then click Properties.
4. Double click on Internet Protocol Version 4 (TCP/IPv4).

ADSL2+ Ethernet Modem HRDSL524
18
5. Check Obtain an IP address automatically and Obtain DNS server address
automatically then click on OK to continue.

ADSL2+ Ethernet Modem HRDSL524
19
6. ADSL2+ Ethernet Modem Configuration
1. Please insert the supplied CD into your CD-ROM drive.
2. The CD should auto-start, displaying as below. Please click Run autorun.exe to
continue. If your CD does not start automatically go to Windows Explorer, Select your
CD drive and click autorun.exe.
3. Please click Configurazione Base.

ADSL2+ Ethernet Modem HRDSL524
20
4. Enter the VPI, VCI, Username and Password your ISP (Internet Services Provider)
provided, and Protocol mode.
5. Please click Setup button, when the procedure is completed, it will start to configure
the device for a while.
6. Now, checking ADSL 2+ Router hardware connection, ADSL2+ settings, settings, and
ADSL2+ Line connection status.
