handtmann 10503 User manual

Operating manual
Lighting fitting for welding
10503, 10504
BA_010503.05_EN
1 / 4 Albert Handtmann Armaturenfabrik GmbH & Co. KG 2018-03-26
1General.............................................................................................................................................................1
2Safety Information............................................................................................................................................2
3Delivery, Completeness, Storage ......................................................................................................................2
4Installation, Operation, Maintenance ...............................................................................................................2
1General
1.1 Manufacturer
Albert Handtmann Armaturenfabrik GmbH & Co. KG
Arthur-Handtmann-Str. 11; D-88400 Biberach
Tel.: [phone]; Fax: [phone]
E-Mail: sales.fit[email protected]
1.2 Proper application
Lighting fitting is used in the food, beverage, pharmaceutical and chemical industries. It is
intended for the tank installation to improve the visual product control.
During installation, operation and maintenance please pay attention to the generally
accepted safety regulations as well as to the operating instructions.
1.3 Misuse
Misuse is:
•Application in different operating conditions as intended for the specific type.
•Installation, operation and maintenance by unqualified staff.
•Any unauthorized modification of the valve or a valve component.
•On-observance of the operating instructions.
Any misuse will automatically lead to a loss of right to claim under guarantee as well as
any liability.
1.4 Duties of operator
The operator has to make sure that:
•The valve/component is operated properly and only in functional condition.
•The legal requirements are kept during operation and maintenance.
•Only sufficiently qualified and authorized staff maintain the valve/component.
•The staff responsible for operation and maintenance know and obey the
operating instructions and in particular the safety advice.
•The safety and warning signs remain on the valve/component and are
always legible.

Lighting fitting for welding
10503, 10504
BA_010503.05_EN
2018-03-26 Albert Handtmann Armaturenfabrik GmbH & Co. KG 2 / 4
2Safety Information
Notice and Safety
The following safety advice is an addition to existing national regulations and laws for
accident prevention. Existing regulations and laws for accident prevention always have to
be adhered to. Pay attention to the specific regulations and laws in your country.
The safety advice does not take into account:
•Coincidences and events that may occur during assembly, operation and
maintenance.
•Local safety regulations in responsibility of the operator.
Basic safety advice
Requirements for a proper function of the valve/component:
•Proper transportation and storage
•Installation and setting into operation by authorized staff
•Operation according to these operating instructions – proper application
•Proper and regular maintenance
WARNING
Warning – general dangers!
To avoid danger for health and life the following safety instructions
strictly have to be obeyed.
•Assembly and setting into operation only by qualified staff.
•Instruction and supervision by the operator.
•Keeping of technical and electrical data as specified in the operating instructions.
•Guarantee the electric safety of external devices.
•Keep legal regulations.
Non-observance may lead to the following dangers:
•Malfunction of the valve/component respectively of the plant.
•Danger for persons due to electrical, mechanical and chemical affects.
•Danger for the environment due to possible leakage of dangerous media.
3Delivery, Completeness, Storage
•Check the data of the delivery note for factual correctness and the material for
completeness. We regret that money cannot be refunded after purchase.
•Always check the material for transport damages. Possible damages have
to be informed immediately.
•Store the material in a dry place and if possible in its original packaging.
4Installation, Operation, Maintenance

Lighting fitting for welding
10503, 10504
BA_010503.05_EN
3 / 4 Albert Handtmann Armaturenfabrik GmbH & Co. KG 2018-03-26
Execution DN 80, 125, 150, 200
Consisting of sight glass housing type 61100 with welding flange and cover
Sight glass from pressed hard glass DIN 8902: temperatures up to 150 °C
max. operating pressure 6 bar
Standard 10503 - Lighting fitting with halogen lamp.
Optional 10504 - LED stainless steel light
4.1 Assembly instructions
Prior to welding-in the lighting fitting has to be dismounted.
•The welding flange has to be welded without getting warped.
•Tighten the screws crosswise in two steps. Torque approx. 20 – 25 Nm.
Stainless steel universal lamp:
The lamp will be supplied with 3 m connecting cable (2 x 0,75 mm2).
It has to be fixed to the hinge on the sight glass (see picture).
•Protection class IP 65 (DIN 40050/IEC 529)
(dust-proof and hose-proof)
4.2 Operation
Article 10503 Operating voltage 24 V (AC/DC)
Performance Short-time operation – halogen lamp 50 W
2-pin base Gy 6.35
>>>> Option Long-time operation – halogen lamp 20 W
2-pin base G 4
Actuating element
(press button)
Button for short-time operation
>>>> Option Switch for long-time operation
Operation conditions Max. continuous surrounding temperature 75° C
Optional:
Article 10504 Operating voltage 24 V (DC)
Performance LED stainless steel light 11,5 W
4-pin base (codiert)
Actuating element
(press button)
Button for short-time operation
4.3 Maintenance

Lighting fitting for welding
10503, 10504
BA_010503.05_EN
2018-03-26 Albert Handtmann Armaturenfabrik GmbH & Co. KG 4 / 4
In case of lamp exchange: Screw down the housing tightly. Do not remove the cable
connection, it is glued in place.
Upon exchange – pay attention to the type of the halogen lamp.
4.4 Spare parts
10503/10504
DN 10503 10504
80 010503.00080LE ---
125 010503.00125LE 010504.00125LE
150 010503.00150LE 010504.00150LE
200 010503.00200LE 010504.00200LE
LE – EPDM
