HAMPTON BAY GLENRIDGE FALLS FCS80433-ST-2 User manual

USE AND CARE GUIDE
GLENRIDGE FALLS 7PC DINING SET - CHAIR
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
Item # 0000 000 000
Model # FCS80433-ST-2
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS CHAIR WAS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure to obey this
caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This chair is heavy, and may
require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for chair is 250 lbs
(113.39 Kg).
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Table of Contents
Pre-Assembly....................................... 3
Planning Assembly ................................. 3
Hardware Included ................................. 4
Package Contents . . . . . ..................... . . . .. . . . . 4
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 5
Table of Contents....................................2
Important Safety Instructions ..........................2
What is covered ................................... 3
What is not covered ................................3
Warranty .......................................... 3
Save These Instructions..............................2
Read All Instructions before Use .......................2
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

3
Warranty
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
the fabric.
WHAT IS NOT COVERED
Its remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a two year limited warranty for
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

4
Pre-Assembly (continued)
HARDWARE INCLUDED NOTE: Hardware not shown to actual size.
PACKAGE CONTENTS
AA BB CC DD
M6x15 Combination Bolt
M6x30 Combination Bolt
24+1
48+1
AA
BB
M6x25 Bolt
Hex Wrench
12+1
1
CC
DD
Part Description Quantity
C
B
D
E
A
Left Arm
Right Arm
Sling Bucket
6
6
6
A
B
C
Connector Bar 6 D
Support Bar 6 E
Part Description Quantity

5
Assembly
1Connecting the Sling Bucket and the Connector Bar to the Right Arm
2Connecting the Sling Bucket, Connector Bar and Support Bar to the Left Arm
Place the right arm (B) on a soft surface.
Attach the sling bucket (C) to the right arm (B) using M6x30 combination bolts (BB).
Attach the connector bar (D) to the right arm (B) using M6x15 combination bolts (AA).
Insert the support bar (E) into the left arm (A) and the right arm (B).
Do not tighten all bolts at this step.
Attach the sling bucket (C) to the left arm (A) using M6x30 combination bolts (BB).
Attach the connector bar (D) to the left arm (A) using M6x15 combination bolts (AA).
Do not tighten all bolts at this step.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
AA
AA
BB
BB
BB
C
BB
B
D
BB
BB
BB
BB
B
D
A
E
C
AA
AA
Place the left arm (A) on a soft surface.

6
Assembly (continued)
3Securing the Support Bar
4Tightening All the Bolts
Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (DD).
Ensure all connections are secure before use.
Turn the chair right side up.
Tighten the support bar (E) to the left arm (A) and the right arm (B) using M6x25 bolts (CC).
Do not tighten all bolts at this step.
A
CC
E
B

7
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach or solvents.
Care and Cleaning
Store the chair in a dry sheltered place when not in use.
wind.
chair away
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
Retain this manual for future use.
For certification use only
Factory chair ID # FCS80433R
HAMPTONBAY.COM
