HAMPTON BAY FP-51186D User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chiminea. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Hampton Bay!
Item #1001 814 396
Model #FP-51186D
USE AND CARE GUIDE
Cast Iron Outdoor Chiminea
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
9 a.m. - 6 p.m., EST, Saturday

2
Table of Contents
Table of Contents ..........................................................2
Safety Information
.........................................................2
Warranty.........................................................................3
What is Covered.........................................................3
What is Not Covered ..................................................3
Pre-Assembly...……………………...……………………. 3
Planning Assembly
.....................................................3
Tools Required
...........................................................3
Hardware Included
..................................................... 3
Package Contents...................................................... 4
Assembly..………………………………………………….5
Maintenance .................................................................. 9
Care and Cleaning ........................................................ 9
Service Parts ................................................................. 10
Safety Information
PLEASE READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE
ATTEMPTING TO ASSEMBLE, OPERATE OR INSTALL THE PRODUCT.
CAUTION: Burn only untreated wood or fire
logs in this fire pit.
WARNING: FOR OUTDOOR USE ONLY!
NEVER LEAVE A FIRE UNATTENED!
WARNING: DO NOT USE THE FIRE PIT TO
COOK FOOD! The fire pit is not designed
for grilling food.
CAUTION: DO NOT use gasoline or kerosene
to start the fire in this fire pit.
WARNING: DO NOT allow children or pets
near fire pit without supervision.
CAUTION: DO NOT use this unit on a wood
deck, long or dry grass and/or leaves, or on
combustible surfaces.
WARNING: DO NOT touch the surface of
the fire pit while in use as it may cause
burns.
CAUTION: DO NOT attempt to move the fire
pit while it is hot or in use.
WARNING: NEVER burn in vehicles, tents
or indoors. CARBON MONOXIDE HAZARD.
CAUTION: Place the fire pit no closer than
8 ft. from walls or combustibles during use.
CAUTION: Adequate fire extinguishing
material should be readily available.
WARNING: Use a poker and/ or heat-
resistant gloves to open/close the mesh
cover while in use.
CAUTION: Always ensure that the mesh
cover is secured over the fire bowl while in
use.
WARNING: DO NOT use water to
extinguish as this is dangerous and can
cause damage to the fire pit.
CAUTION: The poker handle may become
hot during and after use.
Operating Instructions ................................................. 9
WARNING: DO NOT burn over 5 lbs
untreated wood or fire logs in this fire pit.
Consumers should check state, provincial, and local codes and regulations regarding the use of the product.
WARNING: FUELS USED IN WOOD OR CHARCOAL BURNING APPLIANCES, AND THE PRODUCTS OF
COMBUSTION OF SUCH FUELS, CAN EXPOSE YOU TO CHEMICALS INCLUDING CARBON BLACK, WHICH IS
KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, AND CARBON MONOXIDE, WHICH IS KNOWN TO
THE STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. For more
information go to: www.P65Warnings.ca.gov.

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
1 YEAR LIMITED WARRANTY
WHAT IS COVERED
We warrant the metal frame to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty
does not cover commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are
not covered under this warranty. We reserve the right to make substitutions with similar merchandise, if the model in
question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Pre-Assembly
PLANNING ASSEMBLY
Carefully remove all pieces from the carton and make sure that you have all parts (refer to parts list). If you are missing
parts, please contact 1-855-HD-HAMPTON for further assistance.
NOTE: Please read and understand the entire
manual before you assemble, operate or install
the fire pit.
TOOLS REQUIRED
Phillips
screwdriver M6 Wrench
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
AA
M6 x 12 mm Bolt
7
BB
M6 x 14 mm Bolt
8
CC
CC
M6 x 25 mm Bolt
8
AA DD
DD M6 Nut 17
BB

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
A
Handle
1
B
Chimney Cover
1
C
Chimney Flue
1
D
Chimney Top
1
E
1
F
Chimney Bottom
1
A
B
C
D
E
F
G
I
G
Stand
4
H
Tray
1
I
Poker
1
Mesh Screen
H
J Wood Grate 1
J

5 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
1
Assembling the mesh cover
□Insert the handle (A) into the hole of the chimney
cover (B).
□Attach the handle (A) to the chimney cover (B) using
a nut (DD). Securely tighten with an M6 wrench (not
included).
CAUTION:
Wear gloves during assembly.
2
Assembling the stand
□Attach the stands (G) to the chimney bottom (F) using
M6 x 14 mm bolts (BB) and M6 nuts (DD).
□Hand tighten the bolts (BB) and nuts (DD). Do not
over-tighten.
BB
G
Assembly
A
B
F
DD
DD

6
Assembly (continued)
3
Attaching the tray
□
Attach the tray (H) to the stand (G) using M6 x 12mm
bolts (AA).
□Securely tighten each bolt (AA) with a Philips
screwdriver (not included).
4
Attaching the mesh screen
□Attach the mesh screen (E) to chimney bottom (F)
using M6 x 25 mm bolts (CC) and M6 nuts (DD).
H
E
AA
G
□Securely tighten each bolt (CC) and nut (DD) with an
M6 wrench and Philips screwdriver (not included).
F
CC
DD

7
Assembly (continued)
5
Attaching the chimney top
□
Attach the chimney top (D) to the chimney flue (C)
using M6 x 12 mm bolts (AA).
□
6
Attaching the chimney flue
□Attach the chimney top (D) to the mesh screen (E)
using M6 x 25 mm bolts (CC) and M6 nuts (DD).
D
AA
C
□Securely tighten each bolt (CC) and nut (DD) with an
M6 wrench and Philips screwdriver (not included).
D
Securely tighten each bolt (AA) with a Philips screwdriver
(not included).
E
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
CC
DD

8
Assembly (continued)
7
Completing the assembly
□
Place the poker (I) near the chimney and the chimney
cover (B) on the top of the assembly.
B
I
J

9 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Maintenance
□To extend the life of your fire pit, clean it after each use.
□To protect fire pit finish, use a soft cloth in lieu of bare hands while handling.
□Clean the fire bowl after each use once ashes have cooled.
□Store assembled in a cool, dry location away from children and pets.
Care and Cleaning
□Do not attempt to clean the fire pit until the fire is completely out and cooled completely.
□Use a soft cloth to wipe the fire pit and poker.
□Do not attempt to clean while hot.
□Keep the fire pit covered when cooled and not in use.
Operating Instructions
Lighting
□Place a layer of dry seasoned hardwood.
□Use a long match or stick lighter to light.
Extinguishing the Fire
□Allow the fire to burn itself out.
□Except in the event of an emergency, do NOT use water to extinguish a fire as this is dangerous and can cause
damage to the outdoor fire pit.
□Use the poker that is provided to operate. Please wear heat-resistant gloves during use.

10
Service Parts
Part Description Quantity Part Description Quantity
A Handle
1
H Tray 1
B Chimney Cover
1
I Poker 1
C Chimney Flue
1
D Chimney Top
1
E Mesh Screen
1
F Chimney Bottom
1
CC
AA DD
BB
GStand 4
J Wood Grate 1
AA M6 x 12 mm Bolt 7
BB M6 x 14 mm Bolt 8
CC M6 x 25 mm Bolt 8
DD M6 Nut 17
A
B
C
D
E
F
G
I
H
J

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
9 a.m. - 6 p.m., EST, Saturday
