HAMPTON BAY FRS60744C-STC User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this sectional. We strive to continually
create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
CAMDEN POINT STEEL WICKER 3PC SECTIONAL DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item # 0000 000 000
#FRS60744C-STCledoM

2
Table of Contents
Table of Contents................................. . . . 2
Important Safety Instructions........................ . . 2
What is covered ...................................3
What is not covered ............................... . 3
Warranty ................................. . . . . . . . . . 3
Pre-Assembly................................... . . . .3
Planning Assembly ............................. . . . .3
Hardware Included ............................. . . . . 4
Corner Chair Package Contents . . . . . . . . . . . . . . . . . . . . . . . . 4
Left Arm Loveseat Package Contents . . . . . . . . . . . . . . . . . . ........ . . 5
Right Arm Loveseat Package Contents . . . . . . . . . . . . . . . . . . ........ . . 6
Care and Cleaning ................................ . . . 14
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS SECTIONAL IS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE; HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the sectional while it is occupied. Failure
to obey this caution could result in injury.
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This sectional is heavy, and may
require two adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the sectional.
WARNING: Weight limit for the sectional is 250lbs
(102.05Kg) for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
Save These Instructions .............................2
Read All Instructions Before Use...................... .2Corner Chair Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Left Arm Loveseat Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Right Arm Loveseat Assembly . . . . . . . . . . . . . . . . . . . . . . . . . 11
Sectional Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Warranty
WHAT IS COVERED
3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY
We warrant the frames to be free of manufacturing defects to the original purchaser for three years, and a three year limited warranty for the
fabric.
WHAT IS NOT COVERED
Its remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.COM
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to assemble this product.
3
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
CORNER CHAIR PACKAGE CONTENTS
Pre-Assembly (continued)
4
M6x20 Combination Bolt 19+1 AA
BB
Part Description Quantity
Metal Plate 5
AA BB DD EE
CC
CC
M6x40 Combination Bolt 10+1
DD
Hex Wrench 1
EE
Metal Clip 2
Left Backrest 1
1
B
Right Backrest
C
Part Description Quantity
A
Corner Chair Seat 1
2
D
Corner Chair Back Cushion
E Corner Chair Seat Cushion 1

LEFT ARM LOVESEAT PACKAGE CONTENTS
Pre-Assembly (continued)
5
Loveseat Back Cushion
Left Arm 1
1
G
Left Arm Loveseat Backrest
2
H
Part Description Quantity
F
I
Left Arm Loveseat Seat 1
Loveseat Seat Cushion K 1
J
K
Loveseat Seat Cushion J 1
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

RIGHT ARM LOVESEAT PACKAGE CONTENTS
Pre-Assembly (continued)
6
Loveseat Back Cushion
Right Arm 1
1
M
Right Arm Loveseat Backrest
2
N
Part Description Quantity
L
I
Right Arm Loveseat Seat 1
Loveseat Seat Cushion K 1
J
K
Loveseat Seat Cushion J 1

Corner Chair Assembly
7
Attaching the Corner Chair Seat to the Right Backrest
2Attaching the Corner Chair Right Backrest and Corner Chair Seat to the Left Backrest
Place the corner chair right backrest (B) on a soft surface.
Attach the corner chair seat (C) to the right backrest (B) using M6x20 combination bolt (AA) and M6x40 combination bolts (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Attach the corner chair right backrest (B) and corner chair seat (C) to the left backrest (A) using M6x20 combination bolts
(AA) and M6x40 combination bolts (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
1
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

Corner Chair Assembly (continued)
8
4Tightening all Bolts
Once all of the bolts are in place, fully tighten all the bolts.
Turn the corner chair right side up.
Connecting the Left Backrest to the Right Backrest
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Connect the left backrest (A) to the right backrest (B) using M6x20 combination bolts (AA) using metal plate (CC).
3

Left Arm Loveseat Assembly
9
Attaching the Left Arm Loveseat Seat to the Left Arm Loveseat Backrest
2Attaching the Left Arm Loveseat Seat and Left Arm Loveseat Backrest
to the Left Arm
Place the left arm loveseat backrest (G) on a soft surface.
Attach the left arm loveseat seat (H) to the left arm loveseat backrest (G)
using M6x20 combination bolt (AA) and M6x40 combination bolts (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Attach the left arm loveseat seat (H) and left arm loveseat backrest (G) to the left arm (F) using
M6x20 combination bolts (AA) and M6x40 combination bolt (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (CC).
1
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

