HAMPTON BAY GENEVA FRS60704-2PKB User manual

THANK YOU
USE AND CARE GUIDE
GENEVA WOVEN 2PK LOUNGE CHAIR - BARE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 1005 442 743
Model # FRS60704-2PKB
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive continually to create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS CHAIR WAS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure
to obey this caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This chair is heavy, and may
require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for each chair is 250lbs
(113.39Kg).
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Table of Contents
Pre-Assembly................................. . . . . . . 3
Planning Assembly ........................... . . . . . . 3
Hardware Included ........................... . . . . . . 4
Package Contents . ........................... . . . . . . 4
Chair Assembly. . . . . ................................. . . . . . 5
Table of Contents....................................2
Important Safety Instructions ..................... . . . . . 2
What is covered ................................... 3
What is not covered ................................3
Warranty ............................. . . . . . . . . . . . . . 3
Save These Instructions..............................2
Read All Instructions before Use .......................2
Care and Cleaning ............................ . . . . . . . 7
4. Do not rock in the chair as you may fall and cause serious injury.
5. Please keep children out of the assembly area before assembly.

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
Pre-assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3 YEAR FRAME LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
We warrant the frames to be free of manufacturing defects to the original purchaser for three years.

4
Pre-assembly (continued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
PACKAGE CONTENTS
M6x15 Combination Bolt
Hex Wrench
20+1
1
AA
BB
Part Description Quantity
Right Arm
Left Arm
Chair Seat
2
2
2
A
B
C
Chair Back 2 D
Back Cushion 2 E
Seat Cushion 2 F
Part Description Quantity
AA BB
E
F
AB
D
C

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1Attach The Chair Seat To The Chair Back
2Attach The Chair Seat To The Left Arm
Place the chair seat (C) and the chair back (D) on a soft surface.
Attach the chair seat (C) to the chair back (D)
using M6x15 combination bolts (AA).
Place the left arm (B) upside down on a soft surface.
NOTE: Loosely tighten all bolts using the hex wrench (BB).
NOTE: Loosely tighten all bolts using the hex wrench (BB).
AA AA
D
C
AAAA
C
B
D
Attached the chair seat (C) to the left arm (B) using M6x15 combination bolts (AA).

6
Chair Assembly (continued)
3Attach The Chair Seat To The Right Arm
4Attach The Left And Right Arms To The Chair Back
Place the right arm (A) upside down on a soft surface.
Turn the chair right side up.
NOTE: Loosely tighten all bolts using the hex wrench (BB).
NOTE: Loosely tighten all bolts using the hex wrench (BB).
D
AAAA
C
A
AA
D
A
B
Attached the chair seat (C) to the right arm (A) using M6x15 combination bolts (AA).
Attach the left arm (B) and the right arm (A) to the chair back (D) using M6x15 combination bolts (AA).

7
Chair Assembly (continued)
5Tightening All The Bolts
Once all of the bolts are in place, fully tighten all the bolts using hex wrench (BB).
Place the back cushion (E) and seat cushion (F) on the chair
Ensure all connections are secure before use.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Store the chair in a dry sheltered place when not in use.
Care
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach or solvents.
Care and Cleaning
E
F
Keep the chair away from , extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