Left Arm Loveseat Assembly (continued)
10
4Tightening all Bolts
Once all of the bolts are in place, fully tighten all the bolts.
Turn the left arm loveseat right side up.
Connecting the Left Arm to the Left Arm Loveseat Backrest
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Connect the left arm (F) to the left arm loveseat backrest (G) using M6 x20 combination bolts (AA) and metal plate (CC).
3

Right Arm Loveseat Assembly
11
Attaching the Right Arm Loveseat Seat to the Right Arm Loveseat Backrest
2Attaching the Right Arm Loveseat Seat and Right Arm Loveseat Backrest
to the Right Arm
Place the right arm loveseat backrest (M) on a soft surface.
Attach the right arm loveseat seat (N) to the right arm loveseat backrest (M) using M6x20 combination bolt (AA)
and M6x40 combination bolts (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Attach the right arm loveseat seat (N) and right arm loveseat backrest (M) to the right arm (L) using M6x20
combination bolts (AA) and M6x40 combination bolt (BB).
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
1
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

Right Arm Loveseat Assembly (continued)
12
4Tightening all Bolts
Once all of the bolts are in place, fully tighten all the bolts.
Turn the right arm loveseat right side up.
Connecting the Right Arm to the Right Arm Loveseat Backrest
NOTE: Loosely tighten all the bolts using the hex wrench (EE).
Connect the right arm (L) to the right arm loveseat backrest (M) using M6x20 combination bolts (AA) and metal plates (CC).
3

Sectional Assembly
13
Connecting the Left Arm Loveseat and the Right Arm Loveseat to the Corner Chair
2Place the Seat Cushions and Back Cushions to the Set
Connect the left arm loveseat and right arm loveseat to the corner chair using metal plate (CC) with M6x20 combination bolts (AA).
Once all of the bolts are in place, fully tighten the bolts using the hex wrench (EE) wrench.
Attach the left arm loveseat and right arm loveseat to the corner chair using the metal clips (DD).
Ensure all connections are secure before use.
Place the loveseat seat cushions J (J), loveseat seat cushions K (K) , the loveseat back cushions (I),
the corner chair seat cushion (E) and the corner chair back cushions (D) to the set.
1
Please contact 1-855-HD-HAMPTON for further assistance.
HAMPTONBAY.COM

14
Care Care and Cleaning
For best results, clean the frame and fabric with adamp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach or solvents.
Store the sectional in a dry sheltered place when not in use.
Keep the sectional out of fire, extreme heat, freezing conditions, and inclement weather as rain, hail, sleet, snow, or wind.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
Retain this manual for future use.
For certification use only
Factory Corner Chair ID# FRS60744C
Factory Left Arm Loveseat ID# FRS60744AL
Factory Right Arm Loveseat ID# FRS60744BL
HAMPTONBAY.COM

Model # FRS60744C-STT
Item# 0000 000 000
USE CARE AND GUIDE
CAMDEN POINT STEEL ROUND DINING TABLE
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Care and Cleaning..........................................................7
5
4
CAUTION: When not in use, secure the product in a cool
and covered location.
!
CAUTION: Do not place heavy objects on the table top.
!
Table of Contents..........................................................2 Pre-Assembly ................................................................ 3
Package Contents...................................................................
Assembly..........................................................................
WARNING: This table unit is heavy, and may require two
adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This table was as made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this table
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
Please keep children out of the assembly area before assembly.
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
3.
This table is not intended to support an umbrella. Umbrellas must
have a suitable base or stand.
4.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA BB
AA
BB 1
Hex wrench
8+1 M6x20 combination bolt
Part Description Quantity
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
3 YEAR FRAME WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for three years.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.COM.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
A
B
C2 Table leg 2
1
Table leg 1
1
Table top
Part Description Quantity
C
B
A

5
1
l
Assembly
ATTACHING THE TABLE LEG 1 TO THE TABLE TOP
Place the table top (A) upside down on a soft surface.
Attach the table leg 1 (B) to the table top (A) using M6x20 combination bolts (AA).
NOTE: Loosely tighten all bolts using the hex wrench (BB).
Please contact 1-855-HD-HAMPTON for further assistance.
AA
B
A
HAMPTONBAY.COM
